| Product Type | Angle grinder (grinder) |
| Brand | Meister Craft |
| Model | MWS2400230 |
| Rated power | 2400 W |
| Power supply | 230 V ~ 50 Hz |
| No-load speed | 6000 min⁻¹ |
| Wheel diameter | 230 mm |
| Spindle thread | M14 |
| Cable length | 300 cm |
| Weight | 5.0 kg |
| Protection class | II (double insulation) |
| Compatible wheel types | Rough grinding and cutting wheels (depressed center A/B, flat) |
| Main functions | Rough grinding and cutting of steel, concrete, stone, aluminum, bronze |
| Soft start | Yes, electronic |
| Brush wear indicator | Control LED: green = good condition, red = replace |
| Auxiliary handle | Mountable in 3 positions |
| Protective guard | Supplied for cutting and grinding wheels (adjustable) |
| Spindle lock | Yes (button) |
| Sound pressure level LpA | 93 dB(A) |
| Sound power level LWA | 104 dB(A) |
| Hand/arm vibration ah | 6.43 m/s², uncertainty K=1.5 m/s² |
| Maintenance and cleaning | Unplug before maintenance; clean air vents; use a damp cloth without solvent |
| Brush replacement | Have them replaced in pairs by a specialist |
| Warranty | Valid with certificate and receipt; opening the device voids warranty |
Frequently Asked Questions - MWS2400230 Meister Craft
What types of work can I perform with this Meister Craft MWS2400230 grinder?
This grinder (angle grinder) is designed for rough grinding and cutting of materials such as steel, concrete, stone, aluminum, and bronze. It must not be used for polishing, brushing, or working with saw blades.
How do I mount and adjust the protective guard?
The protective guard (supplied for cutting and grinding wheels) is mounted by loosening the screw (7), turning the guard to the desired position, then retightening the screw. The closed side of the guard must always face the operator for optimal protection against sparks and debris.
What is the power and speed of this device?
The rated power is 2400 W at 230 V/50 Hz. The no-load speed is 6000 min⁻¹. It features a soft start thanks to the Softstart function.
How do I change the wheel?
Unplug the device. Press and hold the spindle lock button (8). Turn the spindle slightly until it engages. Use the supplied flange wrench to loosen the clamping nut. Replace the wheel, then tighten the nut firmly. Caution: the wheel may be hot after use – let it cool down.
How do I clean and maintain the device?
Always unplug before cleaning. Use a damp cloth (no solvent) and dry thoroughly. Clean the air vents regularly. For frequent metal work, blow out the vents and use a residual current device (RCD). Check the carbon brushes via the LED indicator: green = good, red = replace by a specialist.
What are the essential safety precautions?
Always wear safety glasses and hearing protection. Use the auxiliary handle, hold the device firmly, and do not wear loose clothing. Ensure the workpiece is securely fastened. Never use a damaged wheel and perform a 30-second test run after each tool change.
What should I do if the LED indicator turns red?
The LED indicator (1) turns red when the carbon brushes are worn. They must be replaced in pairs by an authorized specialist. Use this opportunity to clean dust from the contacts with a brush or compressed air.
What is the noise level of this device?
The sound pressure level LpA is 93 dB(A) and the sound power level LWA is 104 dB(A). Wear appropriate hearing protection.
Can I use this device with different diameter wheels?
This device is designed for wheels with a maximum diameter of 230 mm. Do not use larger diameter wheels. Smaller wheels can be used with appropriate adapters, but observe the permitted speeds.
How can I obtain spare parts or repairs?
Contact Meister after-sales service or an authorized specialist. Use only original parts. Opening the device voids the warranty. Keep the warranty certificate and receipt for any claims.
