Product Type	Travel Garment Iron
Brand	Eldom
Model	Ride DA34
Power	1000 W
Power Supply	230/115 V ~ 50/60 Hz
Dual Voltage Switch	Yes, mechanical switch for 115V or 230V
Steam Function	Yes, with steam switch (on/off)
Steam Shot	Yes, via button for extra steam
Folded Grip	Yes, for compact storage; lock release button at base
Indicator Light	Yes, illuminates when heating and cycling
Thermostat Control	Adjustable knob with temperature marks
Water Tank	Transparent with MAX level mark
Water Filling	Via inlet at top; use included funnel; tap or distilled water
Soleplate	Standard soleplate (material not specified)
Storage	Vertical, with cord wrapped loosely around heel; empty water tank
Cleaning	Wipe body and soleplate with damp cloth; do not immerse
Safety Features	Thermostat prevents overheating; child safety (age 8+ under supervision)
Intended Use	Household, occasional/travel ironing; not for regular use

Frequently Asked Questions - Ride DA34 Eldom

How do I change the voltage on my Eldom Ride DA34 iron?

Before connecting to mains, ensure the iron is unplugged. Use a flat-ended screwdriver to slide the voltage switch (on the base) to the correct position: 230V or 115V, matching your local supply. Do not switch when plugged in.

Can I use the steam function at any temperature?

No. Steam and steam shot work only when the thermostat is set to high temperature (marked on the dial). At lower settings, water may leak instead of producing steam. This is normal and not a defect.

How do I fill water into the iron?

Unplug the iron. Use the provided funnel (shaped to fit the inlet) to pour clean tap or distilled water into the tank (5). Do not exceed the MAX mark. Never fill directly from the tap.

How do I fold the grip for travel?

Ensure the iron is unplugged and cool. Press the lock release button (12) on the base and gently fold the grip (2) down. To unfold, pull the grip upward until it clicks into place.

What kind of water should I use?

Use clean tap water at room temperature or distilled water. Do not use mineral water, water with high calcium content, or battery water, as they may damage the iron.

How do I clean the iron?

Unplug and let the iron cool completely. Wipe the body and soleplate with a damp cloth, then dry with a clean cloth. Never immerse the iron or cord in water. Do not use abrasive cleaners.

Why is the iron not producing steam?

Check that the thermostat is set to a high temperature (steam zone). Ensure the steam switch (7) is in the steam position. Also, verify the water tank has enough water (below MAX). If water leaks instead, the temperature may be too low.

Can I use this iron for daily ironing at home?

No, this is a travel iron designed for occasional use. The manual states it is not suitable for regular use. For frequent ironing, consider a full-sized model.

What does the indicator light mean?

The light (1) turns on when the iron is heating and goes off when the selected temperature is reached. It cycles on and off during use as the thermostat maintains the temperature.

How should I store the iron?

Unplug and let it cool completely. Empty the water tank. Wrap the cord loosely around the heel rest. Store upright in a safe place to prevent residual water from leaking.

USER MANUAL Ride DA34 Eldom

Exterior view of a white and gray electric iron with open lid (no text or symbols visible)

_

| _

一

1

WSKAZÓWKI BEZPIECZEŃSTWA

• Before first use familiarise with the whole instruction manual
- Before plugging in make sure tally plate data are compliant to mains parameters. The iron can be operated with either of two power supply voltage systems: 115 V and 230 V. Before connecting the device to the mains, make sure that the switch (8) is in the position indicating the power supply voltage of your network.
- Plug the device in the socket with earthing
- Before plugging in and unplugging position the temperature dial on "min"
- The appliance should be unplugged by pulling the plug not the cable
- Before storing the iron wait until cools down completely and empty the water tank. For storing period you may wrap loosely the cord around the heel rest. Too tight wrapping may damage the cord.
- Store in safe place, in vertical position to prevent the remaining water leaking from steam vents and damaging the soleplate
- Keep the cord away from heat sources
• Before filling the water tank unplug the iron
• Do not leave without supervision when working
- Contact with hot metal surfaces as well as the steam may result in burning. Be careful while ironing.
- The device can be used by children aged 8 and older and by persons with limited physical, sensory or mental capabilities, or persons without sufficient experience and knowledge only under supervision or if previously instructed on the safe use of the appliance and the possible risks. Children shall not play with the appliance. Cleaning and maintenance that are theresponsibility of the user shall not be carried out by

children without supervision. Protect the appliance and the power cord against children under 8 years old.

• Do not use outdoors
• Do not immerse the cord or the appliance in water
• Unplug before cleaning
• Use only in households
• Serves only for ironing clothes
- Do not place in horizontal position on ironing board while ironing
• Do not use with damaged cord
- If the cord is damaged, to avoid danger, exchange it by authorised service providers
- Any mending of the device should be held by authorised service providers. Any modernisations or using spare parts or other elements other than original is forbidden and dangerous.
- Eldom sp.z o.o. shall not be responsible for any damages occurring as a result of improper usage

CAUTION: Travel iron is not suitable for regular use.

1. Indicator light
2. Folded grip
3. Steam shot button
4. Water inlet
5. Water tank
6. Thermostat knob
7. Evaporation switch
8. Voltage switch
9. Body
10. Sole
11. Base
12. Grip lock release

SPECIFICATION

power: 1000 W

Power supply: 230/115V \~ 50/60Hz

USE

Before the first use, remove (unpeel) the factory cover of the sole (10), unroll the power cord fully and set the proper power supply voltage with the switch (8).

During the initial use of the device, harmless odour may be emitted from it. This is short-lasting and has no effect on the operation.

POWER SUPPLY VOLTAGE SWITCH

The iron can be operated with either of two power supply voltage systems: 115 V and 230 V (fig. 2)

Before connecting the device to the mains, make sure that the switch (8) is in the position indicating the power supply voltage of your network. The position of the switch may be changed with a flat-ended screwdriver.

CAUTION

The switch position must not be changed when the device is connected to the mains!

FOLDED GRIP

The iron is fitted with the folded grip (2) and the sole (10). This solution facilitates storage of the device, e.g. during travels. To prepare the iron for use, hold it by the body (9) and pull the grip upwards to hear the click sound. This will release the sole (10) from the body (9). The grip may be folded after pressing the button (12) in the base of the device (11) (fot 1).

CAUTION

The grip may be folded and unfolded only when the iron is disconnected from the mains and is not hot (is cold).

IRONING WITHOUT STEAM

Before connecting the device to the mains, make sure that the switch (8) is in the position indicating the power supply voltage of your network.

Set the thermostat knob (6) in the position "off", and the steam switch (7) in the position "×" (no steam). Pull the grip (2) upwards and place the iron on the base (11).

Connected the device to the mains.

Set the temperature with the thermostat knob (6). The light (1) will go on.

Ironing may be started when the light (1) goes off, which means that the iron reached the required temperature. The thermostat will maintain the selected temperature, which will be signalled with the light (1) going on and off.

IRONING WITH STEAM

Ironing with steam and the steam shot function is only possible when high temperature is set. The range of temperature appropriate for use of steam is marked on the knob of the thermostat (6)

“✗ — ⚙” The steam function will not work correctly with different settings. Instead of producing steam, the iron will spill water, which is a normal symptom and is not subject to guarantee repairs.

The button (3) may be used to release additional volume of steam. The additional steam shot facilitates ironing of exceptionally resistant creases.

NOTE.

Steam is hot. Danger of scalding or burns.

The sole of the iron is heating up very quickly and needs more time to cool down. It must not be touched.

FILLING IN WITH WATER

Before filling up or replenishing water in the tank (5), disconnect the device from the mains. The iron may be filled up with clean tap water at room temperature or with distilled water. Never use mineral water, water with high calcium content or water for batteries. Use the enclosed container (with the shape matching the inlet opening) to fill up the iron tank.

Never pour water to the iron directly from the tap!

When pouring in water to the iron, make sure that the water level is below the "MAX" mark on the tank (5).

TIPS

• use tap or distilled water for the iron,
• reducing temperature with the thermostat knob will not make it go down immediately, you need to wait for the indication light to go on,
• do not use steam when the temperature is set to low,
• the iron should be stored disconnected from the mains, cooled down and without water,
• make sure to empty the tank (5) for travel. After emptying the tank (5), putting the iron aside is recommended for a longer time on the surface absorbing humidity so as to remove all residues of water.

CLEANING AND MAINTENANCE

Before cleaning, plug out the iron and wait for it to cool down completely.

The iron must not be immersed in water.

The iron must not be cleaned with rough, abrasive cloth or sponge, as it may destroy the device.

Wipe the body of the iron and the sole with a damp cloth, and dry it up with a clean cloth.

PROTECTION OF THE ENVIRONMENT

• The device is made of materials that may be reprocessed or recycled,
• they are to be delivered to the point of collection and recycling of electrical and electronic devices.

GUARANTEE

• The device is intended for private household use,
• it may not be used for professional applications,
• the guarantee shall become void if the unit is improperly operated.
