USER MANUAL DIS-179 ULTIMATE SPEED

Intended use Page 12

Parts description Page 13

Technical data......Page 13

Safety notices....Page 13

Before Use......Page 14

Assembly of the carrying handle Page 14

Assembly of the lifting handle Page 14

Use the support plate/adapter......Page 14

Distribution of the hydraulic oil....Page 14

Initial use Page 14

Raising the vehicle....Page 14

Lowering the vehicle Page 15

Cleaning and care....Page 15

Maintenance and service....Page 15

Disposal Page 15

Warranty and service......Page 15

Warranty declaration Page 15

Service address......Page 16

Manufacturer......Page 16

EU Declaration of Conformity Page 16

11 GB/IE

List of pictograms used
	Please read the operating instructions!		The product complies with the applicable product-specific European directives.
	Observe the warnings and safety instructions!		TÜV Süd/GS certified
[###]	Safety notices Instructions for use	###	allowable (rated) load capacity
[GWH3]	The product incl. accessories, manual and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.		Observe the stroke length!
			Dispose of paper and cardboard packaging in the blue recycling container.
		[DX0X]	Packaging from responsible sources

Hydraulic Trolley Jack

- Introduction

This document is a shorter printed version of the complete instruction manual. By scanning the QR code, you will be taken

straight to the Lidl service website (www.lidl-service.com) where you can view and download the complete instruction manual by entering the article number (IAN) 467100_2404.

WARNING! Observe the complete instruction manual and safety notes to prevent personal injury and property damage. The short guide forms an integral part of this product. Prior to using the product, familiarize yourself with all operation and safety notes. Keep the short manual well preserved and if you hand the product on to third parties, all documentation should be passed on as well.

PDF ONLINE www.lidl-service.com

Intended use

The hydraulic vehicle jack is intended for raising and lowering motor vehicles.

Other uses or modification of the hydraulic vehicle jack are considered improper use and may lead to risks of life-threatening injury or damage. The manufacturer does not assume any liability for damage arising from improper use. The product is not intended for commercial use.

12 GB/IE

- Parts description

1 Release valve
2 Lifting handle socket
3 Magnetic storage (e.g. for wheel nuts)
4 Cover plate
5 Support plate
6 Mount (lifting handle, both sides)
7 Adapter (support plate)
8 Carrying handle
9 Lifting handle (two-piece)
10 Lifting arm
11 Blind plug (for hydraulic oil fill opening)

●Technicaldata

Stroke length with

load capacity: 135 mm - 342 mm

Nominal load: 2,000 kg

Hydraulic oil grade: SAE 10

Hydraulic oil quantity: 110ml

Maximum force on lever: 350 N*

*If the generated output exceeds this value, the output must be reduced with the help of additional persons.

Safety notices

DANGER! Follow the instructions below to avoid the threat of loss of life, injury, or damage to the product etc.

■ Always use axle stands and wheel chocks in addition to your hydraulic vehicle jack. Never work under a raised vehicle unless you have taken additional safety precautions. This is intended to prevent the vehicle from rolling away, sliding off or overturning the jack. The jack is only suitable for lifting.

Use the product on a solid, level surface only. Using the product on an unstable or uneven surface – such as a gravel surface – may lead to the load slipping.

Ensure that you never exceed the allowable (rated) load capacity.

The person operating the jack must be able to see the jack and the load during all movements.

■ Never work under the raised load if it has not been made secure by suitable means.

Do not allow the hydraulic vehicle jack to be used by uninstructed or inexperienced persons.

Before using the hydraulic vehicle jack, take precautions to prevent the vehicle from rolling away. Put the handbrake on, place the vehicle in gear (with automatic gearboxes set to "P") and chock the wheels.

Even with safety measures in place always remain alert and make a visual check that the support plate 5 is firmly seated against the vehicle jacking point.

Make sure that no petrol, battery acid or any other dangerous substance can flow out of the vehicle when the vehicle is being lifted.

- Check that no person or object is under the vehicle before you lower it.

■ Lower the vehicle slowly.

- Check that all parts have been assembled and fitted properly and are undamaged.

Before each use check that the hydraulic vehicle jack is working properly. Check the screws and valves of the hydraulic vehicle jack for correct seating and look out for hydraulic oil leaks in particular.

Never use the hydraulic vehicle jack for moving or loading a vehicle. Never use it to lift a whole vehicle completely off the ground.

It is prohibited to lift people using the hydraulic jack; please verify that nearby individuals keep an adequate distance to the vehicle while the hydraulic jack is in use.

Before using the vehicle jack, the user must be made familiar with the device by an experienced person. The pump force and the transferred force are equal to approximately 350 N.

If the markings on the product are damaged enough so as to be illegible then the vehicle jack must not be used until the markings are renewed.

No modifications may be carried out to the hydraulic trolley jack. Any physical modification of the device has an effect on the safety of the device and its compliance with EN 1494/A1:2008.

13 GB/IE

• When using the jack, the applied force must be below 350 N. The equates to a force on the lever of approximately 35 kg.
  The operating temperature for this product's hydraulic oil is between -20 °C and +40 °C.
  ■ Only use this device to life and lower the vehicle, not to keep the vehicle in a lifted position. Do not move it whilst raising or lowering.
  ■ After use return all parts used into their original position. Have the hydraulic oil or oil pump replaced by a professional if the parts can no longer be moved.
  If you notice oil leaks, please stop working and use a cloth to remove the spillage. Have the product repaired by a specialist.
  If the jack can no longer be lowered as desired, secure the vehicle at all costs using safety stands to prevent it from being lowered unintentionally. Procure another jack to hoist the vehicle as far up as possible for you to be able to safely remove the defective jack. Seek professional help if you are uncertain.

Before Use

• Assembly of the carrying handle

☐ Attach the carrying handle as shown in Figure A.

• Assembly of the lifting handle

☐ The lifting handle is in two parts. Press and hold down the retaining spring at the lower end of the first part of the lifting handle (with handle), then guide it into the second part of the lifting handle. Make sure that the retaining spring locks into the hole on the second rod, thus securing the connection.

• Use the support plate/adapter

To start with, make yourself aware of where the attachment points are on the vehicle. These are usually labelled on the underbody with an arrow or are covered in the manual.

Depending on the attachment point, use the pre-installed support plate 5 or also attach the adapter 7 provided. Loosen the screw with a ratchet and a 19 mm nut. Use a 19 mm ring spanner as a counter to the lower self-locking nut (see also Fig. D). Remove all screw parts, insert the adapter 7 and screw it tightly into position.

Note: The stroke is always 207 mm and cannot be adjusted. However, the minimum and maximum position of the support plate can be adjusted with the adapter.

• Distribution of the hydraulic oil

☐ With the release valve 1 closed, insert the lifting handle 9 into the lifting handle socket 2. Use at least 6 firm pumping movements to charge the hydraulic system (move lifting handle 9 up and down). This action distributes the hydraulic oil evenly.

Note: Check that the release valve is closed by inserting the lifting handle 9 and trying to turn it clockwise (see Fig. B). DO NOT CLOSE TOO TIGHT! When you cannot turn it any further, the release valve 1 is closed.

- Initial use

- Raising the vehicle

☐ With the release valve closed turn the lifting handle 9 clockwise into the lifting handle socket 2.
Place the hydraulic vehicle jack under one of the lifting positions as shown in the owner's manual supplied by the vehicle manufacturer.
☐ Ensure that the support plate 5 is centrally loaded. By moving the lifting handle 9 up and

down, raise the vehicle sufficiently to allow you to insert axle stands under the vehicle.

☐ Allow the vehicle to come down on to the axle stands by slowly opening the release valve 1 by turning the lifting handle 9 anticlockwise (see Fig. C).
■ The jack is NOT SUITABLE FOR KEEPING THE VEHICLE IN A LIFTED POSITION.

- Lowering the vehicle

DANGER TO LIFE! Check that no person or object is under the vehicle before you lower it.

☐ First raise the vehicle slightly (as described earlier) in order to be able to remove the axle stands.
☐ Turn the release valve 1 anticlockwise until the vehicle lowers, but do not turn it to the extent that it detaches or hydraulic oil leaks from the release valve 1.

CAUTION! Lower the vehicle slowly. Risk of injuries and damage to the floor jack and/or the car.

☐ Pull the trolley jack out from under the vehicle and fully lower the lifting arm 10.
☐ Close the release valve 1 by turning it clockwise.

- Cleaning and care

■ Never use harsh or corrosive cleaning agents.
□ Liberally grease all external moving parts.
□ Clean the hydraulic trolley jack using a slightly oily cloth.

Maintenance and service

Note: Refilling or topping up with hydraulic oil may only be carried out by specialist personnel! Only use hydraulic oil that fulfils the specification for SAE 10. Please note that filling with too much oil may adversely affect the functioning of the vehicle jack. Fill with a maximum of 110 ml oil when all the oil has been used. Add hydraulic oil to the bottom edge of the fill port.

Add hydraulic oil to the bottom edge of the fill port.

Note: The wear life of 3 years is voided if the car jack is not serviced by a qualified technician.

Note: The seal for topping up oil can be removed using a flat head screwdriver.

Note: The hydraulic fluid must be checked when the lever has been fully lowered.

■ Defective hydraulic vehicle jacks must be repaired by a specialist workshop only. Never attempt to repair the hydraulic vehicle jack yourself.
■ Never take the hydraulic vehicle jack to pieces. Taking the vehicle jack to pieces yourself may result in it not working properly.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

The product incl. accessories, manual and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

Dispose of the hydraulic oil in an environmentally compatible manner. Ask your local repair garage to see to its disposal or find your nearest waste materials collection centre.

- Warranty and service

- Warranty declaration

This product comes with a 3-year guarantee. Please keep your receipt as proof of purchase. The product has been manufactured with care and thoroughly inspected prior to delivery. The guarantee only

15 GB/IE

applies to faults in material or manufacture when used properly. Any unauthorised modifications will void the warranty. This warranty does not limit your legal rights. In the event of a warranty claim, please contact the service centre.

Service address

MTS Group

Please have your receipt and the item number (IAN 467100_2404) ready as your proof of purchase when enquiring about your product.

IU item no.: 204368

Model no.: DIS-179

Manufacturer

MTS Group

• EU Declaration of Conformity

Product meets the applicable European product-specific directives. The CE declaration of conformity may be requested

from the manufacturer.

The latest version of these operating instructions can also be downloaded as a PDF file from our homepage under the link http://iuqr.de/DIS179.

16 GB/IE

Original declaration of conformity

Hersteller / Manufacturer	MTS Group Inter-Union Technohandel GmbH
Anschrift	Carl-Benz-Straße 2
Address	76761 Rülzheim
Telefon / Phone	Tel. [phone]
E-mail:	[e-mail]
Produkt	Hydraulischer Rangierwagenheber
Product	hydraulic trolley jack
Modell:	Modell-Nr.:	DIS-179
Model:	model no.:	DIS-179
Kenndaten / Technical Data	NennlastRated Load	2.000 kg
	min. Höhemin. height	135 mm / 150mmmit/ohne Adapter with/without adapter
	max. Höhemax. height	342 mm / 357mmmit/ohne Adapter with/without adapter
	Hubhöhe mit Nonnlastfilling height with rated load	135 - 342 mm / 150 - 357mmmit/ohne Adapter with/without adapter

The object of the declaration is in conformity with the relevant Union harmonisation legislation:

Machinery Directive 2006/42/EG

Normen/Standards:

EN 1494:2000+A1:2008

Ort, Datum Place and date of issue
