USER MANUAL CLR-2310 ROADSTAR

Digital FM Clock Radio

User manual

Bedienungsanleitung

- Your new unit was manufactured and assembled under strict ROADSTAR quality control. Thank you for purchasing our product for your music enjoyment. Before operating the unit, please read this instruction manual carefully. Keep it also handy for further future references.

1. MEM/M+ button / SET button
2. ALARM 1 button / VOL DOWN button / ALARM OFF button
3. ALARM 2 button / VOL UP button / ALARM OFF button
4. BACKWARD button
5. FORWARD button
6. RADIO ON/OFF button
7. SNOOZE button / SLEEP button / DISPLAY DIMMER button
8. Display
9. Low Battery Indicator (When lit, indicates backup batteries should be replaced.)
10. Alarm 1 (When lit, indicates Alarm 1 is armed. If not lit, Alarm 1 is not armed.)
11. Alarm 2 (When lit, indicates Alarm 2 is armed. If not lit, Alarm 2 is not armed.
12. Speaker
13. DC IN jack
14. Battery compartment
15. Antenna

POWER SOURCES

AC POWER: You can power your clock radio by plugging the Power adaptercord into a wall AC power outlet. Check that the rated voltage of your appliance matches your local voltage.

BATTERY BACK-UP POWER FAILURE PROTECTION

This radio has a battery back up circuit that will keep the correct time and alarm settings in the event of a temporary power interruption.

Install a 3V CR-2032 battery (not included), into the battery compartment located on the bottom of the unit.

Change the battery every 9 to 12 months for best result and avoid possible battery leakage.

If power is temporarily interrupted the display will blink and the radio will not play. However, the battery back-up circuit will continue to maintain the clock and alarm settings. When power is restored the clock will display the correct time and alarm settings, and no adjustment is necessary.

CLOCK SETTING

In standby mode, press and hold the [SET] button (1) to enter the clock setting mode.

Setting the time: Press the [BACKWARD] (4) button to set the hour time and [FORWARD] button (5) to set the minute time.

Press the [SET] button (1) to confirm each setting option.

ALARM SETTING

In stand by mode:

Press the [ALARM 1] or [ALARM 2[ button (2 or 3) to show the current alarm 1 or 2 setting, respectively.

Press and hold the [ALARM 1] or [ALARM 2] button (2 or 3) to enter the alarm time setting mode.

In the alarm setting mode, press the [ALARM 1] or [ALARM 2] (2 or3) repeatedly to cycle through the setting options:

Alarm hour time > alarm minute time > Alarm sound source

Press the [BACKWARD] or [FORWARD] button (4 or 5) to adjust the values in each setting option. Press and hold the button to change the values quickly.

Press the [ALARM 1] or [ALARM 2] button (2 or 3) to confirm each setting option.

Once settings are done, the alarm is enabled and the corresponding AL 1 or AL 2 icon (10 or 11) will turn on.

Note: Select the buzzer ("bu" shows on the display), the radio (the last played radio frequency shows on the display), as the alarm sound source.

When the alarm is set to radio mode, the alarm will use the last tuned radio station.

When the clock time is displayed, press the [ALARM 1] or [ALARM 2] button (2 or 3) to enable or disable the respective alarm. The corresponding Alarm 1 or Alarm 2 indicator (10 or 11) (alarm or radio) will switch on when the alarm is enabled.

SNOOZE

To temporarily silence a sounding alarm, press the [SNOOZE] (7) button. The alarm will sound again when the snooze period (9 minutes) is over.

The corresponding Alarm 1 or Alarm 2 indicator (alarm or radio) flashes on the display during the snooze period.

To cancel the snooze period and the alarm, press any ALARM OFF button.

TO USE THE RADIO

Press the [RADIO ON/OFF] button (6) to switch the radio on.

Press the [BACKWARD] or [FORWARD] button (4 or 5) to adjust frequency.

Press and hold the [BACKWARD] or [FORWARD] button (4 or 5) to automatically tune to the next available FM station. Press the [RADIO ON/OFF] button (6) to switch the radio off. Note: For a better reception reorient the antenna.

PRESETS

Tune to a station. Press and hold the [MEM/M+] button (1) until “P01” (or the next available preset slot) shows on the display.

Press the [BACKWARD] or [FORWARD] button (4 or 5) to select a preset number (P01-P10).

Press the [MEM/M+] button (1) to confirm. The preset station has been set up.

Press the [MEM/M+] button (1) repeatedly while listening to the radio to select a preset station. Alternatively, press the [MEM/M+] button (1) once and then press the [BACKWARD] or [FORWARD] button (4 or 5) to select a preset station.

SLEEP TIMER

This sleep function defines the duration of time before the radio switches itself off automatically.

When the radio is switched on, press the [SLEEP] button (7) repeatedly to select a sleep period (Options: Off, 10, 20, 30, 40, 50, 60, 70, 80 and 90 minutes).

The radio will automatically switch off when the sleep period is over.

Press the the [SLEEP] button (7) button to check the remaining time before the radio switches off. Press the [RADIO ON/OFF] button (6) to cancel this function.

LED DIMMER

In Stand by mode, short press [SNOOZE] (7) button to set LED lightness.

CARE AND MAINTENANCE

To prevent fire or shock hazard, do not allow this clock radio to be exposed to rain or moisture.

This clock radio should not be exposed to direct sunlight, very high or low temperature, moisture, vibration, or placed in a dusty environment.

Do not use abrasives, benzine, thinners, or other solvents to clean the surfaces of the clock radio. To clean it, wipe with a mild non-abrasive detergent solution on a clean soft cloth. Never attempt to insert wires, pins, or other objects into the ventilation holes or openings on the clock radio.

Note: When setting the Clock or Alarm times remember that this clock radio has a 24 Hour clock mode.

TECNICAL SPECIFICATIONS

Power Supply:

AC 100/240V \~ 50/60Hz /DC 5V 1A Adapt.

Battery Backup 1X CR2032 (not included)

Radio Frequency Coverage

FM:

87.5 - 108 MHz.

General

Output Power: 1 x 0.35 Wrms.

Specifications and design are subject to possible modifications without notice due to improvement.

WARNINGS

CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN

The exclamation point within the triangle is a warning sign alerting the user of important instructions accompanying the product.

The lightening flash with arrowhead symbol within the triangle is a warning sign alerting the user of “dangerous voltage” inside the unit.

To reduce the risk of electric shock, do not remove the cover. No user serviceable parts inside the unit. Refer all servicing to qualified personnel.

This unit operates by AC/DC adaptor AC 100-240V\~50/60Hz / 5V 1A Ensure all connections are properly made before operating the unit.

This unit must not be exposed to moisture or rain.

This unit should be positioned so that it is properly ventilated. Avoid placing it, for example, close to curtains, on the carpet or in a built-in installation such as a bookcase.

Do not expose this unit to direct sunlight or heat radiating sources.

CORRECT DISPOSAL OF THIS PRODUCT (Waste Electrical & Electronic Equipment)

This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

LAGE DER BEDIENUNGSELEMENTE

Battery Backup 1X CR2032 (not included)

Simple line drawing of a trash bin with two crossed lines (no text or symbols)

Battery Backup 1X CR2032 (non inclus)

Simple line drawing of a trash bin with two crossed lines (no text or symbols)

COMMENT ÉLIMINER CE PRODUIT

Simple line drawing of a trash bin with crossed lines indicating no waste or plastic discharge (no text or symbols)

Simple line drawing of a trash bin with two crossed lines (no text or symbols)

Simple line drawing of a trash bin with two crossed lines and a black rectangular base (no text or symbols)

Simple line drawing of a trash bin with two crossed lines and a black bar at the bottom (no text or symbols)

CORRECTE AFVALVERWERKING VAN HET PRODUCT (elektrisch en elektronisch afval)

Simple line drawing of a trash bin with two crossed lines and a black rectangular base (no text or symbols)

Simple line drawing of a trash bin with diagonal lines crossing it, no text or symbols present

Hereby, Roadstar Management SA declares that the radio equipment type CLR-2310BK is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://roadstar.com/images/ce/CLR-2310BK.pdf or by scanning the following QR Code.

QR code image containing encoded data, no visible human-readable text

TEST REPORT - Energy Efficiency RegulationsEnergy Efficiency of External Power Suppliers
Nameplate Information	Value and precision	Unit	Verdict(PASS/FAIL)
Manufacturer's name or trade mark, commercial registration number and address	DongGuan Obelieve Electronic Co., Ltd/Address: Huazhaoxin industrial Park B-4/F, Golden Phoenix industrial Zone, Fenggan Town, Dongguan, guangdong Province, People'sRepublic of China.	-- --
Model identifier	OBL-0501000E	--	--
Input voltage	100-240V	V	--
Input AC frequency	50/60Hz Hz --
Output voltage	5 V --
Output current	1 A --
Output power	5 W --
Average active efficiency	73.62 % --
Efficiency at load 10%	75.2 % --
No-load power consumption	0.1	W	--
