USER MANUAL BDV212 BLACK & DECKER

Your Black & Decker travel cooler/freezer and warmer provides convenient temporary storage for cold or hot beverages and foods. This appliance is intended for consumer use only.

Safety instructions

Warning! When using battery-powered appliances, basic safety precautions, including the following, should always be followed to reduce the risk of fire, leaking batteries, personal injury and material damage.

◆ Read all of this manual carefully before using the appliance.
The intended use is described in this manual. The use of any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.
◆ Retain this manual for future reference.

Using your appliance

Always take care when using the appliance.

• This appliance is not intended for use by young or infirm persons without supervision.
  ◆ The appliance is not to be used as a toy.
  ◆ Use in a dry location only. Do not allow the unit to become wet.
  ◆ Do not immerse the appliance in water.
  Do not open body casing. There are no user-serviceable parts inside.
  Do not operate the appliance in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
  ◆ To reduce the risk of damage to plugs and cords never pull the cable to remove the plug from a socket outlet.

After use

When not in use, the appliance should be stored in a dry, well ventilated place out of the reach of children.
◆ Children should not have access to stored appliances.
When the appliance is stored or transported in a vehicle it should be placed in the boot or restrained to prevent movement following sudden changes in speed or direction.

Inspection and repairs

Before use, check the appliance for damaged or defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.
- Do not use the appliance if any part is damaged or defective.
◆ Have any damaged or defective parts repaired or replaced by an authorised repair agent.
- Never attempt to remove or replace any parts other than those specified in this manual.

The following symbols are found on your appliance:

COLD/OFF/HOT switch (4), hot position.

COLD/OFF/HOT switch (4), cold position.

Low vehicle battery indication.

Vehicle dc power cord.

The appliance is intended to maintain the temperature of pre-heated or pre-cooled food and beverages. It is not designed to warm or cook items from cold.
This unit is intended for use with a 12 Vdc power source that can provide at least 5 amps of current. DO NOT attempt to use with any other power source.
- Never operate unit in an enclosed space. ALWAYS ensure that there is adequate ventilation and free flow of air around the unit, so that air expelled by the fan is effectively dissipated.
When operating the unit in a vehicle or boat cabin, adequate ventilation must be provided by an air conditioning system or open window. In a car with windows up, air temperatures can reach 65°C.
This unit is intended for portable use only; it is not designed to be built-in or recessed, this would interfere with the unit's air dissipation system, and could cause a fire or other safety hazard.
Use only with the supplied power cord. If the cord becomes worn or damaged, discontinue use and have the cord replaces by an authorised Black & Decker repair agent.
Do not place food and beverages directly into the heating/cooling chamber. Seal the food or beverage in a suitable container before placing into the appliance.
This unit does not automatically turn on and off. Do not operate unattended for extended periods of time.
The interior of this unit gets hot in the warming mode. Take care when placing containers in or removing containers from the appliance.
- The cooler will automatically shut-off when vehicle battery power falls below 10.7 Volts. When operating from a vehicle battery, start your engine after 3-4 hours of operation to recharge the vehicle battery.
If the engine is switched off for a long period (overnight), it is recommended the appliance is disconnected from the accessory outlet to avoid draining the vehicle's battery.
◆ This appliance is not approved for medical use.
◆ Instructions for food hygiene
- Food and beverages will maintain their temperature for some time after the unit is disconnected or turned off,

ENGLISH

but the temperature will eventually rise to that of the surrounding air.

• Observe hygiene rules common to any food preparation appliance. Do not eat or drink perishable items that may have spoiled or become contaminated.
• Clean the appliance thoroughly after use and before subsequent uses.

Features

This appliance includes some or all of the following features:

1. Low vehicle battery LED indicator
2. Hot LED indicator
3. Cold LED indicator
4. On/off switch
5. Padded top
6. Storage pouch
7. Built-in heat dissipation fan
8. Vehicle dc power cord

USE

Connecting to a portable 12 Vdc power supply, for use away from the vehicle (fig.A)

◆ Move the COLD/OFF/HOT switch (4) to the OFF position.
◆ Insert the 12 Vdc plug on the power cord (8) into the 12 Vdc socket on the portable power supply.

Note: Keep the COLD/OFF/HOT switch (4) in OFF position for five minutes before switching between HOT and COLD.

Using the appliance as a cooler

• Move the COLD/OFF/HOT switch (4) to the OFF position. Start the vehicle or turn the ignition switch to the "accessory" position.
  ◆ Insert the 12 Vdc plug on the power cord (8) into the vehicle's 12 Vdc accessory outlet.
  ◆ Move the COLD/OFF/HOT switch (4) to the COLD position.
• The COLD LED indicator (3) will light to show that the unit is cooling.
  ◆ Place items into the cooler and close the lid. Do not overfill the cooler, make sure that the lid can close.
• Keep the cooler lid closed during use and close it quickly after adding or removing items.
  ◆ After use, move the COLD/OFF/HOT switch (4) to the OFF position and remove all food items.
  ◆ Disconnect the vehicle dc power cord (8) from the vehicle's accessory outlet.
  ◆ Clean the unit as described in the Maintenance section.

Using the appliance as a warmer (fig. A)

◆ Move the COLD/OFF/HOT switch (4) to the OFF position. Start the vehicle, or turn the ignition switch to the "accessory" position.

◆ Insert the 12 Vdc plug on the power cord (8) into the vehicle's 12 Vdc accessory outlet.
◆ Move the COLD/OFF/HOT switch (4) to the HOT position.
- The HOT LED indicator (2) will light to show that the unit is warming.
Put items into the warmer and close the lid. Do not overfill the warmer. Make sure that the lid can close.
◆ The unit's warming system is thermostatically controlled.
- Keep the warmer lid closed during use, and close it quickly after adding or removing items.
◆ After use, move the COLD/OFF/HOT switch (4) to the OFF position and remove all food items.
◆ Disconnect the vehicle dc power cord (8) from the vehicle's accessory outlet.
◆ Clean the unit as described in the Maintenance section.

To change this appliance to a freezer (fig B)

Fill the sealable ice tray (9) (included) a quarter full with water. Fit the lid and place the tray at the bottom of the cooler.
◆ Place the freezer insulation pad (10) (included) on top of the sealed ice tray to convert the cooler to a freezer.

Hints for optimum use

The warmer takes about 100-120 minutes to reach its maximum warm temperature (approx. 48 °C). It is recommended that items to be stored in the warmer be preheated. This will assist the warmer in reaching the maximum temperature as quickly as possible.

The cooler takes about 120-200 minutes to reach its maximum cool temperature (approximately 27 °C below that of surrounding air). It is recommended that items to be placed in the cooler be pre-chilled. This will assist the cooler in reaching the lowest temperature as quickly as possible.

The travel cooler/freezer and warmer can be used with most food and drinks, either cold or hot. Use with standard household containers or ready-to-use food and drink packaging.

MAINTENANCE

Your Black & Decker tool has been designed to operate over a long period of time with a minimum of maintenance.

Continuous satisfactory operation depends upon proper tool care and regular cleaning.

Warning! Before performing any maintenance or cleaning on the appliance, unplug the appliance.

- From time to time wipe the appliance with a damp cloth. Do not use any abrasive or solvent-based cleaner. Do not immerse the appliance in water.

Protecting the environment

Should you find one day that your appliance needs replacement, or if it is of no further use to you, think of the protection of the environment. Black & Decker repair agents will accept old Black & Decker tools and ensure that they are disposed of in an environmentally safe way.

Separate collection of used products and packaging allows materials to be recycled and used again. Re-use of recycled materials helps prevent environmental pollution and reduces the demand for raw materials.

Local regulations may provide for separate collection of electrical products from the household, at municipal waste sites or by the retailer when you purchase a new product.

Black & Decker provides a facility for the collection and recycling of Black & Decker products once they have reached the end of their working life. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf.

You can check the location of your nearest authorised repair agent by contacting your local Black & Decker office at the address indicated in this manual. Alternatively, a list of authorised Black & Decker repair agents and full details of our after-sales service and contacts are available on the Internet at: www.2helpU.com.

Technical data

	BDV212F
Voltage Vdc 12
Input current A 5
Cable length m 2.1
Container size I 9
Weight kg 4.3
Climatic class T

EC declaration of conformity

BDV212F

Black & Decker declares that these products conform to:

Standards & Legislation.

95/54/EC, 73/23/EEC, 89/336/EEC, EN60335,

EN50366, EMC E4

Kevin Hewitt

Director of Consumer Engineering

Spennymoor, County Durham

DL16 6JG,

United Kingdom

31-08-2006

Guarantee

Black & Decker is confident of the quality of its products and offers an outstanding guarantee. This guarantee statement is in addition to and in no way prejudices your statutory rights. The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area.

If a Black & Decker product becomes defective due to faulty materials, workmanship or lack of conformity, within 24 months from the date of purchase, Black & Decker guarantees to replace defective parts, repair products subjected to fair wear and tear or replace such products to make sure of the minimum inconvenience to the customer unless:

• The product has been used for trade, professional or hire purposes.
  ◆ The product has been subjected to misuse or neglect.
• The product has sustained damage through foreign objects, substances or accidents.
  ◆ Repairs have been attempted by persons other than authorised repair agents or Black & Decker service staff.

To claim on the guarantee, you will need to submit proof of purchase to the seller or an authorised repair agent. You can check the location of your nearest authorised repair agent by contacting your local Black & Decker office at the address indicated in this manual. Alternatively, a list of authorised Black & Decker repair agents and full details of our after-sales service and contacts are available on the Internet at:

www.2helpU.com

Please visit our website www.blackanddecker.co.uk to register your new Black & Decker product and to be kept up to date on new products and special offers. Further information on the Black & Decker brand and our range of products is available at www.blackanddecker.co.uk.
