| Product type | Children's drawing projector |
| Brand | Crelando |
| Model | HG07964 |
| Power supply | 3 LR6/AA batteries (1.5 V) included |
| Operating voltage | 4.5 V DC |
| Power | 0.1 W |
| Bulb type | Non-replaceable LED |
| Lighting duration | Approximately 100 hours |
| Package contents | 1 projector, 1 base, 4 pattern discs, 5 sheets of paper, 6 colored pencils, 3 batteries, 1 instruction manual |
| Recommended age | From 3 years (under adult supervision) |
| Dimensions (approx.) | 15 x 10 x 10 cm |
| Weight (approx.) | 200 g |
| Use | Indoor only |
| Focusing | Manual adjustment via wheel |
| Number of patterns | 4 discs with varied patterns |
| Certification | CE |
| Cleaning | Wipe with a dry, lint-free cloth |
| Repairability | Non-replaceable LED, replace the entire unit |
Frequently Asked Questions - HG07964 Crelando
User questions about HG07964 Crelando
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Projector in PDF format for free! Find your manual HG07964 - Crelando and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. HG07964 by Crelando.
USER MANUAL HG07964 Crelando
KINDER-MALPROJEKTOR/KIDS' DRAWING PROJECTOR/PROJECTEUR DE PEINTUREPOURENFANTS
DE AT CH
KINDER-MALPROJEKTOR
Kurzanleitung
FR BE
PROJECTEUR DE PEINTUREPOURENFANTS
List of pictograms used
Introduction
Intended use
Parts description.. Page 13
Technical data.. 14
Scope of delivery.. 14
General safety instructions
Special safety instructions for handling batteries.. Page 14
Safety instructions for batteries/rechargeable batteries Page 15
Start-up Page 15
Inserting/replacing batteries.. 15
Use
Disposal
Service
| List of pictograms used | |||
| --- | Direct current/voltage | OPEN LOCK | This symbol indicates that the screw must be turned clockwise using a cross-tip screwdriver to lock the battery cover. |
| ······ | Adjust focus | ||
| Light on | CE | CE mark indicates conformity with relevant EU directives applicable for this product. | |
| ○ | Light off | ||
Kids' Drawing Projector
Introduction
This quick reference guide is a fixed part of the operating instructions. Keep both this
and the operating instructions in a safe place. When passing this product on to third parties, please be sure to include all documentation. Read the operating instructions before use, and pay particular attention to the safety instructions included in the operating instructions.
Scan the QR code, or download the complete operating instructions at www.lidl-service.com.
Intended use
This Kids projector is designed to trace images from the projector by using color pencils on the paper.
Any use other than that described above is prohibited and will result in product damage. The product is suitable for use in private households and not intended for commercial use. Damage compensation claims arising from unintended use, improper repairs, unauthorised alterations or the use of unapproved replacement parts will not be accepted. The user shall bear the sole risk.
- Partsdescription
Before reading, unfold the pages containing the illustrations and familiarise yourself with all functions of the product.
1 Projector
1a Focus control
[1b] On/Off button
2 Projector base
3 Motif disc
Color pencil
5 Battery
6 Drawing paper
7 Fixing screw (battery compartment cover)
8 Battery compartment
9 Battery compartment cover
Technical data
Operating
voltage:4.5V
Power: 0.1 W
Lamp: 1 LED (LED not replaceable).
Batteries: 3 × 1.5 ~V = L R6 (type AA)
Light on time: approx. 100 hours
- Scope of delivery
Remove all parts of this product from the packaging and remove all packaging materials. Before use, verify that the package contents are complete and undamaged! If you notice any damages or missing parts, please contact the retailer from whom you purchased this product.
1 Projector
1 Projector base
4 Motif disc
5 Drawing paper
6 Color pencil
3 Batteries (LR6/AA, 1.5V)
1 Instructions manual
General safety instructions
Before using the product, please familiarise yourself with all of the safety information and instructions for use! When passing this product on to others, please also include all the documents! Damage due to failure to comply with these operating instructions will avoid the warranty! We assume no liability for property damage or personal injury caused by improper handling or failure to observe the safety notes!
WARNING. Not suitable for children under 36 months. Small parts. Choking hazard.
WARNING. To be used under the direct supervision of an adult.
WARNING. Keep away from fire.
Mounting / Dismantling only by adults due to small parts which can be swallowed.
WARNING. All packaging materias are not part of the toy and for safety reasons should always be removed before it is handed over to children to play with.
- Never leave children unattended with the product or the packaging material. There is a danger of suffocation. Children frequently underestimate the dangers. Always keep children away from the packaging material. Children frequently underestimate the dangers. Always keep children away from the packaging material.
Retain packaging for future reference.
The product is suitable for children aged from 3 years old.
This product may be used by children as well as persons with physical, sensory or mental impairments or lacking experience and knowledge so long as they are supervised or instructed in the safe use of the product and they understand the associated risks. Cleaning and user maintenance must not be performed by children without supervision.
Use the product only in dry indoor areas.
This product's illuminant is not replaceable. The entire product needs to be replaced if the illuminant has reached the end of its service life.
Avoid the risk of damage to property
Check the product for damages before each use! Stop using the product if you notice any damages!
- Keep the product away from moisture, dripping water and splashing water!
Special safety instructions for handling batteries
Only an adult may insert and remove the batteries.
Rechargeable batteries may only be charged under adult supervision.
Remove rechargeable batteries from the toy before charging.
Safetyinstructions for batteries/ rechargeable batteries
DANGER TO LIFE! Keep batteries/ rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.
- Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION!
Never recharge non-rechargeable batteries. Do not short-cir
cuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.
- Never throw batteries/rechargeable batteries into fire or water.
- Do not exert mechanical loads to batteries/rechargeable batteries.
Risk of leakage of batteries / rechargeable batteries
- Avoid extreme environmental conditions and temperatures, which could affect batteries / rechargeable batteries, e.g. radiators / direct sunlight.
If batteries / rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!
WEAR PROTECTIVE
GLOVES! Leaked or damaged batteries/rechargeable bat
teries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.
In the event of a leakage of batteries / rechargeable batteries, immediately remove them from the product to prevent damage.
Only use the same type of batteries / rechargeable batteries. Do not mix used and new batteries / rechargeable batteries.
- Remove batteries/rechargeable batteries if the product will not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery / rechargeable battery!
Insert batteries/rechargeable batteries according to polarity marks (+) and (-) on the battery / rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery / rechargeable battery and in the battery compartment before inserting!
- Remove exhausted batteries/rechargeable batteries from the product immediately.
- Start-up
- Inserting/replacing batteries (see Fig. B)
Open the battery compartment cover on the back of the projector 1. To do this, remove the fastening screw 7 using a cross-tip screwdriver.
Remove any used batteries from the battery compartment 8 and insert three new batteries 5 (LR6 (type AA)) in the battery compartment 8.
Put the battery compartment cover back on the battery compartment 8 and fasten it by screwing the fastening screw 7 back on with a cross-tip screwdriver.
The product is now ready for use.
Use
Lay the projector bαs flat on the table, making sure that it stands firmly and does not wobble.
Place the projector in the opening provided in the projector base 2 and let it click into place (see Fig. C).
Select a motif and carefully insert it into the slot provided in the projector (see Fig. D).
IMPORTANT: Do not touch the foils of the motif discs 3.
Place a sheet of drawing paper under the projector base 2 (see Fig. E).
Switch off the light in the room or dim it if possible.
Switch the projector on using the on/off button 1b. The projector 1 projects the subject, e.g. a vehicle or an animal on the drawing paper 6
Use the focus control to adjust the focus so that the desired subject is shown in focus on the drawing paper (see Fig. F).
Turn the motif d to select a different motif, if necessary (see Fig. G).
Slide the drawing paper so that the projected subject appears in the desired location on the drawing paper.
Draw the motif on the drawing paper with a color pencil 4 (see Fig. H).
Tip: Alternatively use a pencil (not included) to trace the outline.
Then use the color pencil to color in the motif.
Change the motif as you wish by turning the motif disc 3 (see Fig.1) or replace the motif disc 3
Disposal
The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics / 20-22: paper and fibreboard / 80-98: composite materials.
The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.
Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.
Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.
Environmental damage through incorrect disposal of the batteries/rechargeable batteries!
Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.
Service
GB Service Great Britain
Tel.: 08000569216
E-Mail: owim@lidl.co.uk
