USER MANUAL GSR 660 TE Professional BOSCH

(2) Stop sleeve (3) Adjusting sleeve for screw depth stop (4) Screw depth stop (5) Belt clip (6) Lock-on button for on/off switch (7) On/off switch (8) Rotational direction switch (9) Handle (insulated gripping surface) (10) Universal bit holder

(triax vector sum) and uncertainty K determined according to EN 62841-2-2: Screwdriving:

The vibration level and noise emission value given in these instructions have been measured in accordance with a standardised measuring procedure and may be used to com- pare power tools. They may also be used for a preliminary estimation of vibration and noise emissions. The stated vibration level and noise emission value repres- ent the main applications of the power tool. However, if the power tool is used for other applications, with different ap- plication tools or is poorly maintained, the vibration level and noise emission value may differ. This may significantly increase the vibration and noise emissions over the total working period. To estimate vibration and noise emissions accurately, the times when the tool is switched off or when it is running but not actually being used should also be taken into account. This may significantly reduce vibration and noise emissions over the total working period. Implement additional safety measures to protect the oper- ator from the effects of vibration, such as servicing the power tool and application tools, keeping their hands warm, and organising workflows correctly. Assembly u Pull the plug out of the socket before carrying out any work on the power tool. Changing the Tool (see figure A) Pull the depth stop (4) off towards you. Pull the screwdriver bit (1) out. If required, the universal bit holder (10) can also be pulled out and replaced. After changing the tool, reattach the depth stop . Operation Starting Operation u Pay attention to the mains voltage. The voltage of the power source must match the voltage specified on the rating plate of the power tool. Power tools marked with 230V can also be operated with 220V. u Products that are only sold in AUS and NZ: Use a resid- ual current device (RCD) with a nominal residual current of 30 mA or less. Setting the Rotational Direction The rotational direction switch (8) is used to change the ro- tational direction of the power tool. However, this is not pos- sible while the on/off switch (7) is being pressed. – Clockwise: To drive in screws, press the rotational direc- tion switch (8) through as far as possible to the left. – Anti-clockwise: To loosen or unscrew screws, press the rotational direction switch (8) through as far as possible to the right. Switching on/off To start the power tool, press and hold the on/off switch (7). Press the lock-on button (6) to lock the on/off switch (7) in this position. To switch off the power tool, release the on/off switch (7); or, if the switch is locked with the lock-on button (6), briefly press the on/off switch (7) and then release it. Adjusting the Speed You can adjust the speed of the power tool when it is on by pressing in the on/off switch (7) to varying extents. A light pressure on the on/off switch (7) results in a low rota- tional speed. Increased pressure on the switch causes an in- crease in speed. Adjusting the screw-in depth (see figure B) The depth to which the screw head is screwed into the work- piece can be preset by turning the adjusting sleeve (3) to 8 engaging steps for each rotation. Each step corresponds to a

0.25 mm change in the screw-in depth.

EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regulations listed below and are in conformity with the following standards. Technical file at: * Screwdriver Article number
