USER MANUAL PWSA 12 C3 PARKSIDE

AKKU-WINKELSCHLEIFER 12 V/CORDLESS ANGLE GRINDER 12 V/MEULEUSE D'ANGLE SANS FIL 12 V PWSA 12 C3

DE AT CH

Translation of the original instructions

FR BE

MEULEUSE D'ANGLE SANS FIL 12 V

Mode d'emploi

List of pictograms used 27

Introduction 28

Intended use. 28
Scope of delivery. 28
Parts list 29
Technical data 29

General safety notes. 30

First set-up of the product 38

Unpacking the product and basic cleaning. 38
Mounting the product. 38
Inserting/removing the rechargeable battery 39

Operation 39

Switching the product on/off. 39
Checking the battery charge level. 39

Troubleshooting 40

Cleaning and maintenance.. 40

Storage 41

Disposal. 41

Warranty 42

Warranty claim procedure. 42

Service 42

EU Declaration of conformity 43

List of pictograms used
Read the instruction manual.	Use the product in dry indoor spaces only.
WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)	~	Alternating current/voltage
	-	Direct current/voltage
CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)	T2A	Fuse
		Protection class II (double insulation)
NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)		Switch the product off and remove the battery pack before replacing attachments, cleaning and when not in use.
INFO: This symbol with the "Info" signal word offers additional useful information.	MAX 50°	Protect the battery pack against heat and continuous intense sunlight.
Cutting only		Protect the battery pack against water and moisture.
Wear a safety helmet! Protect the battery pack! fire.
Wear eye protection! Unplug
Wear ear protection! Wear a dust mask!
Wear safety gloves! Not approved for wet grinding
Wear protective, slip-resistant footwear! Not approved for side grinding

Do not use if damaged.	CAUTION! Do not touch moving parts.
Direction of rotation, clamping screw Direction of rotation.
Cutting disc diameter: 76 mm Not for grinding.
Safety information Instructions for use	CE CE mark indicates conformity with relevant EU directives applicable for this product.

CORDLESS ANGLE GRINDER 12 V

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

The product is suitable for cutting and grinding metal, stone and wood materials, plastic, tiles and non-ferrous metals without using water. There is a special disc for each of the separate applications. Please refer to the information from the disc manufacturer.

The tool should not be used in any other application (e.g. cutting/grinding with coolant solutions, cutting/grinding harmful substances such as asbestos).

The device is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. The tool is to be used by adults. Children over the age of 16 may not use the tool except under supervision.

The manufacturer is not liable for damages caused by an improper use or incorrect operation of this product.

Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 Cordless angle grinder
1 Cutting disc (only for non-ferrous metals, preassembled)
1 Hex key (4 mm)
1 Storage case
1 User manual

INFO: Battery and charger are not included in the scope of delivery.

Parts list

Figure A:

1	Protective hood
2	Cutting disc
3	Clamping screw
4	Spindle stop button
5	On/off switch
5a	Pressure point on the on/off switch
6	Battery indicator (3 LEDs)
7	Handgrip
8	Battery release button
9	Battery*
10	Storage case
11	Hex key

Figure B:

12 Mounting flange
13 Clamping flange

• Battery and charger are not included in the scope of delivery.

Technical data

Cordless angle grinder PWSA 12 C3

Rated input voltage: 12 V	---
Idling speed (n): 19000 min	-1
Weight (without battery, without cutting disc): 0.73 kg
Dimensions of cutting/grinding disc: Ø 76×1.0 mm
Bore hole: Ø 10 mm
Diameter grinding disc: max. Ø 76 mm
Thickness of grinding discs:	max. Ø 6.5 mm
Grinding spindle thread:	M5
Ingress protection:	IP20

Cutting disc HG10078 (included):

ldling speed n0:	max. 20100 min-1
Disc speed v0:	max. 80 m/s*
Outer diameter:	Ø 76 mm
Bore hole:	Ø 10 mm
Thickness:	1 mm

• The cutting disc must keep a rotational speed of 80~m / s .

Recommended ambient temperature:

Maximum temperature:	max. +50 °C
During charging process:	+4 to +40 °C
During operation:	-20 to +50 °C
During storage:	0 to +45 °C

Noise emission value

The measured values have been determined in accordance with EN 60745. The A-rated noise level of the power tool is typically as follows:

Sound pressure level \( {\mathrm{L}}_{\mathrm{{pA}}} \) :	69.8 dB
Uncertainty \( {\mathrm{K}}_{\mathrm{{pA}}} \) :	3 dB
Sound power level \( {\mathrm{L}}_{\mathrm{{WA}}} \) :	80.8 dB
Uncertainty \( {\mathrm{K}}_{\mathrm{{WA}}} \) :	3 dB

Vibration emission value

Vibration total values (triaxial vector sum) determined according to EN 60745:

Vibration \( {a}_{h} \) :	\( {3.530}\mathrm{\;m}/{\mathrm{s}}^{2} \)
Uncertainty K:	\( {1.5}\mathrm{\;m}/{\mathrm{s}}^{2} \)

The values apply for the work mode surface grinding. Other applications may have different vibration emission values.

WARNING!

Wear ear protection!

NOTE

The declared vibration emission value has been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared vibration emission value may also be used for a preliminary assessment of exposure.

WARNING!

The vibration emission value during actual use of the power tool can differ from the declared value depending on the manner in which the tool is used.

It is necessary to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time).

Battery pack/Charger/Charging time

The product is part of the series Parkside X 12 V TEAM and can be operated with batteries of the series Parkside X 12 V TEAM. The batteries may only be charged using chargers of the series Parkside X 12 V TEAM.

Battery pack: PAPK 12 B4 *

Type: Lithium-lon

Rated voltage: 12 V

Capacity: 4.0 Ah

Energy: 48 Wh

Number of cells: 6

Charger: PLGK 12 A3 *
Input:
Rated voltage: 220-240	V~
Rated frequency: 50-60 Hz
Rated power consumption:	50 W
Fuse (internal):	T2A T2A
Output:
Rated voltage: 12 V	---
Rated current: 2.4 A
Protection class:	II/□ (double insulation)

Charging time

Battery pack Charging time (h)
PAPK 12 B4, 4 Ah * 2
PAPK 12 A4, 2 Ah * 1

• Battery and charger are not included in the scope of delivery.

General safety notes

General power tool safety warnings

WARNING!

Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

1) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
3) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

1) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
2) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
3) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
4) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
5) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
6) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

1) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
2) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
3) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
4) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
5) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
6) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

Power tool use and care

1) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
2) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
3) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
4) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
5) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
7) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

Careful handling and use of battery devices

1) Charge the batteries only in chargers that are recommended by the manufacturer. Risk of fire if a charger that is suitable for a specific type of battery is used with other batteries.
2) In the power tools, use only the batteries designed for the purpose. The use of other batteries may result in injuries and risk of fire.
3) Keep the unused battery away from paper clips, coins, keys, nails, screws and other small metal objects, which could cause bridging of the contacts. A short circuit between the battery contacts may cause burns or fire.
4) If used incorrectly, liquid may leak from the battery. Avoid contact with this. In the event of accidental contact, rinse off with water. If the liquid gets into eyes, seek medical assistance. Leaking battery fluid may cause skin irritations or burns.

Service

1) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

WARNING!

Wear safety glasses and a dust mask!

Angle grinder warnings Common safety instructions for grinding and cutting

1) This electric tool is to be used as a grinder and cutting grinder. Follow all safety instructions, directives, illustrations and facts which you receive with the device. If you do not follow these instructions, an electrical shock, fire and/or serious injury may occur.

2) This electric tool is not suitable for sanding, wire brushing and polishing. Operations for which the power tool was not designed may create a hazard and cause personal injury.
3) Do not use accessories which are not specifically designed and recommended by the tool manufacturer. Just because the accessory can be attached to your power tool, it does not assure safe operation.
4) The rated speed of the accessory must be at least equal to the maximum speed marked on the power tool. Accessories running faster than their rated speed can break and fly apart.
5) The outside diameter and the thickness of your accessory must be within the capacity rating of your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled.
6) Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted by flanges, the arbour size hole of the accessory must fit the locating diameter of the flange. Accessories that do not match the mounting hardware of the power tool will run out of balance, vibrate excessively and may cause loss of control.
7) Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged accessory.

After inspecting and installing an accessory, position yourself and bystanders away from the plane of the rotating accessory and run the power tool at maximum no-load speed for 1 minute. Damaged accessories will normally break apart during this test time.

8) Wear personal protective equipment. Depending on application, use face shield, safety goggles or safety glasses. As appropriate, wear dust mask, hearing protectors, gloves and workshop apron capable of stopping small abrasive or workpiece fragments. The eye protection must be capable of stopping flying debris generated by various operations. The dust mask or respirator must be capable of filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss.
9) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation.
10) Hold the power tool by insulated gripping surfaces only, when performing an operation where the cutting tool may contact hidden wiring. Contact with a "live" wire will also make exposed metal parts of the power tool "live" and could give the operator an electric shock.
11) Never lay the power tool down until the accessory has come to a complete stop. The spinning accessory may grab the surface and pull the power tool out of your control.
12) Do not run the power tool while carrying it at your side. Accidental contact with the spinning accessory could snag your clothing, pulling the accessory into your body.
13) Regularly clean the power tool's air vents. The motor's fan will draw the dust inside the housing and excessive accumulation of powdered metal may cause electrical hazards.
14) Do not operate the power tool near flammable materials. Sparks could ignite these materials.

15) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electrocution or shock.

Further safety instructions for all operations - Kickback and related warnings:

Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool to be forced in the direction opposite of the accessory's rotation at the point of the binding.

For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the wheel that is entering into the pinch point can dig into the surface of the material causing the wheel to climb out or kick out. The wheel may either jump toward or away from the operator, depending on direction of the wheel's movement at the point of pinching. Abrasive wheels may also break under these conditions.

Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below.

1) Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during start-up. The operator can control torque reactions or kickback forces, if proper precautions are taken.
2) Never place your hand near the rotating accessory. Accessory may kickback over your hand.
3) Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel's movement at the point of snagging.

4) Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback.
5) Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent kickback and loss of control.

Additional warnings specific for grinding and cutting-off operations

Safety warnings specific for grinding and cutting-off operations

1) Use only wheel types that are recommended for your power tool and the specific guard designed for the selected wheel. Wheels for which the power tool was not designed cannot be adequately guarded and are unsafe.
2) The grinding surface of centre depressed wheels must be mounted below the plane of the guard lip. An improperly mounted wheel that projects through the plane of the guard lip cannot be adequately protected.
3) The guard must be securely attached to the power tool and positioned for maximum safety, so the least amount of wheel is exposed towards the operator. The guard helps to protect the operator from broken wheel fragments, accidental contact with wheel and sparks that could ignite clothing.
4) Wheels must be used only for recommended applications. For example: do not grind with the side of cut-off wheel. Abrasive cut-off wheels are intended for peripheral grinding, side forces applied to these wheels may cause them to shatter.

5) Always use undamaged wheel flanges that are of correct size and shape for your selected wheel. Proper wheel flanges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different from grinding wheel flanges.
6) Do not use worn down wheels from larger power tools. Wheel intended for larger power tool is not suitable for the higher speed of a smaller tool and may burst.

Additional safety warnings specific for cutting-off operations

Other special safety warnings specific for cutting-off operations

1) Do not "jam" the cut-off wheel or apply excessive pressure. Do not attempt to make an excessive depth of cut. Overstressing the wheel increases the loading and susceptibility to twisting or binding of the wheel in the cut and the possibility of kickback or wheel breakage.
2) Do not position your body in line with and behind the rotating wheel. When the wheel, at the point of operation, is moving away from your body, the possible kickback may propel the spinning wheel and the power tool directly at you.
3) When wheel is binding or when interrupting a cut for any reason, switch off the power tool and hold the power tool motionless until the wheel comes to a complete stop. Never attempt to remove the cut-off wheel from the cut while the wheel is in motion otherwise kickback may occur. Investigate and take corrective action to eliminate the cause of wheel binding.
4) Do not restart the cutting operation in the workpiece. Let the wheel reach full speed and carefully re-enter the cut. The wheel may bind, walk up or kickback if the power tool is restarted in the workpiece.

5) Support panels or any oversized workpiece to minimize the risk of wheel pinching and kickback. Large workpieces tend to sag under their own weight. Supports must be placed under the workpiece near the line of cut and near the edge of the workpiece on both sides of the wheel.
6) Use extra caution when making a "pocket cut" into existing walls or other blind areas. The protruding wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback.

Additional safety instructions

1) Only use cutting/grinding discs where the indicated rotational speed is at least as high as what has been specified on the name plate of the product.
2) Carry out a visual inspection of the cutting/ grinding disc before use. Do not use any damaged or deformed cutting/grinding discs. Replace any damaged or worn cutting/ grinding discs.
3) Make sure that the sparks produced by cutting/grinding do not present a danger, e.g. reach people or ignite flammable substances.
4) Always wear safety goggles, safety gloves, respiratory protection and ear protection when grinding, brushing and cutting.
5) Never keep the fingers between the cutting/ grinding disc and spark protection or in close proximity to the protective hoods. There is a risk of crushing.
6) The rotating parts of the product cannot be covered due to functional reasons. Therefore, proceed cautiously and hold the workpiece firmly in order to avoid slipping which could cause your hands to come into contact with the cutting/grinding disc.
7) The workpiece gets hot during cutting/ grinding. Do not touch the machined area, allow it to cool down. There is a risk of burning. Do not use coolants or the like.
8) If you are tired or have consumed alcohol or tablets, do not work with the product. Always have a break on time.

9) Turn off the product and remove the battery from the product before servicing the product.
10) Do not use any accessories that are not recommended by PARKSIDE. This can result in electric shock or fire.

Vibration and noise reduction

To reduce the impact of noise and vibration emission, limit the time of operation, use lowvibration and low-noise operating modes as well as wear personal protective equipment.

Take the following points into account to minimise the vibration and noise exposure risks:

Only use the product as intended by its design and these instructions.
Ensure that the product is in good condition and well maintained.
Use correct accessory tools for the product and ensure they are in good condition.
- Keep tight grip on the handles/grip surface.
- Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate).
Plan your work schedule to spread any high vibration tool use across a longer period of time.

Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
- Switch the product off and disconnect it from the mains if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
Danger of injury and property damage caused by flying objects.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

Safety instructions for chargers

WARNING!

Do not dispose of batteries in household waste, fire or water. Do not subject the battery to strong sunlight over long periods and do not leave it on a heater (max. 50^ ).

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

Do not charge non-rechargeable batteries. Disregarding this instruction is hazardous.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Protect the electrical parts against moisture. Do not immerse such parts in water or other liquids to avoid electrical shock. Never hold the appliance under running water. Pay attention to the instructions provided for cleaning, maintenance and repair.
The appliance is suitable for indoor use only.

ATTENTION! This charger is only designed for charging the battery pack types:

Parkside 12 V battery pack
PAPK 12 A4 2 Ah 3 cells
PAPK 12 B4 4 Ah 6 cells

Customers can obtain compatible replacement batteries and chargers from the LIDL online shop www.lidl.de.

Practical tips

Cutting disc:

WARNING!

Never use a scrubbing wheel for cutting!

Only certified, fibre-reinforced cutting or grinding discs may be used.
In general, work with small scrubs. Exert only moderate pressure on the workpiece.
Always work in the counter-direction. This ensures that the device is not pushed out of the cut through lack of control.

Cutting of stone materials:

NOTE

Slits in structural walls are subject to the standard DIN 1053 Part 1 or country-specific regulations. These regulations must be observed without fail. Before beginning work you should ask the structural engineer, architect or relevant construction supervisor for advice.
It is best to use a diamond cutting disc to cut stone materials. Make sure in any case that the cutting disc is suitable and labelled for our application.
- When cutting stone materials, ensure that there is sufficient dust extraction.
Wear a dust protection mask.
The device may only be used for dry cutting/ dry grinding.

Scrubbing wheels:

WARNING!

Never use a cutting wheel for scrubbing!

NOTE

Exert only moderate pressure on the workpiece. Move the product evenly back and forth.
A working angle of 30^ to 40^ achieves the best results for scrub grinding.

Replacement parts/accessories:

Spare parts and accessories such as cutting discs can be obtained through your authorized dealer. When buying always consider the technical requirements of this product (see "Technical data"). If you are not certain, ask a qualified specialist and get advice from your trusted dealer. If you are not sure where to purchase, please contact the Lidl service hotline.

- First set-up of the product

Unpacking the product and basic cleaning

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

- Mounting the product

CAUTION! RISK OF INJURY!

Ensure that you have sufficient space in which to work, and that you do not endanger other people.

Setting the protective hood

CAUTION!

The product must only be operated with the protective hood 1 mounted.

NOTE

Adjust the protective hood such that any sparks or detached parts cannot hit either the user or any bystanders.
The protective hood must also be positioned such that the sparks cannot ignite combustible parts, including those in the surroundings.

1. Press the battery release buttons 8 and pull the battery 9 out of the product.
2. Turn the protective hood into the working position. The closed side of the protective hood must always face the operator.

Installing/changing the cutting/grinding disc

CAUTION!

Before initial operation, check the tightness of the clamping screw 3.

NOTE

If the direction of rotation is marked on your cutting/grinding disc, make sure that it matches the direction of rotation mark on the product.

NOTES ON REPLACEMENT

Never operate the product without protective equipment.
Ensure that the rotation speed stated on the cutting/grinding disc is the same or higher than the nominal rotation speed of the product.
Ensure that the cutting/grinding disc dimensions match those of the product.
Only use flawless discs (ringing test: when you strike the grinding disc with a plastic hammer, it results in a clear sound).
Never re-drill a locating hole which is too small to make it larger.
Never use separate bushings or adapters in order to make grinding discs with a hole that is too large fit the product.
Do not use any saw blades.
To clamp the grinding tools only use the clamping flange provided.

The clamping screw must not be too tight in order to avoid breaking the cutting/ grinding disc.

1. Press and hold the spindle retaining tab 4.
2. Loosen the clamping screw 3 with the hex key 11. Release the spindle retaining tab.
3. Position the desired cutting/grinding disc 2 on the mounting flange 12. The label on the cutting/grinding disc should always face the product.
4. Reposition the clamping flange [13]. The side of the clamping flange with recess generally points to the attachment tool and thus to the cutting/grinding disc.

The side with the marking on the clamping flange must be visible.

1. Press the spindle retaining tab and tighten the clamping screw using the hex key. Release the spindle retaining tab.

- Inserting/removing the rechargeable battery

□Inserting the battery: Push the battery 9 along the guide rails into the product. The battery clicks into place.

• Removing the battery: Press the release button 8 on the battery and pull the battery out.

Operation

WARNING!

Wear protective gloves when changing the tool so as to avoid injuries from cuts.

WARNING!

Switch the product off and remove the battery pack before replacing attachments, cleaning and when not in use.

CAUTION! RISK OF INJURY!

Only use grinding discs and accessories recommended by the manufacturer. Using other attachment tools and other accessories can represent a risk of injury for you.
Only use accessory parts which bear information about the manufacturer, type of connection, dimension and permitted number of revolutions.
Only use accessory parts where the printed rotational speed is at least as high as what has been specified on the name plate of the product.
Do not use any broken, cracked, or otherwise damaged grinding discs.
Never operate the product without protective equipment.

CAUTION! RISK OF INJURY!

Support the plates or workpieces in order to reduce the risk of kickback from a jammed cutting disc. Large workpieces may bend under their own weight. The workpiece must be supported on both sides of the disc, not only near the cutting disc, but also at the edge.
- Keep your hands away from the disc when the product is in operation. Risk of injury.

- Switching the product on/off

CAUTION! RISK OF INJURY!

The cutting/grinding disc still runs even after the product has been switched off.

NOTE

After switching on the product, wait until the product has reached its max. speed. Only then should you start with the work.

• Switching on: Push the pressure point on the on/off switch 5a downwards and slide the on/off switch 5 forwards. The product turns on and starts. To engage the product, push the on/off switch forwards.
• Switching off: Push down the pressure point on the on/off switch 5a to tilt the on/off switch 5 downwards. The product switches off.

Trial run

Always carry out a trial run before carrying out your first grinding procedure and after every disc replacement. Switch the product off immediately if the grinding disc is not rotating smoothly, if considerable vibration occurs or if you hear abnormal noises.

- Checking the battery charge level

NOTE

The battery indicator 6 indicates the charge level of the battery 9.

The charge level of the battery is indicated by the LEDs when the product is in operation. Push the pressure point on the on/off switch 5a downwards and slide the on/off switch 5 forwards.

LED Status
red-yellow-green	Battery fully charged
red-yellow Battery	half charged
red Battery needs to be charged

Troubleshooting

Problem Possible	cause Solution
The product does not start.	The battery 9 is discharged.	Charge the battery 9.
	The battery 9 is not inserted in the product.	Insert the battery 9 into the product.
	The on/off switch 5 is damaged.	Contact the service centre.
	The product is damaged.
The grinding tool does not move although the engine is running.	The clamping screw 3 is loose.	Tighten the clamping screw 3 (see „Installing/ changing the cutting/grinding disc").
	Workpiece, remaining workpieces or remaining grinding tools block the drive.	Remove the blockages.
The engine is slower and stops.	The product is overloaded through the workpiece.	Reduce the pressure on the grinding tool.
		The workpiece is unsuitable.
The grinding disc does not rotate smoothly, abnormal noises can be heard.	The clamping screw 3 is loose.	Tighten the clamping screw 3 (see „Installing/ changing the cutting/grinding disc").
	The cutting/grinding disc is defective.	Change the cutting/grinding disc (see „Installing/ changing the cutting/grinding disc").

- Cleaning and maintenance

WARNING!

Switch the product off and remove the battery pack before replacing attachments, cleaning and when not in use.

WARNING!

Do not use any cleaning agent or solvent. Chemical substances can etch the plastic parts of the product.
Never clean the product under running water.

CAUTION!

Contact our service center about repairs and servicing not described in this user manual. Only use original parts.

NOTE

The following cleaning and servicing should be done regularly. This will ensure a long and reliable service life.
Always check the product before using it for obvious deficiencies such as loose, worn or damaged parts, correct the positioning of screws or other parts. Examine the grinding disc in particular. Exchange the damaged parts.

Thoroughly clean the product after every use.
Clean the ventilation openings and the surface of the product with a soft brush or cloth.

Storage

Store the product in a dry and dustproof location and out of reach of children.
Before prolonged storage, remove the battery from the product and charge it fully.
The storage temperature for the rechargeable battery and the product is between 0^ and +45^ . Avoid extreme cold or heat during storage to ensure the battery output is not adversely affected..
Cutting/grinding discs must be dry and stored upright and should never be stacked.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Remove the batteries/battery pack from the product before disposal.

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/ rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 445936_2307) available as proof of purchase.

You will find the item number on the rating plate, an engraving, on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB Service Great Britain

Tel.:[phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail: [e-mail]

EU Declaration of conformity

EU DECLARATION OF CONFORMITY (445936_2307)

IAN:

445936 2307

Product identification:

"Parkside" Cordless Angle Grinding 12V

Model Number:

HG10995

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EC

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 60745-1:2009/A11:2010

EN 60745-2-3:2011/A13:2015

Directive 2014/42/EC

EN IEC 55014-1:2021

EN IEC 55014-2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

Directive 2011/65/EU

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm

30.10.2023

ppa. Stefan Haensel

Authorised Signatory

EN

REMARQUES RELATIVES AU REMPLACEMENT

Watte doen in noodgevallen

Productidentification:

"Parkside" ACCU-HAAKSE SLJPMACHINE 12V

Modelnummer:

HG10995

= 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0

m = 311

来
