ZU720T - Projector OPTOMA - Free user manual and instructions

Product type	DLP laser projector
Native resolution	WUXGA (1920 x 1200)
Brightness	7200 ANSI lumens
Contrast ratio	100,000:1
Light source	Phosphor laser (up to 20,000 hours)
Throw ratio	1.25 - 1.79:1
Keystone correction	Vertical and horizontal (4 corners)
Lens shift	Vertical ±100%, Horizontal ±30%
Power supply	100-240V AC, 50/60 Hz, 500W (max)
Dimensions (W x D x H)	486 x 393 x 160 mm
Weight	15 kg
Video inputs	2 x HDMI 1.4a, 1 x VGA, 1 x HDBaseT
Connectivity	RS232, RJ45, USB (service), 12V trigger
Noise level	34 dB (eco mode)
Key features	24/7 projection, Color correction, HDCP 1.4
Maintenance and cleaning	Clean air filter every 1000 hours
Security	Kensington lock, power-on password
Spare parts and repairability	Remote control, power cable, replacement filter
General information	2-year warranty, 3D compatibility (DLP Link)

Frequently Asked Questions - ZU720T OPTOMA

What is the lifespan of the light source of the ZU720T?

The laser light source of the projector has a lifespan of up to 20,000 hours in normal mode and can reach 30,000 hours in eco mode.

How to clean the projector's air filter?

It is recommended to clean the air filter every 1000 hours of use. Remove the filter, wash it with warm water and mild detergent, rinse and dry completely before reinstalling.

Can I use a standard HDMI cable to connect my computer?

Yes, the projector is equipped with two HDMI inputs compatible with HDMI 1.4a signals. Use a standard HDMI cable to connect your computer or other video source.

How do I adjust the size of the projected image?

Use the zoom ring on the lens to adjust the image size. The throw ratio is 1.25 to 1.79:1. You can also move the projector relative to the screen.

What should I do if the image is distorted?

Use the keystone correction (OSD menu) to straighten the image vertically and horizontally. You can also enable the 4-corner correction for precise adjustment.

Does the projector support 3D?

Yes, the ZU720T supports 3D DLP Link. You will need compatible active 3D glasses and 3D content (via HDMI). Enable 3D in the menu.

How do I reset the security password?

Access the Security menu via the OSD. To reset a forgotten password, contact Optoma support with the unlock code displayed on screen.

What image modes are available?

The projector offers several preset modes: Cinema, Presentation, sRGB, DICOM Sim, etc. You can also customize your own settings in the Image menu.

Can I install the projector on the ceiling?

Yes, the ZU720T supports ceiling installation. Use a suitable mounting kit (not included). Ensure the mount can support a weight of 15 kg.

How to use the HDBaseT function?

The HDBaseT port allows transmission of video, audio, and control (RS232) over a single Ethernet cable, up to 100 meters. Connect an HDBaseT transmitter to your source.

USER MANUAL ZU720T OPTOMA

Technical line drawing of a rectangular electronic device with a circular housing and mounting feet (no text or symbols)

TABLE DES MATIÈRES

SÉCURITÉ 4

"WARNING: MOUNT ABOVE THE HEADS OF CHILDREN."

Additional warning against eye exposure for close exposures less than 1 m.

"AVERTISSEMENT : INSTALLER AU-DESSUS DE LA TÊTE DES ENFANTS."

Complies with 21 CFR 1040.10 and 1040.11 except for conformance as a Risk Group 2 LIP as defined in IEC 62471-5:Ed. 1.0. For more information see Laser Notice No. 57, dated May 8, 2019.

IEC/EN 60825-1:2014 PRODUIT LASER DE CLASSE 1 GROUPE DE RISQUE 2

This Class B digital apparatus complies with Canadian ICES-003.

Remarque :

[Écran de projection]

[Écran de langue]

▶ HDR(High Dynamic Range)

Classification :

Line drawing of a computer monitor with ventilation grilles and an external panel, showing no text or symbols.

INFORMATIONS SUPPLÉMENTAIRES

47697 Westinghouse Drive,

Fremont, CA 94539, USA

www.optomausa.com

888-289-6786

510-897-8601

[e-mail]

Japon

東京都足立区綾瀬3-25-18

株式会社オーエス

[e-mail]

www.os-worldwide.com

Canada

47697 Westinghouse Drive,

Fremont, CA 94539, USA

www.optomausa.com

888-289-6786

510-897-8601

[e-mail]

Taiwan

12F., No.213, Sec. 3, Beixin Rd., Xindian Dist., New Taipei City 231, Taiwan, R.O.C.

www.optoma.com.tw

[phone]

[phone]

[e-mail]

asia.optoma.com

Amérique Latine

47697 Westinghouse Drive,

Fremont, CA 94539, USA

www.optomausa.com

888-289-6786

510-897-8601

[e-mail]

Hong Kong

Unit A, 27/F Dragon Centre,

79 Wing Hong Street,

Cheung Sha Wan,

Kowloon, Hong Kong

[phone]

[phone]

www.optoma.com.hk

Europe

Unit 1, Network 41, Bourne End Mills,

Hemel Hempstead, Herts,

HP1 2UJ, United Kingdom

(Royaume-Uni)

www.optoma.eu

[e-mail]

Chine

5F, No. 1205, Kaixuan Rd.,

Changning District

Shanghai, 200052, China (Chine)

[phone]

[phone]

www.optoma.com.cn

Benelux BV

Randstad 22-123

1316 BW Almere

Les Pays-Bas

www.optoma.nl

[phone]

[phone]

France

Bâtiment E

81-83 avenue Edouard Vaillant

92100 Boulogne Billancourt, France

[phone]

[phone]

[e-mail]

Espagne

C/ José Hierro,36 Of. 1C

28522 Rivas VaciaMadrid,

Espagne

[phone]

[phone]

Allemagne

Wiesenstrasse 21 W

D40549 Düsseldorf,

Germany (Allemagne)

[phone]

[phone]

[e-mail]

Scandinavie

Lerpeveien 25

3040 Drammen

Norway (Norvège)

[phone]

[phone]

[e-mail]

PO.BOX 9515

3038 Drammen

Norvège

Corée

WOOMI TECH.CO.,LTD.

4F, Minu Bldg.33-14, Kangnam-Ku,

Seoul,135-815, KOREA

korea.optoma.com

+82+2+34430004

+82+2+34430005
