Product type	Battery charger for power tools
Brand	Novus
Model	SC 30
Compatible batteries	Li-Ion CAS (Cordless Alliance System) 12-18 V, 1.3-10 Ah, 3-10 cells
Charging current	Not specified, varies by battery
Charging time	Variable depending on capacity and temperature
Supply voltage	230 V ~, 50 Hz (check rating plate)
Power consumption	Not specified
Protection class	II (double insulation)
Recommended charging temperature	0 °C to 40 °C
LED indicators	Power display (green) and alert indicator (red)
Functions	Self-test, automatic maintenance charge, protection against faulty battery and excessive temperature
Usage	Indoor only
Maintenance	Unplug before cleaning; wipe with a dry, lint-free cloth; do not use cleaning products
Safety	Do not charge non-rechargeable batteries; keep away from children; unplug if smoke appears; use a residual current circuit breaker type F ≤30 mA
Repairs	Reserved for a qualified electrician or Novus customer service
Weight	Approx. 0.5 kg
Dimensions (L x W x H)	Approx. 180 x 100 x 80 mm

Frequently Asked Questions - SC 30 Novus

What types of batteries can I charge with the Novus SC 30?

The charger is designed for Li-Ion batteries of the CAS (Cordless Alliance System) from 12 V to 18 V, with a capacity of 1.3 Ah to 10 Ah (3-10 cells). Never charge non-rechargeable batteries.

How do I charge a battery with the SC 30?

Push the battery fully onto the sliding seat (2) until it stops. The power display (3) flashes during charging. Once charging is complete, the light stays on steadily.

What does a permanently lit warning light (red) mean?

This indicates that the battery is not being charged due to temperature too high or too low. If the battery temperature is between 0°C and 50°C, charging starts automatically.

What should I do if the warning light flashes?

Flashing means the battery is defective or incorrectly inserted. Immediately remove the battery from the charger and check that it is pushed fully onto the sliding seat.

Can I leave the battery on the charger after charging?

Yes. The charger automatically switches to maintenance charge when the battery is full. The battery can remain in place and is always ready to use.

Is the charger suitable for outdoor use?

No, it is intended for indoor use only. Protect it from moisture and do not expose it to rain.

What safety precautions are there for children?

Children must not use the device. Keep them away from the charger and the work area. Store the charger out of their reach.

How do I clean the SC 30 charger?

Always unplug the charger before cleaning. Wipe it with a dry, lint-free cloth. Do not use cleaning products or liquids.

What to do in case of smoke or fire?

Immediately unplug the power cord. Do not use water to extinguish an electrical fire. Use a suitable extinguisher (CO2 or powder).

How to dispose of the charger at end of life?

Do not dispose of the device with household waste. Follow the WEEE directive (2012/19/EU): take it to a collection point for recycling of electrical and electronic equipment.

USER MANUAL SC 30 Novus

Black industrial electrical switch device with power cord and buttons (no visible text or symbols)

MONDAY Laser in 10V Ulmance B

SC 30
t (min)	46	92	52	60	80	104	120	160	52	60	80	88	104	120	124	140	160	208	220	248	280	320	400
U (V)	12	14,4	18
I_c (A)	2,6	1,5

WARNING Please read all instructions on safety and proper use. Failure to observe these instructions on safety and proper use can lead to electric shocks, fires and/or serious injury.

Please retain all instructions on safety and proper use for the future.

Safety instructions for chargers

1) General safety instructions

a) Please read the attached safety instructions and operating instructions thoroughly before using the charger. Please keep all attached documents. These documents must be included when passing on the charger.

2) Intended use

a) The chargers are only suitable for charging CAS (cordless alliance system) battery packs. b) This device is not suitable for use by persons with limited physical, sensory or mental capacity or with no experience and/or knowledge, unless where such persons are supervised by a person responsible for safety or have received instructions on how to use the device.

c) Never try to charge non-re-chargeable batteries. Risk of explosion! d) The user bears sole responsibility for any damage caused by improper use. e) Generally accepted accident prevention requirements and the supplied safety information must be observed. f) SC 30 is suitable for charging:

Li-ion battery packs (12–18 V, 1.3–10 Ah, 3–10 cells).

3) Special safety instructions

a) You must follow all text marked with this symbol to ensure your own protection and to protect your electrical device!

b) Danger of hazardous electrical voltage!

c) Slightly acidic, flammable fluid may leak from defective Li-ion battery packs! d) If battery fluid leaks out and comes into contact with your skin, rinse immediately with plenty of water. e) If battery fluid comes into contact with your eyes, wash them out with clean water and seek medical attention immediately! f) Do not recharge a fully charged battery pack!

g) Only for indoor use.

h) Protect your charger against moisture! i) Never allow children to use the device. j) Children should be supervised to ensure that they do not play with the device. k) Keep children away from the charger and/or work area! l) Store the charger in a place out of reach of children! m) Disconnect the power plug immediately if smoke or fire appears from the charger! n) Do not use a battery pack if it is defective!

4) Overview

a) See page 2. The images apply for all devices as an example.

1. Battery pack

2. Sliding seat

3. On indicator

4. Warning indicator

5) Commissioning

a) Prior to putting the device into operation, check to ensure the mains voltage and mains frequency stated on the nameplate match the data of your power supply.
b) Devices such as this that generate direct current can easily affect fault-current circuit breakers. Use type F or better with a release current of max. 30 mA.

6) Self-test

a) Insert the power plug.
b) The warning indicator (4) and on indicator (3) will light up for approx. 1 second.

7) Use

a) Charging the battery pack:

Slide the battery pack all the way to the stop using the sliding seat (2).

The on indicator (3) will flash.

Note: To show the charging status for Li-ion battery packs, first remove the battery pack from the charger and push the button on the battery pack.

b) Trickle charging

Once charging is complete, the charger will automatically switch to trickle charging.

The battery pack can remain on the charger and is therefore always ready for use.

The on indicator (3) will stay illuminated.

8) Fault

a) The warning indicator (4) will stay illuminated

Battery pack is not charged. Temperature too high/low. If the battery pack temperature is between 0^ C and 50^ C, the charging process will begin automatically.

b) Warning indicator (4) flashes

Battery pack is defective. Remove the battery pack from the charger immediately.

Battery pack was not slid on the sliding seat (2) correctly. See Chapter 7.

9) Repair

a) Repairs on the charger may only be carried out by a qualified electrician! b) If the device's mains cable is damaged, it must be replaced by the manufacturer, its customer service team or a similarly qualified person to avoid any further damage.
c) If your Novus charger requires repair, please contact your Novus representative.

10) Environmental protection

a) Please follow the national regulations for the environmentally responsible disposal and recycling of decommissioned machines, packaging and accessories.

b) Only for EU countries:

Do not dispose of power tools with normal household waste! In accordance with European Directive 2012/19/EU on waste electrical and electronic equipment and its implementation in national law, all used electrical equipment must be collected separately and sent for environmentally compliant recovery.

11) Technical data

a) See page 2.

U = voltage range of the battery pack

C = battery pack capacity

I_c = charging current

t = charging time 1)

b) ^1) Depending on the remaining capacity and temperature of the battery pack, actual charging times may differ from specifications.

c) Recommended ambient temperature for charging:

0^ to 40^

d) Information subject to changes in technical advancements.

e) Device of protection class II

f) \~ alternating current

I_c = Ladestrøm

t = Ladetid 1)

$$ C = a k u m a h t u v u s $$

$$ I _ {c} = \text { laadimisvool } $$

$$ t = \text { laadimisaeg } ^ {1)} $$
