USER MANUAL HS 0703 SEVERIN

1. Trimming comb and blade

4. Connecting jack – hair trimmer

5. Connecting jack – charging base (rear of

8. Slide control for cutting length adjustment

10. Push-on comb attachments, large/small

11. Connecting plug - adapter

Important safety instructions ■ Do not use the appliance in the vicinity of a bath, shower or swimming-pool, over a washbasin filled with water or any other receptacle containing water. There is also a risk when the appliance is switched off. Additional protection is offered by fitting an earth-leakage circuit-breaker with a rated tripping current not exceeding 30mA into your home installation. Please consult a qualified electrician. ■ Protect the appliance from moisture and splashing water and do not operate it with wet hands. ■ Before the appliance is used, the main body as well as any attachment fitted should be checked thoroughly for any defects. Should the appliance, for instance, have been dropped onto a hard surface, it must no longer be used: even invisible damage may have adverse effects on the operational safety of the appliance. ■ Switch off and remove the adapter from the wall socket - after use, - in case of any malfunction during use, - before cleaning the appliance. ■ Do not leave the appliance unattended. ■ Caution: the trimming blade is extremely sharp; to prevent injuries, ensure that at all times during use the blade does not touch the skin. ■ This appliance is not intended for use by any person (including children) with reduced physical, sensory or mental capabilities, or lacking experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. ■ Children should be supervised to ensure that they do not play with the appliance. ■ No responsibility is accepted if damage results from improper use, or if these instructions are not complied with. ■ This appliance is intended for domestic use only and not for commercial applications. ■ In order to comply with safety regulations and to avoid hazards, repairs of electrical appliances must be carried out by qualified personnel, including the replacement of the power cord. If repairs are needed, please send the appliance to one of our customer service departments. The address can be found in the appendix to this manual. Connection to the mains supply Make sure that the supply voltage corresponds with the voltage marked on the rating label of the adapter. Charging process Before using the appliance for the first time the battery must be fully charged, which will take about 10 hours. However, the appliance can 10remain on charge for a longer period without damage or danger. If you experience a considerable decrease in trimming performance, or if the indicator light starts flashing red, switch off the appliance and recharge the battery. The hair trimmer may also be used by means of the adapter. In this case, however, the battery must be briefly charged for approximately 10 minutes. The charging process, shown by the charge indicator, starts only once the unit is switched off.

Insert the connecting plug of the adapter into the corresponding jack on the charging base.

Ensure that the hair trimmer is switched off and place it into the charging base.

Insert the adapter into a suitable wall socket. The charging process begins automatically and is shown by the charge indicator, which remains lit as long as the base is connected to the mains. The charging process will only start if the unit has been switched off.

When the battery is fully charged, the indicator light changes from red to green.

Once the charging process is complete, always remove the adapter from the wall socket first before disconnecting the jack from the charging base.

The battery can also be recharged by inserting the connecting plug of the adapter directly into the connecting jack on the hair trimmer.

While charging, the transformer within the adapter will become warm. This is perfectly normal and safe and does not indicate a malfunction of any kind.

If the appliance has not been used for a long period, the capacity of the battery may decrease by a certain amount. However, full capacity will be restored after several charge/discharge cycles. Use Adjusting the cutting length The push-on comb attachments supplied allow for a step-by-step cutting length adjustment from 4 to 40 mm. The length can be gradually changed to 14 different positions by using the adjustment slide control and the two combs provided. Simply press the slide control button and select the desired cutting length. With the smaller comb, the following lengths can be selected: 4mm, 7mm, 9mm, 12mm, 15mm, 17mm and 20mm. The larger comb allows for lengths of 24 mm, 27 mm, 29 mm, 32 mm, 35 mm, 37 mm and 40 mm. To remove the comb attachment, set the adjustment slide control to its highest position and pull the comb off. 3-position switch The 3-position switch allows for the following settings: 0 appliance switched off 1 normal operation Turbo turbo function for thicker hair Operation ■ Before each use, always put a few drops of acid-free oil between the trimming comb and the trimming blade.

Always start with the highest setting of the push-on comb.

The hair should first be combed, and then generally cut against its natural direction.

For longer hair-cuts use the push-on comb or a normal comb.

Cut from bottom to top with the trimming comb lying against the head; lead the appliance upwards through the hair, moving it gradually away from the head at the same time.

For a shaped cut, reverse the appliance and shorten the hair from top to bottom without using the push-on comb.

Proceed in the same fashion when trimming a beard. 11Removing the batteries

The batteries can be taken out after one half of the housing has been removed. Use a small screwdriver to loosen the screws, then cut the terminal wires one by one, taking special care that the terminals are not short-circuited by mistake. Care and Cleaning ■ It is essential to switch off the appliance and then remove the adapter from the wall socket before cleaning and oiling. ■ To avoid the risk of electric shock, the appliance and the adapter must not be immersed in liquid or even allowed to come into contact with liquid.

If necessary, the exterior surfaces of the charging base and hair trimmer may be wiped with a dry, lint-free cloth. Trimming comb and trimming blade

After each use, use the cleaning brush to remove hair from between the trimming comb and the blade. The trimming head itself can be removed for occasional thorough cleaning, by using the thumbs to push the head gently down towards the base of the appliance. ■ Before use, and again after every 15 minutes’ operation,, put a few drops of acid-free oil between the trimming comb and the trimming blade and then switch the appliance on briefly to ensure that the oil is evenly distributed. Regular oiling will guarantee good cutting performance over a long period and a long service life.

When the appliance is not in use, put the protective cover over the trimming comb. Battery pack and battery disposal Remember to protect our environment. Do not dispose of the rechargeable Ni-MH battery pack contained in the hair trimmer in your domestic garbage. All batteries must be disposed of through the proper local ‘special garbage collection points’. Disposal Do not dispose of old or defective appliances in domestic garbage; this should only be done through public collection points. Guarantee This product is guaranteed against defects in materials and workmanship for a period of two years from the date of purchase. Under this guarantee the manufacturer undertakes to repair or replace any parts found to be defective, providing the product is returned to one of our authorised service centres. This guarantee is only valid if the appliance has been used in accordance with the instructions, and provided that it has not been modified, repaired or interfered with by any unauthorised person, or damaged through misuse. This guarantee naturally does not cover wear and tear, nor breakables such as glass and ceramic items, bulbs etc. This guarantee does not affect your statutory rights, nor any legal rights you may have as a consumer under applicable national legislation governing the purchase of goods. If the product fails to operate and needs to be returned, pack it carefully, enclosing your name and address and the reason for return. If within the guarantee period, please also provide the guarantee card and proof of purchase. 12F Tondeuse à cheveux rechargeable Chère cliente, Cher client, Avant d’utiliser cet appareil, l’utilisateur doit lire attentivement les instructions suivantes. Ce produit est conforme à toutes les directives relatives au marquage “CE”. Familiarisez-vous avec votre appareil
