USER MANUAL PAMFWP 20Li B2 PARKSIDE

AKKU-MULTIFUNKTIONSWERKZEUG 20 V / CORDLESS MULTI-PURPOSE TOOL 20 V / OUTIL MULTIFONCTION SANS FIL 20 V PAMFWP 20-Li B2

DE AT CH

AKKUMULTIFUNKTIONSWERKZEUG 20V

Operation and safety notes Translation of the original instructions

FR BE

OUTIL MULTIFONCTION SANS FIL 20 V

GB/IE Operation and safety notes Page 23

Pack: PAP 20 A2, PAP 20 A3

Lade- Parkside 20 V Lade gerat PLG 20 A1,

gerät: PLG 20 A2, PLG 20 B1, PLG 20 A3

Bedienung

Warnings and symbols used 24

Introduction. 24

Intended use. 24
Scope of delivery. 25
Parts description. 25
Technical data 25

Safety instructions. 27

General power tool safety warnings. 27
Sander safety warnings. 30
Vibration and noise reduction. 30
Behaviour in emergency situations. 31
Residual risks 31
Battery charger safety warnings 32

Before first use. 32

Accessories 32

Operation 33

33
Checking the battery pack charging level. 33
Charging the battery pack. 33
Connecting/removing the dust extractor 34
Selecting an accessory tool.. 34
35
Setting the oscillation speed. 36
Switching on and off 36
Trial run 37

Working instructions 37

Cleaning and care 37

Cleaning. 37
Maintenance 37
Repair. 38
Storage 38
Transportation 38

Disposal. 38

Warranty 39

EC declaration of conformity 40

Warnings and symbols used The following warnings are used in this instruction manual, on the packaging and on the rating label:
	Read the instruction manual.		Switch the product off and remove the battery pack before replacing attaches, cleaning and when not in use.
	Follow the warnings and safety notes!	max. 45°C	Protect the battery pack against heat and continuous intense sunlight.
	Use in dry indoor rooms only.		Protect the battery pack against water and moisture.
	Wear protective gloves! Protect the battery	pack from fire.
	Wear hearing protection! Protection class II	double insulation)
	Wear eye protection!	~	Alternating current
		-	Direct current
	Wear dust mask!	T3.15A	Fuse

CORDLESS MULTI-PURPOSE TOOL

20V

PAMFWP 20-Li B2

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This cordless multi-function tool (hereinafter "product" or "power tool") is designed for sawing, cutting, and sanding. The product should preferably be used for the following materials: Wood, plastic, drywall materials, light and non-ferrous metals, fasteners (e.g. nails, screws), and wall tiles. The product is particularly suitable for flush applications and applications close to the edge. The product is not intended to work on very hard materials such as cement or concrete.

Always use the correct accessory tools according to the intended use! Observe the technical requirements of this product (see "Technical data") when purchasing and using accessory tools!

The LED work light [12] on this product is intended to illuminate the immediate work area.

Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage. The manufacturer is not liable for any damages caused by improper use. The product is not intended for commercial use or for any other use.

Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 x Cordless multi-purpose tool 20 V PAMFWP 20-Li B2
1 x Dust extractor with adaptor (for external dust extraction)
1 x Battery pack PAP 20 A1
1 x Rapid battery charger PLG 20 B1
1 x Carrying case
1 x Instruction manual

Parts description

Figure A:

Accessory tool release lever
On/off switch
3 Battery pack
4 Oscillating speed dial
5 Connection ring
6 Locking cap
7 Adaptor (for external dust extraction)
8 Dust extractor
9 Groove
[10] Clamping nut
[11] Accessory tool holder
12 LED work light

Figure B:

3 Battery pack
[13] Release button for battery pack
14 button (charging level)
[15] Charging level LEDs (red/orange/green)

Figure C:

16 Battery charger (rapid battery charger)
17 Power cord with power plug
[18] Charging control LED - Green
19 Charging control LED - Red

Not illustrated:

20 Carrying case

Technical data

Cordless multi-purpose PAMFWP tool 20-Li B2

Rated voltage: 20V

No-load speed n_0 : 8000 -

Oscillation angle: 3.2^

Battery pack

Type: Lithium-lon Rated voltage: 20 V = = = max.

Capacity: 2 Ah

Energy value: 36 Wh

Number of cells: 5

Rapid battery charger PLG 20 B1

Input:

Rated voltage: 230 - 240V

Rated frequency: 50 Hz

Rated power: 120 W

Output:

Rated voltage: 21.5V

Charging current: 4.5 A

Protection class:

Fuse (internal):

3.15A/ T3.15A

Charging time:

Battery type PAP 20 A1, 2.0 Ah (supplied): 45 minutes
Battery type PAP 20 A3, 4.0 Ah (available separately): 60 minutes

Recommended ambient temperature:

While charging: +4 to +40 °C

During operation: +4 to +40 °C

During storage: +20 to +26 °C

Noise emission value

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the power tool is typically as follows:

Sound pressure level L_pA : 76.2 dB(A)

Uncertainty K_PA : 3 dB

Sound power level Lw: 87.2 dB(A)

Uncertainty Kwa: 3 dB

Vibration emission value

Vibration total values (triaxial vector sum)

determined according to EN 62841:

Sanding:

Vibration emission value a_h : 3.72 m/s²

Uncertainty K: 1.5m / s^2

WARNING!

Wear ear protection!

NOTE

The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

WARNING!

The vibration and noise emissions during actual use of the power tool can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed.

Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the power tool is switched off and when it is running idle in addition to the trigger time).

Safety instructions

• General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

1) Keep work area clean and well lit. Cluttered or dark areas invite accidents.

2) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

3) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

1) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.

2) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

3) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

4) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

5) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
6) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

1) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
2) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

3) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
4) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
5) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
6) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

8) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

1) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
2) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
3) Disconnect the plug from the power source and / or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
4) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

5) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
7) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
8) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Battery tool use and care

1) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.

2) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
3) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
4) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
5) Do not use a battery pack for tool that is damaged or modified. Damaged or modified batteries exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
6) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130^ may cause explosion.
7) Follow all charging instruction and do not charge the battery pack or tool outside the temperature range specified in the instruction. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of the fire.

Service

1) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
2) Never service damaged battery packs. Service of battery packs should be only be performed by the manufactured or authorized service providers.

Sander safety warnings

WARNING!

Dust from materials such as lead paint, some types of wood, and metal can be harmful to your health.
Contact with or inhaling this type of dust can present a danger to the user or persons nearby.

WARNING!

Wear safety glasses and a dust mask!

Vibration and noise reduction

To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment.

Take the following points into account to minimise the vibration and noise exposure risks:

Only use the product as intended by its design and these instructions.
Ensure that the product is in good condition and well maintained.
Use correct accessory tools for the product and ensure they are in good condition.
- Keep tight grip on the handles / grip surface.
- Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate).
Plan your work schedule to spread any high vibration tool use across a longer period of time.

Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
- Switch the product off and disconnect it from the mains if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
Danger of injury and property damage caused by flying objects.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

Battery charger safety warnings

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

• Do not charge nonrechargeable batteries. Disregarding this instruction is hazardous.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

• Protect the electrical parts against moisture. Do not immerse such parts in water or other liquids to avoid electrical shock. Never hold the appliance under running water. Pay attention to the instructions provided for cleaning, maintenance and repair.

The appliance is suitable for indoor use only.
■ ATTENTION! This charger is only designed for charging the battery pack types:

Parkside 20 V battery pack

PAP 20 A1 2 Ah 5 cells

PAP 20 A2 3 Ah 10 cells

PAP 20 A3 4 Ah 10 cells

An up-to-date list of battery compatibility can be found at www.lidl.de/akku.

Before first use

Accessories

To operate this product safely and correctly, the following accessories, i.e. tools and accessory tools, are necessary:

Suitable accessory tools
Suitable personal protective equipment

Accessories and accessory tools are available through your authorised dealer. When buying always consider the technical requirements of this product (see "Technical data"). If you are not certain, ask a qualified specialist and get advice from your trusted dealer.

NOTE

This instruction manual contains information and suggestions for several accessory tools and their uses. The accessory tools depicted are not included in the shipment (see "Scope of delivery"), but are meant to indicate additional possibilities for using this product.

WARNING!

Do not use accessories not recommended by Parkside. This may result in electric shock or fire.

Suitable battery packs and chargers

Battery Parkside 20 V battery pack

pack: PAP 20 A1, PAP 20 A2, PAP 20 A3

Charger: Parkside 20 V charger PLG 20 A1, PLG 20 A2, PLG 20 B1, PLG 20 A3

Operation

• Attaching/removing the battery pack

Removing the battery pack: Press the battery pack release button 13. Remove the battery pack 3 (Fig. D).
- Attaching the battery pack: Align the battery pack 3 to the handle and slide it into it. Ensure it clicks noticeably in place.

The battery pack can only be inserted into the product in one direction.

- Checking the battery pack charging level

(Fig. B)

Check battery pack charge level: Press the button 14. The charging level LEDs 15 light up:

LED 15

Charging level

Red/orange/green Maximum

Red/orange Medium

Red Low

Charging the battery pack (Fig. C)

NOTE

The battery pad may be charged at any time without reducing the life.
Interrupting the charging process does not damage the battery pack 3

Charge the battery pack before operation when it is at medium or low charging level.
The charging control LEDs (green and red 19) indicate the status of the charger 16 and the battery pack 3:

LED Status

Red LED lights up Battery pack

charges

Green LED lights up Battery pack fully

charged

Green and red LED

Battery pack

flashing

defective

Red LED flashing Battery pack too

cold or too warm

Green LED lights up

Charger ready

(without battery pack)

Insert the battery pack into the charger 16.
Connect the power cord with power plug of the charger 16 to the socket.

When the battery pack is fully charged: Remove the battery pack from the charger 16 Then disconnect the power cord with power plug 17 of the charger from the socket.

• Connecting/removing the dust extractor

WARNING! FIRE HAZARD!

Using power tools with a dust extraction element which can be connected to a vacuum cleaner poses a fire hazard! Unfavourable conditions, e.g. sparking, sanding metal or metal pieces in wood, wood dust inside the vacuum bag can ignite. This can particularly occur if the wood dust is mixed with paint particles or other chemicals and the ground product is hot after long work periods. Therefore avoid the sanding material and the product overheating. Always empty the vacuum bag in the vacuum cleaner before taking breaks.

Always use a dust extractor.
Ensure the work area is well ventilated.
Observe your country's applicable rules for the materials you are working on.

NOTE

When connecting or removing the dust extractor [8], no accessory tool may be mounted.

(Fig. E)

Pull the locking cap on its side grips. Place the dust extractor 8 on the product. Make sure that the connection ring 5 is positioned in the groove 9. Release the locking cap. The dust extractor should be freely movable in the groove.
Push the hose of a proper vacuum cleaner (e.g. a workshop vacuum cleaner) onto the adaptor 7.
Removing the dust extract: Proceed in reverse order.

• Selecting an accessory tool

NOTE

The following accessory tools constitute the most common types. If desired, consult specialist retailers about further accessory tools.

Plunge saw blade

(Fig. F, a)

Materials:

Wood
Plastic
Plaster
other soft materials

Use:

Cut-off cuts
Plunge cuts
Sawing close to the edge, including in hard to reach areas

Example:

Cutting notches in light construction walls

Diamond saw blade	(Fig. F, b)
Materials:	Tile cement
	Tile joints
Use:	Removing material residue
Examples:	Removing tile cement when replacing damaged tiles
	Reaming out joint compound between wall and floor tiles
Scraper	(Fig. F, c)
Materials:	Mortar/cement residu
	Tile/carpet adhesive
	Paint/silicone residue
Use:	Removing material residue
Example:	Removing carpet adhesive residue on floors
Sanding plate	(Fig. F, d)
Materials:	Wood and metal
	Wood*
	Metal*
	*depending on sanding sheet
Use:	Sanding along edges
	Sanding along hard-to-reach areas

- Attaching/removing the accessory tool

(Fig. G)

CAUTION! RISK OF INJURY!

Accessory tools can be sharp and may become hot during use. Always wear protective gloves when handling accessory tools!

WARNING!

Always switch the product off, remove the battery pack 3 and let the product cool down before making any adjustments!

CAUTION! RISK OF INJURY!

• Keep your hands away from the accessory tool when the product is in operation.

NOTE

To use the dust extract, you will need to connect it before attaching the accessory tool (see "Connecting/removing the dust extractor").

Inserting the accessory tool

(Fig. G)

• Fold the insert tool release level all the way upwards (180°).
• The clamping nut is lifted up and allows access to the accessory tool holder.

Inserting open end accessory tools: Place the accessory tool into the accessory tool holder [11]
Inserting close end accessory tools: Additionally, remove the clamping nut [10]. Reattach the clamping nut after inserting the accessory tool.

NOTE

You can attach the accessory tools into the accessory tool holder [1] in any lock-in position (Fig. H).

Tightening the accessory tool

(Fig. G)

Push the tool release lever all the way down.

Removing the accessory tool

(Fig. G)

• Fold the insert tool release lever all the way upwards (180^) .
  Removing open end accessory tools: Pull the accessory tool out of the accessory tool holder 11

Removing close end accessory tools: Additionally, remove the clamping nut to remove such accessory tools. Reattach the clamping nut after pulling out the accessory tool.

After removing the accessory tool: Push the tool release lever all the way down.

- Setting the oscillation speed

Use the oscillation speed adjustment wheel 4 to set the oscillation speed (Fig. J).

Setting 1: Low oscillation speed Setting 6: High oscillation speed

NOTE

The oscillation speed required varies by material and working conditions and can be determined with tests.
The oscillation speed can also be changed during operation.

- Switching on and off

CAUTION! RISK OF INJURY!

Always wear protective gloves when handling or working with the product.

CAUTION! RISK OF INJURY!

Always hold the product with both hands while working (Fig. 1).

CAUTION! RISK OF INJURY!

• Keep your hands away from the accessory tool when the product is in operation.

CAUTION! HEALTH RISK!

Never work on materials containing asbestos. Asbestos is considered carcinogenic.

(Fig. K)

Switching on: Slide the on/off switch 2 forward (ON).
- Switching off: Slide the on/off switch 2 back (OFF).

Trial run

NOTE

Always carry out a no-load trial run before starting work and after every accessory tool replacement.

The trial run is to make sure the accessory tools are correctly locked in place and will not became loose during operation.

- Working instructions

Working principle:

The oscillating motor allows the accessory tool to oscillate back and forth 8000 to 20000 times per minute. This allows for precision in the tightest of spaces.

Sawing/cutting:

Only use undamaged saw blades free from defects. Bent, dull or otherwise saw blades can break.
Observe the law and the recommendations of the material manufacturers when cutting light construction materials.
Only soft materials such as softwood, gypsum plasterboard etc. may be processed using plunge cutting!

Sanding:

Apply even pressure to extend the life of the sanding sheets.

Cleaning and care

WARNING!

Always switch the product off, remove the battery pack 3 and let the product cool down before performing inspection, maintenance and cleaning work!

- Cleaning

Never allow fluids to get into the product.
The product must always be kept clean, dry and free from oil or grease. Remove debris from it after each use and before storage.
Regular and proper cleaning will help ensure safe use and prolong the life of the product.
Clean the product with a dry cloth. Use a soft brush for areas that are hard to reach.
In particular clean the air vents after every use with a cloth and soft brush.

The vents must always be clear.

NOTE

Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.

Maintenance

The product is maintenance-free.
Before and after each use, check the product and accessories (e.g. accessory tools) for wear and damage. If required, exchange them for new ones as described in this instruction manual. Observe the technical requirements (see "Technical data").
Check covers and safety devices for damages and correct installation. Replace as necessary.

Repair

This product does not contain any parts that can be repaired by the user. Contact an authorised service centre or a similarly qualified person to have it checked and repaired.

Storage

Switch the product off.
Clean the product as described above.

Store the product and its accessories in a dark, dry, frost-free, well-ventilated place.
Always store the product in a place that is inaccessible to children. The ideal long term storage (longer than 3 months) temperature is between +20 and +26^ .
Store the product in its ca

Battery pack advice

Only store the battery pack partially charged. The battery pack should be charged to 40 to 60% (red and orange LED in the charge indicator light up) before storing for extended periods.
Check the battery pack charge about every 3 months when storing for extended periods. Recharge as necessary.

Transportation

Switch the product off.

Transport the product in its carrying case 20.
- Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles.
Secure the product to prevent it from slipping or falling over.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1 - 7: plastics / 20 - 22: paper and fibreboard / 80 - 98: composite materials

The product and packaging materials are recyclable, dispose of it separately for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries / rechargeable batteries!

Before disposal: Remove the battery pack from the product.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 5 years from the date of purchase. Should this product show any fault in materials or manufacture within 5 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

The warranty for the battery pack is 1 year from the date of purchase.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (e.g. IAN 123456_7890) available as proof of purchase.

You will find the item number on the type plate, an engraving on the front page of the instructions (bottom left), or as a sticker on the rear or bottom of the appliance.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., {peak})

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

C

EC declaration of conformity

EC DECLARATION OF CONFORMITY

IAN:

322688

Product identification:

CORDLESS MULTI-PURPOSE TOOL 20V

Model Number:

HG05467

The object of the declaration described above is in conformity with the relevant Community harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2014/35/EU

Directive 2011/65/EU

References to the relevant harmonised standards used or references to the specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 62841-1:2015

EN 62841-2-4:2014

EN ISO 12100:2010

Directive 2014/30/EU

EN 55014-1:2006/A2:2011

EN 55014-2:1997/A2:2008

EN 61000-3-2:2014

EN 61000-3-3:2013

Directive 2014/35/EU

EN 60335-1:2012/A13:2017

EN 60335-2-29:2004/A11:2018

EN 62233:2008

Directive 2011/65/EU

EN 50581:2012-09

Additional information - Further related standards:

N°/Parts

EN 55014-1:2017

EN 55014-2:2015

Name and address of the manufacturer:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Original declaration of conformity

WAARSCHUWING! BRANDGEVAAR!

Akumulator: Akumulator Parkside 20 V: PAP 20 A1, PAP 20 A2, PAP 20 A3

tadowarka: tadowarka Parkside 20 V: PLG 20 A1, PLG 20 A2, PLG 20 B1, PLG 20 A3

Obstuga

DEKLARACJA ZGODNOSCICI WE

IAN: 322688

Okreslenie wyrobu: AKUMULATOROWE NARZEDZIE WIELOFUNKCYJNE 20 V Model Number: HG05467

Rychlonabiječka PLG 20 B1

Vstup:

Jmenovite napeti: 230-240 V~

Jmenovita frekvence: 50 Hz

Jmenovity vykon: 120 W

Vystup:

Akumulator: Parkside 20 V akumulator
PAP 20 A1, PAP 20 A2,
PAP 20 A3

Nabijačka: Parkside 20 V nabijačka PLG 20 A1, PLG 20 A2, PLG 20 B1, PLG 20 A3

Obsluha

Vybratie/vlozenie umulatóra
