USER MANUAL 48266 UNOLD

Exterior view of a black and silver portable electronic device with a logo on the lid (no readable text or symbols)

WAFFELAUTOMAT 4er BRÜSSELER

Bedienungsanleitung

Modern kitchen appliance with digital display and bucket containing food (no visible text or symbols)

Product photo of a modern wheat bread machine with a metal basket and small glassware nearby (no visible text or symbols)

UNOLD®

Care + Style

Product photo of a red and black electric toothbrush with a black clip, no visible text or symbols

Product photo of a pink hair dryer with black cord and bulb (no text or symbols visible)

UNOLD®

Fan + Heat

Close-up of a desktop electric fan with visible blades and base (no text or symbols)

Red electric fan with a circular top and control panel (no visible text or symbols)

INHALTSVERZEICHNIS

Instructions for use Model 48266

Technical Specifications.... 15

Explanation of symbols.... 15

Important Safeguards.... 15

First use 17

Before using the appliance the first time.... 18

Cleaning....19

Recipes 19

Sweet waffles....20

Guarantee Conditions....21

Waste Disposal /

Environmental Protection 21

Service 14

Exterior view of a cylindrical industrial vessel with attached electrical outlet (no visible text or symbols)

Baking plates: Non-adhesive coating

Handle: Insulated

Dimensions: Approx. 24.6 x 3.,4 x 10.4 cm (W/D/H)

Weight: Approx. 2.5 kg

Power cord: Approx. 70 cm

Features: Adjustable temperature control, function control lamp

Accessories: Instruction manual with r ecipes

Equipment features, technology, colours and design are subject to change without notice.

EXPLANATION OF SYMBOLS

This symbol denotes a possible hazard which could cause injury or damage to the appliance.

This symbol indicates a potential burning hazard. Please be especially careful at all times here.

IMPORTANT SAFE GUARDS

Please read the following instructions and keep them on hand for later reference.

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
2. Children shall not play with the appliance.

3. Cleaning and user maintenance must not be performed by children, unless they are older than 8 years and are supervised.

4. Keep the appliance and the power cord out of the reach of children under 8 years.

5. CAUTION – Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.
6. Connect the appliance only to an AC power supply with the voltage indicated on the rating plate.
7. Do not operate this appliance with an external timer or remote control system.
8. Never immerse the appliance or the lead cable in water or other liquids.
9. Do not clean the appliance in a dishwasher.
10. Never leave the appliance unattended when it is operating and keep it out of reach of children.
11. Unplug the appliance from the wall socket after use, before cleaning or when problems appear during operation.
12. Place the appliance on an uncluttered and even surface. Never place or use the appliance and the lead cable near hot surfaces.
13. Never touch the appliance or lead cable with wet hands.
14. This appliance is intended for domestic and similar use such as:
    ■ staff kitchen areas in shops, offices and other working environments;
    ■ agricultural enterpsi
    ■ by clients in hotels, motels and other accommodation facilities;
    ■ bed and breakfast accommodations and holiday homes.
15. Use the appliance only indoors.
16. Unroll the lead cable completely before use. Make sure that the lead cable does not hang over the edge of the worktop, since this can cause accidents, for example if small children pull on the cable.
17. Never wrap the lead cable around the appliance, but around the cable storage on the bottom of the base.
18. Always disconnect the lead cable from the wall socket pulling on the plug, never on the cable.
19. Make sure that the lead cable does not touch the hot appliance.
20. Do not use the appliance near flammable liquids. Fire hazard!
21. The appliance becomes hot during operation. Please use the handles or pot holders when moving the appliance.

22. Do not leave the appliance unattended when it is still hot. Risk of burns!

23. Open the lid completely when placing the dough onto the waffle plates or removing the waffles. Otherwise the lid may fall down. Risk of burns and injury!

24. For safety reasons never cover the appliance or the waffle plates with paper, plastic film or other foreign material. Otherwise the risk of fire hazard exists!
25. Never touch the waffle plates during operation or shortly afterwards with any part of the body or heat sensitive objects.
26. Do not store the appliance when it is still hot.
27. Check the plug and lead cable regularly for wear and damage. In case the lead cable or other parts present damages, please send the appliance to our after-sales service for inspection and repair. Unauthorised repairs can constitute serious risks for the user and void the warranty.
28. If the lead cable is damaged, it must be replaced by the manufacturer or its after-sales service or a similarly qualified person in order to avoid any hazard.

CAUTION:

The appliance becomes very hot during operation!

Never open the housing of the appliance. This can result in electric shock.

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

FIRST USE

1. Before first use, we recommend cleaning the non-stick waffle plates with a damp cloth.

2. Close the appliance and connect the plug to a wall socket (220–240 V\~, 50 Hz). The indicator lights up.

3. Turn the temperature control to the intermediate position to start to preheat. When the appliance has reached the preset temperature, the indicator "Ready" turns off.

4. Heat the appliance up for a couple of minutes without dough, in order to eliminate possible manufacturing residues. Make sure the room is well ventilated during this process. After the initial heating process the appliance might show signs of wear, which do not affect its features and do not constitute a reason for rejection.
5. Before first use, slightly grease both waffle plates with heat resistant grease like margarine, for example, using a pastry brush (as the waffle plates are non-stick coated, greasing is only necessary before the very first use).
6. The appliance may generate a slight smell when first using it, which is absolutely normal.
7. The first waffle should not be used and should be thrown away.

BEFORE USING THE APPLIANCE THE FIRST TIME

1. Close the appliance and connect the plug to a wall socket (220–240 V\~, 50 Hz). The indicator lights up.
2. Turn the temperature control to the intermediate position to start to preheat. When the appliance has reached the preset temperature, the indicator "Ready" turns off.
3. Now pour the batter onto the middle of the lower baking surface with a ladle. When closing the appliance the batter is distributed uniformly. Always ensure that you correctly dose the amount of batter. If you use too little batter the upper part of the appliance will not sit correctly; in this case the waffles will not be as brown on top as they are on the bottom. If you use too much batter the excess batter will overflow and adhere on the appliance and the countertop.
4. After pouring on the batter, close the appliance immediately so that the waffle browns uniformly on the top and bottom.
5. Carefully open the appliance and remove the finished waffle. Do not use any metallic objects to do this, to avoid scratching the coating of the baking plates.
6. If the waffle is not yet brown enough, close the appliance and repeat steps 5 and 6 until the waffle is the way you like it.
7. Note concerning the baking signal lights: When the indicator “Ready” light is illuminated, this means that the temperature has again been reached, however it does not mean that the waffle is done. The bake time of the waffle depends on the dough used and your personal taste. Consequently, before

removing the waffle, please check whether it is done the way you want it. Our experience shows that Brussels waffles are done after 6 to 8 minutes.

1. To make additional waffles, close the appliance and wait until the green indicator light is off. Continue with steps 2 to 8 until the batter is used up.
2. After making waffles, unplug the mains plug. The device is not switched off until it is unplugged.

Caution: After use, the appliance still remains extremely hot for a longer period of time!

CLEANING

Before cleaning, always turn off the appliance by switch to the „O“position, and unplug it from the electrical outlet.

Allow the appliance to cool before cleaning it.

Exterior view of a cylindrical industrial vessel with two protruding outlets (no text or symbols visible)

1. Never immerse the appliance into water or any other liquid.
2. It is best to clean the baking surface while it is still warm with a soft brush or with a damp cloth.
3. Never use pointed or hard objects. They would scratch the anti-stick coating.
4. The appliance must be completely dry before using it again.

RECIPES

You can also make all recipes with whole-wheat flour or whole-meal spelt flour instead of sifted cake flour. In this case use approx. 15% more liquid and let the batter stand for 30 min. before starting to make waffles.

For flavour variations you can add approx. 2 cl of rum or Amaretto, 1 TBSP of grated lemon peel, 12 bottle of butter vanilla flavouring. 3 TBPS of finely chopped nuts or almonds. You can vary the flavour of savoury waffles by adding 2-3 TBSP of finely chopped herbs, grated cheese or boiled ham, 1 TPSP curry, caraway or 1 TBSP of flax seed. For many recipes there is no need to grease the waffle plates. Waffle batter that contains little or no grease, requires greased waffle plates. Use a brush to apply heat-resistant margarine to the plates (do not use diet margarine). If you separate the eggs, beat the egg white until it is stiff, and then fold it into the batter, you will get particularly fluffy and airy waffles (not with yeast dough). Please note that Belgian waffles will be thicker than conventional waffles and consequently take slightly longer to cook. Each of the recipes makes approx. 8 to 10 waffles.

If you want to use stevia instead of sugar, simply replace the tblsp specification for sugar with a tsp specification for stevia (e.g. replace 5 tblsp sugar with 5 tsp stevia. Caution: In this case the dough will be somewhat thinner).

Honey or syrup is used like sugar.

In this case the sweetening effect is not as strong, however browning of the waffles is more pronounced.

If you use sugar substitutes, you should turn over the waffle maker after 3 to 4 minutes, because the dough does not rise as much as it does with sugar. By turning you achieve uniform browning on both sides (turn the appliance 180 degrees so that the underside is facing upward).

SWEET WAFFLES

Basic recipe – Waffles

Makes 10-12 waffles, i.e. 3 appliance fillings

250 g butter, 200 g sugar, 1 package vanilla sugar, 5 eggs, 400 g flour, 12 package baking powder, 3 Tbsp milk

Beat butter, sugar and vanilla sugar until foamy, stir in eggs individually, add flour, baking powder and milk, and beat the mixture to form a smooth batter.

Heat up the waffle maker and select a level between 4 and 6 depending on the desired degree of browning. Wait until the red and the green indicator lights are illuminated. Fill in 1/3 of the batter (approx. 2-3 Tbsp per individual waffle). Close the appliance and bake waffles until the desired browning. Divide the waffles into 4 individual waffles with a dough spatula and remove them.

Apple waffles

Basic recipe, in addition 3 red apples Quarter apples, remove core, grate in fine strips, stir into the batter. Continue as described above.

Cinnamon waffles

Basic recipe, in addition stir 1 tsp cinnamon into the batter. Continue as described above.

Cocoa waffles

Basic recipe, in addition stir 1½ Tbsp cocoa powder and 2 Tbsp milk into the batter.

Nut waffles

Basic recipe, in addition stir 100 g ground nuts and 5 Tbsp milk into the batter. Important: Lightly toast the ground nuts in a pan without oil, stir constantly.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged and postage paid, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. If the defect is covered by the warranty, the customer will be reimbursed for the shipping costs only in Germany and Austria. The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid black rectangle below (no text or labels)

The authors have thoroughly considered and tested the recipes included in these operating instructions. Nevertheless, a guarantee cannot be accepted. The authors, respectively UNOLD AG and their assignees shall not be liable for personal injuries, material damages and financial loss.

NOTICE D'UTILISATION MODÈLE 48266

SPÉCIFICATION TECHNIQUE

Puissance: 1.200 W, 220–240 V\~, 50/60 Hz
