Brand	Bosch
Model	CompactPower MFW3X18B
Product type	Multifunction meat grinder
Power supply	Mains 220-240 V, 50/60 Hz
Power	500 W (estimated)
Speeds	2 speeds (slow/fast) + reverse function
Bowl capacity	Not specified
Functions	Grinding, mixing, sausage making, grating, slicing, citrus juicing, cereal milling, fruit pressing
Included accessories	Meat grinder, sausage attachment, slicing attachment (3 inserts), citrus juicer, cereal mill, fruit press, pusher, cleaning brush
Perforated discs	Fine (2.7 mm), medium (4 mm), coarse (8 mm)
Care and cleaning	Clean after each use; hand-washable parts (not dishwasher safe); dry metal parts immediately; lightly oil
Safety features	Lock button, reverse function, overload protection, do not touch blades, use pusher
Repairability	Spare parts available: perforated discs, accessories; repair by authorized service center
Certifications	WEEE Directive 2012/19/EU
Warranty	According to manufacturer's conditions
Weight	Approx. 3.5 kg (estimated)
Dimensions (L x W x H)	Approx. 25 x 20 x 30 cm (estimated)
Control type	Push buttons with operation indicator
Product code	MFW3X18B

Frequently Asked Questions - CompactPower MFW3X18B BOSCH

How to assemble the meat grinder?

Insert the auger into the housing, place the blade and the desired perforated disc, then screw on the ring. Make sure the pusher is ready. For more details, see the section Preparing the meat grinder in the manual.

How to use the reverse function?

Turn off the appliance with the O/I button and wait for it to stop completely. Press and hold the 1-2|rev button for 5 to 10 seconds until the auger rotates in reverse. Release the button and wait for it to stop. This function is used to unblock stuck food. Do not use it with the cereal mill or fruit press.

Can I wash the parts in the dishwasher?

No, never wash the parts in the dishwasher. Wash them by hand with warm water and dish soap, then dry them thoroughly. Metal parts must be dried immediately and lightly oiled to prevent rust.

What types of meat can I grind?

You can grind raw or cooked meat (beef, pork, poultry, fish), lard, and hard vegetables like carrots. Remove bones, tendons, and hard parts. Cut meat into pieces suitable for the filling opening.

How to prevent food from clogging the grinder?

Cut food into small pieces, do not force with the pusher, and use the appropriate speed. If a blockage occurs, use the reverse function or disassemble the accessory to clean it.

What is the maximum continuous operating time?

Do not run the appliance for more than 15 minutes continuously. Then let it cool down for at least 45 minutes at room temperature.

How to change the speed?

Briefly press the 1-2|rev button to switch from speed 2 (fast) to speed 1 (slow) and vice versa. Some accessories require speed 1 (slow) for slicing/cutting inserts.

Can the cereal mill grind coffee?

Yes, the cereal mill can grind coffee beans, pepper, spices, cereals, flax seeds, etc. Select the appropriate grinding degree with the adjustment ring. Do not use it for very oily products with fine adjustment.

How to maintain the metal parts?

After cleaning, dry the blades and metal discs immediately. Apply a thin layer of food-grade oil to prevent rust. Store them in a dry place.

Where can I find spare parts?

Spare parts (perforated discs, accessories) are available from Bosch customer service or at www.bosch-home.com. Refer to the part numbers listed in the manual.

USER MANUAL CompactPower MFW3X18B BOSCH

CompactPower Meat mincer

MFW39... MFW3X...

[de] Gebrauchsanleitung Fleischwolf 3 [en] Instruction manual Meat mincer 18 [fr]Mode d'emploi Hachoir 32 [i] Istruzioni per l'uso Tritacarne 47 [nl] Gebruiksaanwijzing Vleesmolen 61 [da] Brugsanvising Kødhakker 76 [no] Bruksanvising Kjøttkvern 89 [sv] Bruksanvising Kottkvarn 102 [fi] Käytöohje Lihamylly 116 [es] Instrucciones de uso Picador de carne 130 [pt] Instruções de service Picadora de carne 146 [el] O8nyiec xpnong EApTma yia kiopa 161 [tr] Kullanim kilavuzu Et parcalama makinesi 178 [p] Instrukcja obstugi Maszynka do mięsa 195 [uk]IHCTpykui3ekcnayataui M'acopy6ka 211 [ru]Инстукшипоэкпayataци Мссорубka 226 [ar] pdswI I sI J 259

Read and follow the operating instructions and keep them for later reference. Enclose these instructions when passing this appliance to someone else.

If the instructions for correct use of the appliance are not followed, the manufacturer's liability for any resulting damage is excluded.

This appliance is intended for domestic use for processing normal quantities of food for household purposes. The appliance and accessories (depending on model) are suitable for the following purposes:

Meat mincer: for cutting and mixing raw meat, poultry, and fish.

Sausage filler: for making sausages and meat mixtures. Shredding attachment: for shredding and grating. Citrus press: for squeezing juice out of citrus fruits. Grain mill: for grinding all types of grain, e.g., poppy seeds, linseeds, sesame, buckwheat, spices, and coffee.

Fruit press: for squeezing juice out of fruit such as raspberries, currants, strawberries, gooseberries, and tomatoes.

Food which is to be processed must not contain hard components (e.g., bones). The appliance should not be used for processing other substances or objects. Additional uses are possible if the accessories approved by the manufacturer are used. Use the appliance only with genuine parts. Never use the attachments or slicing/shredding discs with other appliances. Only use matching parts for the appliance. Only use the appliance indoors at room temperature and at altitudes up to 2000 m above sea level. Do not place the appliance on hot surfaces, e.g., hobs.

Your work surface should be easily accessible, firm, flat, dry, and large enough to prevent accidents and to let you work unhindered.

This appliance can be used by persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance and if they understand the hazards involved. Keep children away from the appliance and its cord, and do not allow them to use the appliance.

Children must not play with the appliance. Cleaning and user maintenance must not be performed by children.

Safety instructions

Danger of electric shock and fire

Connect and operate the appliance only according to the plate specifications. Do not use if the main cable shows any signs of damage. To avoid potential hazards, such as replacing a damaged cable, must only be done by our customer service personnel. Never connect the appliance to timer switches or remote-controllable sockets. Do not leave the appliance unattended while it is switched on. Ensure the appliance is never switched on for longer than necessary to process the ingredients.

The mains cable must not come into contact with hot parts or be pulled across sharp edges. Never immerse the appliance in water or place it in the dishwasher. Do not steam-clean the appliance. Do not use the appliance with damp hands and do not touch the plug with wet hands. The appliance must always be disconnected from the mains after each use, whenever the appliance is unattended, before disassembly or cleaning, and in the event of a fault.

Risk of injury

Immediately after using the appliance, wait for it to cool down before fitting or replacing attachments. The appliance must be switched off and disconnected from the mains.

Do not grasp the sharp blades and edges of the slicing inserts.

Keep hands clear of rotating parts. Never reach into the feed tube or outlet opening. Never put the food to be processed into the chute with your hands. Only use the pusher provided. Never clean the sharp blades and edges of the slicing inserts with your bare hands. Clean them with a brush.

Caution! Risk of damaging the appliance

Check that there are no foreign objects in the attachments. Do not poke objects (e.g. knife, spoon) into the chute or outlet opening.

Before changing the direction of rotation (reverse), wait until the drive has come to a complete standstill. On each use, let the appliance run uninterrupted for a maximum of 10 minutes, then allow it to cool down to room temperature.

Important!

It is essential to clean the appliance as described in the instructions, especially before first use or after it has not been used for an extended period. See "Daily cleaning" on page 27.

Congratulations on the purchase of your new Bosch appliance.

On the following pages of these instructions you will find important information for safe use of this appliance. We request that you read these instructions carefully and observe them. This ensures you will enjoy this appliance for a long time. The results will confirm your choice. Retain these operating instructions for subsequent use or for the next owner. You can find further information about our products on our website.

Content

Intended use.. Safety instructions 3

Overview. Before using for the first time. Control and display elements. Overload protection. Speed setting.

Reversing function. Base unit. Base attachment.

Shredding attachment. Citrus press attachment.

Grain mill attachment. Care and daily cleaning.

Recipes. Tips.

Disposal. Guarantee. Spare parts and accessories.

Troubleshooting.

Threaded ring.

Blade. Perforated disc; medium. Perforated disc; coarse.

Sausage filter insert. Bearing ring. Sausage filter nozzle.

Fig. C. Shredding attachment.

Housing. Feed chute.

Collecting tray. Filter insert. Pressing cone. Driving shaft with spring.

Grain mill attachment*.

Housing.

b Feed chute

c Filling tray

d Worm gear

e Grinding ring

f Grinding cone

Grinding chamber

h Setting ring

i Adjustment screw with j Threaded ring

8 Fruit press attachment*

Use filling tray and pusher attachment.

a Housing

b Feed chute

c Worm gear with sealing r

d Filter inserts: fine (1)

e Filter holder with seal i

f Threaded ring

g Outlet funnel

h Pulp nozzle (adjustable)

i Hook for removing the filter

j Cleaning brush

• depending on the model

The operating instructions for the models of the appliance are provided on the pages with figures. Fig.

Spare parts and accessories available from Customer Service

www.bosch-home.com. → "Spare parts and accessories" see page 30

Before using for the first time

Before the new appliance can be used, it must be fully unpacked, cleaned, and checked.

Caution!

Never operate a damaged appliance.

Remove the base unit and all

accessories from the packaging

Remove the packaging material present.

order, as described under , P

Check all parts for complete

Fig. A / C

1）8 nseperote a(2) parts for visible

ing thoroughly clean and dry allbefore using for the first time

→ "Care and daily cleaning" see

page 27

filter insert

Control and display

e le ments

MFW39

Button I

Press button I to switch on thethe drive will start up at oncevice or at

Button O

Press button O to switch off the drive. The drive stops.

Button O/I

Press button O/I to switch on the drive. The drive starts running immediately at speed 2 (fast). Press button O to switch off the appliance. The drive stops.

Button 1-2 | rev

Pressing button 1-2|rev briefly switches the speed of the appliance between 1 (slow) and 2 (fast). See "Speed setting" on page 22.

Pressing and holding button 1-2 starts the reversing function.

See "Reversing function" on page 22.

Operation indicator

The operation indicator lights up when the appliance is switched on. When the reversing function is active, the indicator flashes for as long as the button is pressed.

Release button

Press the release button to detach the attachment fitted on the appliance. When the release button is pressed, it is possible to turn the attachment and remove it from the base.

Cable storage compartment

The mains cable can be pulled out of the cable storage compartment again. Only ever pull out as much as is required.

Storage compartment

Unused perforated discs for the meat mincer can be kept in a compartment and it can be closed with a lid.

Overload protection

To prevent serious damage to the appliance if the base is overloaded, the agitator has a predetermined breaking point. If overloading occurs, the agitator will break at this point. A replacement paddle is available from Customer Service (No. 10005188). The predetermined breaking point is not covered by our warranty obligations.

Replace agitator paddle → Fig. 3

1. Release the screw in the faulty paddle with a screwdriver (PH2).
2. Fit a new agitator paddle again.

Speed setting

ONLY MFW3X.

The speed setting feature can be set to 1 (slow) or 2 (fast). The function indicator lights up when the setting is active.

Caution! Button is

For certain applications, it is recommended to use speed 1 (slow). Take note of the recommended speeds! See Fig. ...

Switch on the appliance with the power switch. The appliance will run at the selected speed. Press switch 1-2 | rev briefly. The appliance will switch to speed 2. Press button 1-2 | rev briefly. The appliance will switch back to the previous speed.

Reversing function

The reversing function is designed to release food that has got stuck in the storage of the worm gear in reversing. The cover switches off after 15 seconds.

Caution!

Never use the reverse function with the grain mill attachment or the ddl attachment! Never press and hold button at or piddle contpundusly while the appliance is switched on. Only press and let stome rton 1-2 rev continuously one part with appliance has come to a compl i n t are not Switch the appliance off with gathons wait until the drive has Press and hold button 1-2|rev After approx. 5-10 seconds, the button 1-2 and wait for the and come to a stand still. Switch the appliance on again e but ton o/1 tight

Note: If food that has got stuck is not released by briefly putting the reverse, switch the appliance off and clean it. → “Care and daily cleaning see page 27

Base unit

Preparation

Risk of injury!

Do not insert the mains plug until preparations for working are complete and the required attachments are assembled correctly and the base unit.

Place the base unit on a work surface.

Pull the mains cable out of the storage compartment to the required length.

The base unit is now prepared.

1. Fit the threaded ring onto and screw tight in a clockwise direction without using force. The meat mincer is now prepared.

Preparation for sausage filling

With the appliance switched off, insert the worm gear with the connected paddle at the front in the hopper. First fit the bearing ring gear and then the sausage nozzle. The sausage filler is now prepared.

Base attachment

The base attachment can be used for the following applications:

Meat mincer

For chopping up raw or cooked meat, using the appropriate perforated disc depending on the type and consistency

to be processed. See "Tips" on page 28

Sausage filler

For filling artificial and natural casings with the pusher when adding sausage meat. For producing meal rolls.

Note: Other applications are possible. Caution!

When using the base attachment and appropriate accessories available from Customer Service, process bones, grist, and solid components.

Service.

Caution!

When assembling the different individual parts, make sure that the notched fittings on the prepared attachment match up with the reference unit, holding it

parts, make sure that the notched fit matches the prepared attachment on the inserts, aligning them with the reference unit while holding it.

Preparation for meat

Preparation for meat

Risk of injury!

Do not reach into the sharp

Caution!

Always only use one perfora

→ Fig. D

1. Insert the worm gear with paddle at the front in the house, since the mains plug. Swi
2. First fit the knife and then the required perforated disc onto the worm gear.

Note (MFW3X. . .):

Caution! (MFW3X..)

After switching on, the appliance always uses the shredding insert at an ideal speed 2 (fast). inserts at speed 1 (slow).

1. Use the pusher to slide the food grating insert at the feed chute, applying light pressure. "Speed setting" see page 22
2. Once you have finished, switch off the

appliance and pull out the main plug. prepared attachment

Remove the filling tray and the base unit, holding

1. Hold down the release button and turn the

attachment clockwise until it clicks into position and then turn it anticlockwise to release

Remove the attachment, take it apart, and clean all parts. → "Care and daily cleaning" see page 27 in the feed chute.

Shredding attachment

Prepare your food. Chop it up beforehand so it fits into

For shredding, grating, and slicing without having to press, such as cheese, fruit, vegetables, nuts, suitable container, almonds, dried bread rolls, and cooked food. Add the prepared foodstuffs. Select the appropriate tray.

depending on the type and consistency of the mains plug. Switch the food to be processed. → "Tips."

page 28

Caution! (MFW3X..)

Preparation

After switching on, the appliance runs at speed 2 (fast). To use the shredding cutting inserts, you must press the button to switch to speed 1. "Speed setting" see page 22

Risk of Injury!

Do not reach into the sharp edges of the shredding, grating inserts.

1. Use the pusher to slide the food into the feed chute, applying light pressure. The food is now cut up or shredded.

→ Fig. 6

1. Open the cap. Fit the required insert into the housing, switch the appliance on and pull out the map.
2. Close the cap until you hear it click into the map position. 9. Remove the filling tray and turn the attachment clockwise. The shredding attachment is now prepared to disengage.
3. Remove the attachment, take it apart and clean all parts. → "Care and cleaning" see page 27
4. Do not reach into the feed chute with your hands.
5. Only use the pusher when adding more food.

Caution!

• The pusher can only be inserted in one direction.
• Remove hard shells (e.g. on nuts).
• Do not apply great force with the pusher.

Citrus press attachment! (MFW3X...)

After switching on, the appliance must press button 1-2|rev once to

Preparation

△ Risk of injury!

The attachment for the citrus press is placed on the press directly assembled on the base and press down. As soon as the insert is in place, plug in the mains plug until all preparations for working with the appliance are complete, then the cone will rotate.

Caution!

The base unit is moved through pressure on the cone. Preparation and use of the citrus press. When you have finished, switch off the attachment. Never use other attachments and pull out the plug in this position. 7 Hold down the release button

Fig.

1. Hold the base unit by the base.

handle and carefully tip up. Remove the attachment, take drive points upwards. Possibly remove all parts. See "Care and cleaning" on page 27

accessible.

1. Insert the driving shaft with the largest amount element pointing down in the base unit. The pressing procedure should be repeated a few times.

Caution!

It should be possible to push the output shaft down lightly with your finger. It must

not get sticky with residue or become blocked with pips or

1. Fit the collecting tray at an angle.
2. Turn the collecting tray until you hear it click into position.
3. Fit the filter insert on.
4. Fit the pressing cone on the shaft.

The citrus press attachment is now on the base unit and prepared.

Remove any foreign bodies from the attachment.

For grinding products such as oats, rice, coffee beans, pepper

with hard shells, walnuts, hazelnuts, mushrooms, almonds, soya, linseed

buckwheat groats, shelled sunflower seeds

to the drive used for grinding very hard products

such as wheat, maize, or popcorn (see page 28)

Use

Fig. 1

1. Cut the citrus fruits in half, place the adjustment screw
2. Place a suitable container under the attachment.
3. Connect the mains plug. Switch on the appliance. The drive is running in a clockwise direction. Adjust the screw for the grinding level.

Fruit press attachment

1. Insert worm gear into the housing. Connect the mains plug. Switch on.
2. Insert grinding ring into the housing.

Note the shape of the parts! Caution!

1. Insert the grinding cone with the appearance may be operated shaft into the corresponding opening or a maximum of the worm gear. Then leave the appliance to cook.
2. Place the grinding chamber on the house.

The recess on the grinding chamber must be situated on the lug on the house.

1. Fit the threaded ring onto the degree of grinding can be and screw tight in the clockwise steps during operation direction without using force...

Caution! Use Setting

Risk of injury!

Do not reach into the feed chute with your hands. Remove the filling tray. Do not look into the feed chute during the filling tray. Operation, as the bouncing particles can turn the attachment clockwise hurt your eye. Disengages.

Caution! 12. Remove the attachment, take when the mill is attached, never and use eave parts. See "Care and function. Attachment may be damage" on page 27.

See Fig.

1. Fit the prepared attachment fruitopness attachmen drive of the base unit, ho ding jit atangjuice out of fruit angle.e g raspberries currants
2. Turn the attachment anticlockwise until you hear it click into position. Tighten threaded ring. Preparation
3. Fit the filling tray.
4. Place a suitable container under the litter for attachment. Fill the filling tray to "Tips" content of fruit, see page 28.

Caution!

Never allow the grain mill attachment to run without ingredients.

1. Set the degree of grinding by turning the filter holder setting ring: gear If not insert them into
2. anticlockwise = coarser grain
3. electronic = finer grain
4. grooves of these parts.
5. clockwise = finer grain 1. Insert the filter insert into Al ways select a value between and press it into place. STOP = see correct degree of
6. STOP - coarsest degree of grinding
7. 1 = finest degree of grinding (never insert the worm gear into the filter holder in

use it at the beginning) Lug on the filter holder mus STOP in the recess on the housing

1. Fit the threaded ring on a t Adj unsotust pulp nozzle. Unscrew tight in the clock makes the pulp more moist; side direction without using for cien makes it dryer and more j
2. Place the outlet funnel on top of the funnel. If the pulp holder until it audiably clicks some words, then use a needle to avoid
3. Screw the pulp nozzle into the helappahender with the pulp.

The fruit press attachment is no one epcaur erdave finished, swi

Use

Warning

Risk of Injury!

Do not reach into the feed chudesongageour hands. Remove the

Caution!

• Remove hard fruit peel, pi p i e a n i ng s e t p a g k s 27
• Berries such as e.g. curants to remove the filter insert pressed together with their hooks into the hole in the fil
• Fruit with larger pips and cariesluyertract.

e.g. plums and cherries muGatuthiaone! their pips or stones removed befRarye sjpuicaiang.g.attention to the ju - Do not process frozen frapi bcess. Make sure filter openi - Do not apply great forcecWooggedheCbaggeng of the housin

→ Fig. N

with the pulp of juicy fruits

1. Fit the prepared attachmenod ng qthe drive unit.

drive of the base unit, holfditthe ihousin outlet becomes o angle. switch off the appliance and put

Turn the attachment anti-clockwise until you hear it click into position and tighten all parts. See page 27 for cleaning the threaded ring.

1. Fit the filling tray and insert the pusher in the feed chute.

Prepare the fruit. Chop the apple and set all attachments beforehand so it fits into the chute without having to be placed in a container each use.

1. Prepare the fruit. Chop the apple and set all attachments beforehand so it fits into the chute without having to be placed in a container each use.
2. Remove larger pips and stones (e.g. cherries, plums). Risk of electric shock! Disconnect the mains cable.
3. Place one container under each of the apertures for juice and for the pulp prior to cleaning. Do not immerse the base unit in water. Add the prepared fruit to the filling tray and do not clean in the dishwasher.
4. Connect the mains plug. Switch on the

appliance.

1. Use the pusher to slide the fruit down into the feed chute, applying pressure to the shredding disc. Do not reach down into the sharp blades.
2. The pressed juice flows into the container. Clean with a brush.

the outlet funnel. The pulp (solid components) is pressed through the pulp nozzle.

Caution!

• Do not wash metal parts in the dishwasher for more than 60 seconds! (perforated disc, medium).
• Do not use any cleaning agent containing alcohol or spirit, and the finely chopped onion and melted butter and mix.
• Do not use any sharp, pointed objects. Add the eggs, salt, and mix into the bread dough.
• Do not use abrasive cloths.
• Use cleaning agents to prove for agents.
• Minutes. Then knead again.

Fig. ⑥ gives an overview of how to shape the dumplings with wet hands. Roll the dumplings in flour.

■ Wipe the outside of the base with a soft, damp cloth and dry off. Place dumplings in boiling water, leave to simmer for approx. 2 minutes. ■ Dismantle the attachments used, then bring to the boil!

Reverse order (see "Preparation" for the relevant attachment). Tips: Clean all accessories with a detergent solution and a soft cloth/Meat grinder.

a soft brush.

■ Allow all parts to dry.

Notes:

• Immediately rub metal parts, and cooked fish for soups; apply a little cooking oil to protect meatloaf; raw liver from rust. bacon for liverwurst; pork for
• Discolouration of plastic parts may occur when processing foods such as raw beef for pâté and similar. This can be removed in a few ways, such as using

cooking oil.

Recipes

Note (MFW3X. . .):

For all operating steps, set to 2 (fast).

Bread dumplings

• 300 g fresh white bread - 20 ml milk
• 40 g butter or margarine
• 3 eggs
• 1 tbsp finely chopped onions. Soak natural casing in lukewarm water
• Parsley
• A little flour
• Salt and pepper. Cut the bread into slices 10 mm thick and halve lengthways. Add 20 ml of milk and soak. Soak natural casing in lukewarm water for about 10 minutes before use. Do not stuff casings too full, as sausages may burst during boiling.

Using the perforated discs

• Perforated disc, fine (2.7): cooked chicken / pork / beef, liver, and cooked fish for soups; beef for meatloaf; raw liver, bacon for liverwurst; pork for pâté and similar. Some parts may occur, and beef for pâté and a few sausages of
• Perforated disc, coarse (8 mm): for roast pork, goulash soup; (joint, sausage) for bakes. If you require a finer consistency for processed food, process it through the different perforated discs one after the other (coarse, medium). You can add other ingredients (e.g. onions, spices) directly during processing. This ensures all are mixed together thoroughly.

Sausage filler

Shredding attachment

Caution! (MFW3X..)

• Always use the shredding inserts at speed 1 (slow).
• Use the grating insert a → "Speed setting" see page 22

Using the inserts

• Slicing insert: for carrots, kohlrabi, courgettes
• Shredding insert (coarse): for nuts, hard cheese (e.g. Emmental)
• Shredding insert (fine): for nuts, hard cheese, Parmesan cheese
• Grating insert: for potatoes, Parmesan cheese, nuts

Guarantee

The guarantee conditions are as defined by our representative in the country in which it is sold. Details regarding

these conditions can be obtained from

the dealer from whom the appliance was purchased. The bill of sale or receipt must

be produced when making any claim under the terms of this guarantee.

Grain mill attachment

• Do not grind oleaginous products at the smallest degree of grinding. The grinder may jam or become blocked.
• In the case of softer grain, such as oats or linseeds, the coarse setting must be selected for grinding.
• Wash the grinder thoroughly when changing from one product to another. This will prevent odours from impairing each other.

Disposal

Dispose of packaging in an environmentally-friendly manner. This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU. Please ask your specialist retailer about current disposal facilities.

Spare parts and accessories

Spare parts and accessories
2.7 mm	10003879	Perforated disc (fine) for meat mincer
4 mm	10003880	Perforated disc (medium) for meat mincer
8 mm	10003881	Perforated disc (coarse) for meat mincer
	00754389	Sausage filler: for filling artificial and natural casings with sausage meat. For producing meat rolls.
	10007189
	12011263	Shredding attachment: for shredding, grating and slicing
	798161	Slicing insert for the shredding attachment
	798162	Shredding insert (coarse) for the shredding attachment
	798160	Shredding insert (fine) for the shredding attachment
	798130	Grating insert for the shredding attachment
	12013990	Citrus press attachment: for squeezing oranges, lemons and grapefruits.
	00578107	Grain mill attachment: for grinding products such as wheat, oats, rice, coffee beans, peppercorns, wild mustard, walnuts, hazel nuts, dried mushrooms, almonds, soya, linseeds, buckwheat groats, shelled sunflower seeds, etc.
	00578112	Fruit press attachment: for squeezing juice out of fruits such as e.g. raspberries, currants, strawberries, gooseberries or grapes and tomatoes.

Spare parts and accessories are available from retailers and Customer Service.

Troubleshooting

Problem Cause Remedy

The appliance does not have power. The mains plug is not inserted. Switch the appliance on.

The appliance is overloaded. Switch the appliance off and wait until it has stopped. Unplug the appliance, remove the attachment, take it apart and clean. The agitator paddle has broken at the predetermined break point. → "Overload protection" see page 22

The food is not being processed or only processed slowly. The attachment is blocked. Switch appliance off, wait until it has stopped, unplug. Remove the attachment, take it apart and clean to remove the blockage. → "Care and daily cleaning" see page 27

Appliances with reversing function: Switch off the appliance with button O/I and wait for drive to come to a standstill. Press and hold button 1-2|rev. After approx. 5-10 seconds, release button 1-2|rev and wait for drive to come to a standstill. Switch the appliance on again and continue to use it. → "Reversing function" see page 22

The pressure on the pusher is too great. Reduce the pressure on the pusher and fill the feed chute with less food.

The food to be processed still contains hard components. Pre-cook/steam vegetables before processing them.

The reversing function does not start. Button 1-2|rev was pressed too briefly. Press and hold button 1-2|rev until the reversing function starts.

The worm gear is blocked. Switch the appliance off, wait until it has stopped, remove the attachment, take apart and clean to eliminate blockage. → "Care and daily cleaning" see page 27

If you are unable to solve the problem, always call the Customer Service. You will find the telephone numbers at the back of the manual.

2 Basic accessories

a Housing

b Filling opening

c Funnel

d Pusher

Storage compartment

Assembly (MFW3X...):

Place the grinding chamber on the housing's nose.

To be noted

If the adjusting ring is turned

during operation, the fruit press attachment

STOP line, there may be larger pits or damage to the appliance, such as plums and cherries.

Let dry grains, nuts, hazelnuts, dried mushrooms, almonds, soybeans.

flaxseed, buckwheat, sunflower seeds. The unit should be stored at a low temperature.

and electronic equipment - WEEE)

March 10095188).Los repectos c

μa μaa) prspscgeto no entran den t epa aigacienes de garantia.

• Remove hard skins and stems from fruits.
• Berries such as, e.g.,

Attention! (MFW3X...)

The manufacturer reserves the right to make changes.

Appliance description. For instructions, see

The figure is for reference only. Fig.

Spare parts and accessories

are available from customer service.

ALL RIGHTS RESERVED. CUSTOMER SERVICE

www.bosch-home.com/tr

www.bosch-yetkiliservisi.com

Kobacn Wnpu: Iy BnroTOBHeHry KOb6aCOK Ta pyneTIB.

Hacadka-Tepka:ДлЯшатkyBaHHЯ,Тeртя i Hapi3aHHЯ npOdyKTiB.

HacaKa-COKOBNTnCKaJ DJIa CHTpyCOBnx:ДЯ BNUaBIOBaHHaCHTpyCOBnxФpyKtIb.

MlnHok:ДЯ MOnOTTЯ 6yDb-ЯKnx COptiB 3epHOBnX KylbTyp (KpIM KyKpyd3N), a TAKOX MaKy, HacIHnY JbOHy, KYNKytU, rpeuKn, npraHoUsiB i KaBN.

BukopncToByTe npnad Inwe BCEpeDnHi npmiiHb npi KIMHaTHi TeMnepatypi Ha BnCoTI He Bnue 2000 M naD pIBhem Mopra. He cTaBte npnad Ha rapayi nobepxhi a6o no6Jn3y ix, Hanp., Ha nnity.

Mn npocmo Bac yBaJHo npouHtN daHy iHCTpyKciIO Ta doTpmyBaTncr BCix Bka3iBOK.

TakIM YINOM, Bn 3MOXeTe DOBRO HACOJOD- KyBaTnCSa NM npNJaDom, a pe3yNbTaTN Ioro po6OTn cTAHyTn DOKa3OM TORO, IIO npN POKyni Bn 3p06nI npaBnHn Bn6ip.

36epiraTe iHCTpyKciIO 3 ekcnnyatauii IJIaIi3HIoKOpncTyBaHHa6O IJIa HAcTynHOro BJaCHnKa npIJaY.

IodatkoBy iHopmaio npo hauy npOdykuio Bn 3naideTe Ha haui ctopinB IHTepneti.

3mict

BnKOpncTaHHa npu3HaueHHaM

IpaBnIaTexHikn6e3neKn

CTnCnn orJd

IpeepnepuMBNkOpncTaHHaM 1

Control elements and indicators

Protection against overload

Speed control

Reverse function of the main unit

Base station

Charging station

Nozzle for pipes 1

1. Nozzle-min.

Nozzle for floors and carpets . . . . . . .

Accessories

Recipes

Tips

Utilization

Warranty conditions

Spare parts list

Control panel

Figure A

1 Main unit

a Attachment hole b Button I or O/L* c Button O d 1-2 | rev* e Operating indicator f Lock button g Handle for storage with hook h Power cord i Cord hook

2 Base attachment

a Body b Brake c Locking button d Cover e Locking catch f Ring

3 Insert-disc

a Blade b Perforated disc with fine holes (2.7 mm)* c Perforated disc with medium holes (4 mm) d Perforated disc with large holes (8 mm)

4 Insert-sausage filler

a Support b Sausage filler nozzle

Figure C

Never use the appliance

Warning!

■ Remove the main unit and all accessories from the packaging. Remove the packaging material.

Control indicator element

■ Disassemble the selected parts into separate components. Follow the reverse order as described in the «Preparation» section. ■ Check all parts for completeness.

→ Figure A / C

■ Carefully check all parts for damage. ■ Before first use, thoroughly clean and dry all parts. → «Care and maintenance» see page 221

Control indicator element

MFW39. . .

Button I

Pressing the button briefly turns the device on. The drive starts slowly.

Button O

Pressing the button briefly turns the device off. The drive stops.

MFW3X. .

Button O/I

Pressing the button O/I briefly turns the device on. The drive starts slowly at speed 2 (slow).

Pressing the button O/I again turns the device off. The drive stops.

Button 1-2 | rev

Brief pressing of button 1-2 | rev changes the speed by 31 (full) to 2 (soft) or vice versa. → «Speed adjustment» see page 215

As a result of pressing button 1-2 | rev, the device starts

reversing. → «Reversing function» see page 216

All models

Operating status indicator

The operating status indicator lights up when the device is turned on. In models with the reversing function, the function indicator blinks while button 1-2 | rev is pressed.

Lock button

Pressing the lock button unlocks the attachment installed on the drive shaft. To turn the attachment counterclockwise and remove it from the main block of the drive, you can only after pressing the lock button.

Cable hook

The cable can be pulled out of the cable hook or wound back. When pulling, pull the cable only to the required length.

Storage hook

Unnecessary wound cables can be placed on the storage hook and closed with the hook.

Overload protection

To prevent damage to the tool and the base attachment in case of overload, the attachment is made with a breaking point (marked with a groove). In case of overload, the breaking point breaks in its place. A new breaking point can be purchased at the service center (No 10005188). The warranty obligations do not apply to the spare part with the marked groove.

Replacing the breaking point

→ Figure B

1. Unscrew the screw from the lock using the appropriate screwdriver (PH2) and remove the damaged lock.
2. Insert the new lock and tighten it.

Speed adjustment

FOR MFW3X ONLY...

The speed adjustment allows you to set the required rotation speed: 1 (low) or 2 (high).

Warning!

For certain situations, use the required speed 1 (low). Consider the recommended speed!

Do not touch the sharp blade.

Warning!

Always use only one pre-formed disc.

→ Figure D

1. First insert the auger with the lock into the housing.
2. Slide the disc onto the auger, then the desired pre-formed disc.
3. Install the screw ring on the housing and tighten it clockwise without excessive force.

The meat grinder is ready for operation.

Preparing the sausage attachment

→ Figure E

1. First, insert the auger into the housing with the locking mechanism.
2. First, put the support rings on the auger, then insert the sausage nozzle into the housing.
3. Install the threaded ring on the housing and tighten it by turning it clockwise without excessive force.

The sausage attachment is ready for operation.

Application

Note: Depending on the purpose of use, the products are processed differently.

→ "Recipes" see page 222

Examples of application

of the basic attachment as a meat grinder:

Danger of injury!

Do not put your hands into the feed opening. - For continuous operation, use the pusher.

Carefully!

• Treat the brush, wipe, and tendons with any hard composition.
• Treat frozen meat with the treatment.
• Do not press on the surface too hard.

→ Accessories F

1. Install the prepared nozzle with the tip on the drive of the main unit.
2. Turn the nozzle clockwise until it clicks into place with a characteristic sound.
3. Install the loading chute and insert the food pusher.

4. Prepare the products. Cut them into large pieces so that they pass through the chute without pressing. Place a bowl under the nozzle. Put the prepared products into the loading chute. 5. Insert the plug into the socket. Turn on the device.

Indicator (MFW3X...)

After turning on, the device starts at optimal speed 2 (speed).

1. Lightly push, push the processed products with the pusher into the chute.
2. After finishing the work, turn off the device and disconnect it from the power supply.

Remove the loading chute and the pusher.

1. Press the fixation button, turn the nozzle counterclockwise until it releases. Remove the nozzle, disassemble it and clean all parts. → "Care and Cleaning" see p. 221

Шаткува на за干嘛ka

For chopping, grating and slicing hard products such as cheese, fruits, vegetables, nuts and other foods, depending on the consistency of the processed product, use the appropriate insert. → See "Tips" on page 222

Preparation

Safety during use!

Do not touch the sharp knives and edges of the chopping and slicing inserts, as well as the grating inserts.

→ For small quantities

1. Remove the lid. Install the insert into the bowl.
2. Close the lid so that it clicks into place with a characteristic sound. The chopping attachment is ready for use.

Application

Safety during use!

Do not insert into the neck. - For processing, switch off the appliance completely.

Attention!

• The inserts can only be inserted in one direction. Remove hard cores or stones (e.g., from nuts).
• Do not press on the inserts too hard.

Attention! (MFW3X...)

• The chopping and slicing inserts can only be used at speed 1 (low). The grating insert should be used at speed 2 (medium).

→ «Adjusting the consistency» see p. 215

→ Under the small bowl

1. Install the prepared nozzle on the drive of the main block.
2. Turn the nozzle clockwise until it clicks into place with a characteristic sound.
3. Install the loading bowl and insert the pusher into the feed tube. 4. Prepare the products. Cut large pieces so that they fit into the feed tube without pressing.
4. Place a suitable container under the nozzle. Put the prepared products into the loading bowl.
5. Insert the plug into the socket. Turn on the appliance.

Attention! (MFG3X...)

When the appliance is turned on, it operates at speed 2 (fast). To use the pusher with the attachments, you must press the button 1-2 times. The appliance will switch to speed 1 (slow). → «Adjusting the consistency» see p. 215

1. Pressing lightly, push the chopped products through the feed tube into the bowl. The products are chopped or pureed.
2. When finished, turn off the appliance and disconnect it from the power supply.
3. Remove the loading bowl and the pusher.
4. While holding the locking button pressed, turn the nozzle counterclockwise until it releases.
5. Remove the nozzle, disassemble it and wash all parts. → «Cleaning and maintenance» see p. 221

Nozzle for citrus fruits

For extracting juice from 3 citrus fruits, for example lemons, oranges, and grapefruits.

Fruit preparation

Danger of injury!

Attach the citrus press attachment directly to the main unit. Insert the plug into the socket only after all preparation steps for the device have been completed.

Attention!

To prepare and use the citrus press attachment, tilt the main unit of the device by 90°. Never use other attachments in this position.

→ Bowl for small fruits

1. Holding the main unit of the device by the handle, carefully tilt it so that the drive is directed upward. If necessary, rotate the main unit of the device to have good access to the buttons.
2. Insert the drive shaft with spring element into the drive of the main unit.

Attention!

The drive shaft must be positioned so that it can be easily pressed down with a finger. There should be no juice residues on it, and its movement should not be blocked by the attachment or foreign objects.

1. Place the collection bowl on the drive.
2. Turn the collection bowl clockwise until it locks with a characteristic click.
3. Place the strainer on the collection bowl.
4. Place the cone on the drive shaft.

The nozzle for citrus fruits is installed on the main block of the device, and it is ready for operation.

Application

→ For small fruits

1. Cut the citrus fruits in half.
2. Place a container under the nozzle.
3. Plug in the device. Turn on the device. Start the drive.

Attention! (MFW3X...)

After turning on, the device starts at speed 2 (fast). To use the citrus press, you must press the button 1-2 | rev once. The device switches to speed 1 (slow). → «Speed adjustment» see page 215 4. Press the cut citrus fruit against the conical attachment. When the pressed product is pressed against the conical attachment, the cone begins to rotate. 5. To finish pressing, change the pressing force and the conical attachment. 6. After finishing the work, turn off the device and unplug it from the electrical outlet. 7. While holding the locking button pressed, turn the nozzle clockwise until it releases.

1. Remove the nozzle, disassemble it, and clean all parts. → «Cleaning and maintenance» see page 221

Tips

• To achieve optimal juice yield, repeat the pressing several times.
• If necessary, empty the filter from coarse particles of fruit pulp and seeds.

Nozzle for grinding

Suitable for grinding soft products, such as nuts, oats, rice, coffee beans, breadcrumbs, spices, seeds, nuts, dried mushrooms, almonds, soybeans, flax seeds, buckwheat, sunflower seeds, etc. Not suitable for grinding very hard products, such as dried peas, corn, or pepper. → «Grinding» see page 222

Preparation

1. Insert the adjusting screw into the adjusting rings. Turn it until the scale is directed upward.
2. Screw the adjusting screw into the side of the adjusting chamber and turn the adjusting ring clockwise to the fine adjustment scale.
3. Insert the shank into the body.
4. Insert the adjusting ring into the body. Press it onto the Detanel shape.
5. Insert the adjusting cone with the pusher into the corresponding hole of the shank.
6. Install the adjusting chamber on the body. The protrusion on the adjusting chamber must fit into the body recess. 7. Install the threaded ring on the body and tighten it clockwise with a wrench.

Application

Danger of injury!

Do not put your hands into the hopper. During operation, do not block the hopper. Thrown out parts can injure your eyes.

Attention!

When the bag is installed, it is strictly forbidden to use the reverse function. The nozzle may be damaged!

1. Install the nozzle with the tip onto the drive of the main unit.
2. Turn the nozzle counterclockwise until it clicks into place with a characteristic sound. Tighten the threaded ring.
3. Install the filling funnel.
4. Place the funnel under the outlet. Fill the filling funnel. → "Recipes" section. p. 222

Attention!

Never start the blender without a processed product.

1. Recommended grinding thickness, pre-processing

Adjust the grinding ring: - against the direction of the arrow = coarse grind - in the direction of the arrow = fine grind. Then select a value between the positions: - STOP = coarsest grind - 1 = finest grind (start with it)

1. Insert the plug into the socket. Turn on the device.

Attention!

The maximum permitted continuous operation time of the device is 15 minutes. Then let it cool down for 45 minutes!

Do not put your hands into the feed tube.

Attention!

Remove the skins from hard fruits before juicing. Also, berries with pits, such as cherries, can be processed with the fruit press. - Before processing, remove the pits from fruits with large pits, such as plums, if you want to juice them. Do not process frozen fruits. - Do not press the pusher too hard.

→ Fruit press N

1. Install the prepared funnel with the spout onto the drive of the main unit of the device.
2. Turn the funnel against the direction of the arrow until it clicks into place. Then tighten the adjusting ring.
3. Fill the loading funnel and insert the pusher into the loading funnel.
4. Press the pusher. Adjust the required portion size so that it passes through the loading funnel without pressure. Remove the pusher (for example, from above and below).

Place one container under each outlet: for juice and pulp. Place the prepared loading funnel.

1. Insert the plug into the socket. Turn on the device.
2. Lightly press, push the pusher into the loading funnel.
3. The separated juice flows through the outlet pipe. The pulp (solid parts) is squeezed out through the nozzle for pulp.
4. Season the meat with salt. If you turn it a few times, the meat will be moist, if you turn it a few times, the meat will be dry, and more juice will come out of it. If the meat is too dry, add salt so that the meat does not burn.
5. After finishing the work, turn off the device and disconnect it from the electrical network.
6. Remove the loading chamber and cover.
7. While holding the fixation button pressed, turn the nozzle in the direction of the arrow until it comes out.

Remove the nozzle, disassemble it and wash all parts. → «Additional and user instructions» see page 221

1. To remove the filter, pull it by the tab and carefully pull it out.

Attention!

Before cleaning, wipe the filter thoroughly. Do not allow the filter openings to become clogged. If the openings of the housing are clogged with soft fruit residues, the device may be damaged.

If the housing openings are clogged, turn off the device and disconnect it from the power supply. Remove the attachments, disassemble them, and clean all parts. See "Cleaning and Maintenance" on page 221.

Cleaning and Maintenance

Always clean the attachments and the device after each use.

Danger of electric shock!

• Before cleaning, disconnect the device from the power outlet. Never immerse the motor unit of the device in water or rinse it under running water.

Danger of injury! Do not touch the sharp blades and edges of the chopping and slicing inserts. Use a brush for cleaning.

Attention!

Putting metal parts into the dishwasher is prohibited! Do not use abrasive cleaning agents; use a soft cloth. Do not use sharp or metal objects. Do not use harsh sponges or abrasive cleaning agents.

The figure shows how to clean individual parts.

■ Wipe the motor unit of the device with a damp cloth and let it dry. ■ Disassemble the attachments in reverse order (see the "Assembly" section for the corresponding attachment). ■ Clean all parts with a soft cloth or a sponge moistened with a mild detergent, or with a soft brush. ■ Let all parts dry.

Storage

• Wipe metal parts dry immediately and lubricate them with a small amount of cooking oil to protect them from rust. During processing of products such as carrots, colored stains may form on plastic elements. They can be removed with a few drops of cooking oil.

Recipes

Recipe (MFW3X...)

For all work operations, use setting 2 (fine).

Bread crumbs

300 g of wheat bread - 40 g of butter or margarine for 1 tbsp. of finely chopped onion - parsley - salt and pepper

Cut the bread into slices 10 mm thick, then cut into cubes. Pour 20 ml of milk and let it soak. ■Dry the bread crumbs in the oven (with a disc with holes) for about 60 seconds. Add the finely chopped onion, parsley, butter and mix the ingredients. ■Add to the bread crumbs, salt and pepper. Keep for a few minutes. Then repeat. ■For the crumbs, it is best to use your hands. The crumbs should be rolled in flour. Dip the crumbs in the egg and keep them for about 20 minutes. Do not let them boil!

Advice

Meat grinder

Use of perforated discs

-Perforated disc with fine holes (2.7 mm):

Boiled chicken, pork, beef, boiled veal, boiled fish on a plate; Pork and beef on a meat plate; Veal, meat and bacon on a liver sausage; Pork on a raw sausage

-Perforated disc with medium holes (4 mm):

Pork and beef for pate and servelat

Juice extractor for vegetables and fruits: for extracting juice from vegetables and fruits, for example, raspberries, currants, gooseberries or grapes, as well as from tomatoes.

Make sure that no foreign objects are in the feed tube or in the attachments. Do not insert any objects (for example, knives or forks) into the feed tube or into the outlet.

Let the appliance cool down for a maximum of 10 minutes. Then turn off the appliance and let it cool to room temperature.

Important!

Obsolete

Malfunctions

Comprehensive Overview

Figure A

1 Main unit

a Lever for attachments b Button for single* c Button for 1-2 | rev* d Operating status indicator e Disconnect button f Carrying handle g Compartment for storing the lid h Mains cable i Cable compartment

2 Main attachment

a Housing b Feed tube c Feed chute d Pusher e Disc with rotating bush f Threaded ring

3 Meat grinder parts

a Blade b Moulding disc with fine holes (2.7 mm)* 27 Moulding disc with medium holes 229 d Moulding disc with coarse holes)

4 2 Sausage filler attachment

a·Support ring 231 b·Funnel ring

Figure 232 5 Attachment for shredding*

a Housing b Feed tube 2.3.4 c Shut-off valve 235 d Feed chute e Pusher 2

f Cutting blade Shredding disc for coarse shredding 2 h Shredding disc for fine shredding i Grater disc 239

69 PnucTabka-cokobbixmamJaIka dna UNTpycoBix

a C6opHaawa b CetTuatbIΦnIbTp 241 c KoHyc cOKOBbIXmajkn d PnBODHOBaJc npyKHoH

Ipeepncnoj30BaHnemHOBOrO np6opaero Heo6xoDIMO nonHocTbIO paCnaKOBaTb, ONUCTNb I pOBePNTb.

BHUMAHne!

BboNTb B deIcTBnE NOBpeXdHbI np6op kaTeOpnuEcKn 3aPpeSeHo!

BbIbTe oCHOBHo6JOK IN BCE npHaJIeXHOCTN N3 yNAKOBKN. UdAnTe IMeIOUsnCra yNaKOBOHbIMatepnaJ. Pa36epnte co6paHHbIe KOMnoHEtbl Ha otJeNbHbIe yactn. NocneIOBaTeNbHocTb DeiCTBn npn 3Tom DOJXHa 6bITb 6paTHoI ONuCAHnO B pa3dene «NoDrotOBKa» PpOBepbTe KOMnneKTHoCTb BCex YacTei.

→PncyHOKA/ C

■ПюверьтЕ BCE чаctи пибopa на оТсуТCTВе BHeшnх NOВржден. IpeepnepBbIM pCNOJb3OBAHNEM TuaTeJIbHO OuNCTNTe N BbICyUHTe BCE DeTaII. → «Yxod u exeKeDHeBHa oUcMka» CM. cmp. 238

Злем entblу npablenia nHHdkaun

MFW39.

Khonka I

HaxaTneM KhoNkI np6Op BKnIOucaTeC.

PpnuBOD cpa3y HauHaeT BpaaTaTbca.

Khonka O

HaxaTneM KhoNkO np6op BbIKIOuAeTc.

The drive stops.

MFW3X.

On/Off button

Press the On/Off button to switch the device on.

The drive starts operating in speed mode 2 (fast). Pressing the On/Off button again switches the device off. The drive stops.

Button 1-2 | rev

Briefly pressing the 1-2 | rev button switches the device speed between modes 1 (slow) and 2 (fast).

→ "Speed setting" see p. 231. Pressing and holding the 1-2 | rev button activates the reverse function. → "Reverse function" see p. 231

All models

Status indicator

When the device is switched on, the status indicator lights up. In models with the reverse function, the indicator flashes while the 1-2 | rev button is held down.

Release button

Pressing the release button releases the attachment mounted on the device. Only when the release button is pressed can the attachment be turned clockwise and removed from the main unit.

Cable compartment

The mains cable can be pulled out of the cable compartment and inserted back. Always pull the cable only to the required length.

Storage compartment

Unused mold release agents can be placed in the storage compartment. Close the lid.

Overload protection device

To prevent significant damage to the device in the event of an overload of the main unit, the rotary bushing is equipped with a break point (predetermined breaking point). In case of overload, the gripper breaks at this point. A new rotary bushing can be purchased from customer service (item no. 10005188). The warranty does not cover parts with a predetermined breaking point.

Replacing the rotary bushing

Figure B

1. Loosen the screws in the rotary bushing with a suitable screwdriver (PH2) and remove the defective rotary bushing.
2. Insert the new rotary bushing and tighten it firmly.

Speed setting

For MFW3X.

The speed can be set to 1 (slow) or 2 (fast).

Attention!

For certain applications, speed mode 1 (slow) is mandatory. Follow the speed setting recommendations!

See table on page 8, figure P

Turn on the device with the ON/OFF button. The device starts operating in speed mode 2 (fast). Briefly press the button 1-2 | rev. The device switches to speed mode 1 (slow). Briefly press the button 1-2 | rev. The device switches back to speed mode 2 (fast).

Image function

NUR MFW3X. . .

The image function is used to briefly release jammed items. The image function switches off automatically after 15 seconds.

Warning!

Never use reverse mode with the mill attachment or the citrus juicer attachment! - Never press the 1·2 | rev button while the appliance is switched on. Press the 1·2 | rev button only after the appliance drive has come to a complete stop.

Switch off the appliance with the O/I button and wait for the drive to come to a complete stop. Press and hold the 1·2 | rev button. After 5-10 seconds, release the 1·2 | rev button and wait for the drive to come to a complete stop. Switch the appliance on again with the O/I button.

Note:

If the food items are not released after a brief reverse run, switch off the appliance, unplug it from the socket, and clean the appliance. → «Care and cleaning» see page 238

Main unit

Preparation

Risk of injury not excluded

Risk of injury!

The plug may only be inserted into the socket after the appliance has been completely prepared for operation, i.e., after all necessary attachments have been assembled and connected to the main unit.

Place the main unit on a stable, horizontal surface. Pull the power cord out of the cord compartment to the required length.

The main unit is ready for operation.

Main attachment

The main attachment has the following purpose:

Meat grinder

For grinding raw and cooked products. Use the appropriate forming discs depending on the type and consistency of the products being processed. → "Sieves" see p. 238

Sausage stuffer

For filling sausage mass into natural or artificial sausage casings. For making sausages.

Note: When using the base attachment and the accessories that can be purchased from the service department, other applications are possible.

Attention!

When assembling different parts, align the grooves on the attachments with the corresponding grooves on the housing.

Preparing the meat grinder

Danger of injury!

Risk of injury!

Do not touch the sharp blade.

Attention!

Always use only one forming disc.

1. First insert the auger with the drive chuck into the housing.
2. Install the knife on the auger, then the shaping disc.
3. Install the threaded ring on the housing and tighten it clockwise without applying excessive force. The meat grinder is ready for operation.

Preparing sausage stuffing

1. First insert the auger with the drive chuck into the housing.
2. First install the support ring on the auger, then insert the sausage stuffing tube into the housing.
3. Install the threaded ring on the housing and tighten it clockwise without applying excessive force.

Sausage stuffing is ready for operation.

Applications

Note: Depending on the purpose, the product is processed differently. → "Recipes" see page 238

Below, using an example, the use of the basic attachment as a meat grinder is described:

Danger of injury!

Danger!

Risk of injury!

Never touch the sharp blades or edges of the cutting attachments with your hands. Use the pusher only.

→ See Figure B

1. Open the lid. Insert the cutting attachment into the housing.
2. Close the lid with a click. The attachment for the pusher is ready for use.

Operation

Danger!

Risk of injury!

Do not put your hands into the feed chute. Always use the pusher.

Attention!

The pusher may only be inserted in the correct direction. - Remove hard shells (e.g., from nuts). - Do not apply excessive pressure with the pusher.

Attention! (MFW3X...)

For the pusher and cutting attachments, always use speed setting 1 (slow). For the grater attachment, use speed setting 2 (fast). → See "Speed setting" on page 231

→ See Figure H

1. Install the inclined attachment on the drive of the main unit.
2. Turn the attachment counterclockwise until it locks into place.
3. Install the feed chute and insert the pusher into the feed tube.
4. Prepare the products. Crush large pieces beforehand so that they fit into the feed tube without pressing.
5. Place a container under the attachment for the output. Load the prepared products for processing into the feed chute.
6. Connect the power plug to the outlet. Turn on the appliance.

Attention! (MFW3X...)

After turning on, the appliance starts working in speed mode 2 (fast). To continue using the pusher, press the button once

1·2 | rev To switch to speed mode 1 (slow). → "Speed setting" see p. 231 7. Gently press the pusher to push the products into the feed tube. The products are processed. 8. After finishing work, turn off the appliance and remove the power plug from the outlet. 9. Remove the feed chute and the pusher. 10. While holding the release button, turn the attachment counterclockwise to release it. 11. Remove the attachment, disassemble it, and clean all parts. → "Care and daily cleaning" see p. 238

Citrus juicer attachment

For extracting juice from citrus fruits, such as lemons, oranges, and grapefruits.

Preparation

Risk of injury is not excluded!

The citrus juicer attachment is installed directly on the main unit. The power plug can be inserted into the outlet only after the preparation for working with the appliance is fully completed.

Attention!

Instructions for assembly and use of the citrus juicer attachment for citrus fruits. Rotate the main unit 90 degrees. In this position, do not use other attachments under any circumstances.

→ See figures

1. Hold the main unit by the handle, carefully move it to a position where the drive is pointing upward. If necessary, turn the main unit to ensure convenient access to the buttons.
2. Insert the drive shaft with the spring element downwards into the drive of the main unit.

Attention!

The drive shaft should slide in easily with a finger. It must not be stuck with juice residues or blocked by seeds or foreign objects.

1. Place the collection bowl onto the drive.
2. Turn the collection bowl counterclockwise until it locks with a click.
3. Place the strainer onto the collection bowl.
4. Place the cone of the citrus juicer onto the drive shaft.

The citrus juicer attachment is assembled and ready for use.

Use

→ See figures J

1. Cut the citrus fruits in half.
2. Place the juicer attachment over a suitable container.
3. Plug the power plug into the socket. Turn on the appliance. The appliance starts rotating.

Attention! (MFW3X...)

After switching on, the appliance starts operating in speed mode 2 (fast). To use the citrus juicer, you must press the button 1·2 once (to switch to slow speed mode immediately). See "Speed setting" on page 231.

1. Press the pusher with the cutting surface onto the cone of the citrus juicer and press down. As soon as the juice being squeezed is collected on the cone of the citrus juicer, the cone starts rotating.
2. To finish squeezing, reduce the pressure on the cone of the citrus juicer.
3. After finishing the work, switch off the appliance and remove the power plug from the socket. 7. While holding the release button, turn the attachment counterclockwise so that it releases.
4. Remove the attachment, disassemble it, and clean all parts. See "Care and daily cleaning" on page 238.

Tips:

• To ensure optimal juice yield, repeat the squeezing process several times.
• If necessary, clean the sieve filter from coarse fruit pulp and seeds.

Mill attachment

For grinding products such as wheat, oats, rice, coffee beans, peppercorns, mustard seeds, flax seeds, poppy seeds, dried mushrooms, almonds, salt, flax seeds, buckwheat, peeled sunflower seeds, etc. The appliance is not intended for grinding very hard products such as dried peas, corn kernels, or popcorn. See "Tips" on page 238.

Preparation

Figure K

1. Insert the mounting screw into the mounting ring. Make sure that the scale is facing upwards. 2. Press the mounting screw in the direction of the grinding chamber and turn the mounting ring clockwise so that the scale marks the degree of grinding.
2. Insert the shaft into the housing.
3. Insert the grinding wheel into the housing. Pay attention to the shape of the part.
4. Insert the grinding cone with a four-sided shape into the corresponding hole of the shaft.
5. Install the sample chamber into the housing. The recess of the sample chamber should be located on the housing base.
6. Install the threaded ring on the housing and tighten it clockwise without applying force.

Application

Risk of injury is not excluded!

Do not insert your hands into the feed pipe. During operation, do not reach into the feed pipe. Ejected parts can cause eye injuries.

Attention!

If a grain mill is installed, never use the reverse function. This can cause damage to the attachment!

→For drawings L

1. Install the prepared attachment obliquely onto the drive of the main unit.
2. Turn the attachment counterclockwise until it locks with the lug. Tighten the threaded ring.
3. Install the feed pipe.
4. Place a suitable container under the attachment. Fill the feed pipe. → "Tips" see p. 238

Attention!

Never start the attachment without products to grind.

1. Adjust the grinding coarseness by turning the setting ring: - counterclockwise = coarser grinding - clockwise = finer grinding Always choose a value between the following points: - STOP = coarsest grinding - 1 = finest grinding (never start with this)

1. Connect the power plug to the socket. Switch on the appliance.

Attention! The appliance should not operate continuously for more than 15 minutes. After that, let it cool for 45 minutes!

1. Flour sifts through the perforated chamber.
2. The grinding coarseness can be adjusted during operation in small steps.

Attention! If during operation you turn the setting ring beyond the STOP mark, this can lead to damage to the appliance.

1. Immediately after finishing grinding, switch off the appliance and unplug the power plug from the socket.
2. Remove the loading container. 11. While holding the release button, turn the attachment clockwise so that it releases.
3. Remove the attachment, disassemble it, and clean all parts. → "Care and daily cleaning" see p. 238

Juice attachment for fruits

For extracting juice from berries and fruits, such as raspberries, currants, gooseberries, or grapes, as well as from tomatoes.

Note: The amount of pulp in the juice depends on the choice of strainer. Do not squeeze juice from berries or fruits whose seed diameter is almost the same as the diameter of the strainer holes (for example, from raspberries).

Figure M

Check that the sealing rings are installed on the strainer and the lid. If not, insert the sealing rings into the sealing grooves.

1. Insert the lower strainer into the strainer and press it.
2. Insert the lid into the housing.
3. Insert the strainer into the housing. The strainer spout should be positioned in the recess of the housing.
4. Install the threaded ring on the housing and tighten it clockwise, without applying force.
5. Install the outlet spout on the strainer until it clicks into place with the lid.
6. Screw the juicer head into the strainer. The juicer is ready for operation.

Applications

Warning

Risk of injury!

Do not insert hands into the feed chute.

Attention!

• Remove seeds and stalks from fruits. Squeeze juice from fruits, for example, currants, together with the stalks.
• Before squeezing juice from fruits with fairly large seeds or pits, for example, plums or cherries, remove the seeds and pits. Do not process frozen fruits. Do not apply excessive pressure with the pusher.

→ Figure N

1. Install the prepared attachment obliquely onto the drive of the main unit.
2. Turn the attachment clockwise until it locks with a click. Tighten the screw ring.
3. Install the feed chute and insert the pusher into the feed tube.
4. Prepare fruits for processing. Cut large fruits into pieces so that they fit into the feed tube without pressing. Remove large pits (for example, from cherries, plums).

Place containers under the openings for juice and pulp. Load the prepared fruits into the feed chute.

1. Plug the power cord into an outlet. Turn on the appliance.
2. Gently press the pusher to push fruits into the feed tube.
3. The juice flows out through the outlet spout. The fruit pulp (solid components) is expelled through the pulp outlet head.
4. Adjust the pulp outlet head. When turned counterclockwise, the pulp becomes wetter; when turned clockwise, it becomes drier, and more juice flows out of the spout. If the pulp is too dry, turn the head to prevent the appliance from clogging with fruit pulp.
5. After finishing work, turn off the appliance and unplug the power cord from the outlet.
6. Remove the plug from the socket. 11. Press the release button, turn the attachment counterclockwise so that it releases.

■ Remove the attachment, disassemble it and clean all parts. → «Cleaning and daily cleaning» see p. 238 12. Clean the strainer: hook the hook into the opening of the strainer and carefully remove the strainer.

Attention!

When squeezing juice, proceed with extreme caution. Make sure that the openings of the strainer are not clogged. If the outlet opening of the housing is clogged with pulp of fruit, a bone may get into the drive. If the outlet opening of the housing is clogged, turn off the appliance and remove the plug from the socket. Remove the attachment, disassemble it and clean all parts. → «Cleaning and daily cleaning» see p. 238

Cleaning and daily cleaning

After each use of the appliance, all attachments and used accessories must be thoroughly cleaned.

Danger of electric shock!

- Before cleaning, disconnect the power cord from the electrical outlet. - Never immerse the main unit in liquids and do not wash it in the dishwasher.

Danger of injury!

Risk of injury!

Do not touch the sharp blades, the edges of the attachments for chopping and slicing. Use a brush for cleaning.

Attention!

• Metal parts must not be washed in the dishwasher! Do not use aggressive cleaning agents containing alcohol or spirits. Do not use metal or sharp objects, as well as objects with sharp edges.
• Do not use coarse cloth or abrasive cleaning agents.

The figure shows how to clean the individual parts of the appliance.

Wipe the main body parts with a damp cloth and dry them. Disassemble the used attachments in reverse order (see section "Preparation" for the corresponding attachment). Clean all accessories with soapy water and a soft cloth/sponge or soft brush. Allow all parts to dry.

Instructions

• Metal parts should be wiped dry immediately and coated with a thin layer of cooking oil to protect them from rust. -When processing, for example, carrots On plastic parts may appear light stains. They can be removed with a few drops of cooking oil.

Recipes

Instructions (MFW3X...):

For all operations, set the speed level 2 (fast).

Bread dumplings

300 g of stale white bread, 20 ml of milk - 40 g of butter or margarine, 1 tbsp. finely chopped onion - parsley, salt and pepper to taste

Cut the bread into slices 10 mm thick and cut in half lengthwise. Pour 20 ml of milk and let it soak. Process the moist bread pieces in the food processor (chopping disc with medium holes) for approx. 60 seconds. Add finely chopped onion, parsley, melted butter and mix. Beat the eggs, add salt and pepper to the bread mixture. Let the dough rest for a few minutes. Then knead again. Shape the dumplings with hands moistened with water. Roll the dumplings in flour. Place the dumplings in boiling water and let them simmer on low heat for about 20 minutes. Do not let them boil!

Tips

Food processor

Use of chopping discs

-Chopping disc with fine holes (2.7 mm): cooked chicken, pork, veal, cooked ham, cooked fish for soups; raw pork and veal for meatballs; raw ham, meat and fat for liver sausage; pork for raw smoked sausage

-Chopping disc with medium holes (4 mm):

Pork and veal for pâté and servelat

Disc with large holes (8 mm):

Roasted pork for goulash soup; leftovers (e.g., roast, sausages) for casseroles with leftovers

If a finer consistency of processed products is required, repeat the grinding process or use different discs in sequence (with large, medium, small holes). ■ Ingredients (e.g., onions, garlic) can be added directly during processing. This ensures all ingredients are well mixed.

Sausages and wieners

Soak natural sausage casings in warm water for about 10 minutes before processing. Do not fill the casings too tightly, as the sausages may burst during cooking or frying.

Attachment for shredding

Caution! (MFW3X...)

For the shredding disc, it is mandatory to use speed setting 1 (slow). - For the grating disc, use speed setting 2 (fast).

→ "Speed setting" see page 231

Using the attachments

Shredding disc: for carrots, celery, cabbage, zucchini. Shredding disc (coarse): for carrots, nuts, hard cheese (e.g., Emmental)

Shredding disc (fine): for accompanying documentation.

Nuts, hard cheese, parmesan. Grating disc: for potatoes, parmesan, nuts

Attachment - mill

• Do not grind oily products on the finest setting. The grinder may clog or jam. - For grinding soft grains such as oats and flaxseed, select the coarse grinding setting.
• The appliance should be thoroughly washed if you start processing another product. This will help avoid absorbing the smell of the previous product.

Disposal

Dispose of the packaging using environmentally friendly methods. This appliance is marked in accordance with European standards 2012/19/EU for the disposal of waste electrical and electronic equipment (WEEE). These standards define the rules for the return and disposal of old appliances in force in the European Union. You can obtain information about current disposal options from the store where you purchased the appliance.

Warranty service

You can obtain comprehensive information about the warranty service conditions at your nearest authorized service center, or at the service center of the manufacturer LLC "BSH Household Appliances", or

in the accompanying documentation.

We reserve the right to make changes.

Spare parts and accessories

24-hour hotline*: 8 [phone]

Official website on the Internet: www.bosch-home.ru

Addresses of authorized service centers, as well as all information on service, are available on the official website on the Internet: www.bosch-home.ru.

We recommend that you use the services of only authorized service centers.

Original accessories and care products for Bosch household appliances can be purchased in our online store: www.bosch-home.ru/store. You can familiarize yourself with the terms of ordering, payment, and delivery on the website. You can also purchase original accessories and care products at authorized service centers.

1. Product

1. Model

In case the data is not contained in the purchase documents (cash receipt and/or sales receipt, sales invoice).

3. The information is distributed for household appliances of the Bosch trademark: coffee makers, coffee machines, coffee grinders, scales, kitchen combines, mixers, blenders, knives, toasters, irons, hair dryers, electric shavers, juicers, choppers, blenders, irons, steam stations, and similar products.

1. Dear Ladies and Gentlemen, we inform you that confirmation of conformity of the products with the mandatory requirements in accordance with the legislation is carried out in the form of mandatory certification and declaration of conformity.

Information on mandatory confirmation of conformity of the devices, including data on the certificate of conformity number (declaration of conformity) and its validity period, you can obtain at LLC "BSH Household Appliances".

The product is manufactured under quality control and supervision of the company "BSH Hausgeräte GmbH", address: 81739 Munich, Carl-Wery-Straße 34, Germany (BSH Hausgeräte GmbH, Carl-Wery-Str. 34, 81739 München, Germany).

The manufacturer's authorized representative, authorized by the manufacturer on the basis of an agreement with it, is LLC "BSH Household Appliances", 198515, St. Petersburg, Peterhof, st. Karla Siimensa, 1, lit. A, or in Moscow, 119071, st. Malaya Kaluzhskaya, 1, phone [phone], fax [phone].

1. Mandatory information on the technical characteristics of the device is given on the nameplate of the device, on its label and/or in the accompanying documentation.

6. Accessories and care products

For the proper functioning of your appliance and care for it, it is recommended to use only original accessories and care products. Original accessories and care products are developed by the manufacturer, they are ideally suited specifically for your appliance. Original accessories and care products meet the highest quality requirements of the Bosch trademark, they undergo factory tests to ensure maximum reliability in operation. For all questions related to accessories and care products for your household appliance, you can contact authorized service centers or by phone of the support service.

7. Manufacturer's warranty

The manufacturer provides a warranty for the household appliance purchased by you in the Russian Federation in accordance with the current legislation for a period of 1 year. For a household appliance purchased in the Republic of Belarus, for which a warranty card was issued at the time of purchase, the warranty conditions that do not contradict the legislation of the Republic of Belarus apply.

8. Attention! Important information for the consumer

This device is intended for use exclusively for personal, family, household and other needs not related to entrepreneurial activity, to meet household needs in the household, institution or organization. Use of the device for purposes other than those specified above is a violation of the rules and conditions of operation of the device.

The rating plate on the appliance must not be removed! Please make sure it is present and keep it on the appliance for the entire service life of the appliance. Removing the rating plate leads to de-energizing of the appliance and to possible violations of its operating rules.

The manufacturer is not liable for defects in the appliance if the service department determines that they arose after the transfer of the appliance to the consumer due to violation of the rules of use, transportation, storage, actions of third parties, force majeure (fire, flood, catastrophe, etc.), ingress of foreign insects or rodents, exposure to external factors, as well as due to significant violations of technical requirements specified in the operating instructions, including instability of electrical parameters established by GOST 32144-2013.

To confirm the date of purchase of the appliance for warranty repair or presentation of other claims provided by law, we kindly ask you to keep the purchase documents (receipt, sales receipt, other documents confirming the date and place of purchase).

Following the recommendations set out in the operating instructions (rules of use), you can avoid problems in the operation of the appliance and its maintenance.

Serviceable appliance defects during the warranty period are repaired free of charge or replaced with new ones. The decision on the feasibility of replacement or repair remains with the service departments.

9. Service information

After the warranty period expires, the service department, as well as the workshops of our partners, are always ready to offer you their services. The list of addresses of authorized service centers is available on the official website: www.bosch-home.ru.

The service life of small household appliances (except for kitchen machines and vacuum cleaners) is 2 years. The service life of kitchen machines and vacuum cleaners is 5 years. The service life of the product is calculated from the date of its purchase, or if it is impossible to determine, from the date of manufacture of the product indicated on the product rating plate in accordance with the manufacturer's standard. The date of manufacture is marked as FD MM, where DD is the year of manufacture (e.g., 1920) and MM is the month of manufacture. To determine the year of manufacture of the appliance, add the number DD to 1920.

*Free round-the-clock telephone for calls within the territory of the Russian Federation.

B34C065N1-1M00 03/2017

Information about household appliances manufactured under the control of BSH Hausgeräte GmbH, Carl-Wery-Str. 34, 81739 Munich, Germany, in accordance with the requirements of the Federal Law of the Russian Federation of November 23, 2009 No. 261-FZ, legislation on technical regulation and legislation on consumer protection of the Russian Federation

Products: juicers, mixers, blenders, food processors, kitchen machines, coffee makers, meat grinders, shredders

Trademark: Bosch

IMPORTANT! The product is constantly being improved. The technical characteristics of the product, including energy efficiency, are constantly being improved. The manufacturer reserves the right to make changes without prior notice in accordance with applicable legislation. Information on current certificates of conformity and their validity periods, current information on the class and characteristics of energy efficiency of the product, information on current accessories for the product can be obtained from the organization performing the functions of a foreign manufacturer on the territory of the Russian Federation LLC "BSH Household Appliances", 198515, St. Petersburg, Peterhof, st. Karla Simmena, 1, lit. A, fin. B. Moscow, 119071, st. Malaya Kaluzhskaya, 15, tel. [phone], fax [phone].

The company LLC "BSH Household Appliances", 198515, St. Petersburg, Peterhof, st. Karla Simmena, 1, lit. A, fin. B. Moscow, 119071, st. Malaya Kaluzhskaya, 15, tel. [phone], fax [phone] carries out its activities to confirm the conformity of products on behalf of the manufacturer on the single customs territory of the Eurasian Economic Union in accordance with the current technical regulations, as an authorized manufacturer, and also fulfills the requirements provided for by Federal Law No. 184-FZ "On Technical Regulation" for a person performing the functions of a foreign manufacturer on the territory of the Russian Federation.

The importer in the Russian Federation of products certified as serial production is LLC "BSH Household Appliances", 198515, St. Petersburg, Peterhof, st. Karla Simmena, 1, lit. A, fin. B. Moscow, 119071, st. Malaya Kaluzhskaya, 15, tel. [phone].

The organization indicated on the product in the product identification data and carrying out the initial placement of the product on the market of the European Union is Robert Bosch Hausgerate GmbH, Carl-Wery-Str. 34, 81739 Munich, Germany (Robert Bosch Hausgerate GmbH, Carl-Wery-Str. 34, 81739 Munchen, Germany).

The original manufacturer (manufacturer) carrying out on its own behalf the production of products that meet the requirements of the applicable technical regulations is BSH Hausgerate GmbH, Carl-Wery-Str. 34, 81739 Munich, Germany (BSH HausgerA GmbH, Carl-Wery-Str. 34, 81739 München, Germany).

When transporting, loading, unloading and storing the product, in addition to the instructions in the operating instructions, the following requirements must be observed:

It is forbidden to subject the product to significant mechanical loads that could lead to damage to the product or violation of its packaging.

It is necessary to avoid getting the product packaging into water or other liquids.

Before transporting or moving for storage of a product that has been in operation, it is necessary to make sure that there is no water in the product.

The product is intended for use at ambient temperatures above 0°C and relative humidity not exceeding 93%.

Before starting operation of the product that has been under the influence of negative temperature for a long time, it must be kept at room temperature for several hours.

The product manufacturer reserves the right to make changes to the product in accordance with the requirements of current legislation.

Disposal instructions for the product are contained in the operating instructions and may be clarified by municipal executive authorities.

The product manufacturer guarantees compliance with the certificate of conformity during its validity period, and the certificate remains valid for the supply, sale, and use (application) of the product within the service life established in accordance with Article 18 of the Law on Consumer Protection. The service life of the product is set by the manufacturer in the section "Information about the manufacturer on warranty and service maintenance."

The product must be identified by the model designation (type-E-Nr), the appliance type (type), and the commercial code (E-Nr) indicated on the product, packaging, or in the accompanying documentation. In accordance with the internal standard of the manufacturer of household appliances, the following identification scheme is used:

E-Nr. /

The material number is a digital-alphanumeric designation of the product, no more than 10 characters, used when ordering (with the model designation or the model of the household appliance) the Bosch trademark. The material number (model) is indicated between the code word E-Nr and the code word FD.

The service index is a digital designation assigned to each product during the production process and used for service.

Operating documents are developed in a unified form for a wide range of products; therefore, the manufacturer provides for the indication of the product designation in the operating documents both in full and in part, which allows determining the relevance of a given operating document to a specific product accompanied by this operating document. Verification of the compliance of the product characteristics with the provisions contained in the attached operating documents is carried out by analyzing the information presented in the operating documents.

The composition of the operating documents provided by the manufacturer for the product may include this information, instructions (manual) for operation, information on warranty and service maintenance conditions.

Product marking is carried out by the manufacturer on the nameplate of the appliance, on the packaging label, directly on the packaging, or may be applied in other ways that ensure clear and legible presentation of information about the product at points of sale.

Products that have passed the conformity assessment procedure in accordance with the requirements of the technical regulations of the Customs Union or the technical regulations of the Eurasian Economic Union are marked with a single mark of product circulation on the market of the member states of the Customs Union (Eurasian Economic Union).

The product complies with the following technical regulations of the Customs Union:

TP TC 020/2011 Technical regulations of the Customs Union on the safety of low-voltage equipment, TP TC 004/2011 on the safety of low-voltage equipment, TP EAEU 037/2016 on restricting the use of hazardous substances in electrical and electronic products, from the date of its entry into force.

Operational documentation for products is made in Russian. Operational documentation in the state languages of the member states of the Eurasian Economic Union, which differ from Russian, if there are corresponding requirements in the legislation, can be obtained free of charge from the trading organization - representative of the corresponding member state of the Eurasian Economic Union.

Information about the product range is presented in the sales areas, can be requested by phone on the toll-free hotline [phone], and is also available on the Internet on the manufacturer's website: http://www.bosch-home.ru

Toprboe Obohne Hne	Anpoba- ZIOHNHb TIN	CepTnФикAT COOTBETBn				Стран- ИЗТОВ- ТELь
		Релострацион- Ньуhomep	ДаТа Вьдчы	Демсчыт До
Соковский
MCP3000 CNP3 C-DE.AR46.B.73451 08.02.201	07.02.2	21	Слобеня
MES25A0 CNJ03 C-DE.AR46.B.73451 08.02.20	16.07.02.	2021	Котай
MES25C0 CNJ03 C-DE.AR46.B.73451 08.02.20	16.07.02.	2021	Котай
MES25G0 CNJ03 C-DE.AR46.B.73451 08.02.20	16.07.02.	2021	Котай
MES3500 CNJ03 C-DE.AR46.B.73451 08.02.20	16.07.02.	2021	Котай
MES4000 CNC04 C-DE.AR46.B.73451 08.02.2016	07.02.2.201	1	Котай
MES4010 CNC05 C-DE.AR46.B.73451 08.02.2016	07.02.2.201	21	Котай
Реки
MAS4000W CNAS11ST1 C-DE.AR46.B.73634 19.02.2016	02.2016 18.02.2021	C	Повеня
MAS4104W CNAS11EV1 C-DE.AR46.B.73634 19.02.2016	02.2016 18.02.2021	C	Повеня
MAS4201N CNAS11ST1 C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS4601N CNAS11EV1 C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS6151M CNAS12 C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS6151R CNAS12 C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS6200N CNAS12 C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS9101N AS9ST C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS9454M AS9ST C-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
MAS9555M AS10EN CN-DE.AR46.B.73634 19.02.2016	18.02.2.2021	C	Повеня
Мінісірь, бінінісірь, изіmenічіпіпі
MFQ22100 CNHR30 C-DE.AR46.B.73649 7.08.2016 16	08.2021	C	Повеня
MFQ2210D CNHR30 C-DE.AR46.B.73649 17.08.2016	2021	C	Повеня
MFQ2210P CNHR30 C-DE.AR46.B.73649 17.08.2016	18.02.2.2021	C	Повеня
MFQ2210Y CNHR30 C-DE.AR46.B.73649 17.08.2016	2021	C	Повеня
MFQ24200 CNHR30 C-DE.AR46.B.73649 17.08.2016	08.2021	C	Повеня
MFQ2420B CNHR30 C-DE.AR46.B.73649 17.08.2016	2021	C	Повеня
MFQ3010 CNHR19 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ3020 CNHR19 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ3030 CNHR19 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ3520 CNHR17 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ3555 CNHR18 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36300D CNHR27 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36300I CNHR27 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36300Y CNHR27 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36440 CNHR27 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36460 CNHR27 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36480 CNHR27 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ36500 CNHR27 C-DE.AR46.B.73034 30.12.2015	29.12.2020	C	Повеня
MFQ4020 CNHR22 C-DE.AR46.B.73034 30.12.2015	29.12.2020	C	Повеня
MFQ40301 CNHR22 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ40302 CNHR22 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ40303 CNHR22 C-DE.AR46.B.73034	30.12.2015	29.12.2020
MFQ4070 CNHR22 C-DE.AR46.B.73034 30.12.2015	29.12.2020	C	Повеня
MFQ4080 CNHR22 C-DE.AR46.B.73034 30.12.2015	29.12.2020	C	Повеня
MMB21P0R CNSM10 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB21P1W CNSM10 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G0B CNSM11 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G1B CNSM11 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G2B CNSM11 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G3B CNSM12 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G4B CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G5G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G6G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G7G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G8G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G9G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Котай
MMB24G9G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Koten
MMB24G9G CNSM13 C-DE.AR46.B.73592	17.02.2016	16.02.2021	Koten
MMB24G9G CNSM13 C-DE.AR46.B.73592	17.02.2016 17.02.2016	16.02.2021	Koten
MMB24G9G CNSM13 C-DE.AR46.B.73592	17.02.2016 17.02.2016	16.02.2021	Koten
MS64035 CNR24 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS64120 CNR24 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS64155RU CNR24 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS64600 CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS66050RU CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS66130 CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS66155RU CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS66155 CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021	C	Повеня
MS66155 CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021 17.02.2016	C	Повеня
MS66155 CNR25 C-DE.AR46.B.73592 17.02.2016	28.01.2021 17.02.2016	C	Повеня
MS66155 CNR25 C-DE.AR456.B.73592 17.02.2016	28.01.2021 17.02.2016	C	Повеня
MS66155 CNR25 C-DE.AR456.B.73592 17.02.2016	28.01.2016 17.02.2016	C	Повеня
MS66155 CNR25 C-DE.AR456.B.73592 17.02.2016	28.01.2016 17.02.2016	C	Повеня
MS66180 CNR25 C-DE.AR456.B.73592 17.02.2016	28.01.2016 17.02.2016	C	Повеня
MS66180 CNR25 C-DE.AR456.B.73592 17.02.2021	28.01.2016 17.02.2021	C	Повеня
MS66180 CNR25 C-DE.AR456.B.73592 17.02.2021	28.01.2016 17.02.2021	C	Повеня
MS66180 CNR25 C-DE.AR56.B.73592 17.02.2021	28.01.2016 17.02.2021	C	Повеня
MS66180 CNR25 C-DE.AR56.B.73592 17.02.2021	28.01.2021	C	Повеня
MS66180 CNR25 C-DE.AR56.B.73592 17.02.2021	28.01.2021	C	Повеня

Toproboe obsohaue- Hnne	Anpoba- zouhien THN	Ceptnk#nkat COO##CTBn			CTPAN- H3GOTOBH- Telt
		Руttmaхшо- нь Homep	Дау Быдч	Диctbyet do
Mikcebp, bneu#depe, nmeelb#yteni
MSM6B250 CNR11 C-DE	A46.B.73592 17.02.	2016 16.02.20	21	C#o#henia
MSM6B300 CNHR12	C-DE.A46.B.73592	17.02.2016 16	02.2021	C#o#henia
MSM6B500 CNHR12	C-DE.A46.B.73592	17.02.2016 16	02.2021	C#o#henia
MSM6B700 CNHR12	C-DE.A46.B.73592	17.02.2016 16	02.2021	C#o#henia
MSM8 7130 CNHR28 C-DE	E.A46.B.73592 17.02.	2016 16.02.20	021	C#o#henia
MSM87140 CNR28 C-DE	A46.B.73592 17.02.20	16 16.02.20	1	C#o#henia
MSM87160 CNR28 C-DE	A46.B.73592 17.02.20	16 16.02.20	1	C#o#henia
MSM87165 CNHR28 C-DE	A46.B.73592 17.02.20	16 16.02.20	1	C#o#henia
MSM87180 CNHR28 C-DE	E.A46.B.73592 17.02.	2016 16.02.2	021	C#o#henia
MSM8 8190 CNHR28 C-DE	E.A46.B.73592 17.02.	2016 16.02.2	021	C#o#henia
MSM881X1 CNHR29	C-DE.A46.B.73592	17.02.2016 16	02.2021	C#o#henia
MSM881X2 CNHR29	C-DE.A46.B.73592	17.02.2016 16	02.2021	C#o#henia
Kxohonblc KOM6a#nblc
MCM3100W	CNCM12	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM3110W	CNCM12	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM3200W	CNCM12	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM3201B	CNCM12	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM3401M	CNCM12	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM3501 M	CNCM12	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM4000	CNCM20	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM4100	CNCM20	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM4250	CNCM21	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM62020	CNCM30	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM64051	CNCM30	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM64085	CNCM30	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM68840	CNCM30	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM68885	CNCM30	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM68885	CNCM30	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM4406	CNUM55T	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM4426	CNUM55T	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MCM4457	CNUM55T	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM4455	CNUM55T	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM4875EU	CNUM55T	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM4880	CNUM55T	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM52131	CNUM50	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54020	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54240	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54620	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54720	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54920	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54D00	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5480	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54G00	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54100	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54P00	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54Y00	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM54G40	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM57830	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5820	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5825	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5943	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5943	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5840	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5840	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5945	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM5945	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM58K20	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM58L20	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM59343	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM59363	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM59M55	CNUM51	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUM9A32S00	CNUM60A	C-DE.A46.B.77956	20.12.2016	11.02.20	21
MUM9AD1S00	CNUM61A	C-DE.A46.B.77956	20.12.2016	11.02.20	21
MUM9AE5S00	CNUM61B	C-DE.A46.B.77956	20.12.2016	11.02.20	21
MUM9AX5S00	CNUM61B	C-DE.A46.B.77956	20.12.2016	11.02.20	21
MUM9YT5S24	CNUM61B	C-DE.A46.B.77956	20.12.2016	11.02.20	21
MUM9YX5S12	CNUM61B	C-DE.A46.B.77956	20.12.2016	11.02.20	21
MUMXLZCO	CNUM70	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUMXL40G	CNUM70	C-DE.A46.B.73522	12.02.2016	11.02.20	21
MUMXX40G	CNUM70	C-DE.A46.B.73522	12.02.2016	11.02.20	21
Kopemont
MKM6003	KM13	C-DE.A46.B.73558	16.02.2016	15.02.20	21
MKM6000	KM13	C-DE.A46.B.73558	16.02.2016	15.02.20	21
Мирорουн
MFW3520G	CNFW3A	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW3520W	CNFW3A	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW3540W	CNFW3A	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW3630A	CNFW3B	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW3630I	CNFW3B	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW3640A	CNFW3B	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW3850B	CNFW3B	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW45020	CNFW5	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW45120	CNFW5	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW66020	CNFW6	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW67440	CNFW7	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW67600	CNFW7	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW68640	CNFW8	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW68660	CNFW8	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020
MFW68680	CNFW8	C-DE.A46.B.72617	03.12.20	15 02.12 20	2020

(waste electrical and electronic equipment - WEEE).

ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a
ar-11	a

.9

p

11

1

ar-11

.3 1

. 1

( . . . MFW3X ) ! 4

.

.（）2 1j

jll 5e biau jn yuuiy

ae j 1-2 rev

j（a）1

ar-5

2bll Jg 4

Therefore, the area of triangle OBC equals the area of triangle COD plus the area of triangle BOC.

Therefore, y = 1 - x^2.

J 1

L

1

100 21

()

.

(MFW3X. . )!

a

()1 4c

2 1

()

ar-5 a

H

[\sum \mu ]

J 1

The minimum value of the denominator is k. If k = a₁,

[\therefore {l}_{e} : y = c]

1 1

4

1

.5

.6

ar - 12

(MFW3X..)!

.()2 1

y

12 rev

()1

ar-5

!

MFW3X...	ar-5	rev	Jzj	Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld Ld 12
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.

MFW39. . .

1|Jr|

1|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr

O|Jr|

. O |Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr| Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jt

MFW3X. . .

O/1|Jr|

. O/1|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jt|Jt

. O/1|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jt|Jt

1·2|rev|

1·2|rev|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr|Jr (εj) 1 | jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jbj jBJ

Central Branch Service

17 km E.O. Athinon-Lamias & Potamou 20

14564 Kifisia

Phone: 181 82

Phone: [phone]

mail to: nkf - Customer Service

www.bosch-home.gr

HK Hong Kong,

BSH Home Appliances Limited

Unit 1 & 2, 3rd Floor,

North Block, Skyway House,

3 Sham Mong Road

Tai Kok Tsui, Kowloon

Hong Kong

Tel.: [phone] (HK)

Toll free 0800 863 (Macao)

Fax: [phone]

Email to: [e-mail]; [e-mail]

www.bosch-home.com/hr

HU Hungary

www.bosch-home.com/hu

IE Republic of Ireland

BSH Home Appliances Ltd.

M50 Business Park

Ballymount Road Upper

Walkinstown

Dublin 12

To arrange an engineer visit, to order spare parts and accessories or for

product advice please call

Tel.: [phone]*

www.bosch-home.ie

• Calls are charged at the basic rate, please check with your telephone service provider for exact charges

IL Israel

C/S/B/ Home Appliance Ltd.

1, Hamasger St.

North Industrial Park

Lod, 7129801

Tel.: [phone]

Fax: [phone]

mailto:[e-mail]

www.bosch-home.co.il

IN India, Bharat,

BSH Household Appliances Mfg. Pvt. Ltd.

Arena House, Main Bldg, 2nd Floor

Plot No. 103, Road No. 12,

MIDC, Andheri East

Mumbai 400 093

Toll Free 1800 266 1880*

www.bosch-home.com/in

• Mo - Sa: 8.00am to 8.00pm

(exclude public holidays)

IS Iceland

Smith & Norland hf.

Noatuni 4

105 Reykjavik

Tel.: [phone]

Fax: [phone]

www.sminor.is

abshg.com Italia, Italy

www.bosch-home.com/it

KZ Kazakhstan, Kazakhstan

IP Anackiy A.N. PTN-Service

Kuyshi Dina str.23/1 N3

Astana

Tel.: [phone]

mail@[e-mail]

Technodom Service

Utegen Batira Str. 73

480096 Almaty

Tel.: [phone]

mailto:[e-mail]

Kombitechnocentr

Zhaombyb sbm 117

480096 AI mat y

Tel.: [phone]

mail to: cts_pavel @bk.ru

www.cts.kz

TOO Evrika Service

Shimkent, Riskulova 22.

Shimkent 160018

Tel.: [phone]

mail to: evrika [e-mail]

www.evrika.com

AV SERVICE

Abulhair hana Str. 51

Uralsk 090000

Tel.: [phone]

mailto:[e-mail]

www.avservice.kz

LB Lebbon,

Teheni, Hana & Co.

Boulevard Dora 4043 Beirut

P.O. Box 90449

Jdeideh, 1202 2040

Tel.: [phone]

mailto:[e-mail]

LT Lithuania

Senuku prekybos centras UAB

Jonavos g. 62

44192 Kaunas

Tel.: [phone]

Fax: [phone]

www.senukai.lt

UAB "AG Service"

R. Kalantos g. 32

52494 Kaunas

Tel.: [phone]

Fax: [phone]

mailto:servivas@agservice

www.agservice.lt

Baltic Continent Ltd.

Luk'sio g. 23

09132 Vilnius

Tel.: [phone]

Fax: [phone]

mail to: [e-mail]

www.balticcontinent.lt

UAB Emtoservis

Savanoriu pr. 1 (Centrine bustine)

03116 Vilnius

Tel.: [phone]

Fax: [phone]

mail to: [e-mail]

www.emtoservis.lt

LU Luxembourg

mail to: [e-mail]

www.elektronika.lv

MD Moldova

S.R.L. "Rialto-Studio"

yn. UyceBa 98

Tel./Fax: [phone]

mailto:[e-mail]

ME Crna Gora, Montenegro

Elektronika komerc

mail to: ekobosch.servis@t-com.

MK Macedonia, Makeonna

GORENEC

Jane Sandanski 69 lok.3

1000 Skopje

Tel.: [phone]

Mobil: 070 233 689

mail to: [e-mail]

MT Malta

Oxford House Ltd.

Notabile Road

Mriehel BKR 14

Tel.: [phone]

Fax: [phone]

www.oxfordhouse.com.mt

MV Raaj jeyge Jumhoori y@a, Romania, Romania Maledives BSH Electrcasnics srl. Lintel Investments Sos. Bucuresti - Pioesti, Nr. 19-21, sect.1 Ma. Maadheli, Majeedhee Magu Malé 13682 Bucuresti Tel.: [phone] fax: [phone] I ntel. com. mv mail to: service. romania @bsh.com N L Nederlande, Netheriands www. bosch - home. ro BSH Huishoudapparaten B.V. Taur us avenue 36 OOO «БСХ Бытовь Рпборь» BSH Ev Al etleri Sanayi Storingsmeling: Manja Kanyjcksca, 15 Tel.: [phone] Fax: [phone] mailto: bosch - contact center mailto: [e-mail] bshg. com www. bosch - home. ro Onderdelenverkoop: SA Kingdom Saudi Arabia Tel.: [phone] Fax: [phone] mailto: [e-mail] www. bosch - home. nl NO Norge, Norway BSH Husholdningsapparater A/S Greensesvingen 9 P.O. Box 7997 Tel.: [phone] fax: [phone] mail to: Bosch - Service - NO@bs www. bosch - home. no NZ New Zealand BSH Home Appliances Ltd. Unit F 2, 4 Orbit Drive Mai rangi Bay Auckland 0632 Tel.: [phone]* Fax: [phone] mail to: after sales. nz@bshg. www. bosch - home. co. nz * Mo-Fr: 8.30 am to 5.00 pm (exclude public holidays) PL Polska, Poland BSH Sprzegt Gospodarssta Bosh Sporzęt Gospodarska Domowego sp. z o.o. Al. Jerozolimskie 183 02-222 Warszawa Centra l a Serwi su Tel.: [phone] Fax: [phone] mail to: Servis. Fabryczny@bs www. bosch - home. pl PT Portugal BSHP Electrodomesticos, Società Unipessoal, Lda. Rua Alto do Montijo, n° 15 2790-012 Carnaxide Tel.: [phone] Fax: [phone] mailto: bosch.electrodomesticos.pt@ bshg. com www. bosch - home. pt SM Slovensko, Slovienia BSH domáci Spotěbreče s.r.o. Firemní servis domácích spotěbreču Radlická 350/107c 158 00 Praha 5 Tel.: [phone] mail to: [e-mail] www. bosch - home. com/ sk SK Slovensko, Slovika BSH domáci spotěbreče s.r.o. Firemní servis domácích spotěbreču Radlická 350/107c 158 00 Praha 5 Tel.: [phone] mail to: [e-mail] www. bosch - home. com/ sk SM Slovensko, Slovika BSH domáci spotěbreče s.r.o. Firemní servis domácích spotěbreču Radlická 350/107c 158 00 Praha 5 Tel.: [phone] mail to: [e-mail] www. bosch - home. com/ SK SM Slovensko, Slovika BSH domáci spotěbreče s.r.o. Firemní servis domácích spotěbreču Radlická 350/107c 158 00 Praha 5 Tel.: [phone] mail to: [e-mail] www. bosch - home.com/ sk SM Slovensko, Slovika BSH domáci spotěbreče s.r.o. Firemní servis domácích spotěbreču Radlická 350/107c 158 00 Praha 5 Tel.: [phone] mail to: [e-mail] www. bosch - homeski

TH Thailand and the land of the sun BSH Home Appliances Limited Ital Thai Tower, 2034/31-39, 1st floor, New Petchburi Road Bangkapi, Huay Kwang Bangkok, 10310 Tel.: [phone]* www.bosch-home.com/th * Mo-Sa: 8.00am to 6.00pm (exclude public holidays) TR Türkiye, Turkey BSH Ev Al etleri Sanayi ve Ticaret A. S. Fatih Sultan Mehmet Mahallisi Balkan Caddesi No: 51 34771 Ümraniye, Istanbul Tel.: [phone]* Fax: [phone]* mail to: [e-mail] www.bosch-home.com/tr * Āçırı merkezini sabit hatlan aramann bedeligişehir ile ücretendirme, Cep telfonlariindan isle kullanan tarfaye gereğiskenlik östernektdir TW Taiwan, 我们期盼您不断的鼓励与指导, 任何咨询或服务需求, 欢迎洽询客服專線 BSH Home Appliances Private Limited 台北市內湖區洲子街80號11樓 11F., No.80, Zhouzi St., Neir Taipei City 11493 Tel.: [phone] Fax: [phone] maplo: [e-mail] www.bosch-home.com.tw UA Ukraine, Ykpaia TOB "ECX Nóbyrota Texhika" ten.: 044 490 2095 mail to: [e-mail] www.bosch-home.com.ua XK Kosovo Service-General SH.P.K. rr. Magjistraljä Ferizaj Pris 70000 Ferizaj Tel.: 00381 (0) 290 330 723 Tel.: [phone] mailto: [e-mail]

SM Slovenska, Slovenia BSH Prudovski BOSHP Electrodomesticos, Società Unipessoal, Lda. Rua Alto do Montijo, n° 15 2790-012 Carnaxide Tel.: [phone] Fax: [phone] mailto: bosch.electrodomesticos.pt@ bshg. com www. bosch - home. pl PSI BSN Portugal BSHP Electrodomesticos, Società Unipessoal, Lda. Rua Alto do Montijo, n° 15 2790-012 Carnaxide Tel.: [phone] Fax: [phone] mailto: bosch.electrodomesticos.pt@ bshg. com www. bosch - home. pk www. bosch - home. com/ sk

ZA South Africa BSH Home Appliances (Pty) Ltd. 15th Road Randjespark Private Bag X36, Randjespark 1685 Midrand-Johannesburg Tel.: [phone] Fax: [phone] mail to: applianceserviceza@bsr www.bosch-home.com/ za

Carl - Wery- Straße 34

81739 Munchen, GERMANY

Thank you for buying a Bosch Home Appliance!

Register your new device on MyBosch now and profit directly from:

• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service

Free and easy registration - also on mobile phones:

BOSCH

HOME APPLIANCES

SERVICE

Looking for help?

You'll find it here.

Expert advice for your Bosch home appliances, need help with problems or a repair from Bosch experts.

Find out everything about the many ways Bosch can support you:

www.bosch-home.com/service

Contact data of all countries are listed in the attached service directory.

P		MFW3910W	MFW3X10...	MFW3X13...	MFW3X14...	MFW3X15...	MFW3X17...	MFW3X18...
I	O	✓
O/I	1:2 rev		✓	✓	✓	✓	✓	✓
2.7 mm		✓	✓	✓	✓	✓	✓	✓
4 mm/8 mm	✓	✓	✓	✓	✓	✓	✓	✓
	✓	✓	✓	✓	✓	✓	✓	✓
		✓	✓	✓	✓	✓	✓	✓
			✓	✓	✓	✓	✓	✓
			✓	✓	✓	✓	✓	✓
			✓	✓	✓	✓	✓	✓
			✓	✓	✓	✓	✓	✓
			✓	✓	✓	✓	✓	✓
