USER MANUAL PBLS 26 B2 PARKSIDE
Petrol Leaf Vacuum / Blower
Translation of the original instructions
NL BE
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.
FR BE
Service-Center....25
Importeur.... 25
Scope of delivery/accessories......28
Overview.... 28
Description of functions....28
Technical data....28
Safety information....29
Meaning of the safety information...... 29
Pictograms and symbols.... 29
General safety instructions.... 30
Assembly....39
Leaf blower.... 39
Leaf vacuum.... 39
Preparation.... 40
Putting on the carrying strap.... 40
Filling with fuel.... 40
Setting the rotational speed......41
Operation.... 41
Working instructions.... 41
Start the engine....41
Stopping the engine....42
Emptying the collection bag.... 42
Transport....42
Cleaning, maintenance and storage..... 42
Cleaning....43
Maintenance.... 43
Storage.... 43
Disposal/environmental protection......44
Service.... 44
Guarantee.... 44
Repair service.... 45
Service Centre.... 45
Importer.... 46
Spare parts and accessories.... 46
Translation of the original EU declaration of conformity.... 47
Exploded view.... 251
Introduction
Congratulations on purchasing your new petrol leaf vacuum/blower (hereafter referred to as device or power tool).
You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device.
The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.
Proper use
This device is only intended for the following use:
- Suctioning dry foliage.
- To collect dry leaves/remove them from hard to reach areas (e.g. under vehicles).
The device is intended for use by adults. Children under the age of 16 may not use the device, except under supervision.
Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.
DANGER! A leaf vacuum is not a wet vacuum! Please avoid vacuuming wet materials (leaves, dirt, branches, limbs, pinecones, grass, sand, bark mulch/shredded material etc.). Do not vacuum on damp or wet grass. Incorrect use can, under certain circumstances, lead to blockages in the shredding chamber and therefore to reduced performance. The machine may then have to be completely disassembled and cleaned. This work must be carried out by a specialist and is not covered by the warranty.
Scope of delivery/accessories
Unpack the device and check that everything is present.
Dispose of the packaging material properly.
• Petrol Leaf Vacuum / Blower
• Suction pipe (three-part)
- Blower pipe (three-part)
- Fuel mixing bottle
- Collection bag
• Hex key with Phillips screwdriver
- Multifunction key
- 2x Phillips screw
• Translation of the original instructions
Fuel not included
Overview
The illustrations for the device can be found on the front and back fold-out page.
(Fig. A)
1 Motor housing
2 Collection bag
3 Zip
4 Carrying strap
5 Suction pipe
6 Suction nozzle (Suction pipe)
7 Outlet pipe
8 Blower pipe
9 Round nozzle (Blower pipe)
10 Flat nozzle (Blower pipe)
11 Hex key
12 Multifunction key
13 Phillips screw
14 Fuel mixing bottle
(Fig. B)
15 Blow connection
(Fig. C)
16 Protective cover
17 Lock (Protective cover)
18 Vacuum connection
(Fig. D)
19 Velcro
(Fig. E)
20 Auxiliary handle
21 Fuel tank
22 Fuel cap
23 Fuel pump (Primer)
24 Starter rope
25 Choke lever
26 Handle
27 Throttle lever
28 On/Off switch
29 Throttle lever lock
(Fig. F)
30 Cover (Air filter)
31 Air filter screw
32 Air filter
(Fig. G)
33 Cover (Spark plug)
34 Spark plug connector
35 Spark plug
Description of functions
In suction mode, the vacuumed leaves are shredded to reduce the volume, then blown through the discharge channel and collected in the collection bag.
In blowing mode, foliage can quickly be gathered or blown out of hard to reach areas with the cordless leaf blower.
Please refer to the descriptions below for information on how the operating elements work.
Technical data
Petrol Leaf Vacuum / Blower .. PBLS 26 B2
Rated power P ...0.9 kW (1.2 PS)/7500 min ^-1
Displacement 25.4 cm ^3
No-load rotation speed n_0 3000 ± 300 min ^-1
Air speed Blowing mode V_max 266 km/h (73 m/s)
Delivery volume 950 m³/h
Chopping rate 10:1
Collection bag 451
Fuel tank volume 420 ml
Approved fuel ...... ROZ 95 (E10)
Fuel mixture 40:1
Weight with accessories ....≈6.4 kg
Sound power level ( L_WA )
– Guaranteed ....109 dB
Blowing mode
Sound power level (LWA)
- Measured .....107.2 dB; K_WA=1.97 dB
Sound pressure level ( L_pA )
87.3 dB; K_pA = 3 dB
Vibration a_h
Handle 5.25 m/s ^2 ; K= 1.5 m/s ^2
Auxiliary handle .... 5.37 m/s ^2 ; K= 1.5 m/s ^2
Suction mode
Sound power level ( L_WA )
- Measured .....104.4 dB; K_WA=2.22 dB
Sound pressure level ( L_pA ). 85 dB; K_pA=3 dB Vibration a_h
Handle 5.11 m/s²; K=1.5 m/s²
Auxiliary handle .... 5.45 m/s ^2 ; K= 1.5 m/s ^2
Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity.
The specified total vibration value and the stated noise emission value have been measured according to a standardised test method and can be used to compare one device with another. The specified total vibration value and the stated specified noise emission value can also be used for a provisional assessment of the load.
WARNING! The vibration and noise emissions may deviate from the specified values during actual use of the device, depending on how the device is being used. Safety measures for the protection of the operator are to be determined that are based on an estimate of the actual vibration load under the real operating conditions (for this, all parts of the operating cycle are to be taken into account, for example, times in which the device is turned off, and those during which it is turned on but running without a load).
Safety information
This section deals with the basic safety instructions for using the device.
Meaning of the safety information
DANGER! If you do not observe this safety instruction, an accident will occur. The result of which is severe bodily injury or death.
⚠ WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.
CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.
NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.
Pictograms and symbols
Symbols on the device
Attention!
Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly.
For safety reasons, the device can only be started if both suction tube sections and the collection bag are fitted or if the flap is closed and the blower pipe is correctly fitted.
Risk of injury due to ejected parts! Keep persons in the vicinity away from the device
Rotating impeller. Keep away from hands!
Use hearing protection
Use eye protection
Use protective gloves
Use foot protection
Guaranteed sound power level L_WA in dB.
0.42 L Fuel tank volume
Fe^+ 40:1 Fuel mixture
Choke open
Choke closed
x7 Press the petrol pump seven times
Open flames, fire, open ignition sources and smoking are prohibited. The device is equipped with a two-stroke engine and is therefore operated exclusively with a mixture of petrol and two-stroke engine oil at a ratio of 40:1.
Symbol on the hangtag
Cold start
| Pull the cold start lever (choke) | |
| Press the petrol pump seven times | |
| 3-4x Pull the starter cord | |
| Pull the throttle lever | |
 |
Warm start
| 7x | Press the petrol pump seven times |
| 3-4x | 3-4x Pull the starter cord |
General safety instructions
▲ WARNING! Read all safety instructions and guidelines carefully. Failure to follow the safety instructions and guidelines may result in fire and/or serious injuries. Only use the fuels recommended in these instructions. Never use fuel that is not mixed with 2-stroke engine oil. This can lead to a total loss and the supplier's warranty will be invalidated.
Keep all safety information and instructions for future reference.
Instruction
- Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Learn how to switch off the machine in an emergency.
- Only use the machine for its intended purpose:
- The movement and accumulation of leaves and grass with different limited weights and small dimensions by blowing.
• Vacuum collection of leaves and grass, various waste with limited weight and small dimensions, excluding liquids of any kind. • The machine must not be used to collect flammable or explosive products, hot embers, ashes, burning cigarettes and branches, sharp objects, metal objects, stones and other objects that could be dangerous to the operator. This can lead to injuries and damage the machine.
- Never allow children to use the machine.
- Never use the machine if people, especially children, or pets are in the vicinity.
- Persons who are unable to use the machine safely due to their physical, sensory or mental capabilities or their inexperience or lack of knowledge should not use this machine without supervision or instruction by a responsible person. Chil-
dren should be super- vised to ensure that they do not play with the ma- chine.
- Never allow other persons who are not familiar with these instructions to use the machine. Local regulations may specify the minimum age for users.
- Do not use the machine if you are tired or you are under the influence of drugs, alcohol or other medication. Do not use equipment or machinery if you are tired.
- Ensure that all documents are handed over in the event that the product is passed on to another user.
- The user is responsible for accidents or hazards that happen to third parties personally or to your property.
General information
- Wear suitable, sturdy, close-fitting work clothing.
- Do not wear loose clothing or jewellery.
Wear long trousers to protect your legs.
- Wear a head covering if you have long hair.
- Loose clothing, jewellery and long hair can be caught by moving parts.
- Wear safety shoes, gloves, safety goggles and a respirator.
• This machine is extremely loud. Wear hearing protection.
• Always switch off the machine engine when you put the machine down and before working on the machine.
- Wear safety goggles when working.
- Use a dust mask for work which generates dust.
- Never use the machine with damaged protective devices or shields.
- Warning! Danger, fuel is highly flammable!
- Store fuel in containers specially designed for this purpose.
- Switch off the machine and allow it to cool down for a few minutes
before topping up with fuel.
- Do not smoke when topping up the fuel or operating the machine.
- Open the filler cap slowly to allow petrol vapours to escape.
- Refuel outdoors only. Fill the fuel mixture using a funnel.
- Top up with fuel before starting the engine.
- Remove the filler cap and never fill the tank when the engine is running or when the engine is hot.
- If fuel is spilled, do not attempt to start the engine, but move the machine away from the area of the spillage and avoid all sources of ignition until all fuel vapours have dissipated.
- Wipe up spilt fuel immediately.
- Never start the machine at the point where you have topped up with fuel.
• Make sure that your clothing does not come into contact with fuel.
Change your clothes immediately if they come into contact with fuel.
• After refuelling, make sure that the filler cap is closed correctly and securely.
- Replace defective silencers
- Carry out a visual inspection before using the machine. Check in particular:
- The throttle lever must be able to move freely and should return to the neutral position automatically and quickly.
- The on/off switch must be easy to operate.
- All electrical cables such as the spark plug cable and the spark plug connector must be in perfect condition to prevent sparks. The spark plug connector must be firmly seated on the spark plug.
- Keep handles dry and free of oil and grease. Handles and protect-
ive devices must not be damaged.
• The fan must not be damaged.
• The collection bag must not be damaged.
- Before starting work, always remove any objects lying on the floor that could
- fly up or out when operating the machine (when used as a blower)
- block the vacuum pipe when operating the machine (when used as a vacuum collector)
• form a source of danger when operating the machine (stones, branches, iron wire, bones, etc.)
Operation
- Keep hands and feet away from rotating parts.
- Never let the internal combustion engine run in a confined space, as dangerous carbon monoxide can accumulate.
- Do not fit any devices or accessories to the ma-
chine that are not intended or authorised by the manufacturer.
- Keep your work area tidy and well lit. Working in areas that are untidy or without lighting can result in accidents.
- Do not use a tool with a defective switch. A tool that can no longer be switched on or off is dangerous and must be repaired.
-
Never use the machine:
-
without fitting all accessories intended for each use (when used as a leaf vacuum or blower)
- if people, especially children, or pets are in the vicinity.
- in closed rooms, in potentially explosive atmospheres in which flammable liquids, gases or dust are present.
- Therefore, always ensure that you are standing securely and firmly so that you can control the machine and maintain your working posture even in
the event of unexpected movements.
- If possible, avoid working on wet, slippery floors. Avoid working on uneven or steep ground that does not guarantee the operator a safe working position.
• Make sure that the machine is fully assembled before you start it.
- Start the engine in an area at least 3 metres away from where you filled up.
- As objects may potentially fly up or out, strangers should keep a safe distance of at least 15 metres from the machine.
-
Do not point the silencer and its associated exhaust gases at flammable materials.
-
Do not make any modifications to the engine.
- Do not overload the machine. Use the appropriate tool for your work. With the right tool, you can work better and more safely in the specified power range.
- Ensure that the machine does not come into contact with foreign objects or foreign objects and dust that may be stirred up by the air.
- Never point the air jet at people or animals.
- Never insert objects into the openings of the machine and avoid sucking in large objects that could damage the fan.
- Keep your hands away from the intake grille and air outlet during use and do not block the fan under any circumstances.
- Stop the engine:
- When converting the machine from a leaf vacuum to a leaf blower.
• If you leave the machine unattended.
• Before refuelling
- When you change the working area.
- Stop the engine and remove the spark plug connector:
• Before cleaning and maintenance work.
- When a foreign body is sucked in. Inspect the
machine for damage before putting it back into operation.
• If the machine starts to vibrate abnormally.
- When you are not using the machine.
- Do not leave the machine with a hot engine on leaves, dry grass or other combustible material. Risk of fire!
- Do not work with the machine in a potentially explosive atmosphere where flammable liquids, gases or dust are present. The machine generates sparks that can ignite the dust or vapours.
- Warning! Do not work near open windows. Watch out for children and pets and blow away foreign objects safely.
- Keep children, other people and pets away when using the machine. Distractions can cause you to lose control of the machine.
- Avoid an abnormal body posture. Ensure that your footing is secure and
keep your balance at all times. This will help you to have better control of the tool in unexpected situations.
- Pay attention, be aware of what you are doing and take the utmost care when working with the tool. Do not use tools if you are tired or you are under the influence of drugs, alcohol or medication. A moment of inattention whilst using the tool can result in serious injuries.
- Avoid starting the machine unintentionally. Having your finger on the switch of the tool while carrying it can cause accidents.
- Remove adjustment tools or spanners away from the area before switching on the tool. A tool or key located in a rotating piece of equipment can lead to injuries.
• We recommend that you only operate the machine at reasonable times – neither early in the morn-
ing nor late at night when others may be disturbed.
- Before starting to blow/vacuum, remove foreign bodies with a rake and broom.
- In dusty conditions, lightly moisten the surface or, if available, use a watering attachment.
• We recommend using the entire blower nozzle attachment so that the air flow can work close to the floor.
Cleaning, maintenance and storage
- Maintain tools with due care. Check that the moving parts are working properly and are not becoming jammed and that parts are not broken or damaged in such a way that the functioning of the tool is impaired. Have damaged parts repaired before using the machine. Many accidents are caused by poorly maintained tools.
- Do not carry out any work on the machine that is not described in this manual.
- Do not store the machine with fuel in the tank in an area where the fuel vapours could reach an open flame, a spark or a strong heat source.
- Allow the engine to cool down before maintenance and cleaning work and before storage.
- Keep the engine, silencer and fuel tank free of dust, branches and leaves. Risk of fire!
- Only empty the tank outdoors or in a well-ventilated area.
- Wear gloves during maintenance work.
- For safety reasons, never use the machine with worn or damaged parts. Damaged machine parts must be replaced or repaired. Only use original spare parts. Defective parts can cause injuries or damage the machine.
- Remove all tools used for maintenance before operating or storing the machine.
- Store the machine out of the reach of children.
Transport
- If the machine is to be worn, you must:
- Switch off the engine and disconnect the spark plug connector.
- Carry the machine by the handles. Do not lift the machine by the pipes.
- When transporting in a vehicle, remove the pipes and load the machine in such a way that it cannot pose a danger to persons. To prevent fuel leaks, damage and injuries, the machine must be secured against tipping over during transport in vehicles.
Environmental protection
- Dispose of packaging and waste materials in accordance with the applicable local laws.
- Residual fuel, oils and the liquid used for cleaning must be disposed of in an environmentally friendly manner!
- Dispose of this machine properly in accordance
with the regulations applicable in your country.
Safely handling fuels
Fuels and fuel vapours are flammable and can cause serious damage if inhaled or on the skin. Care must therefore be taken when handling fuel and good ventilation must be ensured.
- Before refuelling the machine, switch off the engine and allow the machine to cool down.
- Do not smoke when re-fuelling and avoid naked flames.
- Wear gloves when refuelling.
- Do not refuel in closed rooms (risk of explosion).
• Take care not to spill fuel or oil. Clean the machine immediately if you have spilt fuel or oil. Change your clothes immediately if you have spilt fuel or oil on them.
• Make sure that no fuel gets into the soil. - Close the filler cap carefully after refuelling and ensure that it does not
come loose during operation.
• Make sure that the filler cap and petrol lines are tight.
- Do not operate the machine if it is leaking.
- Only transport and store fuels in approved and labelled containers.
- Keep children away from fuels.
- Do not transport or store fuels in the vicinity of flammable or highly flammable substances, sparks or naked flames.
• To start the machine, move at least three metres away from the filling station.
- Keep the handles dry, clean and free of fuel mixture.
- Never anchor while the engine is running or hot.
Residual risks
There will always be residual risks even if you operate this device according to the instructions. The following hazards may occur
in connection with the type and design of this device:
- Eye damage if no suitable eye protection is worn.
- Lung damage if suitable respiratory protection is not worn.
• Hearing damage if suitable ear protection is not worn.
• Health injuries resulting from the effect of hand/arm vibration in the event that the tool is used over a longer period of time or is not used and maintained properly.
▲ WARNING! Danger due to electromagnetic field generated while the tool is in operation. Under certain circumstances, this field may negatively affect active or passive medical implants. In order to reduce the danger of serious or fatal injuries, we recommend that individuals who wear medical implants should consult their doctor and the manufacturer of the implant before operating the tool.
Assembly
⚠ WARNING! Risk of injury! During fitting or removal, the machine must be switched off and all moving parts must be stationary.
- Fully assemble the machine before use.
- Place the device on a level surface.
- The leaf vacuum and leaf blower differ in the way they are assembled.
Leaf blower
Fitting the blower pipe
Note
The machine cannot be started as a leaf blower if the blower pipe is not fitted.
Procedure (Fig. B)
- Remove the pre-assembled screw on the blow connection (15) using the hex key (11).
- Push the blower pipe (8) into the blow connection (15). The lug on the blower pipe (8) fits into the recess on the motor housing (1).
- Tighten the screw again using the hex key (11).
Fitting the flat nozzle/round nozzle (Fig. B)
- Select the flat nozzle (10) or the round nozzle (9).
- Align the nozzle with the blower pipe (8). The nozzle must point towards the ground.
- Slide the nozzle onto the blower pipe (8). Turn it clockwise (90°). Make sure that the screw slot of the blower pipe (8) and nozzle are aligned.
- Tighten the Phillips screw (13) using the hex key (11).
Leaf vacuum
Attaching the suction pipe
⚠️ CAUTION! Risk of injury. Completely assemble the machine before putting it into operation.
Procedure (Fig. C)
- Release the lock (17) using the multifunction key (12).
Fold the protective cover (16) open. -
Place the suction pipe (5) on the vacuum connection.
-
Attach the suction pipe (5). To do this, turn the suction pipe (5) clockwise ∪ as far as it will go.
Fitting the suction nozzle (Fig. C)
-
Slide the suction nozzle (6) onto the suction pipe (5). Turn the suction nozzle (6) clockwise ∪ (90°). Hold the suction pipe (5) firmly and at the same time press the sides of the suction pipe (5) inwards slightly to make installation easier. Make sure that the screw slot of the suction pipe (5) and suction nozzle (6) are aligned.
-
Tighten the Phillips screw (13) using the hex key (11).
Fitting the outlet pipe (Fig. D)
- Remove the pre-assembled screw on the blow connection (15).
- Push the outlet pipe (7) into the blow connection (15).
- Tighten the screw using the hex key (11).
Fitting and removing the collection bag
⚠ WARNING! In suction mode the machine must only be operated with the collection bag mounted.
Fitting the collection bag (Fig. D)
- Fit the collection bag (2) onto the outlet pipe (7).
- Attach the collection bag (2) to the outlet pipe (19) using the Velcro (7).
- Close the zip (3) of the zip fastener on the collection bag (2).
Removing the collection bag (Fig. D)
- Loosen the Velcro (19) on the outlet pipe (7) and remove the collection bag (2).
Preparation
⚠ WARNING! Risk of injury due to unintentional start-up. Do not start the motor until the device is fully prepared for use.
Putting on the carrying strap
⚠ WARNING! Never wear the strap diagonally across your shoulder and chest, but only on one shoulder. This allows you to quickly remove the machine from your body in case of danger.
Note
Adjust the height of the shoulder strap (4). The collection bag (2) must not kink.
Filling with fuel
⚠️ DANGER! Risk of fire or explosion! Always ensure good ventilation when handling fuel. Do not smoke while refuelling and keep any heat sources at a distance. Never refuel while the engine is running. Carefully open the fuel filler cap so that any overpressure can slowly dissipate. Start the device at a distance of at least 3 m from the fuelling point.
⚠ WARNING! Danger to health! Avoid direct skin contact with petrol and inhalation of petrol fumes.
CAUTION! Use only the fuel mixture recommended in the instructions. The fuel mixture ages. Therefore, do not use fuel mixtures that are older than 3 months (E10: 30 days). If this not done, the engine may become damaged and your warranty will become null and void.
Open flames, fire, open ignition sources and smoking are prohibited.
The device is equipped with a two-stroke engine and is therefore operated exclusively with a mixture of petrol and two-stroke engine oil at a ratio of 40:1.
Fuel mixture
- Use quality unleaded petrol with an octane rating of at least 95.
- For optimal performance, use oil for air-cooled two-stroke engines.
- The filling volume of the fuel tank is 420 ml.
Procedure (Fig. A/E)
- Mix petrol and oil in the fuel mixing bottle (14). Use the scale 40:1.
- First fill petrol „GASOLINE“ into the fuel mixing bottle (14) up to the 487.8 mark. Then fill with oil „OIL“ up to the second 500 mark.
- Close and shake the fuel mixing bottle (14).
- Place the machine on a level surface with the fuel cap (22) facing upwards.
- Unscrew the fuel cap (22).
- Pour the fuel mixture into the fuel tank (21).
- Wipe fuel residues off and close the fuel cap (22) again.
Setting the rotational speed
Notes
- Do not work at full power for the first 8 hours.
- Low speed for light material.
• High speed for heavy material. - Observe noise protection rules and other local regulations.
Procedure (Fig. E)
- Use the throttle lever lock (29) to set the desired speed.
Operation
DANGER! Risk of injury! Always wear appropriate protective equipment and work gloves while working with the machine. Make sure that the machine is in working order before each use. Ensure that the collection bag and pipe are installed correctly. Stop using the machine if the On/Off button, throttle lever or throttle lever lock is damaged. Personal protective equipment and a fully functional machine reduce the risk of injuries and accidents.
⚠ WARNING! Injury hazard caused by rotating tool. After the machine has been switched off, the impeller continues moving for some time.
Working instructions
⚠ WARNING! Risk of injury! Always wear appropriate protective equipment and work gloves while working with the machine. Make sure that the machine is in working order before each use. Ensure that the collection bag and pipe are installed correctly. Personal protective equipment and a fully functional machine reduce the risk of injuries and accidents.
- Use hearing protection
- As a blower for piling up dry foliage or blowing it out of hard-to-reach places.
- As a vacuum for vacuuming up dry foliage. The machine also serves as a shredder in suction mode.
The dry leaves are shredded, their volume reduced and prepared for possible composting. The intensity of the shredding depends on the size of the leaves and the residual moisture they contain. Any use other than that which is described above
can damage the machine and thus pose a risk to the user.
⚠ WARNING! When working with the machine, take care not to knock it against hard objects that could cause damage. Do not vacuum up solid objects such as stones, branches or branch cuttings, fir cones or similar, as these could damage the machine, especially the shredding unit. Repairs of this kind are not covered by the warranty.
Blowing mode
- Close the protective cover before operation.
- For best results with the blower, maintain a distance of 5-10 cm from the ground.
- Direct the flow of air away from you. Be careful not to catch any heavy objects in the jet of air which could cause injuries or damage.
- Start work with the highest blowing power to quickly collect the leaves lying around. Select a lower blowing power to compact the previously collected pile of leaves.
- Before blowing, use a broom or rake to loosen any leaves stuck to the ground.
- Hold the machine by the handle or by the handle and auxiliary handle when working.
Suction mode
- Always hold the machine tight with both hands during operation: Use the handle and the auxiliary handle for this.
- Make sure that not too many leaves are sucked in at the same time. This prevents the suction pipe from clogging and blocking the impeller.
Start the engine
Notes
- Place the machine on a firm and level surface before operating it.
- Pull the starter rope straight out and hold it firmly by the handle. Do not pull the starter rope out too far to prevent it from breaking. Never allow the starter rope to spring back.
Cold start
Notes
- Auto choke function: The throttle lever is actuated and the choke lever jumps into position |+|
- High outside temperature: The engine may start cold without choke
Procedure (Fig. E)
- Move the choke lever (25) onto position N.
- Press the fuel pump (primer) (23) 7 times.
- Hold the machine by the handle (26) with one hand. With the other hand, pull the starter rope (24) quickly up to 4 times until the engine starts.
- Actuate the throttle lever (27) as soon as the engine has started. The auto-choke function causes the choke lever (25) to jump to the "warm start" operating position |↑|.
- If the engine has run out: Pull the starter rope (24) again quickly up to 4 times until the engine starts.
- Allow the engine to warm up for 1 to 2 minutes.
Warm start
The machine was in operation less than 20 minutes ago.
Procedure (Fig. E)
- Press the fuel pump (primer) (23) 7 times.
- Hold the machine by the handle (26) with one hand. With the other hand, slowly pull the starter rope (24) until you feel resistance.
- Pull the starter rope (24) quickly up to 4 times. Repeat the "cold start" procedure if the engine does not start.
Stopping the engine
Stopping the engine immediately (Fig. E)
- Press the on/off button (28) to the "0" position until the engine has come to a standstill.
Stopping the engine normally (Fig. E)
- Release the throttle lever lock.
- Let go of the throttle lever (27).
- Press the on/off button (28) to the "0" position until the engine has come to a standstill.
Emptying the collection bag
Notes
- The suction capacity is significantly reduced when the collection bag is full.
- Compostable material does not belong in household waste!
Procedure (Fig. A)
Empty the collection bag (2) when it is full or when the suction power of the machine decreases.
- Switch off the machine and allow the engine to cool down completely.
- Open the zip using the zip fastener (3) on the collection bag (2).
- Empty the collection bag (2) completely.
Transport
Information on transporting the machine:
- Switch off the machine and allow the engine to cool down completely. Remove the spark plug connector.
- Carry the machine with two hands. Use the handle (26) and auxiliary handle (20) for this.
- Before transporting between two locations, empty the fuel tank with a petrol suction pump. Do not empty the fuel tank indoors, near fire or when smoking. Gas vapours can cause explosions or fire.
- To prevent fuel loss, damage or injury, the machine must be secured against tipping over and slipping during transport in vehicles.
Cleaning, maintenance and storage
⚠ WARNING! Risk of injury due to unintentional start-up. Protect yourself when performing maintenance or cleaning work. Switch off the engine.
⚠️ CAUTION! Always carry out maintenance and adjustment work with the engine switched off and the spark plug connector (34) disconnected.
You should have any repair and maintenance work that is not described in these instructions carried out by our Service Centre. Only use original replacement parts.
Cleaning
NOTICE! Risk of damage. Chemical substances may attack the plastic parts of the machine. Do not use any cleaning agents or solvents.
- Keep the ventilation slits, motor housing and handles of the machine clean. Use a damp cloth or brush to do this.
- Use a brush to remove dirt from the pipes and nozzles.
- Clean the collection bag using a brush and, if needed, compressed air.
Maintenance
- Check the device before each use for obvious defects such as loose, worn or damaged parts.
- Check the covers and protective devices for damage and correct fit. Replace these if necessary.
Removing obstructions and blockages
Leaves and fresh plant cuttings may obstruct the machine.
⚠ WARNING! Risk of injury! Switch off the machine and allow the engine to cool down.
Procedure (Fig. A/C/D)
- Remove the suction pipe (5) and suction nozzle (6) in the assembled state. Turn the suction pipe (5) anticlockwise and pull it out of the vacuum connection (18).
- Remove the collection bag (2) by detaching the Velcro (19) from the outlet pipe (7).
- Put on the safety gloves.
- Carefully remove blockages and obstructions from the machine and accessories. Take special care when handling the impeller.
- Fit the suction pipe (5), suction nozzle (6) and collection bag (2).
Spark plug maintenance
Notes
- Worn spark plugs, or a spark plug gap that is too large, will lead to a reduction in engine power.
- Carry out the first maintenance after 10 operating hours. Carry out subsequent maintenance every 50 operating hours.
Procedure (Fig. G)
-
Unscrew the cover (33) of the spark plug (35) using the hex key (11).
-
Pull the spark plug connector (34) from the spark plug (35). Use the multifunction key (12) for this
- Unscrew the spark plug (35) anticlockwise using the multifunction spanner (12).
- Check the spark plug gap with the help of a feeler gauge (available from specialised dealers).
The electrode air gap must be 0.6-0.7 mm. - Reset the gap if necessary, by carefully bending the ground/side electrode of the spark plug (35).
- Clean the spark plug (35) with a wire brush.
Air filter maintenance
Notes
- Never operate the machine without an air filter. Otherwise, dust and dirt will get into the engine and cause damage.
- Clean the air filter regularly. Replace the air filter if it is worn, damaged or very dirty.
Check more frequently if the air is very dusty. - Never use petrol or flammable solvents for cleaning!
Procedure (Fig. G)
- Turn the air filter screw (31) anticlockwise ⬆.
- Remove the cover (30).
- Remove the air filter (32).
- Tap out the air filter (32) or clean them with compressed air if necessary. Replace the air filter (32) earlier if it is very dirty (see Spare parts and accessories, p. 46).
- Assemble the individual parts in reverse order.
Storage
Always store the device and accessories:
- clean
- dry
• protected against dust
• out of the reach of children - Do not enclose the device in nylon sacks as this may cause moisture to form.
-
Do not expose the machine to direct sunlight, but store it in the dark or semi-dark.
-
Clean the machine thoroughly at the end of the season and during the winter. Clean the collection bag by removing it, emptying it and washing it with lukewarm water and neutral soap. Reattach the dried collection bag.
- Ensure that all nuts, bolts and screws are tightened so that the machine is in a safe operating condition.
Preparation (Fig. E/G)
- Drain the fuel tank (21) in a well-ventilated place.
- Start the engine, allowing it to idle until the engine stops and the carburettor is free of fuel.
- Allow the engine to cool down completely.
Winter break (more than 3 months)
- Remove the spark plug (35) (see Spark plug maintenance, p. 43).
- Fill a teaspoon with pure 2-cycle engine oil into the combustion chamber and pull the starter rope several times slowly to distribute the oil in the engine interior.
- Put the spark plug (35) back in.
Disposal/environmental protection
Dispose of the tool in accordance with the local regulations. For further information, please contact your local administration.
- Do not dispose of waste oil and petrol residues in the sewage system or down the drain. Dispose of waste oil and petrol remnants in an environmentally friendly way – take them to your local recycling centre.
- The tool, accessories and packaging should be properly recycled.
- Machines must not be disposed of with domestic waste.
- Empty the oil and fuel tanks carefully and return your tool to a recycling centre.
- Dispose of empty oil and fuel containers in an environmentally friendly manner.
- The plastic and metal parts used on your tool can be properly sorted according to materials and grades and efficiently recycled.
- If you have any other questions, contact the service centre.
- Feed clippings to composting and do not throw them into the refuse bin.
Service
Guarantee
Dear Customer,
This product is provided with a 3 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.
Terms of Guarantee
The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred.
If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.
Guarantee Period and Statutory Claims for Defects
The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.
Guarantee Cover
The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery. The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts(e.g. Blower pipe, Suction pipe, Collection bag) or to cover damage to breakable parts (e.g. switch). This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the
instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.
The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.
Processing in Case of Guarantee
To ensure efficient handling of your query, please follow the directions below:
- Please have the receipt and product number (IAN 486916_2501) ready as proof of purchase for all enquiries.
- Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.
- Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.
- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.
Repair service
For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.
• We can only work on devices which are sent in properly packed and with postage paid.
Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.
- The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.
• We will dispose of defective devices you ship to us free of charge.
Service Centre
Service Great Britain
Tel.: 0800 051 8970
Contact form on parkside-diy.com
IAN 486916_2501
Service Malta
Tel.: 800 65168
Contact form on parkside-diy.com
IAN 486916 2501
Importer
Please note that the address below is not a service address. Contact the service centre named above first.
Spare parts and accessories
You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 45
Pos. nr. Name Order No.
| 8 Blower pipe (three-part) 91120339 |
| 5 Suction pipe (three-part) 91120338 |
| 2 Collection bag 91120340 |
| 14 Fuel mixing bottle 91120342 |
| 13, 11, 12 Tool set (2x Phillips screw, Hex key, Multifunction key) 91120341 |
| 32 Air filter 91120329 |
| 30 Air filter Cover 91120330 |
| 35 Spark plug 91120327 |
Translation of the original EU declaration of conformity
Product: Petrol Leaf Vacuum / Blower
Model: PBLS 26 B2
Serial number: 000001-013000
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
2006/42/EC • 2014/30/EU • 2000/14/EC & 2005/88/EC • 2011/65/EU & (EU) 2015/863
The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
To ensure conformity, the following harmonised standards and national standards and regulations have been applied:
EN 15503:2009/A2:2015 • EN IEC 63000:2018 • EN ISO 14982:2009
In accordance with the Directive 2000/14/EC relating to noise emission, the following is confirmed: Sound power level ( L_WA )
- Measured: 107.2 dB/104.4 dB;
- Guaranteed: 109 dB
Followed conformity assessment procedure according to 2000/14/EC, Annex V.
This declaration of conformity is issued under the sole responsibility of the manufacturer:
Authorised representative of documentation
Sommaire
Introduction...... 48
Garantie (France)....69
Service-Center....71
Importateur.... 72
Service-Center....94
Importeur.... 94
Service-Center....116
Importador.... 117
Saco colector ....45 l
Service-Center....140
Importatore.... 140
Ricambi e accessori.... 140
Service-Center....160
Dovozce....160
Service-Center....180
Importér.... 180
parkside-diy.com
Service-Center....246
Importør.... 246
