USER MANUAL SKHL 1200 B1 TRONIC

Model No.: HG10190A/HG10190B

Version: 06/2025

KERAMIK-HEIZLÜFTER / CERAMIC FAN HEATER / RADIATEUR SOUFFLANT CÉRAMIQUE TKHL 1200 B1

DE AT CH

KERAMIK-HEIZLÜFTER

Kurzanleitung

This product is only suitable for well-insulated rooms or occasional use.

FR BE

RADIATEUR SOUFFLANT CERAMIQUE

SK KERAMICKY TEPLOVZDUŠN¥ VENTILÁTOR

Krátky námod

GB/IE Short manual Page 16

List of pictograms used 17

Short manual. 17

Intended use. 17
Parts list 18
Technical data 18

General safety instructions. 18

First set-up of the product 22

Unpacking the product and basic cleaning. 22
Setting up the product 22

Operation. 22

Switching the product on. 23
Setting the temperature 23
Switching the product off. 23
Overheating protection. 23
Tip-over protection 23

Cleaning 23

Transport 24

Disposal 24

Warranty 24

Warranty claim procedure. 24
Service 24

Information requirements for electric local space heaters... Page 25

List of pictograms used
!	DANGER! - Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)	~	Alternating current/voltage
!	WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)	Hz	Hertz (supply frequency)
		W	Watt
!	CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)		Danger - risk of electric shock!
!	NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)		Symbol for a Protection Class II product
i	INFO: This symbol with the "Info" signal word offers additional useful information.		WARNING! Do not cover the product to prevent it from overheating.
	Use the product in dry indoor spaces only.		Safety information Instructions for use
CE	CE mark indicates conformity with relevant EU directives applicable for this product.

CERAMIC FAN HEATER

Short manual

This document is a shorter printed version of the complete instruction manual. Scanning the QR code takes you straight to the Lidl service website (www.lidl-service.com) where you can view and download the complete instruction manual by entering the article number (IAN) 487570_2501.

The short guide forms an integral part of this product. Prior to using the product, familiarize yourself with all operation and safety notes. Store the short guide in a safe place, and if you give the product to third parties, all documentation should be passed on to them as well.

Intended use

The product can be used for short-term heating of rooms. The product can also be used as a fan with the heating function turned off.
The product is not suitable for use in rooms where special conditions exist, such as a corrosive or potentially explosive atmosphere (dust, vapour or gas).
Do not use the product outdoors.
Any other use or modification of the product shall be deemed to be improper and entails a considerable risk of accidents.
The product is designed for household use; it is not suitable for commercial use.
The manufacturer accepts no liability for damages caused by improper use.

Parts list

(Fig. A)

Control light
2 Handle
3 Air outlet
4 Anti-slip feet
Tip-over protection
6 Air inlet
7 Mains cord with mains plug
8 Temperature controller
Healing level switch

Technical data

Input voltage: 220-240 V~, 50 Hz
Nominal power consumption: 1200 W
Low heating level: 700 W
High heating level: 1200 W
Fan operation: No heating power
Protection class: II/	☐

General safety instructions

BEFORE USING THE PRODUCT, FAMILIARISE YOUR SELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, ALSO INCLUDE ALL THE DOCUMENTS!

In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

Children and persons with limitations

WARNING! DANGER OF DEATH AND ACCIDENTS FOR TODDLERS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation.

Children frequently underestimate the dangers. Always keep children away from the packaging material.

CAUTION! This product is not a toy for children! Children are not aware of the dangers associated with handling electrical products.

Children of less than 3 years should be kept away unless continuously supervised.

Children aged from 3 years and less than 8 years shall only switch on/off the product provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.

Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the product or perform user maintenance.

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.

Children shall not play with the product.
- Cleaning and user maintenance shall not be made by children without supervision.

DANGER! Risk of electric shock! Never attempt to repair the product yourself. In case of malfunction, repairs are to be conducted by qualified personnel only.
WARNING! Risk of electric shock! Do not immerse the product's electrical components in water or other liquids. Never hold the product under running water.
CAUTION! Risk of electric shock! Do not use if there are visible signs of damage to the product. Disconnect it from the power supply and contact your retailer in the event of damage.
WARNING! Risk of injury! Turn off the product and disconnect it from the power supply before cleaning and when the product is not in use.
WARNING! Improper use may result in personal injury. Use the product only as described in the user manual. Never attempt to alter the product in any way.
The product must not be located immediately below a socket-outlet.

Do not use this product in the DANGER! Fire hazard!

immediate surroundings of a bath, a shower or a swimming pool.

Use this product on an even, horizontal and stable surface.
Use the product in dry indoor rooms only.

Fire/burn hazard and heat

CAUTION! Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.

WARNING! In

order to avoid overheating, do not

cover the product.

WARNING! Do not use this product in small rooms when they are occupied by persons not capable of leaving the room on their own, unless constant supervision is provided.
DANGER! To reduce the risk of fire, keep textiles, curtains, or any other flammable material a minimum distance of 1 m from the air outlet.

Do not cover the product's air vents. Make sure the product has sufficient ventilation. Do not place the product in a cabinet.

Do not operate the product near flammable materials such as curtains, furniture or other flammable materials.
- Keep the product at least 100cm away from other objects (curtains, walls, etc.).
Regularly remove dust and filth with a soft, dry cloth.
Before use, always check the air inlet and outlet for debris and dust. An unclean air inlet or outlet prevents air from flowing through. This may result in the product overheating.
Remove from the product's heating area all firm, liquid and gaseous materials that might ignite.
Never insert any fingers or foreign objects into the product's openings.
NEVER touch the heating elements with your hands.
If you notice any smoke or unusual noises, immediately disconnect the product from the power supply. Have the product checked by a specialist before continued use.

In the event of a fire, first the plug from the power outlet or disconnect the product from the power supply before taking appropriate fire-fighting measures.

Never leave the product unattended while it is in use.

DANGER! Fire hazard!

This product is not intended to be operated by means of an external timer or separate remote-control system. The product may be switched on, for example even when it is covered.

Do not move the product while it is in operation or cooling down.
Do not use the product anymore if it has been dropped.
Do not operate the product close to or below curtains, wall cupboards or other inflammable materials.
Place the product on a level, stable and heat resistant floor.
Do not place any open fire sources, such as candles, on the product.
Never block the air c3 or the air inlet 6.
Do not use an extension cord.

Electrical safety

WARNING! Risk of electric shock! Use the product only with an RCD-protected socket-outlet.

The product may not remain unattended as long as it is connected to the power supply.
Make sure that the nominal voltage on the rating plate complies with the supply voltage.
The product has increased energy consumption. Do not connect any other devices (e.g. heaters, air conditioners, etc.)

to the same circuit.

Shield the product, power cord and plug from dust, direct sunlight and dripping and splashing water.
- Protect the product from heat. Do not place the product in direct proximity to open flames or heat sources such as heaters, ovens or stoves.
Protect the power cord from damage. Do not allow it to hang over sharp corners; do not crush or bend it. Keep the power cord away from any hot surfaces and open flames. Make sure that no one may accidentally pull on it or trip over it.

Regularly check power plug and power cord for damages.

Do not operate the product if the power cord or power plug are damaged, if the product does not work or is damaged in any way.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Do not operate the product with wet hands or while standing on a wet floor. Do not touch the power plug with wet hands. Do not use the product in very humid environments. 1. Ta 2. Cl

Always turn off the product before disconnecting it from the power supply.

• Do not unplug the product by pulling on the power cord.
• Do not wrap the power cord around the product.

Make sure that the details on the rating label are in conformity with your mains voltage. Only connect the product to alternating current with an earthing contact as otherwise a protection against electric shock is not provided.

In the event of malfunctions, remove the mains plug from the mains socket.

Cleaning and storage

• Disconnect the product from the wall outlet during periods of disuse and before cleaning.

Instructions on cleaning the product: see "Cleaning".

Store the product in a cool, dry place protected from sunlight and out of the reach of children.

- First set-up of the product

- Unpacking the product and basic cleaning

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included.
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".
4. Before first use, clean all parts of the product as described in the chapter "Cleaning".

Setting up the product

1 INFO: The anti-slip feet 4 guarantee a secure stand of the product.

Place the product on an even, horizontal and stable surface.
- Maintain the following clearances around the product:

• 30 cm to the left, right, top, and rear
• 100 cm to the front

Operation

1 INFO: The product may give off some vapours or odours during first use. These are production or transport residue that will quickly subside. There may also be quiet noises such as clicking or crackling. These will also quickly subside once the plastic parts have finally adjusted to the operating conditions.

- Switching the product on

i INFO:

Make sure that the supply voltage of the mains outlet meets the requirements described in the "Technical data" chapter.
If the heating level switch is set to or position, the control light is switched on.
If the heating level switch is set to 0 position, the control light is switched off.

1. Set the temperature controller 8 to and the heating level switch9 to
2. Connect the mains plug 7 to an RCD-protected mains outlet.
3. Switching on: Turn the heating level switch 9 clockwise to select the desired position. The adjustable positions are shown in the table below:

Position Meaning

0 Product turned off

Fan operation no heating power

Low heating level 700 W

High heating level 1200 W

1 INFO: Set the temperature range to position (high) in fan operation mode.

- Setting the temperature

1. Turn the temperature controller 8 clockwise until it stops to regulate the temperature at high or low heating level. The following table shows the adjustable temperature ranges:

Position	Temperature range
	Low
	Low to medium
	Medium to high
	High

1. As soon as the desired temperature has been reached, turn the temperature controller 8 counter-clockwise until you hear a clicking sound.

1 INFO: The integrated thermostat automatically turns the heating function on and off to keep the temperature at a constant level.

Hints:

1. Check whether the product is giving off sufficient heat:
2. Is the product covered or is it too close to a wall or other obstruction?
3. Is the grid blocked in the front or at the back?
4. Is the fan blocked?
5. Rectify the problem if possible, or contact the service hotline (see "Service").

- Switching the product off

1 INFO: If you have used the product at high or low heating power, let the product run in fan mode for about 30 seconds. This will prevent heat build-up in the housing.

1. Set the temperature controller 8 to and the heating level switch to
2. Disconnect the mains plug from the mains outlet.

Overheating protection

DANGER! There is usually a reason for overheating! It can indicate a risk of fire!
① INFO:

The product is equipped with overheating protection. If the product overheats, the heating element turn off automatically. However, the fan continues to run so that rapid cooling is achieved. The product turns on again automatically once it has cooled down properly.

Tip-over protection

The tip-over protection 5 switches the product off automatically as soon as the product tips over.

- Cleaning

DANGER! Risk of electric shock! Before cleaning Always disconnect the mains plug 7 from the mains ou before cleaning the product.
WARNING! Never immerse the product in water or other liquids. Never hold the product under running water.

Wipe down the product with a slightly damp cloth. If necessary, use a little cleaning detergent.
Do not let any water or other liquids enter the product interior.

Do not use any abrasive, aggressive cleaners or hard brushes to clean the product.

Let all parts dry completely after cleaning.
Use a vacuum cleaner to clean the safety guards of the air inlet 6 and the air outlet 3 when they have become dirty.

Transport

WARNING! Do not move the product while it is in operation or cooling down.

Bring the handle 2 in position before carrying the product (Fig. A).
Carry the product by the provided handle 2 only.

Disposal

The packaging is made of environmentally friendly materials, which may be disposed of through your local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product incl. accessories, manual and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your wornout product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

To ensure quick processing of your claim, observe the following instructions:

Make sure to have the original sales receipt and the item number (IAN 487570_2501) available as proof of purchase.

You can find the item number on the rating plate, an engraving on the product, on the front page of the instruction manual (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, contact the service department listed below either by telephone or by e-mail.

Once the product has been recorded as defective you can return it free of charge to the service address that will be provided to you. Ensure to enclose the proof of purchase (sales receipt) and a short, written description outlining the details of the defect and when it occurred.

Service

Service Great Britain

Tel.:[phone]

E-Mail: [e-mail]

Service Ireland

Tel.: [phone]

E-Mail:[e-mail]

Information requirements for electric local space heaters
Contact details	OWIM GmbH & Co. KGStiftsbergstraße 174167 NeckarsulmGERMANY
Model identifier(s): Ceramic fan heater, TKHL 1200 B1, HG10190A/HG10190B
Item	Symbol	Value Unit Item Unit
Heat output Type of heat output/room temperature control
Nominal heat output P	nom	1.2 kW		Single stage heat output and no room temperature control	No
Minimum heat output (indicative) P	min	0.7 kW		Two or more manual stages, no room temperature control	No
Maximum continuous heat output P	max, c	1.2 kW With mech		Electric thermostat room temperature Yes
Power consumption				With electronic thermostat room temperature No
In off mode P	o	0.00 W		Electronic room temperature control plus day timer	No
In standby mode P	sm	N/A W		Electronic room temperature control plus week timer	No
In idle mode P	icle	0.00 W		Other control options
In network standby	Pnom	N/A W		Room temperature control, with presence detection	No
Standby mode with display of information or status No				Room temperature control, with open window detection	No
Seasonal space heating energy efficiency in active mode	ηs,on	85.0	%	Distance control option	No
				Adaptive start control	No
				Working time limitation	No
				Black bulb sensor	No
				Self-learning functionally	No
				Control accuracy	No

KERAMICKY TEPLOVZDUŠNÍ

VENTILATOR

Kort vejledning
