USER MANUAL HG11090 SILVERCREST

Translation of the original instructions

FR BE

Warnings and symbols used Page 18

Introduction Page 19

Intended use.... Page 19

Scope of delivery.... Page 19

Parts list Page 19

Technical data Page 19

General safety instructions.... Page 20

First use ...... Page 23

Assembly Page 23

Product assembly Page 23

Attaching the wiper Page 23

Operation Page 23

Charging the product.... Page 23

Cleaning windows Page 24

Switching the product on/off Page 24

Vacuuming windows Page 24

Troubleshooting Page 24

Cleaning and maintenance Page 24

Storage Page 25

Disposal Page 25

Warranty Page 26

Warranty claim procedure.... Page 26

Service Page 26

EU Declaration of conformity Page 27

Warnings and symbols usedThe following warnings are used in this user manual and on the packaging:
	DANGER! This symbol in combination with the signal word “Danger” marks a high-risk hazard that if not prevented could result in death or serious injury.	——	Direct current/voltage
			NOTE: This symbol in combination with “Note” provides additional useful information.
	WARNING! This symbol in combination with the signal word “Warning” marks a medium-risk hazard that if not prevented could result in death or serious injury.		For indoor use only.
			Danger - risk of electric shock!
	CAUTION! This symbol in combination with the signal word “Caution” marks a low-risk hazard that if not prevented could result in minor or moderate injury.		Symbol for a protection class III product: The main part of the product operates within a completely safe voltage range.
	Do not use bleach Do not tumble dry
	Do not dry clean Washable at 60 °C
	Do not iron		Protected against splashing water from all directions.
	CE mark indicates conformity with relevant EU directives applicable for this product.		Safety information Instructions for use

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is designed for cleaning and vacuuming smooth surfaces (e.g. windows). Do not use it for any other purpose.

This product is only intended for private household use, not for commercial purposes.

The manufacturer accepts no liability for damages caused by improper use.

- Scope of delivery

After unpacking the product, check if the delivery is complete and if all parts are in good condition. Remove all packing materials before use.

1x Vacuum attachment
1x Dirt water container
1x Motor unit
1x Wiper
1x Water container
2x Fiber cover
1x USB cable (Type A - Type C)
1x User manual

Parts list

1 Vacuum attachment
2 USB cable (Type A - Type C)
3 Fiber cover (x2)
4 Wiper
5 Spray nozzle
6 Water container (of spray bottle)
7 Charging socket (with cover)
8 Dirt water container
9 Motor unit
10 (on/off button with indicator light)
11 Eject buttons
12 Suction head
13 Release button (vacuum attachment)

- Technical data

Window vacuum cleaner

Rated input voltage: 5 V ---

Rated input power: 6 W

Battery type: Li-Ion Battery, 3.7 V 2200 mAh

Operating time: approx. 40 minutes

Charging time: approx. 2.5 to 3.5 hours

IP protection class: IPX4

Protection class: III

Emission Sound

pressure level: < 70 dB(A), K=3 dB

Dirt water container 270 ml (about 150 ml at capacity: MAX marking)

Spray bottle: 360 ml

General safety instructions

BEFORE USING THE PRODUCT, PLEASE FAMILIARISE YOURSELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, PLEASE ALSO INCLUDE ALL THE DOCUMENTS!

In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

Children and persons with disabilities

⚠ WARNING! RISK OF LOSS OF LIFE OR ACCIDENT TO INFANTS AND CHILDREN!

Never leave children unsupervised with the packaging material.

The packaging material represents a danger of suffocation. Children frequently underestimate the dangers. Always keep children away from the packaging material.

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. The product shall not be left unattended while it is connected to the supply mains. Keep the product out of reach of children when it is energized.

■ Children shall not play with the product.
■ Cleaning and user maintenance shall not be made by children without supervision.

Intended use

⚠ WARNING! Misuse may lead to injury. Use this product solely in accordance with these instructions. Do not attempt to modify the product in any way.

⚠️ATTENTION! Risk of product damage!

Do not expose the product to direct sunshine or heat. The ideal ambient temperature is between +5 and +35 °C. Extreme low or high temperature may damage the battery or the product.

Electrical safety

⚠️DANGER! Risk of electric shock! Never attempt to repair the product yourself. In case of malfunction, repairs are to be conducted by qualified personnel only.

⚠ WARNING! Risk of electric shock! Do not

immerse the product in water or other liquids. Never hold the product under running water.

⚠ WARNING! Risk of electric shock! Never use a damaged product. Disconnect the product from the power supply and contact your retailer if it is damaged.

⚠ WARNING! Risk of

injury! Switch the product off and disconnect it from the power supply before cleaning work and when not in use.

⚠ WARNING! Risk of

injury! This product contains a Lithium-Ion rechargeable battery that is only replaceable by skilled persons. Do not throw the product into a fire.

⚠ WARNING! To charge the rechargeable battery, use only a Class II power supply (not provided) approved for use with household appliances. SELV output: DC 5V, max. 6W.

• Do not operate the product while it is being charged.
  ■ Always charge the product in an open area away from flammable materials and liquids.

Misuse can cause fire and burns.

■ The product is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
■ Protect the connection cord against damages.

Do not let it hang over sharp edges, do not squeeze or bend it. Keep the connection cord away from hot surfaces and open flames.

Ensure that nobody can pull on or trip over it unintentionally.

Operation

■ Before using the product: Disconnect the USB cable 2 from the product.
- Keep the charging socket closed with the cover at all times to ensure the product's ingress protection against splashing water.
- Do not obstruct the ventilation slots during operation. A blocked ventilation circuit can result in overheating and damage to the product.

Cleaning and storage

■ Protect the product against dust and direct sunlight.
■ Store the product in a cool, dry place, protected from moisture and out of the reach of children.
■ Protect the product against heat.

Do not place the product close to open flames or heat sources such as stoves or heating appliances.

- First use

■ Remove all packaging materials. Check if all parts are complete.

NOTE: The product's built-in battery is not charged on delivery. Charge the battery completely before first use (see "Charging the product" section).

Assembly

Product assembly

Place the vacuum attachment 1 onto the suction head 12.

- Attaching the wiper

i NOTES:

Prior to assembling the wi 4 , fill the water container 6 with water and/or cleaning detergent.
- Do not use abrasive or aggressive cleaning detergents. These could damage the product.
Do not exceed the water contain 6 maximum capacity of 360 ml.
Screw the wi 4 onto the water container 6.
Unfasten the hook-and-loop strap on the side of the fiber cover 3 where is it is located.
Place a fiber co 3 on the wiper 4.
■ Fasten the hook-and-loop strap of the fiber cover 3.

Operation

● Charging the product

i NOTES:

Before charging the battery: Switch off the product.
■ Connect the USB ca2 to the product.
Connect the USB type A connector on the USB cable 2 to a suitable class II power supply (not provided) with rated output DC 5V, max. 6W. 10 lights up red.
■ When the battery is fully charged, 10 lights up blue.
■ Disconnect the product from the USB cable 2.
Do not leave the product permanently connected to the USB cable 2 to avoid damage to the battery or the product.

⚠ WARNING! To charge the rechargeable battery, use only a Class II power supply (not provided) approved for use with household appliances. SELV output: DC 5V, max. 6W.

On/off button light pattern

Light	10 Status
Blue on Power on. Fully charged (when charging).
Red on Charging.
Red flashing (slow)	Low power level.The product keeps operating.
Red flashing (fast)	Battery empty. The product turns off after 1 minute.
■ Close the charging soc7 with the cover7 properly. (see Line drawing)

- Cleaning windows

- Rotate the spray nozzle 5 to the desired setting:

Spray nozzle 5

STREAM	Jet stream
SPRAY	Water mist stream
OFF	No stream

Spray the window.
Wipe over the sprayed areas with the wiper 4. Loosen stubborn dirt.

- Switching the product on/off

■ Turning the product on: Press ⏻10. lights up blue.

■ Turning the product off: Press 10 again. The blue light goes off.

Vacuuming windows

i NOTES:

• Do not hold the product upside down. Do not move the product sideways.
  The maximum capacity of the dirt water container 8 is 270 ml. Stop operation when the MAX marking of the dirt water container is reached.

Turn on the product.
■ Move the blade of the vacuum attachment 1 slowly from top to bottom.

- When the MAX marking on the dirt water container 8 is reached, turn off the product.

■ Empty the dirt water contain 8 before further operation.

NOTE: To empty the dirt water container 8, pull it out from the motor unit 9 first. Remove the protective cap. Then, empty the dirt water container.

For best cleaning results, briefly dry the rubber wiper of the vacuum attachment 1 with a clean cloth after each removal.

● Troubleshooting

Problem Solution

The product is not working	Charge the product.
Streaks keep appearing during vacuuming	Clean the wi4 with water and/or detergent. After cleaning, let all parts dry completely.Use less detergent while cleaning the window.
The spray of the wiper 4 is not working	Refill the water container 6.Turn the spray no25 to SPRAY or STREAM.

● Cleaning and maintenance

⚠️ DANGER! Risk of electric shock!

Before cleaning: Always disconnect the product from the USB cable 2.

⚠ WARNING! Do not immerse the product's electrical components in water or other liquids. Never hold the product under running water.

- Do not use any abrasive, aggressive cleaners or hard brushes to clean the product and its accessories.

Cleaning the vacuum attachment 1, suction head 12 and motor unit 9

Press the release button 13 to remove the vacuum attachment 1 from the suction head 12.

Press the eject butt 11 to remove the suction head 12 from the motor unit 9.
■ Wipe down the parts with a slightly damp cloth.
- Do not let any water or other liquids enter the product interior.
■ After cleaning: Let all parts dry completely.

Cleaning the water container 6, dirt water container 8 and wiper 4

- Rinse the parts in water and/or mild detergent.

■ After cleaning: Let all parts dry completely.

Cleaning the fiber covers

The fiber covers 3 can be cleaned in a washing machine.

- Clean the fiber covers 3 with a mild setting, up to 60 °C.

■ After cleaning: Let the fiber cov 3 dry completely.

Storage

■ Store the product in the original packaging when it is not in use.

■ Store the product at a dry location out of the reach of children.

■ Store the product with an emptied water container 6 and dirt water container 8 only.

- Regularly charge the built-in battery (for example: monthly) if you do not use the product for a long period of time. This is necessary to preserve the battery.

Disposal

The packaging is made of environmentally friendly materials, which may be disposed of through your local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your wornout product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries / rechargeable batteries!

Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.

● Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

To ensure quick processing of your claim, observe the following instructions:

Make sure to have the original sales receipt and the item number (IAN 444808_2307) available as proof of purchase.

You can find the item number on the rating plate, an engraving on the product, on the front page of the instruction manual (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, contact the service department listed below either by telephone or by e-mail.

Once the product has been recorded as defective you can return it free of charge to the service address that will be provided to you. Ensure to enclose the proof of purchase (sales receipt) and a short, written description outlining the details of the defect and when it occurred.

Service

GB Service Great Britain

Tel.:[phone]

E-Mail:[e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail:[e-mail]

● EU Declaration of conformity

EU DECLARATION OF CONFORMITY (444808_2307)

IAN:	444808_2307
Product identification:	"SILVERCREST" CORDLESS WINDOW VACUUM CLEANER
Model Number:	HG11090

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2006/30/EC

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 60335-1:2012/A15:2021

EN 60335-2-2:2010/A1:2013

EN 60335-2-54:2008/A2:2021

EN 62233:2008

EN ISO 12100:2010

Directive 2006/30/EC

EN IEC 55014-1:2021

EN IEC 55014-2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 25.09.2023

Place

Date

ppa. Stefan Haensel

Authorised Signatory

Authorised Signatory
