USER MANUAL PET 25 D4 PARKSIDE

PDF ONLINE www.lidl-service.com

Exterior view of a Parkside electric shocker (no text or symbols on body)

ELECTRIC NAIL GUN/STAPLER / ELEKTROTACKER AGRAFEUSE ELECTRIQUE PET 25 D4

GB IE

ELECTRIC NAIL GUN/STAPLER ELEKTROTACKER

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

DE AT CH

Description of components 5

Package contents 5

Technical data....5

General Power Tool Safety Warnings 6

1. Work area safety....6
2. Electrical safety....6
3. Personal safety....7
4. Power tool use and care....7
5. Service 8

Appliance-specific safety instructions for electric staple guns....8

Before use....9

Filling the magazine....9

Setting the impact force....9

Use....9

Switching on and off....9

Stapling/nailing 10

Working with the rip fence....10

Troubleshooting....10

Maintenance and cleaning 10

Disposal 10

Warranty 1

Service 12

Importer 12

Translation of the original Conformity Declaration 13

ELECTRIC NAIL GUN/STAPLER PET 25 D4

Introduction

Congratulations on the purchase of your new appliance. You have chosen a high-quality product. The operating instructions are part of this product. They contain important information about safety, usage and disposal. Before using the product, please familiarise yourself with all operating and safety instructions. Use the product only as described and for the range of applications specified. Please also pass these operating instructions on to any future owner.

Intended use

This electric staple gun is intended for stapling cardboard, insulating material, leather, material (textiles or natural fibre) and comparable materials onto softwoods or plywood-like material in private households. The appliance is only for use in dry rooms. Any other uses of or modification to the appliance is deemed to be improper and carries the risk of serious personal injury. The manufacturer accepts no responsibility for any damage attributable to misuse. This appliance is not intended for commercial use.

Description of components

1 Trigger
② ON/OFF switch
③ Impact force control
4a Quick release button
4 Magazine slider
4b Marking of the fill level indicator
⑤ Rip fence
6 Magazine
⑦ Scale
⑧ Fill level window
3a Red line of the fill level indicator
9 Face plate

Package contents

1 electric nail gun/stapler

300 staples 25 mm

200 staples 15 mm

300 nails 32 mm

200 nails 25 mm

1 hex key

1 set of operating instructions

Technical data

Type PET 25 D4

Rated voltage 230 V \~, 50 Hz (AC)

Rated current 1.5 A(S2: 15min)

Operations up to

30 impacts/min

Short-term operation

(SO) max. 15 min

Protection class II / (Double insulation)

Staple width

6 mm

Staple length

15–25 mm

Nail length 15, 20, 25, 32 mm

alternating current

Read the instructions

This symbol indicates that the device complies with the protection class II.

Declaration of conformity (see chapter "Declaration of conformity"): Products marked with this symbol meet all the applicable Community regulations of the European Economic Area.

Noise and vibration data:

Noise measurement value determined in accordance with EN 60745-1. The A-rated noise level of the power tool is typically as follows:

Sound pressure level L_pA=81,1 dB (A)

Sound power level L_WA=92,1 dB(A)

Uncertainty K_pA / WA = 3 dB(A)

Wear hearing protection!

Vibration values determined in accordance with EN 60745-1:

Vibration emission value a_h = 3.013 m/s^2 ,

Uncertainty K = 1.5 m/s^2 .

WARNING!

The specified vibration emission value has been measured according to a standardized test method and can be used to compare an electric tool with another. The specified vibration emission value can also be used for an introductory assessment of the suspension. The vibration emission value can differ from the specification value during the actual use of the electric tool, depending on the way the electric tool is used.

NOTE

Try to determine security measures to protect the operator based on an estimate of the suspension during the actual terms of use (all parts of the operating cycle must be taken into account, for example times when the electric tool is switched off, and those in which it is switched on, but runs without stress).

General Power Tool Safety Warnings

WARNING!

Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/orserious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or batteryoperated (cordless) power tool.

1. Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

2. Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with
b) earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,

pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the offposition before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related\hazards.

4. Power tool use and care

a) Do not force the power tool.

Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.

b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children. Do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and

clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits, etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

5. Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

Appliance-specific safety instructions for electric staple guns

■ Always check that the power tool contains staples. Careless handling of the staple gun can lead to unexpected ejection of staples which could cause injuries.
■ Never aim the power tool at yourself or other people in the vicinity. Unintended triggering will cause a staple to shoot out, which can lead to injuries.
■ Do not activate the power tool until it is pressed firmly

against the workpiece. If the power tool is not in contact with the workpiece the staple can rebound off the fastening point.

■ Disconnect the power tool from the mains or battery if a staple becomes jammed in the power tool. If the staple gun is connected to a power source, it could be unintentionally activated while removing a jammed staple.

■ Be careful when removing a jammed staple. The system may be live and the staple could be forcefully ejected while you are attempting to unblock the jam.

■ Never use this staple gun for fastening electrical cables. It is not suitable for the installation of electrical lines, can damage the insulation of electrical cables and thus cause electrical shocks and increase the risk of fire.

WARNING!

To avoid risks, damaged mains cables of the appliance should be replaced by the manufacturer or the manufacturer's customer service department or a similarly qualified person.

Before use

NOTE

Only fill the magazine when the appliance is switched off! Set the ON/OFF switch ② to the position "0" and pull out the plug!

Filling the magazine

◆ Push the quick release button up 4, the magazine slider 4 will pop up automatically.
◆ Pull the magazine slider 4 to the maximum opening (see fig. A).
Fill the magazine 6 with staples or nails. Be sure the nails lie flat against the left side of the magazine. (See fig. B.) The nail heads must rest in the magazine's internal groove.
After filling, push the magazine slider ④ back into the magazine ⑥ as far as the stop and you hear and feel it click into place.

NOTE

When filling with nails, use the right shaft (as shown in fig. B). Ensure that the nail heads are always at the top.
Note the maximum fill level of approx. 72 staples or approx. 70 nails.
If the red line on the front of the magazine slider 8a coincides with the marking of the fill level indicator 4b, then the magazine is empty.

Setting the impact force

NOTE

Select the lowest impact force sufficient for stapling. Take into account the length of the staples or nails you are using as well as hardness of the material you are working with.

Impact force control ③

Increasing the impact force

◆ Turn the impact force control ③ to the left handside.
◆ Turn the impact force control ^3 to the right handside.

Reducing the impact force

Use

Switching on and off

Set the ON/OFF switch ② to the position "I" to switch the appliance on.
Set the ON/OFF switch ② to the position "0" to switch the appliance off.

Stapling/nailing

Switch the appliance on by moving the ON/OFF switch ② to the position "I".
◆ Press the face plate ⑨ of the appliance onto the location on the material that you want to staple/nail.
◆ Press the trigger 1.

NOTE

The integrated safety switch on the face plate prevents accidental triggering.

Working with the rip fence

If you want to tack with nails or staples at a constant distance to an edge, proceed as follows:

◆ Pull out the rip fence 5.
Move the rip fence ⑤ along the scale ⑦ until it is at the required distance from the edge of the object that you want to work on.
Place the rip fence ⑤ onto the edge of the object that you want to work on.
Proceed as described in the section Stapling/nailing.

Troubleshooting

CAUTION!

Ensure that the appliance has been disconnected from the power in order to prevent it from being accidentally switched on and causing injuries.

Cause

A staple or nail is blocking the appliance.

Solution

Open the magazine slider 4 (fig. A). This will remove the tension. Use the hex key (fig. C) to remove the screws from the face plate 9.
◆ Remove the staple or nail.

The device may only be connected to a power supply with an impedance Z_max = 0.463 or less. If necessary, please contact your local power supplier or supply authorities.

Maintenance and cleaning

WARNING! RISK OF INJURY

▶ Always remove the plug from the power socket before working on the appliance.

The electric staple gun is maintenance free.

■ The appliance must always be kept clean, dry and free from oil or grease.
■ Always clean the appliance directly after finishing work.
■ Never permit liquids to enter inside the appliance.
■ Use a cloth to clean the housing. Never use petrol, solvents or cleansers which can damage plastic.

Disposal

The packaging consists of environmentally friendly material. It can be disposed of in the local recycling containers.

Do not dispose of power tools in your normal domestic waste!

The adjacent symbol of a crossed -out garbage can on wheels indicates that

this device is subject to the 2012/19/EU directive. This guideline states that at the end of its usage time you are not allowed to dispose of this device with normal household waste, but have to hand in in specially furnished collection points, recycling centers or disposal companies. This disposal is free of charge for you. Protect the environment and dispose of properly. The following applies to the German market:

When buying a new device, you have the right to return the corresponding old device to your dealer. Dealers of electrical and electronic devices with a sales area of at least 400 sqm and food dealers with a sales area of at least 800 sqm that regularly sell electrical and electronic devices are also obliged to take out old devices free of charge, even without a new device being bought if the old devices are bought in no dimensions are larger than 25 cm. The importer or seller offers you return options directly in the branches and markets. Find out more about the return options on site from your dealer.

If your old device contains personal data, you are responsible for your deletion before you return it. If this is possible without destroying the old device, you can see the old batteries or batteries and lamps before returning the old device for disposal and lead it to a separate collection. In the case of fixed batteries, it must be pointed out when disposal that the device contains a battery. You can find out further options for the disposal of the disused product from your community or city administration.

Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material

components for disposal if necessary. The packaging material is labelled with abbreviations (b) and numbers (a) with the following meanings: 1–7: plastics, 20–22: paper and cardboard, 80–98: composites

Your local community or municipal authorities can provide information on how to dispose of the worn-out product.

Warranty

Dear Customer,

This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.

Warranty conditions

The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.

If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.

If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.

Warranty period and statutory claims for defects

The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.

Scope of the warranty

This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.

The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches or parts made of glass.

The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.

This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.

The warranty period does not apply to

■ Normal reduction of the battery capacity over time
■ Commercial use of the product
■ Damage to or alteration of the product by the customer
■ Non-compliance with safety and maintenance instructions, operating errors
■ Damage caused by natural hazards

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN) 443711_2307 available as proof of purchase.
- You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com.

This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 443711_2307.

WARNING!

Have your appliance repaired by qualified specialists only. Always use genuine spare parts.
Plugs and power cords should only be replaced by the manufacturer of the power tool or the manufacturer's authorised customer service agent.

This will ensure that the safety of the appliance is maintained.

NOTE

Replacement parts not listed (such as carbon brushes, switch) can be ordered via our service hotline.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

IAN 443711_2307

Importer

Please note that the following address is not the service address. Please use the service address provided in the operating instructions.

Ga-Po Vertrieb GmbH

Heinrich-Horten-Str. 5

47906 Kempen

Germany

Translation of original CE declaration of conformity,

We, GA-PO Vertrieb GmbH, Heinrich-Horten-Str. 5, 47906 Kempen, Germany hereby explain that our product Electric Nail Gun/Stapler, Model no.: PET 25 D4 correspond the following guidelines:

Machinery Directive (20 06/42/EC)

EMC directive (2014/30/EU)

Rohs directive, changed by (EU) 2015/863 (2011/65/EU*)

*) The object described above fulfills the provisions of Directive 2011/65/EU of the European Parliament and the Council of June 8, 2011 to restore the use of certain dangerous substances in electrical and electronic devices.

Applied harmonized norms and specifications:

EN 60745-1:2009/A11:2010

EN 60745-2-16:2010

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021

EN 61000-3-11:2019

EN IEC 63000:2018

Documentation representative:

Dirk Wohlrab

Ga-Po Vertrieb GmbH

Heinrich-Horten-Str. 5

D-47906 Kempen

Poland Huelan

CE

Location, date: Kempen, 19/01/2024 Legal signature:

Roland Menken

Managing Director

Ga-Po Vertrieb GmbH

Inhaltsverzeichnis

Einleitung 15

Directive relative aux machines

(2006/42/EG)

WAARSCHUWING! LETSELGEVAAR
