USER MANUAL SFR 3.7 A1 SILVERCREST

Operation and safety notes

NL BE

ELEKTRISCH SCHEERAPPARAAT

GB/IE Operation and safety notes Page 32

Intended use....Page 34

Parts description Page 34

Technical data......Page 35

Scope of delivery Page 36

Safety notes......Page 36

Safety instructions for batteries/rechargeable batteries...... Page 41

Charging the product ...... Page 43

Use Page 44

Transport lock......Page 44

Shaving Page 45

Dry shaving......Page 45

Wet shaving (cordless use only) Page 45

Cutting longer hair Page 46

Shaving a three-day beard....Page 46

Cleaning and care......Page 47

Dry cleaning Page 48

Wet cleaning......Page 48

Replacing the shaving foil frame and the cutter block...... Page 49

Troubleshooting Page 50

Disposal Page 50

Warranty Page 52

Warranty claim procedure......Page 53

Service Page 53

List of pictograms used
	Read the instruction manual
[y8wz]	Volt
IP44	IP44 - Protection against harmful ingress of water (for USB adapter)
	Use indoors
	USB-Type-C connector
	Observe the warnings and safety information!
	Direct current/voltage
	Protection against powerful water jets
	On/Off switch
	CE mark indicates conformity with relevant EU directives applicable for this product.
[3XX2]	Safety informationInstructions for use
	Alternating current/voltage

Electric shaver

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intendeduse

This product is a electric shaver solely intended for cutting human hair. This product is only intended for private household use and must not be used for commercial purposes. The product may only be used indoors.

Partsdescription

Electric shaver (Fig. A)

1 Shaving foil
2 Release buttons for shaving foil frame (on both sides)
3 Shaving foil frame
4 Shavinghead
5 Release buttons for shaving head (on both sides)

6 ON/OFF button

7 Grips (Soft touch)

8 Display

9 USB-Type-C socket

10 USB-Type-A to C cable

11 USB-Type-C connector

Display (Fig. B)

12 Battery indicator
13 Battery symbol
14 Plug symbol
15 Cleaning symbol
16 Lock symbol

Accessories (Fig. C)

17 Guard
18 Cleaning brush
19 Storage bag
20 Cutter block
21 Cutter block amount (Fig. G)
22 Hair clippers (Fig. H)
23 USBadaptor

- Technicaldata

Electric shaver: HG06654B

Input: 5V

= 1A

Battery: 1 x 3.7 V Li-Ion, 800 mAh

Standby mode power

consumption: 0.0W

Operating temperature: 0 °C to +40 °C

Protection class: IPX6 (Protection against powerful water jets)

Only charge the product with the following USB Adapter 23:

Information Value	Unit
Manufacturer name or brand, commercial registry number and address	Zhejiang Mootree Electronic Technology Co.,Ltd91331100063153135U Floor 3, Plant 2,No.107, xianglong stree Nanming-shan Street,Liandu District 32300 Lishui City,Zhejiang Province PEOPLE'S REPUBLIC OF CHINA
Information Value Unit
Model identifier M26EU050100
Input voltage 100-240 V~
Input AC frequency 50-60 Hz
Output voltage 5.0 V
Output current 1.0 A
Output power 5.0 W
Average efficiency during operation	75.2 %
No-load power consumption 0.07 W
Input current	0.2 A

- Scope of delivery

1 Electric shaver

1 Storage bag

1 USB-Type-A to C cable

1 USB adaptor

1 Guard

1 Set of instructions for use

1 Cleaning brush

Safety notes

WARNING! DANGER TO LIFE AND RISK OF ACCIDENTS

FOR INFANTS AND CHILDREN! Never

leave children unattended with the packaging

material or the product. There is a danger of suffocation.

This product may be used by children aged 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or those lacking experience and/or knowledge, as long as they are supervised or instructed in the safe use of the product and they understand the associated risks. Do not allow children to play with the product. Never allow children to clean or maintain this product unsupervised.

⚠️DANGER! This symbol indicates the product can be cleaned under running water. First disconnect the product from the USB-Type-C connector 11. Only use the included USB-Type-A to C cable 10 and only use the USB adapter 23 for corded use.

keep the USB!

adapter

23

and USB-Type-A to C cable 10 dry!

■ Disconnect the shaver from the USB-Type-A to C cable 10 before cleaning it with water.

• Keep this product away from baths, showers, wash basins or other vessels containing water when connected to the USB adapter 23.
• Warning! Defect the no-d-held part from the USB-Type-A to C cable 10 before cleaning it in water.
  ■ Protect the product from moisture, drips of water and splashes of water when connected to a mains power adapter (not included).
• Do not touch the product with wet hands during charging.
  ■ Never immerse the product and USB-Type-A to C cable 10 and USB adapter 23 in water or other liquids or rinse under running water when connected to power.
  If the product falls into water, immediately disconnect from power, then take the product out of the water. In this case, so not use the product again and have it inspected by a professional.
  If liquid enters the product, have the product inspected before using it again.
  If the product is charged in a bathroom, unplug the USB adapter 23 after use as proximity

to water is a hazard even when the product is switched off.

For added protection we recommend installing a residual current operated device (RCD) with a rated trigger current not to exceed 30 mA in the electrical circuit. Consult an electrician. The RCD must be installed by an electrician.

Do not use the product if the product, the USB-Type-A to C cable 10 and the USB adapter 23 shows damage or if the product has been dropped.

Do not plug in the USB adapter 23 until the USB-Type-C connector 11 is connected to the product.

Only plug the USB adapter 23 into a properly installed, easily accessible mains socket with a voltage that corresponds to the information on the type plate. The mains socket must also be easily accessible after the product has been plugged in.

■ Ensure the USB-Type-A to C cable 10 will not be damaged by sharp edges or hot surfaces.

■ Ensure the USB-Type-A to C cable 10 will not be pinched or crushed.
■ Always unplug the product by the USB adapter 23.
■ Unplug the power adapter from the mains socket after after charging, if a fault occurs, before connecting the product to the USB-Type-C connector 11 before cleaning the product, and during storms.
To prevent hazards, do not modify the product. Repairs should only be carried out by a specialist workshop or by the service centre.
- Do not use the product if the attachment is damaged.
■ Switch off the product before attaching or replacing attachments and before cleaning.
- Lay the USB-Type-A to C cable 10 and the USB adapter 23 so nobody will step on or trip over it.
- Do not use the product on open wounds, cuts, sunburns or blisters.
■ Only use the original accessories.

■ Never place the product on hot surfaces (e.g. hobs) or near heat sources or open fire.
■ To avoid overheating, never cover the USB adapter 23.
- Keep the USB-Type-A to C cable 10 away from hot surfaces, sharp edges and mechanical stress.
- Clean the product (see "Clean ing and Care").

Safety instructions for batteries/rechargeable batteries

WARNING! For the purpose of recharging the batteries, only use the USB adapter 23 (M26EU050100) and USB-Type-A to C 10 provided with this appliance.

■ DANGER TO LIFE! Keep batteries/rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.

DANGER OF EXPLOSION! Never

recharge non-rechargeable batteries.

Do not short-circuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable batteries.

Risk of leakage of batteries/recharge-able batteries

• Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.
  If batteries/rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES!

Leaked or damaged batteries/

rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

This product has a built-in rechargeable battery which cannot be replaced by the user. This product contains a battery which is non-replaceable. When disposing of the product, it should be noted that this product contains a rechargeable battery.

- Charging the product

Note: Charge the product for 60 minutes before using it for the first time and subsequent charging.

Note: The display 8 shows the battery level 12 in percent (01, 02, 03, ..., 100% - in 1% increments).

Note: The plug symbol 14 lights up continuously when the battery is almost empty. The product can then only be used cordless briefly.

Note: A quick charge for one shave takes about 5 minutes.

Note: A fully charged battery provides approx. 70 minutes of cordless use.

☐ Switch off the product using the ON/OFF switch 6
☐ Connect the USB-Type-C connector 11 to the USB-Type-C socket 9 on the product.

Connect the USB-Type-A connector with the USB-Type-A to C cable 10 to the USB-Type-A socket of the USB adaptor 23. Connect the USB adaptor 23 to mains socket.

☐ The plug symbol 14 in the display 8 lights up red and the battery is being charged. When the battery is fully charged, the display 8 will show 100%.

Standby mode

The product is under standby mode while connecting with power supply and no operation.

Use

Note: Before first use, press and hold the ON/OFF button 6 for approx. 3 seconds to deactivate the transport lock.

This appliance can be used cordless or with the USB adapter 23.

CAUTION! Some oil residue may remain on the shaving head after unpacking. Clean this off with an absorbent, lint-free cloth before using the product.

☐ Use the guard 17 for the respective attachment when the product is not being used. Carefully slide the guard 17 over the shaving head 4 (see Fig. D).

☐ To remove the guard 17, carefully pull it off the shaving head 4.

Transportlock

The lock symbol 16 lights up continuously for a few seconds if a key is pressed when the transport lock is activated.

☐ Press and hold the ON/OFF button 6 for approx. 3 seconds to activate/deactivate the transport lock.
☐ It cannot be activated during charing.

Shaving

Do not apply excessive pressure to the shaving head 4 It is thin and can easily become damaged.
■ The shaver can be used both corded and cordless.
■ After the first uses you may notice temporary reddening or irritation of the skin, as the skin first needs to become used to shaving. This is normal and generally lasts between 2 and 4 weeks.

Dryshaving

□ Remove the guard 17.
☐ Press the ON/OFF button 6
☐ Hold the product at a right angle to the surface of the skin and guide it gently across your face.
☐ Shave against the growth.
☐ In difficult areas, e.g. the chin, tauten the skin for better results.
☐ Switch off the product after use by pressing the ON/OFF button 6.

- Wet shaving (cordless use only)

■ Wet shaving is only permissible in cordless operation.
■ Only wet shave with shaving foam or soapsuds, never use shaving gel or shaving cream. These can build up on the shaving head 4.
□ Apply a thin layer of shaving foam to the skin before shaving.

☐ Shave your face as described in section "Dry shaving".
☐ If shaving foam clogs the shaving unit with the shaving head 4 whilst shaving, clean the shaving unit under running water (see section "Cleaning and care").

• Cutting longer hair

Use the hair clippers 22 on the product to cut longer beard hair and side burns (see Fig. J).

☐ Remove the guard 17 and slide the hair clippers 22 upwards (see Fig. D + H).
☐ Press the ON/OFF button 6.
☐ Position the hair clipper 22 on the skin as shown in figure J and shave.
☐ Switch off the product after use by pressing the ON/OFF button 6
☐ Slide the hair clippers 22 back into their original position.

• Shaving a three-day beard

Note: Depending on individual beard growth and shaving habits, the appearance of a three-day beard can vary greatly.

☐ To maintain the appearance of your three-day beard, regularly carry out a dry shave with the guard 17 in place. The guard 17 functions as a stubble attachment.
☐ Shave your face as described in the chapter "Dry shaving" (see Fig. K).

- Cleaning and care

A timer built into the product adds the shaving times. After 30 minutes of shaving the cleaning symbol 15 will start flashing in the display 8. This reminds you to thoroughly clean the product, which is required regularly. When switching off the product with the cleaning symbol 15 flashing, the shaving timer will restart.

■ Never immerse the product, the USB-Type-A to C cable 10 and the power adapter in water or other liquids during charging or rinse under running water.
■ Always switch off the product before cleaning it.
- Do not use aggressive or abrasive cleaning agents.
☐ Store the product in the protective pouch 19 if it will not be used for extended periods.

Note: Do not put the product to direct sunshine or heat. The ideal ambient temperature is between -10 and +60 °C. Extreme low or high temperature may damage the battery or the product.. Suggest to charge the product at least 60 minutes when you wanted to store the item more than 6 months etc.

□ Clean the product's housing using a damp cloth. When doing so, miss out the shaving foil 1.

Do not apply excessive pressure to the shaving foil 1. It is very thin and can easily become damaged.

- Regularly charge the built-in battery if you do not use the product for a long period of time. This is necessary to preserve the battery.

■ Only use the cleaning brush 18 for the cutter block 20 and never for the shaving foil 1. Otherwise it may become damaged.

- Clean the shaving foil 1 by using the water and dry the shaving foil in normal environment.

☐ The cutter block 20 can be oiled (The oil not included) before use and after cleaning to guarantee complete functionality.

□ Always switch off the product before oil the cutter block 20 (Fig.G).

□ Apply one or two drops of oil on the top of cutter block 20 and distribute them evenly.

☐ Wipe off any excess oil which is out of the cutter block 20 with a cloth.

Note: Use any acid-free oil (such as sewing machine oil).

Warning: Keep the oil out of reach of children. Do not ingest the oil, do not get it into your eyes. Keep it in a safe place if it is not being used.

Dry cleaning

□ Clean the shaving head 4 using the enclosed cleaning brush 18 after every use.

☐ Press the release buttons 2 and remove the shaving foil frame 3.

□ Carefully tap the shaving foil frame 3 to clean it.

Remove any leftover hair trimmings using the cleaning brush 18.

☐ Re-attach the shaving foil frame 3 to the product so that it clicks into place (see Fig. F).

Wet cleaning

□ Press the release buttons 5 and pull off the shaving head 4

□ Clean the shaving head 4 under running water. Allow the water to flow through the shaving head 4 from the inside to the outside.

□ Allow the shaving head 4 to dry completely.

☐ Re-attach the shaving head 4 to the product so that it clicks into place (see Fig. E).

● Replacing the shaving foil frame and the cutter block

Note: You can place a repeat order online for the shaving foil frame 3 and the cutter block 20 under the item number 460330_2401 on the website www.optimex-shop.com.

WARNING! Do not use the product if the shaving foil 1 is damaged. If

- you notice any damage,

- your skin hurts when shaving,

- you do not get a clean shave,

and this cannot be remedied by oiling the shaving foil 1 and the cutter block 20 (see chapter "Cleaning and care"), then the shaving foil 1 and the cutter block 20 must be replaced.

The amount of wear and tear depends on the usage intensity, but in general the components must be replaced after approximately one year.

☐ Press both release buttons for the shaving head 5 and pull off the shaving head 4 (see Fig. 1).

☐ Press both release buttons for the shaving foil frame 2 and pull the shaving foil frame 3 off the product (see Fig. I).

☐ Replace the shaving foil frame 3 with a new one.

☐ Hold the cutter block 20 between your thumb and forefinger and pull it carefully off the razor (see Fig. G). Make sure that the spring that is located between the cutter block 20 and the black bracket does not fall out.

☐ Hold the new cutter block 20 between your thumb and forefinger and guide it carefully into the black bracket. Push it down as far as it will go, until it audibly clicks into place on the cutter block mount 21.

☐ First put the new shaving foil frame 3 back on the product, followed by the shaving head 4.

- Troubleshooting

Fault Possible causes Action
No function. The battery may not be charged.		Recharge the product.
Cutting performance is deteriorating.	Hair may be stuck inside the cutter block 20 or hair clipper 22.	Clean the product, as described in the corresponding chapter.
Battery cannot be charged or the battery performance is very low.	The battery have reached the end of its service life.	The product must be disposed properly as described in the corresponding chapter.
When product under charging, red plug symbol not shown, only shown the battery symbol and battery level.	Using product in very hot environment.	Bring your product back to cooler environment.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment. The Triman logo is valid in France only.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject

to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

• Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 460330_2401) available as proof of purchase.

You will find the item number on the rating plate, an engraving on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

Service Ireland

Tel.:[phone]

E-Mail: [e-mail]

Accessoires (afb. C)

17 Beschermkap

18 Reinigingskwastje

19 Opbergzakje

20 Messenblok

21 Messenblok-bevestiging (afb. G)

NOSTE OCHRANNÉ RUKAVICE!

NOSTE OCHRANNÉ RUKAVICE!

Barbering....Side 216

Tørbarbering....Side 217

Illustration of a tooth with a magnified inset showing the dental tool (no text or symbols)

Technical diagram of a hand-operated electric shaver with labeled parts and directional arrows indicating assembly or movement.

OWIM GmbH & Co. KG

Stiftsbergstraße 1

74167 Neckarsulm

GERMANY

Model-No.: HG06654B

Version: 07/2024
