Product type	Weather station
Brand	TECHNOLINE
Model	WS 9136
Station power supply	2 AA batteries (LR6, 1.5 V)
Transmitter power supply	2 AAA batteries (LR3, 1.5 V)
Transmission frequency	868 MHz
Maximum transmission power	-7.54 dBm
Indoor temperature range	-9.9 °C to +37.8 °C
Outdoor temperature range	-39.9 °C to +59.9 °C
Transmission range	Approx. 100 m in open field
Display	Radio-controlled DCF-77 time, weather forecast (3 icons), indoor/outdoor temperature, MIN/MAX
Functions	Alarm with snooze, adjustable time zone, low battery indicator
Station dimensions (L x W x H)	124.4 x 25 x 130.4 mm
Transmitter dimensions (L x W x H)	32.4 x 14.1 x 86.5 mm
Maintenance	Clean with a soft damp cloth. Do not use abrasive products. Do not immerse.
Safety	Do not open the housing. Do not expose to extreme temperatures, sunlight or moisture. Keep batteries out of reach of children.
Repairability	Do not attempt to repair. Return to point of purchase.
General information	Compliant with directives 2014/53/EU and ROHS 2011/65/EC.

Frequently Asked Questions - WS 9136 TECHNOLINE

How to install batteries in the station and transmitter?

For the station, remove the back cover, insert 2 AA batteries (LR6, 1.5 V) observing polarity. For the transmitter, slide the battery compartment, insert 2 AAA batteries (LR3, 1.5 V). Replace the covers. Always replace batteries at the same time.

How to set the time manually?

Press the SET button to enter settings. Use the + button to set the time zone, then confirm with SET. Next, activate/deactivate DCF reception (ON/OFF). Finally, set the hours and minutes with the + button and confirm with SET.

How to activate or deactivate DCF signal reception?

Press SET until 'ON' flashes. Use the + button to toggle between ON (activated) and OFF (deactivated). Confirm with SET. In OFF mode, the clock works as a normal quartz clock.

What to do if the outdoor temperature is not displayed?

Check that the transmitter batteries are installed correctly. Make sure the distance between the station and the transmitter does not exceed 100 m and that no metal obstacles or interference (screen, TV) obstruct the signal. If necessary, reset both devices by removing batteries for 30 seconds.

How to set and use the alarm with snooze function?

Press and hold ALARM for 3 seconds to set the alarm time. Use + for hours, then briefly press ALARM for minutes. Confirm with ALARM. To activate/deactivate, press ALARM once. When the alarm sounds, press MIN/MAX RESET to activate snooze (10 minutes).

What is the transmission range between the transmitter and the station?

The maximum range is approximately 100 meters in open field. Inside buildings, the range may be reduced by walls, metal structures, and electrical interference. Keep devices at least 1.5 m away from interference sources.

How to interpret the weather icons and trend indicator?

The icons display Sunny, Cloudy or Rainy based on atmospheric pressure changes. The trend arrows indicate whether pressure is rising (improvement) or falling (deterioration). Forecasts are accurate to about 75% and require 12 to 24 hours of data collection after installation.

Why is the weather forecast not displaying correctly after installation?

After installation, the station needs 12 to 24 hours to collect pressure data at constant altitude. During this period, forecasts may be inaccurate. If you move the station to a different altitude, remove batteries for 30 seconds and reinstall.

How to reset MIN/MAX temperature values?

Press and hold the MIN/MAX RESET button for 3 seconds. All indoor and outdoor MIN and MAX data will be reset simultaneously.

How to mount the weather station on the wall?

Use a screw (not supplied) leaving the head protruding about 5 mm. Fold down the station foot and hang it on the screw. Ensure good signal transmission before final mounting.

USER MANUAL WS 9136 TECHNOLINE

DRAHTLOSE 868 MHz WETTERSTATION

WIRELESS 868 MHz WEATHER STATION

STATION METEO SANS FIL 868 MHz

DRAADLOOS 868 MHz WEERSTATON

STAZIONE METEOROLOGICA CON RADIOTRASMISSIONE DATI A 868

MHz

WETTERV OR HERSAGESYMBOLE:

Congratulations on purchasing this Weather Station with wireless 868 MHz transmission of outdoor temperature and display of indoor temperature, weather forecast icons and weather tendency indicators. It is further featuring a DCF-77 radio controlled clock and alarm function. With four easy-to-use function keys, this innovative product is ideal for use in the home or office.

FEATURES:

The Weather Station

LCD Display 12:34 23s 10s Function Keys

Hanging hole Battery compartment cover Fodout stand

• DCF-77 Radio controlled time function with manual time setting options
• DCF time reception ON/OFF
  • 24 hour display
  • Alarm function with snooze
  • Time zone +/- 12 hours
  • Temperature display in degree Celsius (°C)
  • hdoor and outdoor temperature with MIN/MAXr records
  • Manual reset of MIN/MAX records
  • 3 weather forecasticons with weather tendency indicator
  • Wireless transmission at 868 MHz
  • Signal reception interval at 4 seconds
• Low battery indicators
  • Wall mounting or table standing (fold out stand)

The Outdoor Temperature Transmitter

• Remotetransm sson or outdoor temperature to Weather station by 868 signals • Shower proof casing • Wall mounting and table sta ndng

SETTING GUP:

Note: This weather station receives only one outdoor transmi er.

1. First, insert the ba eries into the Temperature transmitter. (see "hstall and replace ba eries in the Temperature transmi er").

2. Within 30 seconds, insert the ba eries into Weather station (see "install and replace ba eries in the Weather station"). Once the ba erie sare in place, all segments of the LCD will light up briefly. Then the time (as 0:00) and the weather icon will be displayed. If these are not displayed after 60 seconds, remove the batteries and wait for at least 30 seconds before reinserting them.

3. After inserting the batteries, the Weather station will start receiving data from the transmitter. The outdoor temperature and the signal reception icon should then be displayed on the Weather station. If this does not happen after 3 minutes, the batteries will need to be removed from both units and reset from step 1.
4. In order to ensure sufficient 868 MHz transmission, this should under good conditions be a distance no more than 100 meters between the final position of the Weather Station and the transmitter (see notes on "Mounting" and "868 MHz Reception").
5. Once the remote temperature has been received and displayed on the Weather station, the DCF time (radio controlled time) code reception is automatically started. This takes typically between 3-5 minutes in good conditions.

Note:

Daily DCF reception is done at 02:00 and 03:00 every day. If the reception at 03:00 is not successful, then at 04:00 and 05:00 and 06:00 there are other tres, until one is successful. If the reception at 06:00 is still not successful, then the next try takes place at 02:00 next day. If reception is successful, the received time will override the manually set time. (Heaserefer also to notes on "DCF-77 Radio Controlled Time" and "Manual Time Se ing").

HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION The Weather Station uses 2 x AA, IECLR6, 1.5V batteries. When

ba eiles need to be replaced, the low baery ton will appear on the LCD. To install and replace the batteries, please follow the steps below: 1. Li up the battery compartment cover. 2. hsert ba eiles observing the correct polarity (s ee marking). Replace compartment cover.

HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER

The Temperature Transmitter uses 2 x AAA, IECLR3, 1.5V baery. To install and replace the batteries, please follow the steps below:

1. Remove the baery compartment cover at the back of the trans mi er.
2. Insert the ba-eries, observing the correct pdaarity (seemarking).
3. Replace the baery compartment cover on the unit.

Note:

In the event of changing b a erles in any of the units, allunits need to be reset by following the setting up procedures. This is because a security code is assigned by the transmit er at start-up and this code must be received and stored by the Weather station in the first 3 minutes of power being supplied to it

BATTERY CHANGE:

It is recommended to replace the batteries in all units regularly to ensure optimum accuracy of these units (Battery life See Specicaons below).

FUNCTION K EYS:

Weather station:

The weather station has bur easy to use function keys.

SET key 25 19 14 6 SET + ALARM MIN/MAX + key ALARM key RESET MIN/MAX RESET key

SET key

- Press the key to enter manual setting modes: Timezone, Time reception ON/OFF and Manual time

- Stop the alarm

+ ke y

• To make adjustment for various settings

- Stop the alarm

ALARM key

• Press and hold to enter the alarm setting mode
• Press the key to switch the alarm ON/OFF
- Stop the alarm

MIN/MAX RESET key

• Press and hold to reset the MIN/MAX temperature records
  • Activate the snooze
• Exit manual setting modes

LCD SCREEN AND SETTINGS:

Radio controlled time reception icon Alarm icon 12:34 Time Weather for east icon Low battery indicator (transmitter) Outdoor Reception Signal Icon* tendency y indicator 23.5 °C 10.3 °C Indoor Temperature in °C Outdoor Temperature in °C

Max. and Mh. indoor temperature records
Max. and Min. outdoor temperature records

* When the outdoor signal is successfully received by the Weather Station, this con will be switched on. (If not successful, the icon will not be shown in LCD) So user can easily see whether the last reception was successful (icon on) or not (icon o).

For a beer display clarity, the LCD screen is split into 3 sedi ons.

Section 1-TIME AND ALARM

• In norm almode disp ayof radb controlled time
- A reception tower symbol will be shown indicating that the DCF-77 time signal is scanned for (flashing) or received (steady). Note: The symbol will not be shown when radiotroneception is not successful or when time reception function is turned off.

- In normal display, the alarm icon will be shown when the alarm is turned on. When the snooze function is activated, the alarm icon will be flashing.

Section2 – WEATHER FORECAST AND WEATHER TENDE NCY ICONS

- Display of the weather to be expected in form of three weather symbols and two weather tendency indicators in form of an arrow, which change their appearance depending on the air pressure development

Section3 - NDOOR AND OUTDOOR TEMPERATURE

• Display the current indoor temperature and indoor MIN/MAX records
  • Display of low battery indicator (weather station)
• Display the current outdoor temperature and outdoor MIN/MAX records
• A signal reception symbol will be shown indicating that receiver is receiving outdoor temperature
  • Display of low battery indicator (transmitter)

MANUALSE TTIN GS:

The following manual settings can be done in the setting mode:

• Time zone
  • Time reception DCF ON/OFF
• Manual time

Press the SET key to enter the seeing mode:

TIME ZONE SETTING:

The time zone default is "0" hour. To set a different time zone:

1. The current time zone value starts flashing.

2. Use the +key to set the time zone. The range runs from 0, -1, -2... -12, 12, 11, 10... 2, 1, 0, in consecutive 1-hour intervals.

3. Confirm with the SET key and enter the Time reception/0 setting.

TIME RECEPTIONON/OFF SETTING

In area where reception of the radio-controlled time (DCF time) is not possible, the time reception function can be turned OFF. The clock will then work as anormal Quartz clock (Default setting is ON).

1. "On" will start flashing on the LCD.
2. Use the + key to turn OFF the time reception function if necessary.
3. Confirm with the SET key and enter the Manualme setting

Note:

If the Time Reception function is turned OFF manually, the click will not attempt any reception of the radio-controlled time (DCF time) as long as the Time Reception OFF function is activated. The Time Reception icon and the DCF icon will not be displayed on the LCD.

MANUAL TIME SETTING

In case the Weather station is not able to detect the radio-controlled time (DCF time) signal (due to disturba noes, transmitting d atance, etc.), the time can be manually set. The clock will then work as a normal Quartz clock.

To set the clock:

1. The hour digits start flashing in the time display section.
2. Use the +key to adjust the hours and then press SET key to go to the minute setting.
3. The minute will be flashing. Press the + key to just the minutes.
4. Confirm with the SET key and exit the setting mode.

Note:

The unit will still try to receive the signal despite a manual setting. When the signals received, the manually set time will automatically be replaced by the received time. During reception attempts, the DCF tower

icon will flash. If reception has been unsuccessful, the DCF tower icon will not appear but reception will still be a emptied.

ALARM SETTING

To set alarm:

1. Press and hold ALARM for about 3 seconds until the alarm time displays.
2. The hour digit and the alarmicon will be flashing. Press the +key to adjust the hour.
3. Press ALARM buon once and minute digit will be flashing.User shall then press + button to set the minute.
4. Press ALARM buon once to confirm the setting.
5. To activate/deactivate the alarm function, press the ALARM buon once. The display of the alarm icon represents that the alarm is "ON".

Note: The duration of alarm sounding is 85 seconds

TO ACTIVATE THE SNOOZE FUNCTION AND STOPPING THE ALARM:

1. When the alarm is sounding, press the MIN/MAX RESET key to activate the snooze function. The alarm will stop and reactivate after the snooze interval of 10 minutes.
2. To stop the alarm completely, press any keys other than the MIN/MAX RESET key.

WEATHER FORECAST AND TENDENCY THE

WEATHER FORECASTING ICONS:

There are 3 weather icons in the second section of LCD which can be displayed in any of the following combinations

sunny

Cloudy with sunny intervals

Ral ny

For every sudden or significant change in the air pressure, the weather icons will update accordingly to represent the change in weather. If the icons do not change, then it means either the air pressure has not changed or the change has been too slow for the Weather station to register. However, if the icon is played is a sun or raining cloud, there will be no change of icon if the weather gets any beer (with sunny icon) or worse (with rainy icon) since the icons are already at their extremes.

The icons display weather forecasts in terms of getting better or worse, and not necessarily sunny or rainy as each icon indicates. For example, if the current weather is cloudy and the rainy icon is displayed, it does

not mean that the product is faulty because it is not raining. It simply means that the air pressure has dropped and the weather is expected to get worse but not necessarily rainy.

Note:

After setting up, readings for weather forecasts should be disregarded for the next 12-24 hours. This will allow sufficient time for the Weather Station to collect air pressure data at a constant altitude and therefore result in a more accurate forecast.

Common to weather forecasting, absolute accuracy cannot be guaranteed. The weather forecasting feature is estimated to have an accuracy level of about 75% due to the varying areas the Weather Station has been designed for use in In area that experience sudden changes in weather (for example from sunny to rain), the Weather Station will be more accurate compared to use in areas where the weather is stagnant most of the time (for example mostly sunny).

If the Weather Station is moved to another boat on significantly higher or lower than its initial standing point (for example from the ground floor to the upper floors of a house), remove the batteries and re-insert them

after about 30 seconds. By doing this, the Weather Station will not mistake the new location as being a possible change in air-pressure when really it is due to the slight change of altitude. Again, disregard weather forecasts for the next 12 to 24 hours as this will allow time for operation at a constant altitude.

THE WEATHER TENDENCY INDICATOR

Working together with the weather icons are the weather tendency indicators (located on the left and right hand side of the weather icons). When the indicator points upwards, it means that the air-pressure is increasing and the weather is expected to improve, but when indicator points downwards, the airpressure is dropping and the weather is expected to become worse.

Taking this into account, you will see how the weather has changed and how it is expected to change. For example, if the indicator is pointing downwards together with cloud and sun icons, then the last noticeable

change in the weather was when it was sunny (sun icon only). Therefore, the next change in the weather will be the cloud with rain icons since the indicator is pointing downwards

Note:

Once the weather tendency indicator has registered a change in the air pressure, it will remain permanently visualized on the LCD.

INDOORTEMPERATURE AND MIN/MAX RECORDS

The indoor temperature and indoor MIN/MAX records are displayed on the last section of the LCD.

Indoor icon INDOOR 23.4°C MAX 24° MIN 18° INDoor Temperature MAX re cord MIN re cord

Note: The MIN/MAX indoor temperature records range from -9°C to +38°C with 1°C resolution.

OUTDOOR TEMPERATURE AND MIN/MAX RECORDS

The outdoor temperature and outdoor MIN/MAX records are displayed on the last section of the LCD.

Outdoor icon Outdoor Temperature MAXrecord OUTDOOR 18.3 MAX 25° MIN 20° Outdoor reception signal con MIN record

Note: The MIN/MAX outdoor temperature records range from -40^ to +60^ with 1^ resolution.

RESETTING THE ND OOR AND OUTDDOR MIN/MAX RECORDS

Note: All the MIN/MAX records will be reset at the same time.

1. In no ma ldispla ymode, press and hold the MIN/MAX RESET key for 3 seconds. This will reset the hdoor and outdoor MIN/MAX temperatures.

LOW BATTERY NDC ADR

Low battery indicator is displayed on the LCD when the batteries require changing.

868 MHz RECEPTION CHECK

The Weather stations should receive the temperature data within 3 minutes after set-up. If the temperature data is not received 3 minutes after setting up (not successfully continuously, the outdoor display shows "---"), please check the following points:

1. The distance of the Weather station or tran smi er s hould be at least 1.5 to 2 meters away from any interferingsources such as computer monitors or TV sets.
2. Avoid positioning the Weather station onto or in the immediate proximity of metal window frames.
3. Using other electrical products such as headphones or speakers operating on the same signal frequency (868MHz) may prevent correct signal transmission and reception.
4. Neighbours using electrical devices operating on the 868MHz signal frequency can also cause interference.

Note:

When the 868MHz signals received correctly, do not re-open the batterycover of either the transmitter or Weather station, as the batteries may spring free from the contacts and force a false reset.

Should this happen accidentally then reset all units(seeSetting up above) otherwise

transmission problems may occur.

The transmission range is about 100 m from the transmitter to the Weather station (in open space). However, this depends on the surrounding environment and interference levels. If no reception is possible despite the observation of these factors, all system units have to be reset (see Seng up).

POSITIONING THE WEATHER STATION:

The Weather Station may be hung onto wall easily or free standing.

To wall mount

Choose ash eltered place. Avoid d red rain and sunshine.

Before wall mounting, please check that the outdoor temperature values can be received from the desired locations.

1. Fix a screw (not supplied) into the desired wall, leaving the head extended out by about 5mm.

2. Hang the station onto the screw. Remember to ensure that it locks into place before releasing.

Free standing

With the following stand, the weather station can be placed onto any flat surface.

POSITIONING THE TEMPERATURE TRANSMITTER:

Transmitter is supplied with a holder that may be aached to a wall with the two screws supplied. The Transmier can also be posted on a latsurface by securing the stand to the boom of the Transmier.

To wall mount:

1. Secure the bracket onto a desired wall using the screws and plastic anchors.
2. Dip the remote temperature sensor onto the bracket.

Note:

Before permanently fixing the transmitter wall base, place all units in the desired locations to check that the

outdoor temperature reading is receivable. Invent that the signal is not received, relocate the transmitters or move them slightly as this may help the signal reception.

CARE AND MAINTENANCE:

• Extreme temperatures, vibration and shock should be avoided as these may cause damage to the unit and give inaccurate forecasts and readings.
• Precautions shall be taken when handling the batteries.juries, burns, or property damage may be resulted if the batteries are in contact with conducting materials, heat, corrosive materials or explosives. The batteries shall be taken out from the unit before the product is to be stored for a long period of time.

• immediately remove all low powered batteries to avoid leakage and damage. Replace only with new batteries of the recommended type.

• When cleaning the display and casings, use a soft damp cloth only. Do not use solvents or scouring agents as they may mark the LCD and casings.

• Do not submerge the unit in water.
• Special care shall be taken when handling a damaged LCD display. The liquid crystals can be harmful to user's health. Do not make any repair attempts to the unit. Return them to their original point of purchase for repair by a qualified engineer.
• Opening and tampering with the unit may invalidate their guarantee.
• Never touch the exposed electronic circuit of the device as there is a danger of electric shock should it become exposed.
• Do not expose the units to extreme and sudden temperature changes, this may lead to rapid changes in forecasts and readings and thereby reduce their accuracy.

Hereby, Technotrade declares that this product WS 9136 is in compliance with the essenal requirements and other relevant provisions of Direcve 2014/53/EU and ROHS 2011/65/EC. The original EU declaraon of conformity may be found at: www.technoline.de/doc/4029665091365

SPECIFICATIONS:

Recommended operating temperature range: 0°C to 50°C Temperature measuring range:

Indoor: -9.9°C to +37.8°C with 0.1°C resolution ("OF.L" displayed if outside this range)

Outdoor : -39.9°C to +59.9°C with 0.1°C resolution ("OF.L" displayed if outside this range)

Indoor temperature checking interval: every 16 seconds Outdoor data reception: every 4 seconds

Transmission frequency: 868 MHz Maximum transmission power: -7.54 dBm

Power consumption:

Weather station: 2 x AA,

IEC, LR6, 1.5V

Baery If e cy de (Alkaline ba erles recommended): Approx. 24 months

Temperature transmitter : 2 x AAA, IEC, LR3, 1.5V

Baery Ifecyde (Alkaline batteries recommended): Approx. 12 months

Dimensions (L x W x H) :

Weather station: 124.4 x 25 x 130.4

mm

Temperature transmitter : 32.4 x 14.1 x 86.5 mm

LIABILITY DI SCLA MER:

• The electrical and electronic wastes contain hazardous substances. Disposal of electronic waste in wild country and/or in unauthorized grounds strongly damages the environment.

- Pleasecontact your local or/and regional authorities to retrieve the addresses of legal dumping grounds with selective collecon.

- All electronic instruments must from now on be recycled. User shall take an acve part in the reuse, recycling and recovery of the electrical and electronic waste.

• The unrestricted disposal of electronic waste may do harm on public health and the quality of environment.

- As stated on the gi box and labeled on the product, reading the "User manual" is highly recommended for the benet of the user.

• This product must rubbish collecon however not be thrown in general points.

• The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any consequences that occur should an inaccurate reading take place.

- This product is designed for use in the home only as indication of the temperature and other weather data.

• This product is not to be used for medical purposes or for public informaon.

• The specicaons of this product may change without prior noce.

• This product is not a toy. Keep out of the reach of children.

- No part of this manual may be reproduced without written authorization of the manufacturer.

Environmental recepon eects

The staon obtains the accurate me with wireless technology. Same as all wireless devices, the recepon is maybe aected by the following circumstances:

• long transming distance
  • nearby mountains and valleys
  • near freeway, railway, airports, high voltage cable etc.
  • near construcon site
  • among tall buildings
  • inside concrete buildings
  • near electrical appliances (computers, TV's, etc) and metallic structures
  • inside moving vehicles

Place the staon at a locaon with opmal signal, i.e. close to a window and away from metal surfaces or electrical appliances.

Precauons

• This main unit is intended to be used only indoors.
• Do not subject the unit to excessive force or shock.
• Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity.
• Do not immerse in water.
• Avoid contact with any corrosive materials.
• Do not dispose this unit in a re as it may explode.
• Do not open the inner back case or tamper with any components of this unit.

Baeries safety warnings

• Use only alkaline baeries, not rechargeable baeries.
• Install baeries correctly by matching the polaries (+/-).
• Always replace a complete set of baeries.
• Never mix used and new baeries.
• Remove exhausted baeries immediately.
- Remove baeries when not in use.
• Do not recharge and do not dispose of baeries in re as the baeries may explode.
• Ensure baeries are stored away from metal objects as contact may cause a short circuit.
- Avoid exposing baeries to extreme temperature or humidity or direct sunlight.
- Keep all baeries out of reach from children. They are a choking hazard.

Use the product only for its intended purpose!

Consideraon of duty according to the baery law

Old baeries do not belong to domesc waste because they could cause damages of health and environment. You can return used baeries free of charge to your dealer and collecon points. As end-user you are commied by law to bring back needed baeries to distributors and other collecng points!

Consideraon of duty according to the law of electrical devices

This symbol means that you must dispose of electrical devices separated from the General household waste when it reaches the end of its useful life. Take your unit to your local waste collecon point or recycling centre. This applies to all countries of the European Union, and to other European countries with a separate waste collecon system.

STATION METEO868MHz

Manuel dUtilisation

INSTANT TRANSMISSION

INTRODUCTION :

REMPLACEMENT DES PIL ES:

Touche SET (r églag e) SET + ALARM MAX / MAX Touche MIN/MAX RESET Touche + Touche ALARM

ToucheSET (Réglage):

ECRAN LCD ET REGLAGES:

TEMOIN DE PILES FAIBLES

DRAADLOOS868 MHz WEER STATION

Handling

INLEIDING:

Technical line drawing of an electrical enclosure with internal components and a separate schematic view (no text or symbols)

Technical line drawing of a mechanical or electrical enclosure with internal components and a separate rectangular component (no text or symbols)

Tasto SET SET + ALARM MIN/MAX RESET Tasto+ Tasto ALARM Tasto MIN/MAX RESET

Technical diagram showing three views of a door handle assembly: front, side, and side (no text or symbols present)

Technical line drawing of an electrical enclosure with a separate component shown in the corner (no text or symbols)

Ted a SET 25 19 14 b SET + ALARM MAX Ted a+ Ted a+ ALARM Tecia MIN/M AX
