KVC 3221 A - Vacuum Cleaner Koenic - Free user manual and instructions

Brand	Koenic
Model	KVC 3221 A
Appliance type	Canister vacuum cleaner with bag
Energy efficiency class	A
Indicative annual consumption	24.4 kWh/year (for 50 tasks)
Carpet cleaning class	C
Hard floor cleaning class	A
Dust emission class	A
Acoustic power level	74 dB
Nominal power input	700 W
Nominal voltage	220-240 V ~
Frequency	50/60 Hz
Protection class	II
Bag type	Microfiber textile dust bag
Container capacity (bag)	Approximately 3 L (not specified, estimate)
Power cord length	Approximately 5 m (common estimate)
Action radius	Approximately 8 m (estimate)
Included accessories	Floor brush, dusting brush, round furniture brush, square furniture brush, hard floor brush, telescopic tube, suction hose
Functions	Adjustable suction power (+/- control and air flow on handle), automatic cord rewind, vertical storage, bag full indicator
Maintenance	Replaceable bag, washable motor and exhaust filters (tap clean)
Safety	Do not vacuum liquids, hot ashes, flammable substances; indoor use; supervision required for children

Frequently Asked Questions - KVC 3221 A Koenic

How to assemble the KVC 3221 A vacuum cleaner?

Insert the suction hose into the connector and turn it to the right to lock. Attach the telescopic tube between the floor brush and the handle. Adjust the tube length by sliding the locking mechanism.

How to adjust the suction power?

Use the +/- button on the device to select the power (from low for curtains to high for hard floors). You can also adjust the air flow on the hose handle.

When should the dust bag be changed?

The filling indicator on the cover turns red when the bag is full. Open the cover, remove the used bag, insert a new one, and close.

How to clean the filters?

The motor filter (fig.16) and the exhaust air filter (fig.17) are cleaned by tapping them to remove dust. Do not wash with water. Reassemble in the correct direction.

Can I use the vacuum cleaner without a bag?

No, the vacuum cleaner works with a provided microfiber textile bag. Never use it without a bag, as the motor would quickly become dirty.

What to do if suction power decreases?

Check if the bag is full or if the filters are clogged. Replace the bag and clean the filters. Also ensure the hose and brushes are not blocked.

Can I vacuum liquids with this vacuum cleaner?

No, this vacuum cleaner is designed only for dry dust. Never vacuum liquids, hot ashes, lit cigarettes, or flammable substances.

How to store the vacuum cleaner?

Wind the cord by pressing the retraction button. For a short break, insert the floor brush into the storage system at the back. For storage, the hose with brush can be mounted vertically on the device.

What accessories are included?

Floor brush (with rocker for hard floors/carpet), dusting brush, round and square furniture brushes, hard floor brush, telescopic tube, and suction hose.

Is the vacuum cleaner suitable for allergy sufferers?

The device is classified A for dust emission. Use a microfiber bag and clean the filters regularly to minimize fine particle emissions.

USER MANUAL KVC 3221 A Koenic

Iris-Cerli
University of Washington
Seattle, Washington, USA
[e-mail]

（000731）244859

KOENIC

Vacuum Cleaner

G. Cui, Xiaotang
Lengcheng, Chengyuan
X. Guo, Muzhou
Y. Hu, Xuehui
J. Ke, Lixin
Z. Ma, Zhenxiong
C. Chen, Zixue
T. L. Li, Kajiang
W. Li, Yizhou
N. Zhongkandu
K. Lu, Kunshan

Culah37
1970-1
1963-17
1958-202
Furukawa 37
Matsus 28-31
Klein 10-11
Kolodinsky 38-42
Kolodinsky 43
Soros 37

100

Sicherheitshinweise

• This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the product.
• Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
• A damaged power cord may only be replaced by the authorised service agent in order to avoid hazards.

• Follow the instructions in the chapter Cleaning and care.

• Read this user manual thoroughly before first use and pass it on with the product. Pay attention to the warnings on the product and in this user manual. It contains important information for your safety as well as for the use and maintenance of the equipment.

• Never leave the product unsupervised while it is switched on.
• Do not place heavy objects on top of the product.
• Never immerse electrical parts of the product in water during cleaning or operation. Never hold the product under running water.

• Do not under any circumstances attempt (e.g. damage in power cord, product is dropped, etc.) to repair the product yourself. For servicing and repairs, please consult an authorised service agent.
  The mains voltage must match the information on the rating label of the product.

• Only unplug from the power socket can separate the product completely from the mains. Please be sure that the power plug is in operable condition.

• Avoid damages to the power cord that may be caused by kinks or contact with sharp corners.
• Keep this product including power cord and power plug away from all heat sources like for example, ovens, hot plates and other heat-producing products/objects.
• Only unplug from the power socket by the plug itself. Do not pull on the cord.
• Unplug the product ...
• when the product is not being used,
• in case of malfunctions,
• before attaching / detaching accessories and
• before cleaning the product.
• Use this product in dry indoor areas only and never outdoors.

English

Safety instructions

This product is not intended for commercial use. It is designed for household use only.
- Do not allow the product to operate unsupervised.
Make sure that the motor unit and supply cord do not become wet.
- Use accessories supplied with the device or recommended by the manufacturer only!
This product is suitable only for private use.
Always switch the product off before disconnecting it from mains supply.
- Let the product cool down sufficiently before storing.
- Do not cover the product while in use. Fire hazard!
- Do not suck up liquids with the product.
Do not suck up lit cigarettes, hot ashes, matches, etc. Fire hazard!
- Do not suck up inflammable or explosive materials and gases. The product must not be used in rooms with explosive gases or liquids.
- Be especially careful when cleaning the stairs
- When in use, keep the product away from clothes and body parts (fingers, hair, face).
- Do not try to clean people or animals with the product.
- Attention! In the event of a malfunction as a result of electrostatic discharge and momentary electrical surges, unplug the appliance and plug it in again.

Congratulations!

Thanks for your purchase of KOENIC product. Please read this manual carefully and keep it for future reference.

Intended use

The vacuum cleaner is designed only to vacuum dry dust and dirt. Using it for anything else can damage the device or cause injury. The Imtron GmbH assumes no liability for damage to the product, for property damage or for personal injury due to careless or improper usage of the product, or usage of product which does not meet the manufacturer's specified purpose.

Before first time use

Remove the product and accessories carefully from the original packaging. It is recommended to keep the original packaging for storage. If you wish to dispose of the original packaging, please observe applicable legal provisions. Should you have any questions regarding proper disposal, contact your local waste management center.

Inspect the delivery contents for completeness and damages. Should the delivery contents be incomplete or damaged, contact your sales outlet immediately.

After unpacking, please refer to chapter

Cleaning and care.

Do not dispose of this product as unsorted municipal waste. Return it to a designated collection point for the recycling of WEEE.

By doing so, you will help to conserve resources and protect the environment. Contact your retailer or local authorities for more information.

Content

1 x Vacuum cleaner
1 x Floor nozzle
1 x Crevicenozzle
1 x Upholstery nozzle round brush
1 x Upholstery nozzle square brush
1 x Hard floor brush
1 x User manual
1x warranty card

Part list

A Suction hose
B Suction level control +/- with display
C Suction tube bracket
D Cover with dust bag fill level indicator
E Carrying grip
F Crevice nozzle
G Upholstery nozzle square
H Upholstery nozzle round
Hard floor brush
1 Wheel
K Floor nozzle
On/Off button
M Telescopic tube holder
Exhaust air filter
0 Cable retraction button
Telescopic tube with locking mechanism
Q Suction tube handle release button
R Variable suction flap
S Suction tube handle

incl. 1 x micro textile dust bag (not shown)

English

Assembling the vacuum cleaner

Fig. 1 Insert the suction hose into the hose connection and rotate it to the right (bayonet lock). Make sure that it has clicked into place.
Fig. 2 Place the floor nozzle on the lower end and the suction tube handle on the upper end of the telescopic tube.
Fig. 3 Adjust the telescopic tube to the desired length, by sliding the locking mechanism up and then pushing the telescopic tube out or squeezing it together.

Use of the accessories provided Floor nozzle (Part K)

Fig. 4 To vacuum hard floors, press the toggle switch down.
Fig. 5 To vacuum carpeted areas, press the toggle switch again in order to retract the brushes.

Upholstery nozzle round/square (Part G, H)

Fig. 6 For vacuuming upholstered furniture, mattresses, cushions, curtains, etc.

Crevicenozzle (Part F)

Fig.7 For vacuuming folds, crevices and corners.

Hard floor brush (Part I)

Fig. 8 For vacuuming hard and wooden floor. Use the hard floor brush to protect the floor from being scratched.

Operation

Fig.9 Pull out the connection cable to the desired length and insert the power plug into a receptacle.
Fig.10 Press the On/Off switch to turn the vacuum cleaner on/off. Select the suction power with the suction control button +/-

Symbol	Suction power	Suitable for
	Low Curtains	textiles
	Medium	Upholstery cushions (sofa, high class carpets, rugs and runners)
	Normal Normal	carpets
	Medium strong	Long-haired carpets
	Strong	Hard floors (highest setting)

Tip:Depends on your need, you can varied the suction power by adjusting the suction flap on the handle.

Fig.11 Switch the vacuum cleaner off after use and unplug it when you have finished working.
Fig.12 Wind the power cable around the cable storage device by pressing the automatic cable retraction switch. While you are doing this keep the cable taut, if possible.

Parking system for pauses in vacuuming

Fig. 13 You can store the telescopic tube with the floor nozzle on the vacuum cleaner for short pauses in vacuuming. Insert the floor nozzle with the parking attachments into the parking system.

Transport and storage

Fig. 14 To carry your vacuum cleaner grasp it by the handle. To store your vacuum cleaner, the suction tube with the floor nozzle can be mounted on the back of the vacuum cleaner in an upright position.

Cleaning and care

Warning

• When cleaning, never use solvents or abrasive materials, hard brushes, metallic or sharp objects. Solvents are harmful to human health and can attack plastic parts, while abrasive cleaning mechanisms and tools may scratch the surface(s).
• Never immerse any electrical parts of the product in water or in other liquids during cleaning. Never place it under running water.

Changing dust bag

Fig.15 If the dust bag fill indicator shows red or if the suction power diminishes, the dust bag must be changed and the filters must be cleaned. Open the lid and put it out. Remove the dust bag by taking it out of the dust bag holder. Insert a new dust bag into the dust bag holder and closed the lid.

Cleaning the motor filter

Fig. 16 Remove the motor filter and tap it to remove the dust. Then re-insert it. Reassemble all of the components that have previously been removed. Assembly is carried out in reverse order.

Warning

Never use the vacuum cleaner without a motor filter, as otherwise, the motor will soon get dirty and will be subject to wear. If the motor filter gets dirty, the suction power will diminish.

Cleaning the exhaust air filter (Part N)

Fig.17 Open the flap, take the filter out and tap it to remove the dust. Assembly is carried out in reverse order. Insert the filter in the right direction so that the correct side is facing the motor.

Technical data

Rated Voltage:220-240V~

Rated input power : 700 W

Rated frequency : 50/60 Hz

Protection class : II

This is a general purpose vacuum cleaner
The Erp test method is according to (EU) No 666/2013, (EU) No 665/2013 & EN 60312:2013
- Please refer to below website for detail technical information, or contact the manufacturer for technical document:

www.koenic-online.com

Espanol

Borsta for hards underlag (Del I)

Fig.8 For dammsugning av hards golv ellertragolv, Skyddar golvet fran repor.

Användning

Energy efficiency class: A
- Indicative annual energy consumption 24,4 kWh per year, based on 50 cleaning tasks. Actual annual energy consumption will depend on how the appliance is used.
- Carpet cleaning performance class: C
- Hard floor cleaning performance class: A
Dust re-emission class: A
Sound power level: 74 dB
The rated input power: 700 W

PRODUKTDATENBLATT // PRODUCT FICHE // FICHA DE PRODUCTO // FICHE PRODUIT

Imtron GmbH

KVC3221A

ES
