USER MANUAL Calvi XP3410 KRUPS

PROBLÈMES CAUSES POSSIBLES SOLUTIONS

Le marc est très humide. Vous n’avez pas mis sufsamment de mouture. Mettez plus de café. L’espresso coule trop lentement. La mouture est trop ne, trop grasse ou farineuse. Choisissez une mouture légèrement plus grosse. Le porte-ltre est sale. Nettoyez votre porte-ltre selon les instructions du paragraphe NETTOYAGE ET ENTRETIEN ‑ B. Du porte‑filtre. Nettoyez également le ltre à café. La grille de passage de l’eau est encrassée. Quand l’appareil est refroidi, nettoyez la grille du passage de l’eau avec une éponge humide. Votre machine est entartrée. Détartrez votre machine conformément aux indications du mode d’emploi. Un écoulement d’eau prolongé du porte-ltre après confection d’un espresso est visible. Votre machine est en train de s’entartrer en raison d’une eau particulièrement calcaire. Détartrer sans plus attendre votre machine conformément aux indications du mode d’emploi. Présence de marc de café dans la tasse. Le porte-ltre est encrassé. Nettoyez le porte-ltre à l’eau chaude. La mouture est trop ne. Utilisez une mouture légèrement plus grosse. Le joint de l’emplacement du porte-ltre est encrassé. Nettoyez l’emplacement du porte-ltre et le joint avec une éponge humide.8

PROBLÈMES CAUSES POSSIBLES SOLUTIONS

PROBLÈMES CAUSES POSSIBLES SOLUTIONS

Ihr Espresso schmeckt nicht gut. Nach dem Entkalken wurde das Gerät nicht korrekt gespült. Spülen Sie das Gerät der Bedienungsanleitung gemäß durch und prüfen Sie die Qualität des Kaffees. Das Gerät funktioniert nicht. Die Pumpe funktioniert nicht, weil zu wenig Wasser im Wasserbehälter ist. Befüllen Sie den Wasserbehälter und setzen Sie die Pumpe wieder in Betrieb (siehe Abschnitt: ERSTMALIGE INBETRIEBNAHME) . Vermeiden Sie, den Wasserbehälter vollständig leer zu pumpen. Der entnehmbare Wasserbehälter ist nicht korrekt positioniert. Setzen Sie den Wasserbehälter korrekt ein.20 A Water tank lid B Removable water tank C Cup tray D Control panel: D1 On/Off button with indicator light D2 Espresso button with indicator light E Filter holder mount F Filter holder G Drip grid H Drip tray I Measuring scoop J Filter one cup TECHNICAL SPECIFICATIONS Electromagnetic pump: 15 bars Filter holder Soft-capsule compatible Automatic shut-off after 5 minutes (environmental protection) Removable water tank (capacity: 1 litre) Power: 1460 W Voltage: 230 V - 50 Hz Safety devices to protect against overheating Dimensions: H. 286 mm, L. 145 mm, D. 309 mm IMPORTANT! Voltage: this appliance is designed to function on 230V alternating current only. Type of use: this appliance is designed for DOMESTIC USE ONLY. PRACTICAL TIPS Thank you for your condence in and loyalty to KRUPS products. You have just purchased the most compact espresso machine in our range. DESCRIPTION For best results, use freshly roasted coffee. Ask a roaster for advice. The freshness of coffee is only preserved for a few weeks after roasting. Good packaging may improve and prolong the preservation of coffee for longer. If you are not sure about the quality of the packaging, choose a recently roasted coffee. Coffee should always be ground just before being prepared. What type of coffee should i choose? For a coffee rich in aromas Choose pure Arabica coffee or those made from a majority of Arabica coffee. Artisan roasted coffees are the best as they offer more complex and rened aromas. To vary the avours, try pure origin coffees. For a full-bodied coffee Choose Robusta blended coffees - not specied as 100% Arabica - Italian roasted coffees, or those specied as Italian. CAUTION: the safety precautions are part of the appliance. Read them carefully before using your new appliance for the first time.21 English Keep ground coffee in the fridge to maintain its avour for longer. Do not ll your lter holder to the top, but use the measuring scoop (1 scoop for a 50ml cup). Remove excess coffee from the rim of the lter holder. If you do not use the appliance for longer than 5 days, empty and rinse the water tank. Before removing the tank to ll or empty it, always ensure that the appliance is switched off. Always place the appliance on a at, stable surface. USING FOR THE FIRST TIME ‑ or after long periods of not using your Espresso maker. Rinsing and initiating the system before first use. Before using your coffee machine, clean all the accessories in soapy water, rinse and then dry. Rinse the system following the procedure below: Plug your machine in (1). Open the lid and remove the water tank (2). Fill the tank with water at room temperature and place it back on the appliance, ensuring that it is tted securely in place. Close the lid (3-4). Switch on the appliance by pressing the On/Off button (D1). A short beep will sound when the machine is switched on and off, which is completely normal. This corresponds to the switching on/off of the pump (5). The temperature light (D1) ashes and then remains on (6). Insert the lter holder (F) (without coffee) into the appliance: turn it to the right as far as it will go (7). Place a container with a volume greater than 1/2 litre under the lter holder (8). To prepare the system, press the Espresso button (D2) and hold down until water ows through the lter holder (9). As soon as water ows out, you can release the button. The duration of this cycle is limited to one minute to avoid any overheating. Leave your appliance to cool. If the water doesn't ow through (pump initiation) repeat the procedure from the beginning without the lter holder. Rinsing the machine: to do this, press Espresso (D2) to allow the equivalent of ve 50ml cups of espresso to ow through (10). Leave to rest for a few minutes. Repeat this procedure four times ensuring that the tank contains enough water Remove the tank, empty, rinse carefully and replace in the appliance. IMPORTANT! If the appliance is not used for five minutes it will automatically switch itself off (environmental protection) IMPORTANT! A beep will sound each time the appliance is switched on or off (when pressing the on/off button (D1)). This is completely normal. This corresponds to the switching on/off of the pump (4).22 IMPORTANT! If the espresso machine is being used for the first time, the appliance must be cleaned as described in the paragraph "USING FOR THE FIRST TIME". With ground coffee The type of ground coffee you choose will determine the strength and avour of your espresso: the ner the coffee, the more intense the espresso. Open the lid and remove the water tank (2). Fill the tank with water at room temperature and place it back on the appliance, ensuring that it is positioned correctly. Close the lid (3-4). Plug your machine in (1). Switch the appliance on by pressing the on/off button (D1). A short beep will sound when the machine is switched on and off, which is completely normal. This relates to the switching on/off of the pump (5). The temperature light ashes while it is heating up and then remains on (6). The appliance is now ready to use. Unlock the lter holder by turning it to the left (11). Place a lter in the lter holder (12). Using the measuring scoop, add your ground coffee (1 scoop per cup) (12). Remove excess coffee from the rim of the lter holder. Insert the lter holder into the appliance, pushing it rmly to the right as far as it will go. Place a cup on the drip tray grid under the lter holder (13). Your appliance is programmed to prepare one or two 50ml cups of espresso. Press the espresso button (D2) (13). When the programmed quantity has been obtained, the espresso machine will stop automatically. Remove the cup. Unlock the lter holder by turning it to the left (11). Remove it from the appliance. To discard the grounds, turn the lter holder over while holding the lter in place using the tab to allow just the coffee grounds to fall out (14). Wash the lter holder and lter under running water to remove any remaining grounds (15). For better results, we recommend that you preheat the accessories in advance (lter holder, lter and cup) following the steps below without adding coffee. Leave your appliance to cool if you have made ve 50ml coffees consecutively. With a soft capsule Your machine is compatible with soft capsules (generally 60mm in diameter). Given that this type of capsule is not specically designed for espresso machines, you will obtain a less intense coffee than with ground coffee. Open the lid and remove the water tank (2). Fill the tank with water at room temperature and place it back on the appliance, ensuring that it is positioned correctly. Close the lid (3-4). Plug your machine in (1). Switch on the appliance by pressing the on/off button. A short beep will sound when the machine is switched on and off, which is completely normal. This relates PREPARING ESPRESSO23 English to the switching on/off of the pump (5). The temperature light ashes while it is heating up and then remains on (6). The appliance is now ready to use. Unlock the lter holder by turning it to the left (11). Place a lter in the lter holder (16). For best results in the cup, and to avoid leaks, place the whole capsule inside the lter. Capsules are designed to make one cup of coffee. Using two capsules on top of each other is not recommended. Insert the lter holder into the appliance, pushing it rmly to the right as far as it will go. To prepare your espresso, follow the procedure for preparing an espresso with ground coffee. Leave your appliance to cool if you have made ve 50ml coffees consecutively. Programming the amount of espresso To modify the pre-programmed quantity of water (50ml per cup approximately), proceed as follows: Fill the tank with water at room temperature and place it back on the appliance, ensuring that it is positioned correctly. Close the lid (3-4). Plug your machine in (1). Switch on the appliance by pressing the on/off button (5). The temperature light ashes while it is heating up and then remains on (6). The appliance is then ready to use. Unlock the lter holder by turning it to the left (11). Place a lter in the lter holder (12). Using the measuring scoop, add your ground coffee (1 scoop per cup) (12). Remove excess coffee from the rim of the lter holder. Insert the lter holder into the appliance, pushing it rmly to the right as far as it will go (7). Place a cup on the drip tray grid under the lter holder. Press the espresso (D2) button and hold down (>3 seconds) until the espresso light (D2) ashes. The coffee will ow through (17-18). When the desired amount of espresso has been obtained, press the espresso button (D2). This amount is then automatically recorded. Please note the volume of coffee shall not exceed 200 mls approximately. The next time the appliance is used, when you press the espresso button (D2), you will obtain the latest quantity recorded. To return to the original programmed amount, simply unplug your appliance.

CLEANING AND SERVICING

A. The appliance Unplug the appliance from the power socket each time you clean it, and leave to cool. Clean the outside of the appliance from time to time with a damp sponge. Clean and dry the tank, drip tray and grid regularly. Rinse the inside of the tank regularly. When a ne white layer clouds your tank, follow the descaling process (see paragraph DESCALING). Do not use alcohol-based cleaning products or solvents. After you have unplugged the appliance, regularly clean the grid through which the water passes, as well as the watertight seal, using a damp sponge (19).24 Clean using only a damp cloth without any detergent or scourer. B. The filter holder Using a damp cloth, clean the lter holder mount regularly in order to remove possible coffee residues stuck to the surface (19). In order to prolong the useful life of the watertight seal on the brewing head, do not put the lter holder back in place if the coffee machine has not been used for extended periods. To remove any deposits that could block the ow of your 1 cup lter, you may use the needle (23). C. The drip tray This should be cleaned each time the appliance is used. The presence of water is normal and is not a sign of leakage. Please empty it regularly (20-21). If necessary, clean the drip tray and the grid with water and a small amount of mild washing up liquid. Rinse and dry (22). IMPORTANT! Warning! Do not clean any parts of this appliance in a dishwasher. DESCALING Regular descaling of your appliance, as described in this paragraph, is the main factor in prolonging its useful life. The frequency with which you descale the appliance is related to the hardness of your water. Get advice from your water supplier. During this procedure, do not place your appliance on a marble work surface. The descaler might alter it. To help you, below is a table indicating the frequency with which you should descale the appliance depending on the hardness of the water used in the machine: DESCALING FREQUENCY Average number of coffees per week Soft water (<19°f) Hard water (19-30°f) Very hard water (30-30°f) Fewer than 7 Once a year Every 8 months Every 6 months From 7 - 20 Every 4 months Every 3 months Every 2 months More than 20 Every 3 months Every 2 months Every month If in doubt, monthly descaling is recommended. No repairs on the coffee machine in the case of: no descaling carried out, limescale build-up, accessories cleaned in a dishwasher, will be covered by the guarantee. A. Descaling the system

1. Unplug the appliance.

2. Insert the lter holder (without coffee) into the appliance and lock it in place, turning

it to the right as far as it will go (7).

3. Place a container with a volume greater than 1/2 litre under the lter holder (8).

4. Fill the tank with a mixture of three parts water to one part vinegar or citric/sulfamic acid.25

5. Plug the appliance in (1).

6. Press the on/off switch (5).

7. When the temperature light on the on/off switch stays on (6), press and hold the

Espresso button (D2) for 40 to 50 seconds (water will ow through the lter holder) (9).

8. Empty and replace the container if necessary.

9. Wait 5 to 10 minutes, then repeat the procedure twice.

10. Ensure that you do not empty the tank completely (in the case of deactivation, see

paragraph: USING FOR THE FIRST TIME). B. Rinsing IMPORTANT! After descaling, rinse two or three times with clean water (without coffee), as described in the paragraph on "USING FOR THE FIRST TIME". The appliance has been descaled and is ready to use again. GUARANTEE Your appliance is guaranteed, however, any connection or handling error, or use other that that described in the instructions will render the guarantee void. This appliance is guaranteed for domestic use only, any other type of use will render the guarantee void. No repairs due to a build-up of limescale shall be covered by the guarantee. For any after-sales problem or for spare parts, please contact your retailer or an approved service centre.

SOLUTIONS TO POSSIBLE PROBLEMS

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The grounds are very damp. You haven't added enough ground coffee. Add more coffee. The espresso ows through too slowly. The ground coffee is too ne, too greasy or oury. Choose a slightly more granular coffee. The lter holder is dirty. Clean the lter holder according to the instructions in paragraph CLEANING AND SERVICING ‑ B. The filter holder. Clean also the coffee lter. The grid through which the water passes is clogged. When the appliance has cooled, clean the grid with a damp sponge. Your appliance has a build- up of limescale. Descale your machine according to the instructions in the user manual.26

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The user sees prolonged water ow from the lter holder after making an espresso. Scale build-up is occurring on your machine because of particularly hard water. Immediately descale your machine as per the directions for use. Presence of coffee grounds in the cup. The lter holder is clogged. Clean the lter holder with hot water. The coffee is too ne. Use a slightly more granular coffee. The hinge on which the lter holder is mounted is clogged. Clean the lter holder mount and hinge with a damp sponge. No crema on the espresso. The coffee is too old. Use freshly ground coffee. The coffee is not suitable for espresso. Use ner ground coffee. There is too little coffee in the lter. Add ground coffee. The water tank leaks when carried. The valve at the bottom of the tank is dirty or defective. Clean the water tank and open the valve at the bottom of the tank with a nger. The valve is blocked by limescale. Descale your machine according to the instructions in the user manual. Water is leaking under the appliance. There's an internal leak. Check that the tank is tted correctly. If the leak continues, do not use the appliance, contact an approved service centre. The drip tray has not been tted correctly. Check that the drip tray is pushed to the back of the appliance. The drip tray is overowing. Empty and carefully rinse the drip tray and replace. The pump is abnormally hot. There is no water in the tank. Fill the tank with water and re-initiate the pump (see paragraph: USING FOR THE FIRST TIME). Avoid emptying the tank completely.27 English

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The espresso leaks over the edges of the lter. The lter holder is not positioned correctly. Put the lter holder in place and lock it (turning it from left to right as far as it will go). Remove excessive coffee grounds that prevent the lter holder to be locked. The rim of the lter holder is encrusted with coffee grounds. Remove excessive coffee grounds and clean the grid through which water passes with a damp sponge. The soft capsule is positioned incorrectly. Check that the soft capsule has been inserted correctly: the paper must not protrude outside the lter. Your espresso tastes bad. The appliance was not rinsed correctly after descaling. Rinse the appliance according to the instructions and check the quality of the coffee. The appliance doesn't work The pump has been deactivated due to a lack of water. Fill the tank with water and re-initiate the pump (see paragraph: USING FOR THE FIRST TIME). Avoid emptying the tank completely. The removable water tank has been tted incorrectly. Position the water tank correctly. If it is not possible to identify the cause of a malfunction, please contact an approved service centre. Never disassemble the appliance. (if the appliance has been disassembled, the guarantee may no longer be valid).
