(29) Dust extraction adapter

(30) Dust extraction hose

(31) Reference mark for cutting depth setting (32) Parallel guide/guide rail adapter

(33) Pair of screw clamps

Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Technical data Hand-held circular saw GKS 12V-26 Article number 3 601 FA1 0.. Rated voltage V 12 No-load speed rpm 1400 Max. cutting depth – at a 0° mitre/bevel angle mm 26.5 – at a 45° mitre/bevel angle mm 17.0 Spindle lock ● Base plate dimensions mm 167 x 88 Max. saw blade diameter mm 85 Min. saw blade diameter mm 85 Max. base blade thickness mm 0.7 Max. tooth thickness/offset mm 1.1 Min. tooth thickness/offset mm 1.0 Locating bore mm 15 Weight according to EPTA-Procedure 01:2014 kg 1.3–1.6

Permitted ambient temperature – during charging °C 0 to +45 – during operation

and during storage °C -20 to +50 Recommended batteries GBA 12V... GBA 10.8V... English | 17 Bosch Power Tools 1 609 92A 4LK | (22.10.2018)18 | English 1 609 92A 4LK | (22.10.2018) Bosch Power Tools Hand-held circular saw GKS 12V-26 Recommended chargers GAL 12.. AL 11.. A) Depends on battery in use B) Limited performance at temperatures <0°C Noise/Vibration Information Noise emission values determined according toEN62841-2-5. Typically, the A-weighted noise level of the power tool is: Sound pressure level 82dB(A); sound power level 93dB(A). Uncertainty K=3dB. Wear hearing protection Total vibration values a

(triax vector sum) and uncertainty K determined according toEN62841-2-5: Sawing wood: a

EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regulations listed below and are in conformity with the following standards. Technical file at: * Hand-held circu- lar saw Article number
