Product type	Rechargeable lithium-ion battery
Brand	Parkside
Model	PAPK 12 B4
Nominal voltage	12 V
Capacity	4.0 Ah
Energy	48 Wh
Number of cells	6
Recommended charge temperature	+4 °C to +40 °C
Operating temperature	+4 °C to +50 °C
Storage temperature	0 °C to +45 °C
Charging time (with PLGK 12 A3)	120 min
Charging time (with PDSLG 12 A1)	60 min
Power supply	12 V DC via X 12 V TEAM series charger
Intended use	For X 12 V TEAM series cordless tools
Package contents	1 × battery, 1 × instruction manual (charger not included)
Material	Lithium-ion (Li-Ion)
Weight (estimated)	Approximately 0.5 kg
Maintenance	Clean with dry cloth; no maintenance required
Warranty	3 years from date of purchase
Safety	Do not expose to fire, water, or excessive heat (>+50°C); use only with suitable charger

Frequently Asked Questions - PAPK 12 B4 PARKSIDE

How to charge the Parkside PAPK 12 B4 battery?

Use only a charger from the X 12 V TEAM series (e.g., PLGK 12 A3 or PDSLG 12 A1). Connect the battery to the charger, then plug the charger into a mains socket. The red LED indicates charging, the green LED indicates the battery is fully charged. Charging takes 120 minutes with PLGK 12 A3 and 60 minutes with PDSLG 12 A1.

What is the capacity of the PAPK 12 B4 battery?

The battery has a capacity of 4.0 Ah and an energy of 48 Wh at a nominal voltage of 12 V.

How do I check the battery charge level in a tool?

Insert the battery into the cordless tool. Press and hold the on/off switch. The LED indicators show the level: red (needs charging), red-yellow (partially charged), red-yellow-green (fully charged).

Can I use the PAPK 12 B4 battery with other Parkside tools?

Yes, this battery is compatible with all cordless tools of the X 12 V TEAM series from Parkside. It can also be charged with chargers from this series.

What are the important safety precautions?

Do not dispose of the battery in fire, do not expose it to water or excessive heat (max +50°C). Avoid short circuits. Use only the suitable charger. In case of electrolyte leakage, rinse thoroughly with water and consult a doctor.

How to store the battery for long term?

Store the battery partially charged (2 to 3 LEDs on) in a dry place between 0°C and +45°C. Check the charge level every 3 months and recharge if necessary.

How to clean the battery?

Clean the battery with a dry cloth. Do not use chemical or abrasive products. Ensure no liquid enters the interior.

What to do if the battery is defective or worn out?

Used batteries must be recycled in accordance with directive 2006/66/EC. Take them to an appropriate collection point. Do not dispose of them with household waste.

What is the warranty period for this battery?

The warranty is 3 years from the date of purchase. It covers material and manufacturing defects. Keep the receipt as proof of purchase.

Can I charge the battery with a non-Parkside charger?

No, use exclusively a charger from the X 12 V TEAM series (PLGK 12 A3 or PDSLG 12 A1). Using other chargers poses a risk of fire or battery damage.

USER MANUAL PAPK 12 B4 PARKSIDE

User manual Translation of the original instructions

FR BE

BATTERIE 12 V 4 Ah

GB/IE User manual Page 37

FR/BE Mode d'emploi

Page 64

List of pictograms used . Page 39

Introduction 42

Intended use. Page 42
Scope of delivery. Page 43
Parts list . Page 43
Technical data . 44

General safety notes.. Page 46

First set-up of the product . Page 50

Unpacking the product and basic cleaning. . . . Page 50

Operation. Page 51

Charging the battery. Page 51
Inserting the battery into the battery device. . . . Page 54
Checking the battery charge level on the
battery device . Page 54
Removing the battery from the battery device . . . Page 55

Cleaning and maintenance . Page 56

Cleaning. Page 56

Maintenance. Page 57

Storage 57

Disposal. Page 58

Warranty 60

Warranty claim procedure.. Page 62

Service . 63

List of pictograms used
Read the instruction manual.
DANGER! - Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)
WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)
CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)
NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)
INFO: This symbol with the “Info” signal word offers additional useful information.
Direct current/voltage
Use the product in dry indoor spaces only.
Protect the battery against heat and continuous intense sunlight.
Protect the battery against water and moisture.
Protect the battery from fire.
Safety information Instructions for use
CE	CE mark indicates conformity with relevant EU directives applicable for this product.
Li-lon	Lithium-ion battery

RECHARGEABLE BATTERY 12V 4Ah

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

The product is to be used in conjunction with a device from the X 12 V TEAM series. The product is compatible with all devices in the X 12 V TEAM series. The product may only be charged using chargers from the X 12 V TEAM series.

The product is not intended for commercial use. Any other usage or modification of the product is deemed to be improper and carries a significant risk of accidents. The manufacturer accepts no responsibility for damage(s) attributable to misuse.

Scope of delivery

1 × Rechargeable battery
1×User manual

INFO: The charger is not included in the scope of delivery.

Parts list

Before reading, unfold the page containing the illustrations and familiarise yourself with all the functions of the product.

1 Rechargeable battery
2 Release button
3 Charger

4 Charging control LED - Red
5 Charging control LED - Green
6 Mains cord with mains plug

• The charger is not included in the scope of delivery.

Technical data

Rechargeable battery (Li-Ion): PAPK 12 B4
Number of cells: 6
Rated voltage: 12 V	---
Capacity: 4.0 Ah
Energy: 48 Wh

Recommended ambient temperature:

Maximum temperature: max. +50 °C

While charging: +4 °C to +40 °C

During operation: +4 °C to +50 °C

During storage: 0 °C to +45 °C

Charging time:

We recommend charging this product with the following chargers:

PLGK 12 A3

PDSLG 12 A1

Charging time PLGK	12 A3 PDSLG 12	A1
PAPK 12 B4 120 min 60 min

Customers can obtain compatible replacement batteries and chargers from the LIDL online shop www.lidl.de.

General safety notes

CAUTION! Risk of explosion!

Do not dispose of batteries in household waste, fire or water. Do not subject the battery to strong sunlight over long periods and do not leave it on a heater (max. 45^ircC ).

Careful handling and use of battery devices

Charge the batteries only in chargers that are part of the X 12 V TEAM series. Risk of fire if a charger that is suitable for a specific type of battery is used with other batteries.

46 GB/IE

In the power tools, use only the batteries designed for the purpose. The use of other batteries may result in injuries and risk of fire.
- Keep the unused battery away from paper clips, coins, keys, nails, screws and other small metal objects, which could cause bridging of the contacts. A short circuit between the battery contacts may cause burns or fire.
If used incorrectly, liquid may leak from the battery. Avoid contact with this. In the event of accidental contact, rinse off with water. If the liquid gets into eyes, seek medical assistance.

Leaking battery fluid may cause skin irritations or burns.

• Do not use damaged or altered batteries. Damaged or altered batteries can be unpredictable and lead to fire, explosion or risk of injury.

• Do not expose batteries to fire or elevated temperatures. Fire or temperatures over +130^ircC can cause an explosion.

• Follow all instructions for charging and never charge the battery or the battery-powered tool outside the temperature range stated in the operating instructions. Incorrect charging or charging outside the permitted temperature range may destroy the battery and increase the risk of fire.

Service

• Never repair damaged batteries. All battery repairs should be carried out by the manufacturer or authorised customer service centres only.

Special safety directions for battery-operated tools

Ensure that the device is switched off before inserting the battery. Inserting a battery into a power tool that is switched on may result in accidents.
- Recharge the batteries indoors only because the battery charger is designed for indoor use only.

To reduce the electric shock hazard, unplug the battery charger from the mains before cleaning the charger.
- Do not subject the battery to strong sunlight over long periods and do not leave it on a heater. Heat damages the battery and there is a risk of explosion.
- Allow a hot battery to cool before charging.
- Do not open up the battery and avoid mechanical damage to the battery. Risk of short circuit and fumes may be emitted that irritate the respiratory tract. Ensure fresh air and seek medical assistance in the event of discomfort.

• Do not use non-rechargeable batteries. The product could be damaged.

- First set-up of the product

Unpacking the product and basic cleaning

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".
4. Before first use, clean all parts of the product as described in the chapter "Cleaning and maintenance".

Operation

Charging the battery

WARNING!

• Charge the battery [1] in a dry room only. Prior to inserting the battery into the charger [3], check that the outer surface of the battery is clean and dry. There is a risk of injury due to electric shock.

CAUTION!

• Do not expose the battery 1 to extreme conditions such as heat or impact. Risk of injury from escaping electrolytic solution! After eye/skin contact, rinse the affected areas with water or a neutraliser and consult a doctor.

NOTE

The rechargeable battery 1 only reaches its full capacity once it has been charged several times.
Charge the battery before using it for the first time.
Only use chargers from the X 12 V TEAM series to recharge the battery 1.
If a fully recharged battery lasts for considerably shorter operating times, the battery is used up and needs to be replaced. Only use an original replacement battery from the X 12 V TEAM series.
Let the battery cool down before charging.
The battery may be charged at any time without reducing the life time of the battery.
Interrupting the charging process does not damage the battery.

Charge the battery 1 before use when it is at medium or low charging level.
The charging control LEDs (green 5 and red 4) indicate the status of the charger 3 and the battery:

LED Status
Green LED lights up without battery inserted Charger ready for use
Green LED lights up Battery fully charged
Red LED lights up Battery charging

1. Remove the battery 1 from the battery device.
2. Insert the battery into the charger 3
3. Connect the mains plug 6 to a socket-outlet.
4. When the battery is fully charged: Remove the battery from the charger. Disconnect the mains plug from the socket-outlet.

- Inserting the battery into the battery device

NOTE

• Only insert the rechargeable battery 1 once the battery device is ready for use.

Push the battery along the guide rail into the device. You will hear it click into place.

- Checking the battery charge level on the battery device

NOTE

The battery 1 must be inserted in the battery device to check the charge level.

The charge level of the battery is indicated by the charge level indicator on the battery device.

Press and hold the power button during operation of the battery device.
The charge level of the battery 1 is indicated by illumination of the corresponding LED lights:

LED Status
red - yellow - green Battery fully charged
red - yellow Battery half charged
red Battery needs to be charged

- Removing the battery from the battery device

NOTE

• Switch off the battery device before removing the battery 1 from the battery device.

Press both release buttons 2 on the battery. Pull the battery out of the battery device.

55GB/IE

Cleaning and maintenance

Cleaning

NOTE

Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.
Never allow fluids to get into the product.
The product must always be kept clean, dry and free from oil or grease. Remove debris from it after each use and before storage.
Regular and proper cleaning will help ensure safe use and prolong the life of the product.

Clean the battery with a dry cloth. Use a soft brush for areas that are hard to reach.

Maintenance

The product is maintenance free.

Storage

Remove the battery 1 from the battery device before storing it for longer periods of time.
During a longer storage period, check the state of charge of the battery roughly every 3 months and recharge if necessary.
The storage temperature for the battery is between 0^ircC and +45^ircC .
- Avoid extreme cold or heat during storage to ensure the battery output is not adversely affected.
- Only store the battery in a partially-charged state. During prolonged storage, 2 to 3 LEDs should be illuminated. The battery charge level indicator of the battery device signalises the charge level of the battery.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

58 GB/IE

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

60 GB/IE

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 426385_2307) available as proof of purchase.

You will find the item number on the rating plate, an engraving, on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

62 GB/IE

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
