USER MANUAL Bobby 48245 UNOLD

Exterior view of a black waffle grater with open lid and tray filled with round food items (no text or symbols visible)

Bedienungsanleitung

Instructions for use Model 48245

Technical Specifications.... 22

Explanation of symbols.... 22

Important Safeguards....22

Putting the appliance into operation 25

Operation....26

Cleaning and care.... 28

Recipes 28

Guarantee Conditions.... 34

Waste Disposal/Environmental Protection ... 34

Service 21

Open waffle grill with honey-coated food, no visible text or symbols

Two black electronic devices with green buttons being handled, one holding a 180° angle indicator (no text or symbols on devices)

Weiterer Ablauf:

Two decorative chocolate fruits with fruit toppings and chocolate chips, served in wireframe stands (no text or symbols visible)

Plate of fresh salad with lettuce, tomato, and greens on a dark dish (no text or symbols visible)

Bowl of soup with egg and green vegetables, accompanied by a black spoon and a food item on a wooden surface (no text or symbols visible)

Baking plates: non-adhesive coating, dimensions approx. 21.5 x 16 cm

Handle: insulated

Dimensions: approx. 28 x 25 x 9.7 cm (W/D/H)

Weight: approx. 2 kg

Power cord: approx. 70 cm

Features: automatic temperature control, function indicator lamps to indicate "ON" and "Ready", high-quality non-stick coating, cool touch stainless steel housing

Accessories: instruction ma nual with recipe

Equipment features, technology, colours and design are subject to change without notice.

EXPLANATION OF SYMBOLS

This symbol denotes a possible hazard which could cause injury or damage to the appliance.

This symbol indicates a potential burning hazard. Please be especially careful at all times here.

IMPORTANT SAFEGUARDS

Please read the following instructions and keep them on hand for later reference.

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

2. Children shall not play with the appliance.

3. Cleaning and user maintenance must not be performed by children, unless they are older than 8 years and are supervised.

4. Keep the appliance and the power cord out of the reach of children under 8 years.
5. CAUTION – Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.
6. Connect the appliance only to an AC power supply with the voltage indicated on the rating plate.
7. Do not operate this appliance with an external timer or remote control system.
8. Never immerse the appliance or the lead cable in water or other liquids.
9. Do not clean the appliance in a dishwasher.
10. Never leave the appliance unattended when it is operating and keep it out of reach of children.
11. Unplug the appliance from the wall socket after use, before cleaning or when problems appear during operation.
12. Place the appliance on an uncluttered and even surface.
13. Never place or use the appliance and the lead cable near hot surfaces.
14. Never touch the appliance or lead cable with wet hands.
15. This appliance is intended for domestic and similar use such as:
    ■staff kitchen areas in shops, offices and other working environments;
    ■agricultura l enterprises;
    ■by clients in hotels, motels and other accommodation facilities;
    ■bed and breakfast accommodations and holiday homes.
16. Use the appliance only indoors.

17. Uncoil the power cord completely to prevent overheating.

18. Make sure that the lead cable does not hang over the edge of the worktop, since this can cause accidents, for example if small children pull on the cable.

19. Never wrap the lead cable around the appliance, but around the cable storage on the bottom of the base.
20. Always disconnect the lead cable from the wall socket pulling on the plug, never on the cable.
21. Make sure that the lead cable does not touch the hot appliance.
22. Do not use the appliance near flammable liquids. Fire hazard!
23. Never use the appliance for defrosting food – fire hazard!
24. Do not overheat your cookware for cooking, broiling or baking to prevent the formation of smoke, which may be hazardous to small animals (e.g. birds) with a respiratory system that is particularly sensitive. We recommend that you do not keep birds in the kitchen.
25. Use the appliance in a well-ventilated area. Leave at least 10 to 15 cm of space on each side of the appliance to allow for power air circulation.
26. The appliance becomes hot during operation. Please use the handles or pot holders when moving the appliance.
27. Do not leave the appliance unattended when it is still hot. Risk of burns!
28. Open the lid completely when placing the dough onto the waffle plates or removing the waffles. Otherwise the lid may fall down. Risk of burns and injury!
29. For safety reasons never cover the appliance or the waffle plates with paper, plastic film or other foreign material. Otherwise the risk of fire hazard exists!
30. Never touch the waffle plates during operation or shortly afterwards with any part of the body or heat sensitive objects.
31. Do not store the appliance when it is still hot.
32. Check the plug and lead cable regularly for wear and damage. In case the lead cable or other parts present

damages, please send the appliance to our after-sales service for inspection and repair.

1. Unauthorised repairs can constitute serious risks for the user and void the warranty.
2. If the lead cable is damaged, it must be replaced by the manufacturer or its after-sales service or a similarly qualified person in order to avoid any hazard.

CAUTION:

The appliance becomes very hot during operation!

Never open the housing of the appliance. This can result in electric shock.

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

PUTTING THE APPLIANCE INTO OPERATION

1. Remove all packaging materials and any transport guards and stickers (not the type plate or the serial number!). Keep the packaging material away from children. Choking hazard! If necessary, dispose of the packaging material according to the applicable statutory waste disposal regulations. Tip: Keep the packaging material in case you wish to return the appliance for repairs at a later time.
2. Inspect the appliance for damage. Do not put the appliance into operation if there are signs of visible damage; in this case, contact our customer service department.
3. Clean all parts with a damp cloth, as described in "Cleaning and care".
4. With the appliance closed, position it so that the indicator lamps for "ON" (red) and "Ready" (green) point upward.
5. Connect the appliance to a power socket (230 V\~, 50/60 Hz). Both indicator lamps light up.
6. Pre-heating begins.
7. Heat the appliance for a few minutes without batter to eliminate any residue from the manufacturing process. Open the kitchen window while the appliance is heating without batter. Afterwards, the appliance may show signs of use; this will not affect the operation of the appliance and does

not constitute grounds for complaint. If you notice a slight odour while the appliance heats up, this is normal and completely harmless.

1. Before first use of the appliance, use a brush to apply heat-resistant fat, such as margarine, to both baking surfaces.
2. Due to possible residue from production, the first waffle may not be fit to eat and should be disposed of.

OPERATION

Important: The appliance will remain very hot for an extended time after use!

Danger of burns from escaping steam.

When flipping the appliance, avoid twisting of the power cable. Tip: Flip the appliance to the left once, and the next time to the right.

1. Close the appliance and connect it to a power socket (230 V\~, 50/60 Hz). Both indicator lamps light up: The red indicator lamp “ON” is illuminated for as long as the appliance is connected to the power supply. The “Ready” lamp lights up green, indicating that pre-heating has started. Once the appliance has reached the pre-set temperature, this indicator lamp goes out.
2. Now, use a ladle to add batter in the centre of the lower baking surface. Then, use a wooden spatula to spread the batter over the bottom baking surface until all indentations are covered with batter. Tip: After mixing the batter in a bowl, pour it into a portioning bottle or a measuring jug with a pouring spout. This will make it easier to portion the batter, which is especially important when making waffles with coloured batter.
3. The batter will spread evenly when you close the appliance. Always make sure to add the right amount of batter. If you add too little batter, the top of the appliance will not be seated properly; the top side of the waffles will then not be as brown as the bottom side. Overflowing batter will be collected in the overflow channel, where it will be baked, or it can flow down the side of the appliance. Remove this excess edge from the waffle after baking, or clean the outside of the appliance before using it again.

Use of the appliance without flipping:

1. Close the appliance immediately after adding batter to allow the waffle to be browned evenly on the top and the bottom. Fasten the locking clip on the appliance handle to prevent batter from running out.

2. The waffle starts baking.

3. Once the waffle has browned to the desired degree, open the appliance carefully and remove the finished waffle. Refrain from using metal objects as they might scratch the coating of the baking plates. Use a wooden fork or wooden skewers.
4. If the waffle is not browned enough, close the appliance again and keep repeating steps 2 through 7 until the waffle has been browned to your satisfaction.

Use of the appliance with flipping

1. Flip the appliance only when making waffles from heavy batter with whole grain flour, gluten-free flour or ingredients such as nuts. Our recipes contain information on this. Flipping is not necessary with light batter!

2. Close the appliance immediately after adding batter to allow the waffle to be browned evenly on the top and the bottom. Fasten the locking clip on the appliance handle to prevent batter from running out while flipping the appliance.

3. Now flip the appliance 180 degrees right away, so the batter can spread evenly into the indentations. Wait 30 seconds, then flip the appliance 180 degrees again, back to the starting position. This ensures even spreading of the batter.

4. The waffle starts baking.

5. Once the waffle has browned to the desired degree, open the appliance carefully and remove the finished waffle. Refrain from using metal objects as they might scratch the coating of the baking plates. Use a wooden fork or wooden skewers.

6. If the waffle is not browned enough, close the appliance again and keep repeating steps 12 through 15 until the waffle has been browned to your satisfaction.

What to watch out for during baking:

1. Notice about the baking lights: When the green indicator lamp goes out, this signals that the temperature has been reached again, but not that the waffle is finished. The baking time of the waffle varies with the batter you use and with your personal taste. Therefore, always check before taking the waffle out if the waffle has been baked to your satisfaction. Our experience shows that the waffle will be done after about 3 minutes.

2. To make more waffles, close the appliance and wait until the indicator lamp "Ready" goes out. Continue making waffles until the batter is used up. It is generally not necessary to grease the baking surfaces again.

3. After baking, unplug the power cable. Only then can you be sure the appliance is safely switched off.

CLEANING AND CARE

Before cleaning the appliance, switch it off by disconnecting the plug from the power socket. Let the appliance cool down before cleaning it.

1. Never immerse the appliance into water or an y other liquid.
2. It is best to clean the baking surface while it is still warm with a soft brush or with a damp cloth.
3. In addition, do not use abrasive cleaners, steel wool, metal objects, hot cleaning agents or disinfectants, as these can cause damage.
4. Never use pointed or hard objects. They would scratch the antistick coating.
5. The appliance can be stored upright to save space.
6. The appliance must be completely dry before using it again.

RECIPES

Bubble waffles, also known as egg waffles, were invented more than 70 years ago in Hong Kong and quickly spread throughout Asia. They soon found their way to the United States, where they became part of the street food scene. Since the first bubble waffle shops opened in Berlin in 2017, this speciality has become ever more popular at fairs and in shops.

The waffles can be sprinkled with powdered sugar or rolled up hot and served in glasses, cups or bags and filled with fruit, ice cream, mousse, sweets, nuts, almonds and various sauces. Another option is to fill the waffle with sandwich makings.

The savoury waffles can also be sprinkled with powdered spices, divided into single bubble portions and served as a snack.

Two decorative waffle dessert containers with chocolate sticks, fruit toppings, and chocolate chips (no text or symbols visible)

Bubble waffles should be eaten right away, but they can also be warmed in a 120 °C oven on baking paper – which is especially practical if the waffles have been frozen.

Our basic recipe for sweet waffles was handed down by Grandmother Minn of Hong Kong, who is almost 90 years old. Although Minn's recipe has already been around for 70 years, we modified it slightly by using baking powder instead of bicarbonate of soda. For this recipe, you do not have to separate the eggs or beat the egg white until stiff. Nor does the appliance have to be flipped.

Close-up of a plated salad with lettuce, tomato, and onion on a black plate (no text or symbols visible)

Before you get started, here is some useful information:

If you use milk instead of mineral water, you should flip the appliance once after filling, wait 30 seconds, then flip it back again as described in "Operation".

If you add ground nuts, freshly chopped herbs or oil seeds to the batter, it is likewise recommended that you flip the appliance as described above. These ingredients can prevent the batter from rising properly.

The addition of 50 g additional cornflour for each 400 g of flour makes the waffles crispier, but they may not be as easy to roll up.

For a savoury variant, you can add your favourite spice to the batter, such as curry, paprika or chilli powder, dried herbs, and salt.

For especially crispy bubble waffles, bake them a little longer

Basic recipe for sweet bubble waffles

Approx. 10–12 waffles

6 eggs, 2 pinches salt, 200 ~g melted butter (not hot!), 125 ~g sugar, 2 envelopes vanilla sugar, 400 ~g flour type 550, 100 ~g cornflour, 1 envelope baking powder, 400 ml highly carbonated mineral water

Beat eggs, salt, butter, vanilla sugar and sugar until fluffy. Sift flour, cornflour and baking powder over the mixture, add mineral water and stir together.

Make waffles without flipping, as described in "Operation".

Variations:

For chocolate waffles, replace 30 g of the cornflour with cocoa.

You can make nut waffles by replacing 50 g of the cornflour with ground nuts.

For matcha tea waffles, add 2 tsp. matcha powder.

Coconut bubble waffles

Approx. 8 waffles

4 eggs, 150 g melted butter, not hot, 1 pinch salt, 1 envelope vanilla sugar, 150 g sugar, 400 g wheat flour type 550, 1 envelope baking powder, 400 ml highly carbonated mineral water, 200 g grated coconut, 1 tbsp. rum

Put eggs, melted butter, salt, vanilla sugar and sugar in a bowl and beat until fluffy. Sift flour and baking powder over the mixture. Add mineral water and wait a moment until the froth has settled. Add grated coconut and rum. Blend all ingredients, for example with the ESGE hand blender and multi mincer.

Prepare the waffles as described in “Operation” and flip the appliance as described there after 30 seconds, then flip it back again right away.

Now you can roll up the hot waffles, put them in a glass to cool, then fill them as desired. Or simply place them flat on a plate, sprinkle with powdered sugar and serve.

Filling for coconut waffles:

■ Fresh pineapple cubes and coconut ice cream
■ Pineapple yoghurt with pineapple chunks and grated coconut

Pina colada cream (sufficient for two waffles): Crush 10 ice cubes with the ESGE hand blender and multi mincer until fine. Other ingredients: 50 ml white rum (optional), 150 ml pineapple juice, 50 g coconut cream, 100 ml whipping cream, 1 envelope ParadiesCreme “White Chocolate”, pineapple chunks, maraschino cherries

Stir together the crushed ice, rum (if desired), coconut cream, whipping cream, pineapple juice and ParadiesCreme until creamy. Fill the waffle alternately with pineapple chunks and the cream mixture. Garnish with a maraschino cherry.

Colourful bubble waffles

Approx. 6 waffles

These waffles are not just for a children's birthday party!

3 eggs, 1 pinch salt, 125 g melted butter, not hot, 75 g sugar, 1 envelope vanilla sugar, 200 g flour type 550, 75 g cornflour, 250 ml water

Beat eggs, salt, melted butter, sugar and vanilla sugar until fluffy. Add flour, cornflour and water and mix well.

Divide batter into portions, depending on the number of desired colours. Add 12 - 1 tsp. food colouring to each portion of batter and mix. The amount of food colouring depends on its consistency and the manufacturer's instructions.

Use small jugs with a pouring spout or small squeeze bottles to distribute the coloured batter in patterns on the bottom baking surface. Close the appliance

quickly for optimal bubbles.

Prepare the waffles according to the instructions in “Operation” and flip the appliance after 30 seconds, as described in that section.

These colourful bubble waffles can be served for example with fruit salad, small sweets, jelly or other fillings popular with children.

Basic recipe for savoury bubble waffles

Approx. 10–12 waffles

4 eggs, 150 g oil, 400 g spelt flour, 100 g cornflour, 1 envelope baking powder, 500 ml highly carbonated mineral water, 2 tsp. powdered vegetable broth

Whisk eggs and oil together. Sift flour, cornflour and baking powder into the batter, add powdered vegetable broth and mix all ingredients thoroughly.

Prepare the waffles according to the instructions in "Operation". For these waffles, do not flip the appliance.

Remove the baked waffle, roll it up while hot and put it in a glass. Let the waffle cool and then fill it as desired.

Variations:

Cheese waffles	Add 50 g grated Parmesan and 30 g sesame seed
Tomato waffles	Replace vegetable broth with 1 package tomato soup powder or 50 g tomato powder (health food store)
Herb waffles	Add 5 tbsp. dried herbs. If fresh herbs are used, the waffles will not be as light.
Beer waffles	Replace half of the water with Pilsner beer and add 50 g finely ground peanuts.
Pizza waffles	Add 1 tbsp. oregano and 2 splashes Tabasco.

Tip: Once they are baked, you can divide the savoury waffles into single bubbles and serve as a snack or add to a soup.

Fillings for savoury waffles

Mozzarella and cocktail tomatoes

Boiled ham, pineapple cubes, Gouda cheese cubes and balsamic dressing

Finely chopped red cabbage, red beets, sour cherries and red cabbage dressing

Canned celery stalks, grated apple, chopped walnuts and celery dressing

Olives, paprika strips of different colours, cubed tomatoes and cucumber, chopped red onions

Radishes, chives, radish dressing

Red cabbage dressing	3 tbsp. sour cherry jam, 1 peeled banana, 150 g apple juice, 2 tbsp. vinegar, 2 tbsp. oil, 1 tsp. sugar, salt pepperMix all ingredients with a hand-held blender (such as the ESGE hand blender)
Celery dressing	150 g mayonnaise, 50 g sour cream, 3 EL lemon juice,salt pepperMix all ingredients with a hand-held blender (such as the ESGE hand blender)
Balsamic dressing	1 clove garlic, finely chopped, 50 ml balsamic vinegar,1 tbsp. vinegar, 70 ml olive oil, 2 EL water, 1 tsp. sweet mustard, salt, pepperMix all ingredients with a hand-held blender (such as the ESGE hand blender)
Radish dressing	150 ml sweet cream, 1 tbsp. vinegar, salt, pepperMix all ingredients with a hand-held blender (such as the ESGE hand blender)

Gluten-free bubble waffles

Approx. 6 waffles

220 g Schär baking mixture “Cakes and Cookies”, 150 g sugar, 125 g butter, 3 eggs, 12 envelope (8 g) baking powder, 125 ml highly carbonated mineral water. Put all ingredients in a bowl and mix until the sugar has dissolved. Allow batter to stand at room temperature for 30 minutes.

Prepare the waffles according to the instructions in “Operation” and flip the appliance after 30 seconds, as described in that section.

Important: For each waffle, grease the baking plates lightly with heat-resistant oil.

Important: If you use a little more batter, you can remove the waffle in one piece after baking. If you use a little less batter, the spaces between the bubbles will be thinner and you can remove the single bubbles with a toothpick.

Tip: Dip each single bubble halfway in melted chocolate and allow to cool on a cake rack. If desired, you can roll them in grated coconut, flaked almonds or coloured sprinkles before the chocolate dries.

Whole grain bubble waffles

Approx. 6 waffles

3 eggs, 1 pinch salt, 100 ~g very soft butter, 75 ~g sugar, 1 envelope vanilla sugar, 250 ~g whole grain spelt flour, 75 ~g cornflour, 1 envelope baking powder, 300 ml highly carbonated mineral water

Beat eggs, salt, butter, sugar and vanilla sugar until fluffy. Sift flour, cornflour and baking powder into the batter. Add mineral water and stir all ingredients together to form a smooth batter.

Prepare the waffles according to the instructions in “Operation” and flip the appliance after 30 seconds, as described in that section.

Bake the waffles a little longer to give them a darker colour. This batter is not very light and therefore needs longer to bake thoroughly.

Tip: You can also make these bubble waffles as savoury waffles. Simply replace the sugar and vanilla sugar with 1 ½ to 2 tsp. vegetable broth powder.

The savoury waffles are excellent served with grilled foods and crispy salads. For more information about savoury waffle batter, refer to the recipe for savoury bubble waffles.

The authors have thoroughly considered and tested the recipes included in these operating instructions. Nevertheless, a guarantee cannot be accepted. The authors, respectively UNOLD AG and their assignees shall not be liable for personal injuries, material damages and financial loss.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. You can print out a return receipt on our website https://unold.de/pages/rucksendungen (only for entries from Germany and Austria). The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a highquality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible, we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. There is a legal requirement to dispose of waste electrical and electronic equipment (WEEE) as well as batteries and accumulators separately from household waste. You can recognise this waste equipment by the crossed-out wheeled bin symbol (WEEE symbol).

Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

NOTICE D'UTILISATION MODÈLE 48245

SPÉCIFICATION TECHNIQUE

Puissance: 700 W, 230 V\~, 50/60 Hz

CONDITIONS DE GARANTIE
