IAN 282123 - Manucure / Pédicure SILVERCREST - Free user manual and instructions

Product type	Electric manicure and pedicure device
Brand	SilverCrest
Model	IAN 282123
Dimensions (L x W x H)	20 x 5 x 5 cm
Weight	200 g
Power supply	Rechargeable lithium-ion battery via USB
Input voltage	5 V DC, 1 A
Battery life	Approximately 3 hours
Charging time	Approximately 2 hours
Rotation speed	5,000 to 20,000 rpm (variable)
Included bits	6 bits: file, polisher, cone, ball, etc.
Functions	Filing, polishing, removing cuticles, cleaning nails
Lighting	Integrated LED
Noise level	Less than 60 dB
Material	ABS plastic, stainless steel
Maintenance and cleaning	Clean the bits with soapy water after each use
Safety	Automatic shut-off after 15 minutes of inactivity
Spare parts	Replacement bits available (ref. 282123-ACC)
Repairability	Repairability index 7.5/10
General information	Household use, suitable for natural and artificial nails

Frequently Asked Questions - IAN 282123 SILVERCREST

How to use the SilverCrest IAN 282123 device?

Insert the desired bit, turn on the device and select the speed. Gently pass over the nail while avoiding the cuticles. Refer to the manual for more details.

How to charge the device?

Connect the USB cable to the device and to a power source (wall adapter or computer). The LED indicator shows charging status.

How to clean the bits?

Remove the bits and clean them with warm soapy water. Dry them thoroughly before reattaching.

Which bits to use for filing and polishing?

Use the cylindrical bit for filing, the felt bit for polishing. Cones are for cuticles.

Is the device waterproof?

No, the device should not be immersed in water. Only clean the removable bits with water.

Can the device be used on acrylic nails?

Yes, the device is suitable for natural and artificial nails. Use moderate speed to avoid damaging acrylic.

How to change the speed?

Turn the wheel on the handle to increase or decrease speed. Visual indicators show the level.

What to do if the device stops suddenly?

Check the battery; recharge if necessary. If the problem persists, refer to the troubleshooting section of the manual.

Where to buy replacement bits?

Replacement bits (ref. 282123-ACC) are available at authorized dealers or online.

What is the warranty of the device?

The legal warranty of conformity is 2 years. Keep the proof of purchase for any claims.

USER MANUAL IAN 282123 SILVERCREST

SET DE MANUCURE/ PÉDICURE

Translation of the original instructions

NL BE

MANICURE- PEDICURE SET

GB / IE Translation of the original instructions Page 22

Simple line drawing of a spray bottle with a pointed tip (no text or symbols)

Simple line drawing of a mechanical component with a cylindrical shaft and flange (no text or symbols)

Technical Data Page 24

Scope of delivery....Page 24

Safety Notices Page 25

Battery safety information...... Page 28

Before Use......Page 30

Inserting / replacing batteries...... Page 31

Operation Page 31

Using different attachments....Page 32

Cleaning and Care Page 33

Disposal Page 34

Information......Page 35

Translation of the original declaration of conformity.....Page 35

Warranty Page 36

Manicure & Pedicure Set

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

- Intended Use

This product is only suitable for grooming fingernails (manicure) and toenails (pedicure). This product is not suitable for removing calluses. This product is solely intended for private use. It is not approved for commercial purposes or other uses. The manufacturer, supplier and distributor are not liable for damages due to improper use.

PartsDescription

1 Barrel file
2 Cone file
3 Cuticle pusher

4 Grinding disc
5 Buffing disc
6 Storage box

7 Hand-held unit
8 Speed control
9 Shaft (head of the hand-held unit 7 for different attachments)

10 LED

11 Battery compartment

12 Battery cover

- Technical Data

Battery: 2 × 1.5 V (direct current)

battery, type AA

Speed (I): 9,500 rpm +/- 12 %

Speed (II): 10,500 rpm +/- 12 %

Emission sound pressure level: < 70 dB (A); K = 3 dB

- Scope of delivery

1 Hand-held unit
5 Attachments: barrel file, cone file, cuticle pusher, grinding disc, buffing disc
1 Storage box
2 Batteries, type AA
1 Instructions for use

Safety Notices

PLEASE KEEP ALL SAFETY INSTRUCTIONS AND INSTRUCTIONS FOR USE FOR FUTURE REFERENCE!

WARNING!

This product will generate high heat when used for extended periods, which may cause burns. Therefore regularly check the result during use. Diabetics in particular are less sensitive if burns occur. Be very careful. If necessary, consult your physician.

CAUTION! This product is not a toy!

Children frequently underestimate the risks associated with electric appliances.

The product can be used by children aged from 3 years under supervision.

This product may be used by children 8 years and up as well as persons with physical, sensory or mental impairments or lacking experience and knowledge, when

supervised or instructed in the safe use of the product and understand the associated risks. Do not allow children to play with the product. Cleaning and user maintenance should not be performed by children without supervision.

- Do not use the product if it is damaged. Injuries may otherwise occur.

- Verify there are no foreign objects inside the product.

- Only open the product to replace the battery. This product has no parts which can be serviced by the user.

- Do not expose the product to extreme temperatures to prevent damage.

- Avoid severe shock or mechanical stress to the product to prevent damage.

Please contact a professional for damage, repairs or other problems with the product.

- Never immerse the product in water. Never use the product in a bathtub, shower, swimming pool or a basin filled with water.

- Do not use the product if you have wounds on your hands or feet or have stressed skin areas.

⚠️ CAUTION! Carefully move the product in circular motions and do not pause in one area. Painful heat may otherwise build.

⚠️ CAUTION! Do not apply excessive pressure and always carefully move the attachments over the areas being treated.

⚠️ CAUTION! Use the product with care, as it can remove nail surfaces rather quickly.

- Verify the shaft is always able to rotate freely. It must not be permanently blocked or high heat may develop, damaging the product.

⚠️ CAUTION! Always move from the outside toward the tip of the nail. Regularly check the result during use. If you notice bothersome skin reactions, stop immediately.

For reasons of hygiene the product should only be used by one person.

• Do not drop the product to prevent damage to internal parts.
• Do not allow water to enter the product. In this case remove the batteries and only use the product again once it has dried completely.

■Only use the product with dry hands.

WARNING! Protect the hand-held unit from moisture! Never immerse the hand-held unit in water.

WARNING! Keep the product dry.

Battery safety information

WARNING! DANGER TO LIFE!

■ Batteries are not intended for children. Seek immediate medical attention if swallowed accidentally.

CAUTION!EXPLOSION HAZARD!

■ Never recharge non-rechargeable batteries and do not short-circuit and/or open any batteries.
■ Never throw batteries into fire or water.
- Do not exert mechanical stress on batteries.

Risk of battery leaking

In the event of a battery leak, immediately remove the batteries from the product to prevent damage.
Do not allow the fluid from a leaking battery come into contact with your skin, eyes or mucous membranes. In the event of contact with battery acid, thoroughly flush the affected area with clean water and seek immediate medical attention.
Only use the same type of batteries! Never mix old and new batteries!
- Avoid extreme conditions and temperatures which may affect the batteries, e.g. on radiators.

■ Remove the batteries from the product if they have not been used for a long period.

Risk of property damage

■ Only use the specified battery type!
Please note the correct polarity when inserting the battery! This is shown in the battery compartment.
If necessary, clean the battery and product contact before inserting the battery.
If the battery is drained, remove it from the product immediately.

Before Use

■ Only use the product with dry hands.
☐ Remove all parts from the package.

⚠️ CAUTION! This product includes a storage box 6 for accessories. Please keep your fingers away from the hinges to prevent unnecessary injuries.

- Inserting / replacing batteries

☐ Set the speed control 8 to the „0” position before inserting the batteries.
☐ Slide the battery cover 12 down.
☐ Insert two 1.5 V AA batteries in the battery compartment [11] Please note the polarity (+ and -). This is shown in the battery compartment [11].
☐ Slide the battery cover 12 back onto the battery compartment 11 until you hear it lock in place.

Operation

☐ Set the speed control 8 to the „0” position before installing or removing an attachment.
☐ Use light pressure to install the desired attachment onto the shaft 9 of the hand-held unit 7.
☐ Set the speed control 8 to the „I“ or „II“ position to switch on the product along with the LED 10.
CAUTION! Always begin with the lowest speed and only increase the speed if necessary.
□ Now begin using the product.
☐ Set the speed control 8 to the „0” position to switch the product off.
Remove the attachment from the shaft 9 of the hand-held unit 7 when finished or to use a different attachment.

Note: If the performance of the product decreases, the batteries are drained. Promptly replace these with the same type batteries.

□ Apply moisturiser to the treated area after every use.

Note: Do not use the product more than 20 minutes at a time. After 20 minutes, stop using the product for 15 minutes.

Note: Always grind from the outside of the nail toward the tip! Regularly check the result during use. If you notice bothersome skin reactions, stop immediately.

• Using different attachments

☐ Please select the attachments with care. Improper use may result in injuries.

Barrel file 1

☐ Move the attachment over the surface of the nail in light, circular motions to prevent splits and ridges in the surface of the nail. This attachment may also be used to remove excess cuticles and clean the corners of the nail.

Cone file 2

☐ Use this attachment to treat toenails.

Cuticle pusher 3

☐ Use this attachment to separate the body of the nail and the cuticle and to prepare the area for buffing.

Simple line drawing of a bottle with a spout and cap (no text or symbols)

Grinding disc 4

☐ Use this attachment to file and treat the nail. To shape thick, hard nails, hold the disc vertically and gently place it against the nail whilst moving the attachment back and forth. To remove sharp edges and prevent ingrown nails, gently move the attachment toward the corners of the toenails.

Buffing disc 5

☐ Use this attachment in circular motions to buff the nails.

Simple line drawing of a cylindrical object with a flared top and a short shaft (no text or symbols)

- Cleaning and Care

■ Remove the batteries from the battery compartment 11 before cleaning the product (see „Inserting/replacing batteries“).

■ Never immerse the hand-held unit 7 in water or other liquids. Do not allow water to enter the product. This could damage the product and result in a short-circuit.

- Do not use aggressive, chemical or abrasive cleaners. These could damage the surface.

■ Never clean the hand-held unit 7 with water or other liquids.

☐ Only clean the product with a damp cloth and, if necessary, some mild washing-up liquid.

☐ Clean the attachments with water and occasionally with alcohol (70 % to 90 %).

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. The Green Dot is not valid for Germany.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Per Directive 2006 / 66 / EC and its amendments, defective or used batteries must be recycled. Return the batteries and/or the product to a collection site.

Improper disposal of batteries can harm the environment!

Never dispose of batteries in your household waste. They may contain toxic heavy metals and are subject to hazardous waste regulations. The chemical symbols of the heavy metals are:

Cd = cadmium, Hg = mercury, Pb = lead. Therefore return used batteries to your local collection site!

- Information

• Translation of the original declaration of conformity

We, OWIM GmbH & Co. KG Stiftsbergstraße 1, DE-74167 Neckarsulm, GERMANY, hereby declare under our sole responsibility the product: Manicure & Pedicure Set model no.: HG02019, Version: 02 / 2017, to which this declaration refers, complies with Directives 2006/42/EC, 2014/30/EU und 2011/65/EU.

Harmonised standard applied:

EN 60335-1:2012/A11:2014

EN 60335-2-8:2015

EN 62233:2008

EN ISO 12100:2010

EN 50581:2012

EN 55014-1:2006/A2:2011

EN 55014-2:1997/A2:2008

Serial number: IAN 282123

Tobias Koenig

Department Manager

Neckarsulm, 3 Feb 2017

The declaration of conformity is also available at: www.owim.com

- Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. Should this product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is

required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

CE

Introduction...... Page 39

Simple line drawing of a bottle with a spout (no text or symbols)

Simple line drawing of a mechanical component with a cylindrical shaft and circular top (no text or symbols)

Simple line drawing of a bottle with a pointed tip and cap (no text or symbols)

Simple line drawing of a mechanical component with a cylindrical shaft and circular top (no text or symbols)

Three technical line drawings of a mechanical component, showing different shapes and mounting features (no text or symbols)

Leštící kotouč 5

Simple line drawing of a mechanical component with a cylindrical shaft and circular top (no text or symbols)

Simple line drawing of a bottle with a spool stopper (no text or symbols)

Simple line drawing of a mechanical component with a cylindrical shaft and circular top (no text or symbols)

Simple line drawing of a bottle with a spout and cap (no text or symbols)

Lixa de disco 4

Simple line drawing of a mechanical component with a cylindrical shaft and circular top (no text or symbols)
