USER MANUAL HG08422A Livarno Lux

Assembly, operating and safety instructions

Adhesive pad Technical data Power adaptor + LED Strip: Total power consumption: 2.8 W LED Strip: LED: 30 LEDs (HG08422A) 32 LEDs (HG08422B) Note: The LED cannot be replaced. Power adaptor: Input voltage: 100–240 V∼ 50‒60 Hz, 0.07A27 GB/IE Output voltage: 12 V , 0.25 A Protection class: Model no.: SPA120025VL-01 SELV: Safety extra low voltage Ta: Maximum rated ambient temperature Tc: Rated maximum operating tempera- ture of the case of a controlgear This product contains a light source of energy efficiency class “F“ (for HG08422A). Scope of delivery 1 LED strip 2 Cable holders 1 Adhesive pad 1 Assembly, operating and safety instructions28 GB/IE Safety notes

KEEP THE INSTRUCTIONS FOR

USE IN A SAFE PLACE! Check the product for damage before use. Never use a dam- aged product. This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental ca- pabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Clean- ing and user maintenance shall not be made by children without supervision. The extremely high speed of the lights change during the colour change effect29 GB/IE can under certain circumstances result in visual impairment of children or predisposed persons (e.g. by mental illness). Never use the product if it is damaged in any way. Where breakage or damage to LEDs occurs the product must not be used/energised but disposed of safely. Only use the product with the components described in these instructions. Do not attach objects to the product.

CAUTION! RISK OF OVER-

HEATING! Do not operate the product inside the packaging or when it is rolled up. Protect the product from sharp edges, mechanical loads and hot surfaces. Do not expose the product to high temperatures or moisture, otherwise the product may be damaged. Do not secure with sharp staples or nails.30 GB/IE Never open a component of the electrical equipment or insert anything into a component of the electrical equipment. If the product is not in use for any length of time (e.g. holi- days), disconnect it from the power adaptor

The power cable cannot be re- paired! Should the power cable be damaged, the product must be rendered useless and must be disposed off appropriately. Ensure that the available net- work voltage agrees with the required input voltage of the power adaptor before use (100–240 V∼). Always check the product for damage before connecting it to the power adaptor

Always unplug the power adap- tor from the socket before instal- lation, dismantling or cleaning. This product does not contain any parts that can be serviced by the user. The LEDs and LED driver cannot be replaced.31 GB/IE The product is only suited for use with the included power adaptor (model no. (SPA120025VL-01). Do not use the product when covered or recessed into a surface. Interconnection shall be made only by the use of the supplied connectors. Any open ends must be sealed-off before use. Do not connect this product to another manufacturer’s product. Please note that the power adaptor continues to draw a small amount of power even if the product is turned off as long as the power adaptor is plugged into a power outlet. To switch the product off completely, unplug the power adaptor from the socket. The illuminants are not replace- able. If the illuminants fail at the end of their lives, the entire product must be replaced. Do not use the rope light when covered or recessed into a surface.32 GB/IE Interconnection shall be made only by the use of the supplied connectors. Any open ends must be sealed-off before use. Do not connect this rope light to another manufacturer’s product. Before use DANGER TO LIFE BY ELECTRIC SHOCK! Before performing any work, first disconnect the product from the mains power. Remove the power adaptor

from the socket. Note: Remove all packaging materials from the product. Mounting Note: Clean the surface well onto which you wish to mount the product. The surface must be clean, free from grease and dry. Otherwise the sticki- ness of the double-sided adhesive strip might be limited.33 GB/IE Remove the protective film from the adhesive strip on the back of the LED strip

and attach the LED strip

at the desired point (see Fig. B). You can also mount the supply cable

by using the included cable holders

using the attached double-sided adhesive strip. Please ensure that the power adaptor

is always accessible. Insert the power adaptor

into the socket before you turn on the product. Shorten the LED strip: You are able to individually shorten the LED strip

. It can be cut with scissors at the marked position (see Fig. C). Be sure to cover the open end of the LED strip

with the adhesive pad

before use (see Fig. E).34 GB/IE Start-up Switching the LED strip on / off Use the ON / OFF cord switch

to switch the LED strip

or off. Cleaning and care DANGER TO LIFE BY ELECTRIC SHOCK! Before performing any work, first disconnect the product from the mains power. Remove the power adaptor

from the socket. Use only a dry, lint-free cloth for cleaning. Disposal The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
