IAN 290040 - Manucure / Pédicure SILVERCREST - Free user manual and instructions

Product type	Electric manicure/pedicure set
Brand	SilverCrest
Model	IAN 290040
Power supply	Batteries (2x AA, not included)
Dimensions (approx.)	20 x 4 x 4 cm
Weight (approx.)	150 g
Speeds	2 adjustable speeds
Rotation direction	Reversible (left/right)
Number of bits	6 sanding and polishing bits
Main functions	Cut, file, polish nails and cuticles
Maintenance and cleaning	Clean the bits with a damp cloth; do not immerse the housing
Safety	Automatic shut-off after 15 minutes of inactivity; overheating protection
Spare parts	Replacement bits available under reference 290040
Repairability	Repairability index not provided; replaceable batteries
Warranty	2-year legal warranty of conformity
General information	Use for natural and artificial nails

Frequently Asked Questions - IAN 290040 SILVERCREST

How to change the bits on the SilverCrest IAN 290040?

To change a bit, gently pull on the current bit to remove it, then insert the new bit until it clicks. Make sure the device is off.

How to clean the device and bits?

Clean the bits with a damp cloth after each use. The housing can be wiped with a dry cloth. Never immerse the device in water.

Which batteries to use?

Use two AA (LR6) 1.5 V batteries. Rechargeable batteries are also compatible. Insert them respecting the polarity indicated in the compartment.

Why does the device no longer rotate?

First check the batteries: if they are dead, replace them. Also make sure the switch is in the on position. If the problem persists, contact customer service.

The device makes an abnormal noise, what should I do?

An abnormal noise may be due to a poorly attached bit or blockage. Stop the device and check that the bit is properly engaged. Also clean the rotation shaft.

How to adjust the speed?

The device has a sliding switch with two positions: low speed (I) and high speed (II). Choose the speed suitable for your use.

Can I use the device on artificial nails?

Yes, this device is designed for natural and artificial nails. Use the appropriate bits (gentle sanding for artificial nails).

How to reverse the rotation direction?

A switch located near the head allows switching from right rotation (clockwise) to left (counterclockwise). This makes it easier to work with both hands.

What to do if the bit is stuck?

If a bit is stuck, do not use force. Try to unscrew it gently by hand. If necessary, use fine-tipped pliers. Contact customer service if the problem persists.

Where can I find replacement bits?

Replacement bits are available under reference IAN 290040 from the manufacturer SilverCrest or in specialist stores. Check compatibility with your model.

USER MANUAL IAN 290040 SILVERCREST

SET DE MANUCURE/ PÉDICURE

Translation of the original instructions

NL BE

MANICURE-

PEDICURE SET

GB / IE Translation of the original instructions Page 23

Simple line drawing of a bottle with a pointed tip and bulb (no text or symbols)

Feilscheibe 4

Simple line drawing of a mechanical component with a cylindrical shaft and circular top (no text or symbols)

Technical Data Page 25

Scope of delivery....Page 25

Safety Notices Page 26

Safety instructions for batteries / rechargeable batteries Page 29

Before Use Page 32

Inserting / replacing batteries...... Page 32

Operation Page 33

Using different attachments....Page 33

Cleaning and Care Page 35

Disposal Page 35

Information......Page 37

Translation of the original declaration of conformity.....Page 37

Warranty Page 38

Manicure & Pedicure Set

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

- Intended Use

This product is only suitable for grooming fingernails (manicure) and toenails (pedicure). This product is not suitable for removing calluses. This product is solely intended for private use. It is not approved for commercial purposes or other uses. The manufacturer, supplier and distributor are not liable for damages due to improper use.

PartsDescription

1 Barrel file
2 Cone file
3 Cuticle pusher

4 Grinding disc
5 Buffing disc
6 Storage box

7 Hand-held unit
8 Speed control
9 Shaft (head of the hand-held unit 7 for different attachments)

10 LED

11 Battery compartment

12 Battery cover

- Technical Data

Battery: 2 x 1.5 V (direct current)

battery, type AA (LR6)

Speed (I): 9,500 rpm +/- 12 %

Speed (II): 10,500 rpm +/- 12 %

Emission sound pressure level: < 70 dB (A); K = 3 dB

- Scope of delivery

1 Hand-held unit
5 Attachments: barrel file, cone file, cuticle pusher, grinding disc, buffing disc
1 Storage box
2 Batteries, type AA (LR6)
1 Instructions for use

Safety Notices

PLEASE KEEP ALL SAFETY INSTRUCTIONS AND INSTRUCTIONS FOR USE FOR FUTURE REFERENCE!

WARNING!

This product will generate high heat when used for extended periods, which may cause burns. Therefore regularly check the result during use. Diabetics in particular are less sensitive if burns occur. Be very careful. If necessary, consult your physician.

CAUTION! This product is not a toy!

Children frequently underestimate the risks associated with electric appliances.

The product can be used by children aged from 3 years under supervision.

This product may be used by children 8 years and up as well as persons with physical, sensory or mental impairments or lacking experience and knowledge, when

supervised or instructed in the safe use of the product and understand the associated risks. Do not allow children to play with the product. Cleaning and user maintenance should not be performed by children without supervision.

- Do not use the product if it is damaged. Injuries may otherwise occur.

- Verify there are no foreign objects inside the product.

- Only open the product to replace the battery. This product has no parts which can be serviced by the user.

- Do not expose the product to extreme temperatures to prevent damage.

- Avoid severe shock or mechanical stress to the product to prevent damage.

Please contact a professional for damage, repairs or other problems with the product.

- Never immerse the product in water. Never use the product in a bathtub, shower, swimming pool or a basin filled with water.

- Do not use the product if you have wounds on your hands or feet or have stressed skin areas.

⚠️ CAUTION! Carefully move the product in circular motions and do not pause in one area. Painful heat may otherwise build.

⚠️ CAUTION! Do not apply excessive pressure and always carefully move the attachments over the areas being treated.

⚠️ CAUTION! Use the product with care, as it can remove nail surfaces rather quickly.

- Verify the shaft is always able to rotate freely. It must not be permanently blocked or high heat may develop, damaging the product.

⚠️ CAUTION! Always move from the outside toward the tip of the nail. Regularly check the result during use. If you notice bothersome skin reactions, stop immediately.

For reasons of hygiene the product should only be used by one person.

- Do not drop the product to prevent damage to internal parts.

- Do not allow water to enter the product. In this case remove the batteries and only use the product again once it has dried completely.

■Only use the product with dry hands.

WARNING! Protect the hand-held unit from moisture! Never immerse the hand-held unit in water.

WARNING! Keep the product dry.

Safety instructions forbatteries/rechargeable batteries

■ DANGER TO LIFE! Keep batteries / rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.

DANGER OF EXPLOSION!

Never recharge

non-rechargeable batteries. Donot short-circuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries / rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries / rechargeable batteries.

Risk of leakage of batteries / rechargeable batteries

• Avoid extreme environmental conditions and temperatures, which could affect batteries / rechargeable batteries, e.g. radiators / direct sunlight.
  If batterie / rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES!

Leaked or damaged batteries /

rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

In the event of a leakage of batteries / rechargeable batteries, immediately remove them from the product to prevent damage.
Only use the same type of batteries / rechargeable batteries. Do not mix used and new batteries / rechargeable batteries.
■ Remove batteries/rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

■ Only use the specified type of battery / rechargeable battery!

- Insert batteries / rechargeable batteries according to polarity marks (+) and (-) on the battery / rechargeable battery and the product.

• Clean the contacts on the battery /rechargeable battery and in the battery compartment before inserting!
  ■ Remove exhausted batteries/rechargeable batteries from the product immediately.

- Before Use

■ Only use the product with dry hands.
☐ Remove all parts from the package.

CAUTION! This product includes a storage box 6 for accessories. Please keep your fingers away from the hinges to prevent unnecessary injuries.

- Inserting / replacing batteries

☐ Set the speed control 8 to the „0” position before inserting the batteries.
☐ Slide the battery cover 12 down.
☐ Insert two 1.5 V AA batteries in the battery compartment 11 . Please note the polarity (+ and -). This is shown in the battery compartment 11 .
☐ Slide the battery cover 12 back onto the battery compartment 11 until you hear it lock in place.

Operation

☐ Set the speed control 8 to the „0” position before installing or removing an attachment.
☐ Use light pressure to install the desired attachment onto the shaft 9 of the hand-held unit 7.
☐ Set the speed control 8 to the „I” or „II” position to switch on the product along with the LED 10.

CAUTION! Always begin with the lowest speed and only increase the speed if necessary.

□ Now begin using the product.
☐ Set the speed control 8 to the „0” position to switch the product off.
Remove the attachment from the shaft 9 of the hand-held unit 7 when finished or to use a different attachment.

Note: If the performance of the product decreases, the batteries are drained. Promptly replace these with the same type batteries.

□ Apply moisturiser to the treated area after every use.

Note: Do not use the product more than 20 minutes at a time. After 20 minutes, stop using the product for 15 minutes.

Note: Always grind from the outside of the nail toward the tip! Regularly check the result during use. If you notice bothersome skin reactions, stop immediately.

• Using different attachments

☐ Please select the attachments with care. Improper use may result in injuries.

Barrel file 1

☐ Move the attachment over the surface of the nail in light, circular motions to prevent splits and ridges in the surface of the nail. This attachment may also be used to remove excess cuticles and clean the corners of the nail.

Cone file 2

☐ Use this attachment to treat toenails.

Cuticle pusher 3

☐ Use this attachment to separate the body of the nail and the cuticle and to prepare the area for buffing.

Grinding disc 4

☐ Use this attachment to file and treat the nail. To shape thick, hard nails, hold the disc vertically and gently place it against the nail whilst moving the attachment back and forth. To remove sharp edges and prevent ingrown nails, gently move the attachment toward the corners of the toenails.

Buffing disc 5

☐ Use this attachment in circular motions to buff the nails.

Simple line drawing of a bottle with a spout and cap (no text or symbols)

Simple line drawing of a cylindrical object with a flared top and a short shaft (no text or symbols)

- Cleaning and Care

■ Remove the batteries from the battery compartment 11 before cleaning the product (see „Inserting/replacing batteries“).

■ Never immerse the hand-held unit 7 in water or other liquids. Do not allow water to enter the product. This could damage the product and result in a short-circuit.

- Do not use aggressive, chemical or abrasive cleaners. These could damage the surface.

■ Never clean the hand-held unit 7 with water or other liquids.

☐ Only clean the product with a damp cloth and, if necessary, some mild washing-up liquid.

☐ Clean the attachments with water and occasionally with alcohol (70 % to 90 %).

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics / 20–22: paper and fibreboard / 80–98: composite materials.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries / rechargeable batteries!

Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.

- Information

- Translation of the original declaration of conformity

We, OWIM GmbH & Co. KG Stiftsbergstraße 1, DE-74167 Neckarsulm, GERMANY, hereby declare under our sole responsibility the product: Manicure & Pedicure Set model no.: HG02019, Version: 02 / 2018, to which this declaration refers, complies with Directives 2006/42/EC, 2014/30/EU und 2011/65/EU.

Harmonised standard applied: EN 60335-1:2012/A11:2014 EN 60335-2-8:2015 EN 62233:2008 EN ISO 12100:2010 EN 50581:2012 EN 55014-1:2006/A2:2011 EN 55014-2:1997/A2:2008

Serial number: IAN 290040

Tobias Koenig Department Manager

Neckarsulm, 3 Oct 2017

The declaration of conformity is also available at: www.owim.com

- Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. Should this product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.
