MJ6350 - Massage device UFESA - Free user manual and instructions

Brand	UFESA
Model	MJ6350
Product type	Massage device
Power supply	Mains 220-240 V ~ 50/60 Hz (typical)
Main functions	Foot massage, leg massage, stimulation nodules, vibrating cushions
Massage modes	Automatic (rhythm, intensity and speed change automatically) and Manual (adjust intensity and speed)
Speed adjustment	3 levels: slow, medium, fast
Intensity adjustment	2 levels: high and low intensity
Safety timer	Automatic shut-off after 15 minutes
Indicator lights	Intensity, speed and massage mode indicators
Recommended use	Sitting on a chair (feet) or lying down (legs)
Maximum usage time	15 minutes per session, with a 30-minute rest before next use
Thermal safety device	Automatic shut-off in case of overheating due to excessive or prolonged use
Maintenance and cleaning	Clean with a slightly damp cloth; for stubborn dirt on the cushion, use 90% alcohol on a cotton swab
Medical precautions	Do not use in case of specific disorders (tuberculosis, tumors, circulatory problems, etc.); consult a doctor if in doubt
Repairs	Must be carried out by an Authorized Technical Service
Electrical protection	Use a residual current device (RCD) of 30 mA max
Operating environment	Indoors, dry, away from water and humidity

Frequently Asked Questions - MJ6350 UFESA

How to turn the device on and off?

Plug the device into the mains. Press the mode/power switch (8) to turn on: first press for AUTO, second for MANUAL, third to turn off.

What massage modes are available?

Two modes: Automatic (automatic variation of rhythm, intensity and speed) and Manual (you adjust intensity and speed).

How to adjust the massage intensity?

In manual mode, press the intensity switch/selector (6) to switch between high and low intensity.

How long can I use the device continuously?

The maximum duration is 15 minutes per session. After that, the device stops automatically. Wait 30 minutes before starting again.

Can I use the device standing up?

No, the device must be used in a sitting position (for feet) or lying position (for legs). Do not use it standing up.

How to clean the device?

Unplug the device. Clean the body with a slightly damp cloth. For the cushion, use a cotton swab soaked in alcohol for stubborn stains. Never immerse the device in water.

What to do if the device stops suddenly?

This is probably the thermal safety device that has been triggered. Unplug the device and let it rest for one hour before using it again.

Are there any medical contraindications?

Yes, do not use in case of tuberculosis, tumors, circulatory disorders, phlebitis, open wounds, etc. Consult your doctor if you have a pacemaker or are in doubt.

Is the device suitable for children?

No, this device is not a toy. It can be used with supervision in the presence of children or disabled persons.

Where to repair the device in case of malfunction?

Repairs must be carried out exclusively by an Authorized Technical Service. Never open the device yourself.

USER MANUAL MJ6350 UFESA

АЯ46

MJ6350

ES INSTRUCCIONES DE USO

GB OPERATING INSTRUCTIONS

FR MODE D'EMPLO!

PT INSTRUÇÕES DE USO

ESPAÑOL

NAMES OF PARTS & FUNCTIONS

1. Carrying handles.
2. Massage intensity indicators.
3. Massage speed indicator
4. Massage mode indicators.
5. Vibrating pads for relieving tension on the soles of the feet.
6. Massage intensity selector/switch.
7. Vibration speed selector/switch
8. Mode selector / OFF switch
9. Stimulation nodules
10. Non-slip feet

IMPORTANT SAFETY INSTRUCTIONS:

• Read through the instructions carefully before using the appliance for the first time. Safeguard them for future reference.
• CAUTION: To reduce the risk of burns, fire electric shock or injury, pay careful attention to the following safety instructions.
• Only to be connected to the voltages stated on the characteristics plate.
• The appliance should be powered via a residual current device (RCD) with a trip setting no higher than 30 mA.
• This appliance has been designed for domestic use only.
• Never use the massage appliance outdoors.
• Only use the massage appliance for the purposes described in this manual. Never use accessories not recommended by the manufacturer.
• This appliance is not a toy. Do not allow children to play with the appliance.
• Do not leave the appliance unattended while it is operating. Be especially careful when it is used by handicapped persons or near children.
• Unplug the appliance from the mains supply when it is not in use and before cleaning it.
• The ON/OFF switch should be in the OFF position when plugging it in or unplugging it
• Do not place the appliance on top of the bath when it is being used.

• The appliance should be placed out of reach of anyone in the bath.
  • Make sure that your hands are dry before touching the switch or unplugging it.

• Do not switch the appliance on if it is covered over by a towel, blanket or pillow. This could cause it to overheat and catch tire, short electrically or cause injuries.

• Never unplug it by tugging on the mains cable. Do not pull on the cable to move the appliance.
• Do not use the mains cable to carry the appliance around or use the cable as a handle.
• Keep the appliance away from heat sources.
• Do not block any of the vents on the appliance or place it on a soft surface, such as a bed or mattress, where the air vent may become obstructed. Keep the vents free from dust, dirt, fluff, etc.
• Never drop or insert objects inside any of the openings.
• Never use spray products while the appliance is operating.
• Do not use close to areas where aerosol sprays are being used or where oxygen is being administered.
• Do not stand while using the appliance, remain seated.
• Do not use it if you feel tired or sleepy.
• NEVER IMMERSE THE APPLIANCE IN WATER OR ANY OTHER LIQUID.
• Do not attempt to touch the appliance if it has fallen in water. Unplug it immediately.
• Do not store the appliance where it might fall into a bath or washbasin. Do not place it or allow it to fall in water or any other liquid. Store it in a dry place.
• Do not switch the appliance on if either the cable or plug are damaged, if it can be detected that it is not operating correctly or if it has suffered any type of damage.
• Cable repairs and replacements must be carried out exclusively by an Authorised Technical Service Centre.

MEDICAL PRECAUTIONS

• Do not use the appliance in the following cases: If suffering from tuberculosis, benign or malignant tumours, bleeding, skin inflammations, phlebitis, thrombosis, fresh open wounds or cuts, contusions, broken skin, varicose veins or diffuse pain in the calves.
• Consult your doctor if you have any doubt about the appliance's therapeutic uses.

• Not to be used on any part of the body that is anaesthetised

• Not to be used on any part of the body that has undergone surgery

• Not to be used for treating unexplained pains without first consulting your doctor.
• If you have any doubts about your state of health, consult your doctor before using this product.
• Not to be used on areas with sensitive skin or circulatory problems Unsupervised use by children or handicapped persons may be dangerous
• If you have a pacemaker fitted, consul your doctor before using this product.
• Not to be used for longer than 15 minutes.

PRODUCT FEATURES:

• An alternative to massage.
• Recuperate from fatigue.
• Stimulate blood circulation.
• Relieve tired muscles.
• Relax tense muscles.
• Alleviate neuralgia and muscle pain.

OPERATING INSTRUCTIONS:

Plug the appliance into the mains supply.

Always place the massager on a flat, stable surface.

Only to be connected to the voltages stated on the characteristics plate.

Do not switch the appliance on it either the cable or plug are damaged, if it can be detected that it is not operating correctly or if it has suffered any type of damage.

Press the Mode selector / OH switch [mode] J, (8).

The [AUTO.] indicator lamp will light up (automatic). Select the desired mode, "Automatic" or MANUAL.

Automatic mode: Automatically changes the rate of vibration, intensity and speed. No manual adjustments possible for intensity or speed of vibration.

Manual mode: The user can select the intensity and speed of vibration.

Whenever manual mode is selected the massage speed and intensity of vibration are set to high by default.

To adjust vibration speed

Press the [+] vibration speed selector / switch (7) to adjust the vibration speed and set the speed to your needs:

Each time the [ ] vibration speed selector/switch is pressed the corresponding speed indicator will light.

To adjust massage intensity

Press the 📄 massage intensity selector / switch (6) to adjust the intensity of the massage. The settings available are:

Each time the [ ] massage intensity selector / switch is pressed the corresponding massage intensity indicator will light.

To stop the appliance during massage, press the mode selector / Off switch [mode] (8).

1^a Press switches the appliance on in the [AUTO] position (automatic).

2^a Press switches over to the [MANUAL position.

3 ^a Press, switches the appliance off.

Unplug the appliance from the mains.

Auto-Off timer:

The timer starts as soon as the appliance is switched on and will automatically detail the massage function after 15 minutes

The timer is activated in both the [ AUTO. and [ MANUAL] positions.

APPLICATIONS

Follow the tips below to use the massager correctly:

To massage the soles of the feet, sit in a chai and place your feet on the vibrating pads. Focus the massage on the soles to alleviate any stress in the feet. (Figure -1)

To massage your legs, lie down and rest you calves on the vibrating pads. (Figure -2)

WARNING: Excessive massaging may produce adverse effects Limit massage time to a maximum of 15 minutes.

Do not halt the vibration mechanism by pressing down on the pads excessively during massage.

Do not extend the massage session after the 15 minutes of massage, i.e. the maximum time limit for each massage. If you wish to continue with the massage, wait 30 minutes before beginning again.

SAFETY DEVICE

Excessive, continued use or pressure on the pad may cause an increase in temperature which will trigger the safety device to stop the appliance. In such cases, unplu the mains cable from the wall socket an leave the appliance to cool down for air hour before attempting to reuse it. If the mains cable is left plugged in the vibration produced when it switches itself back or may cause an accident.

CLEANING & MAINTENANCE:

Unplug the appliance from the mains supply before proceeding to clean it. Otherwise there is a risk of electric shock and/or injury.

Do not use water to wash it. This could damage certain electric components or cause accidents.

To remove dirt from the main casing, use a slightly dampened cloth.

Do not use benzene based solvents or spray cleaners

Use cotton balls dampened with alcohol to remove any stubborn stains from the surface of the massage pad.

Storage

Keep the massager out of children's reach.

Store the massager in a cool dry place, not exposed to direct sunlight.

ADVICE ON DISPOSAL:

Our goods come in optimised packaging. This basically consists

in using non-contaminating materials which should be handed over to the local waste disposal service as secondary raw materials.

This product complies with EU Directive 2002/96/CE. The crossec wheelie bin symbol shown on the appliance indicates that when it

comes to dispose of the product it must no be included in with household refuse. It must be taken to a special refuse collection point for electric and electronic appliances or returned to the distributor when purchasing a similar appliance. Under current refuse disposal regulations, users who fail to take discarded appliances to special refuse collection points may be penalised. Correct disposal of discarded appliances means that they can be recycled and processed ecologically, helping the environment and allowing materials used in the product to be reused. For more information on available waste disposal schemes contact your local refuse service or the shop where the product was purchased. Manufacturers and importers are responsible for ecological recycling, processing and disposal of products, whether directly or via a public system.

Your local town council can provide you with information about how to dispose of obsolete appliances.

FRANÇAIS

NOMS DES ÉLÉMENTS ET FONCTIONS

PRECAUTIUNI MEDICALE
