Product type	Pneumatic stapler
Brand	DeWalt
Model	D51845
Recommended working pressure	4.8 - 8.3 bar
Max working pressure	8.3 bar
Air consumption per stroke	2.04 L (at 6.9 bar)
Sound pressure level (LCA)	< 92 dB(A)
Sound power level (LWA)	< 105 dB(A)
Hand/arm vibration level	3.21 m/s²
Magazine angle	20°
Fastener type	Full round head nails
Fastener length	50 - 90 mm
Shank diameter	2.9 - 3.3 mm
Weight	3.4 kg
Power supply	Compressed air
Work mode	Contact (bump) and sequential action
Package contents	1 nailer, 1 sequential trigger, 1 pair of safety glasses, 1 instruction manual
Warranty	1 year (plus 30-day satisfaction)
Maintenance	Daily lubrication with 10-15 drops of DeWalt pneumatic tool oil
Safety	Trigger lock-off switch and dry fire lockout
Depth adjustment	Yes, by unlock/lock button on the nosepiece
Belt/chevron hook	Integrated, reversible on both sides
Air fitting	3/8" standard with 3/8" to 1/4" adapter included

Frequently Asked Questions - D51845 DEWALT

How to load the D51845 nailer?

Always disconnect the tool from the air supply before loading. Lock the nail pusher in the rear position. Insert nails into the loading notch above the magazine. Unlock the pusher by pulling it back and then gently slide it forward to apply pressure against the nails.

How to clear a jammed nail in the tool?

Disconnect the air hose and lock the trigger. Remove all nails from the magazine. Turn the cam lock, hold it down and slide the magazine back to expose the jammed nail. Remove it with pliers if necessary. To replace the magazine, align the pin, push the lock and slide the magazine forward to the locked position.

How to adjust the driving depth?

To reduce the depth, press the unlock button, push the contact surface down, then lock. To increase the depth, press the unlock, push the surface up, then lock. Only perform this adjustment when the tool is disconnected from the air and the trigger is locked.

What types of nails to use with the D51845?

Use full round head nails, with a shank diameter of 2.9 to 3.3 mm, a length of 50 to 90 mm and an angle of 20° to 22°. Only use fasteners that meet the specifications in the manual.

How to lubricate the nailer?

Lubricate daily the tool with 10 to 15 drops of DeWALT pneumatic tool oil. Pour the drops into the air fitting on the end cap of the tool. Perform this operation after disconnecting the air.

What to do if the tool does not work?

First check the air supply, pressure and connection. If the temperature is low, warm the tool. Check that the air vent is not blocked and the tool is lubricated. If the problem persists, contact a DeWALT authorized repair center.

How does the sequential action mode work?

Sequential mode drives one nail each time you pull the trigger after pressing the contact surface against the workpiece. It is recommended for precise work. To use it, install the gray trigger (with a single nail icon). Press the contact surface, then pull the trigger.

How to use the nailer in bump mode?

Bump mode (with black trigger with three nails) allows fast nailing by holding the trigger pressed and bumping the contact surface against the workpiece. For a single nail, proceed as in sequential mode. For multiple nails, first pull the trigger then repeatedly press the contact surface.

What safety precautions to take when using?

Always wear safety glasses and hearing protection. Never point the tool at yourself or others. Disconnect the tool from air before any intervention. Use the trigger lock-off switch to prevent accidental firing. Never exceed the maximum pressure of 8.3 bar.

How to maintain the nailer to extend its life?

Each day, lubricate the tool with DeWALT pneumatic oil. Drain condensation from compressor tanks and hoses. Clean the magazine, pusher and contact mechanism with compressed air. Check that all fasteners are tight. Have the tool serviced regularly by an authorized center.

USER MANUAL D51845 DEWALT

You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make DeWALT one of the most reliable partners for professional power tool users.

Technical data

	D51823	D51845
Sound pressure (Lva) dB(A) < 92 < 92
Acoustic power (Lw) dB(A) < 105 < 105
Hand/arm weighted vibration m/s23.21	3.21
Recommended operating pressure bar 4.8 - 8.3 4.8 - 8.3
Max. operating pressure bar 8.3 8.3
Air consumption per shot 2.04 (at 6.9 bar)
Actuating mode	contact actuating	contact actuating
Magazine angle	31° 20°
Fasteners
type	clipped head	full round head
length	mm 50 - 90	50 - 90
shank diameter	mm 2.9 - 3.3	2.9 - 3.8
angle	31°-34°	20°-22°
Weight	kg 3.4	3.45

1) This value is a tool-related characteristic value and does not represent the influence to the hand-arm-system when using the tool. The influence to the hand-arm-system when using the tool will for example depend on the gripping force, the contact pressure force, the working direction, the adjustment of energy supply, the workpiece and the workpiece support.

EC-Declaration of conformity

D51823/D51845

DeWALT declares that these tools have been designed in compliance with: 98/37/EC, EN 792-13, EN 12549, EN 12096

For more information, please contact DeWALT at the address below, or refer to the back of the manual.

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40, D-65510, Idstein, Germany

Safety instructions

When using tools, always observe the safety regulations applicable in your country to reduce the risk of personal injury. Read the following safety instructions before attempting to operate this product. Keep these instructions in a safe place!

General

1 Keep work area clean

Cluttered areas and benches can cause accidents.

2 Consider work area environment

Do not expose tools to humidity. Keep work area well lit. Do not use tools in the presence of flammable liquids or gases.

3 Keep children away

Do not let children or visitors come into contact with the tool. Supervision is required for those under 16 years of age.

4 Store idle tools

When not in use, tools must be stored in a dry place and locked up securely, out of reach of children.

5 Dress properly

Do not wear loose clothing or jewellery. They can be caught in moving parts. Preferably wear rubber gloves and non-slip footwear when working outdoors. Wear protective hair covering to keep long hair out of the way.

6 Do not overreach

Keep proper footing and balance at all times.

7 Stay alert

Watch what you are doing. Use common sense. Do not operate the tool when you are tired.

ENGLISH

8 Use appropriate tool

The intended use is described in this instruction manual. Do not force small tools or attachments to do the job of a heavy-duty tool. The tool will do the job better and safer at the rate for which it was intended.

Warning! The use of any accessory or attachment or performance of any operation with this tool, other than those recommended in this instruction manual may present a risk of personal injury.

9 Maintain tools with care

Keep the tools in good condition and clean for better and safer performance. Follow the instructions for maintenance and changing accessories. Keep all controls dry, clean and free from oil and grease.

10 Check for damaged parts

Before using the tool, carefully check it for damage to ensure that it will operate properly and perform its intended function. Check for misalignment and seizure of moving parts, breakage of parts and any other conditions that may affect its operation. Have damaged guards or other defective parts repaired or replaced as instructed.

11 Have your tool repaired by an authorized DEWALT repair agent

This tool is in accordance with the relevant safety regulations. To avoid danger, tools must only be repaired by qualified technicians.

Additional safety instructions for pneumatic nailers

Always wear safety glasses.
Always wear ear protection.
Only use fasteners of the type specified in the manual.
- Do not use any stands for mounting the tool to a support.
- Never use the tool for any other purpose than specified in this manual.
- Prior to each operation check that the safety and triggering mechanism is functioning properly and that all nuts and bolts are tight.
- Use quick-action couplings for connection to the compressed air system. The non-sealable nipple must be fitted to the tool in such a way that no compressed air remains in the tool after disconnection.

Always use clean, dry compresses
Do not use oxygen or combustible gases as an energy source for this tool.
- Only connect this tool to an air supply where the maximum allowable pressure of the tool cannot be exceeded by more than 10% . In case of higher pressures, a pressure reducing valve including a downstream safety valve shall be built into the compressed air supply.
- Only use hoses with a rating exceeding the maximum operating pressure of the tool.
- Before transporting the tool, disconnect it from the compressed air system, especially where ladders are used or where unusual physical posture is adopted while moving.
- Disconnect the tool from the air supply when it is not in use.
- Avoid weakening or damaging the tool, for example by:

• punching or engraving
• modifi cations not authorised by the manufacturer
  guiding against templates made of hard material such as steel
• dropping or pushing across the floor

• applying excessive force of any kind

• Do not use the equipment as a hammer.

• Never point any operational fastener driving tool at yourself or at any other person.
• While working, hold the tool in such a way that no injuries can be caused to the head or to the body in the event of a possible recoil due to a disruption in the energy supply or hard areas within the workpiece.
• Never actuate the fastener driving tool into free space.
• In the work area, carry the tool at the workplace using only one handle, and never with the trigger actuated.
• Consider the conditions in the work area. Fasteners can penetrate thin workpieces or slip off corners and edges of the workpiece, and thus put people at risk.
• Do not drive fasteners close to the edge of the workpiece.

• Do not drive fasteners on top of other fasteners.
  Only use spare parts specified by the manufacturer or his authorised agents.

• Have repairs carried out only by the manufacturer or authorised agents having due regard to the information given in the manual and using the appropriate tools and equipment.

• Do not disassemble or block any parts of the fastener driving tool such as the safety yoke.
• Have the tool serviced properly and at regular intervals.

The following pictograms are shown on the tool:

Pneumatic tool with safety yoke.

Do not use on a ladder.

Compatible nail angles.

Maximum number of nails in magazine.

Nail diameter.

Nail length.

Max. operating pressure.

Nail type: full round head.

Nail type: clipped head.

Package contents

The package contains:

1 Nailer
1 Sequential action trigger
1 Pair of safety glasses
1 Instruction manual

• Check for damage to the tool, parts or accessories which may have occurred during transport.

Take the time to thoroughly read and understand this manual prior to operation.

Description (fi g. A)

Your nailer D51823/D51845 has been designed for driving fasteners into wooden workpieces.

1 Trigger/lock-off switch
2 Air fitting
3 Contact trip
4 Magazine

Assembly and adjustment

Trigger selection

These tools are assembled with a bump action trigger. A sequential action trigger is also included with the original packaging. For defini tions of "bump action" and "sequential action", see below.

• The grey trigger with a single nail printed on the side is the sequential action trigger. Installation of this kit causes the tool to function in sequential action mode.
• The black trigger with three nails printed on the side is the bump action trigger. Installation of this kit causes the tool to function in bump action mode.

Removing the trigger (fi g. B)

• Disconnect the airline from the tool.
• Remove all nails from the magazine.
• Remove the rubber grommet (5) from the end of the dowel pin (6).
• Remove the dowel pin.
• Remove the trigger assembly (7).

Fitting the trigger (fi g. B)

• Select the appropriate trigger.
• Insert the trigger assembly into the trigger cavity, ensuring that the trigger spring (8) is properly sealed.
• Ensure that the contact trip guide (9) is pushed fully upward so that it is flush with the tool housing and aligned with the housing holes (10).
• Insert the dowel pin (6) through the tool frame, contact trip guide and trigger assembly.
• Push the rubber grommet (5) onto the end of the dowel pin.

ENGLISH

Air fi tting (fi g. A)

These tools have a standard 3/8" pipe thread for the air fitting (2). The tool is assembled with a 3/8" to 1/4" adapter installed in the end cap.

• Wrap the male end of the fitting with Teflon tape to prevent air leaks.
• To install a 1/4'' fitting, screw the fitting into the 3/8'' to 1/4'' adapter in the end cap and tighten firmly.
  To install a 3 / 8'' ftting, remove the 3 / 8'' to 1 / 4'' adapter, if present. Screw the ftting into the end cap and tighten firmly.

Instructions for use

Always observe the safety instructions and applicable regulations.

Preparing the tool (fi g. C)

• Drain all condensation from the air compressor tanks and hoses.
• Lubricate the tool. See "Maintenance".
• Remove all nails from the magazine.
• Lock the nail pusher (11) in the back position.
• Check if the contact trip (3) and nail pusher (11) can move freely.

Do not use the tool if the contact trip or nail pusher cannot move freely.

• Check that the pressure of the air supply is below the maximum recommended operating pressure.
• Connect the air hose to the fitting on the tool.
• Check for audible leaks around valves and gaskets.
• Set the air pressure to the minimum recommended operating pressure.

Never use a tool that leaks or has damaged parts.

Cold weather operation

When operating tools at temperatures below freezing:

• Keep the tool as warm as possible before use.
• Disconnect the airline from the tool.
• Put 10 to 15 drops of D'WALT pneumatic tool oil (or winter-weight pneumatic oil containing ethylene glycol) into the air inlet.

• Set the air pressure to a maximum of 5.5 bar.

• Connect the air hose to the fitting on the tool.

• Load nails into the magazine as described below.
• Actuate the tool 5 or 6 times into scrap lumber to lubricate the o-rings.
• Increase the air pressure to the normal operating level.
• Use the tool in the normal manner.

Hot weather operation

The tool should operate normally. Avoid the heat of direct sunlight to avoid damage to the bumpers, o-rings, and other rubber parts.

Loading the tool (fi g. C)

Always disconnect the tool from the air supply before loading fasteners.

• Lock the nail pusher (11) in the back position.
• Select an appropriate collated nail stick. See "Technical data".
• Insert collated nail stick (s) into the loading slot on top of the magazine.
• Unlatch the nail pusher by pulling rearward and carefully slide the nail pusher forward to press against the nails.

Actuating the tool (fi g. D)

These tools are equipped with a trigger/lock-off switch (1). When rotated to the right, this switch prevents the tool from actuating.

When the switch is centred, the tool will be fully operational. The tool can be operated using one of two modes: sequential action mode or bump action mode. The trigger installed on the tool determines the mode of actuation.

Sequential action mode

The sequential action mode is used for intermittent nailing when very careful and accurate placement is desired.

• Fit the grey trigger as described above.
• Push the contact trip against the work surface.
• Pull the trigger to actuate the tool. Each trigger pull with the contact trip pushed against the work surface will drive one nail.

Bump action

The bump action mode is used for rapid nailing on fl at, stationary surfaces.

• Fit the black trigger as described above.
  To drive a single nail: Operate the tool as described for sequential action.
• To drive several nails: Pull the trigger first, and then push the contact trip repeatedly against the work surface.

Do not keep the trigger depressed when the tool is not in use. Keep the trigger lock-off switch rotated to the right to prevent accidental actuation when the tool is not in use.

Dry fire lockout

To protect the tool from damage, these tools are equipped with a dry fire lockout. The dry fire lockout prevents the tool from actuating when the magazine is nearly empty. When approximately 4 or 5 nails remain in the magazine and the tool ceases to operate, follow the loading instructions to load sticks of collated nails. See "Loading the tool".

Clearing a jammed nail (fi g. E)

If a nail becomes jammed in the nosepiece, follow these instructions to remove the nail:

• Disconnect the airline from the tool.
• Lock the trigger with the trigger lock-off switch.
• Remove all nails from the magazine.
• Flip up the cam latch (12).
• Push and hold the cam latch firmly inward as shown by the arrow (13) until the narrow portion of the latch pin (14) is exposed.
• At the same time, slide the magazine (4) rearward as shown by the arrow (15) to expose the bent nail.
• Remove the bent nail, using pliers if necessary.
• If the driver blade is in the down position, push the driver blade upward using a screwdriver.

• If the nail cannot be removed with the magazine retracted to the first stop, remove the magazine from the tool entirely. This can be accomplished by holding the cam latch (12) firmly inward while pulling the magazine rearward until it separates from the tool.

• To reattach the magazine, insert the latch pin (14) into the magazine bracket, align the front end of the magazine with the nosepiece pegs (16), push inward on the cam latch (12) and slide the magazine onto the tool.

• Slide the magazine forward to the fully closed position.
• Press the cam latch (12) into the locked position.
• Connect the air hose to the fitting on the tool.
• Load nails into the magazine. See "Loading the tool".

If nails become jammed in the nosepiece frequently, have the tool serviced by an authorised DeWALT service centre.

Depth Setting (fi g. F)

To reduce risk of serious injury from accidental actuation when attempting to adjust depth, ALWAYS:

• Lock OFF trigger.
• Disconnect air supply.
• Avoid contact with trigger during adjustments.

The depth that the nails are driven can be adjusted using the depth adjustment on the nosepiece of the tool.

To reduce the depth, press the unlock button (17) in. Slide the contact trip (3) down. Press the lock button (18) to secure contact trip.
To increase the depth, press the unlock button (17) in. Slide the contact trip (3) upward to the extent desired. Press the lock button (18) to secure contact trip.

Belt/rafter hook

These tools have an integrated belt/rafter hook. The hook can be rotated to either side of the tool and can be folded out of the way when not in use. To remove the belt/rafter hook:

• Remove the air hose from the fitting on the tool.
• Use pliers or a wrench to remove the nut for the belt/rafter hook from the end cap of the tool.
• Remove the belt/rafter hook, washer and detent spring.

ENGLISH

Maintenance

Your DeWALT tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends on proper tool care and regular cleaning.

Perform the following maintenance operations every day:

Lubricate tool with 10-15 drops of DEWALT pneumatic tool oil

• Insert drops into the air fitting on the end cap of the tool.

Drain all condensation from the air compressor tanks and hoses

• Open petcocks or other drain valves on the compressor tanks.
• Allow any accumulated water to drain from hoses.

Clean magazine, pusher, and contact trip mechanism

• Clean by blowing with compressed air.

Ensure that all fasteners on the tool are tight and undamaged

• Tighten loose fasteners using the appropriate tool.

Troubleshooting

If your tool seems not to operate properly, follow the instructions below. If this does not solve the problem, please contact your repair agent.

Tool does not work

• Check the air supply.
  If the temperature is low, warm the tool up.

Tool has insufficient power

• Check the air supply.
• Check if the air exhaust is clear.
• Lubricate the tool.

Top cap leaks air

• Tighten the cap screws.

Tool skips nails

• Check the air supply.
• Lubricate the tool.
  Clean the magazine and nosepiece.
• Check that the magazine latch is holding the magazine firmly.

Fasteners jam in tool

Make sure only to use fasteners of the type specified.
- Check that the magazine latch is holding the magazine firmly.
- Tighten the nosepiece screws.

Protecting the environment

Separate collection. This product must not be disposed of with normal household waste.

Should you find one day that your DeWALT product needs replacement, or if it is of no further use to you, do not dispose of it with household waste. Make this product available for separate collection.

Separate collection of used products and packaging allows materials to be recycled and used again. Re-use of recycled materials helps prevent environmental pollution and reduces the demand for raw materials.

Local regulations may provide for separate collection of electrical products from the household, at municipal waste sites or by the retailer when you purchase a new product.

DEWALT provides a facility for the collection and recycling of DEWALT products once they have reached the end of their working life. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf.

You can check the location of your nearest authorised repair agent by contacting your local DeWALT offi ce at the address indicated in this

manual. Alternatively, a list of authorised DeWALT repair agents and full details of our after-sales service and contacts are available on the Internet at: www.2helpU.com.

Unwanted tools and the environment

Take your tool to an authorized DEWALT repair agent where it will be disposed of in an environmentally safe way.

GUARANTEE

• 30 DAY NO RISK SATISFACTION GUARANTEE If you are not completely satisfi ed with the performance of your DeWALT tool, simply return it within 30 days, complete as purchased, to the point of purchase, for a full refund or exchange. Proof of purchase must be produced.

• ONE YEAR FREE SERVICE CONTRACT If you need maintenance or service for your DeWALT tool, in the 12 months following purchase, it will be undertaken free of charge at an authorized DeWALT repair agent. Proof of purchase must be produced. Includes labour and spare parts for Power Tools. Excludes accessories.

- ONE YEAR FULL WARRANTY

If your DeWALT product becomes defective due to faulty materials or workmanship within 12 months from the date of purchase, we guarantee to replace all defective parts free of charge or, at our discretion, replace the unit free of charge provided that:

The product has not been misused.
- Repairs have not been attempted by unauthorized persons.
Proof of purchase date is produced. This guarantee is offered as an extra benefit and is additional to consumers statutory rights.

For the location of your nearest authorized DeWALT repair agent, please use the appropriate telephone number on the back of this manual. Alternatively, a list of authorized DeWALT repair agents and full details on our after-sales service are available on the Internet at www.2helpU.com.

ESPANOL

MARTILLO CLAVADOR D51823/D51845

Enhorabuena!

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40, D-65510, Idstein, Alemania

L'emballage contient:

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40

D-65510, Idstein, Tyskland

1 ARS FRI VEDLIKEHOLDERSERVICE

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40, D-65510, Idstein, Alemanha

• Introduza as gotas no bocal

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40, D-65510, Idstein, Saksa

Turvallisuusohjeet

Director Engineering and Product Development Horst GroBmann

DeWALT, Richard-Klinger-StraBe 40, D-65510, Idstein, Tyskland

Sakerhetsinstruktioner

Piv xnpoonnoeTo epyaale diaa

npoeekia Tcapakatowoyiec kalpualaTe

Tες kaλά.

1 Daampeite Kaapo to xwpo epyaiaac

AkaTaoTAtoi Xwpoi Kai naykoE ykuovoukivuo Tpaumiaou.

2 Aβετε un' χηπ ειδραδεις τοῦ

περιβαλνοτός

MnV EkTeTE epyaiae Uypaia. PovTiTe yia Tov kaLo wTioo Tou xwpou epyaiaoc aC. MnV XpOauonoiEe pyaia KovTa oEupkTA uypa kalepia.

EouoiobotnEvo Kaataomua Service,

napakaiaoee va naepwnoeTe oTo
nanaeotepo Kaataaeta Service nC eTapiac
paac (Bne npakatw).Evaalaktka,mu laota
eouiootmeevv Kaataonmuatv Service
DeWALT kai noaec aeantoupeiec oxetuka e
tnv umpeia after-sales evai diaeoeuec oTo
Internet atd sieuuvan www.2helpU.com.

105

Belgique et Luxembourg	DeWALT	Tel:	+32 (0)015 - 15 47 9211
België en Luxemburg	Mechelen Campus, Schaliënhoevedreef 20E Fax:	+32 (0)015 - 15 47 9210
	B-2800	Mechelen	www.dewalt.com
Denmark	DeWALT TIf: 70 20 15 10
Sluseholmen 2-4 Fax: [phone]
2450 København SV www.dewalt-nordic.com
Deutschland	DrWALT Richard-Klinger-Straße 65510	Tel: Fax:	06126-21-2770 www.dewalt.de
		Idstein
Erlaç	Black & Dockcr (Hellas) S.A. Στράβωνος 7 & Bουλαγμενης 159 Πλυφάδα 16674, Αθηνα	Tηλ: Φαξ:	[phone] (01) 8983-570 (01) 8982-630
Espana	DrWALT Parque de Negocios "Mas Blau" Fax: [phone]	Tel:		934 797 400
Edificio Muntadas, c/Bargadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
France	DrWALT Tel: [phone]
Le Paisy Fax: [phone]
BP 21, 69571 Dardilly Cedex	www.dewalt.fr
Schweiz	DrWALT Tel: 01 - 730 67 47
Suisse	In der Luberzen 40	Fax:	01 - 730 70 67
Swizzera	8902 Urdorf	www.dewalt.ch
Ireland	DrWALT	Tel:		00353-2781800
Calpe House Rock Hill	Fax: [phone]
Black Rock, Co. Dublin	www.dewalt.ie
Italia	DrWALT	Tel:		800-014353
Viale Elvezia 2	Fax: [phone]
20052 Monza (Mi)	www.dewalt.it
Nederland	DrWALT BV	Tel:	0164 283000
Joulehof 12	Fax: [phone]
4622 RG Bergen Op Zoom	www.dewalt.com
Norge	DrWALT Tel: [phone]
Postboks 4814, Nydalen	Fax: [phone]
	0422	Oslo	www.dewalt-nordic.com
Österreich	DrWALT Tel: 01 - 66116 - 0
Workzeugevertriebs GmbH	Fax: 01 - 66116 - 14
Eriaerstraße 165, Postfach 320,1231 Wien	www.dewalt.at
Portugal	DrWALT Tel: [phone]
Rua Egas Moniz 173	Fax: [phone]
João do Estoril, 2766-651 Estoril
Suomi	DrWALT Puh: 010 400 430
Keilasatama 3	Faksi: [phone]
	02150	Espoo	www.dewalt-nordic.com
Kägelhamnen 3	DrWALT Fax: [phone]	Tel:	010 400 430
	02150	Esbo	www.dewalt-nordic.com
Sverige	DrWALT, c/o Regus
Fabriksgatan 7	Fax: [phone]
412 50 Göteborg	www.dewalt-nordic.com
Türkije	Merkez Servis
	Tersane Cad.	Tel:	0212 361 60 20
	Nafe Sokak 1-3/4 Karaköy - Istanbul	Faks:	0212 361 60 19
United Kingdom	DrWALT	Tel:		01753-56 70 55
210 Bath Road	Fax: [phone]
Slough, Berks SL1 3YD	www.dewalt.co.uk
648923-00			01/07
