USER MANUAL SUADFK 12 A1 SILVERCREST
Operation and safety notes
FR BE
DIFFUSEUR DE BRUME À ULTRASONS
Road, Dongfeng Villa
ge, Leliu Street, Shunde
District, Foshan City,
Guangdong Province,
China.
Warnings and symbols used 37
Introduction 38
Intended use. Page 38
Scope of delivery. Page 38
Safety instructions. 39
Parts description. 47
Technical data 48
Ceramic Diffuser (HG10428A) 49
Operation. 49
Switching on the product . 49
Timer control. 49
Mist Control. Page 50
LED ON/OFF & color control. Page 50
Sleeping Mode . 52
Switching off the product. 52
Flame Effect Diffuser (HG10428B) 53
Operation. 53
Switching on the product . 53
Timer control. 53
Mist Control. Page 54
LED ON/OFF & brightness control . 54
LED Flickering mode. Page 56
Switching off the product. Page 56
Ceramic Diffuser (HG10428A) &
Flame Effect Diffuser (HG10428B): (Fig. E) Page 57
Replacing the battery. Page 57
Cleaning and care 58
Dscaling. 58
Storage 58
Troubleshooting 59
Disposal. 59
Warranty 60
Warranty claim procedure.. . Page 61
Service. 61
| Warnings and symbols used The following warnings are used in this user manual and on the packaging: | |||
| Use the product in dry indoor spaces only. | Symbol for a Protection Class II product | ||
| Clean the water tank every 3 days. | Polarity | ||
| IP20 | Protection against penetration of solid objects (Ø > 12.5 mm) | t_a | Highest rated ambient temperature |
| NOTE: This symbol in combination with "Note" provides additional useful information. | Short-circuit proof safety transformer | ||
| SMPS (Switch mode power supply unit) (switching power supply) | |||
| CE | CE mark indicates conformity with relevant EU directives applicable for this product. | Safety Information Instructions for use | |
| Do not use the charger if the pins of the plug are damaged. | |||
ULTRASONIC
AROMATHERAPY DIFFUSER
Introduction
We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.
Intended use
The product is designed for air refreshing and humidification in enclosed spaces.
Do not use the product for any other purpose.
The product is only intended for private household use, not for commercial purposes.
The manufacturer accepts no liability for damages caused by improper use.
Scope of delivery
After unpacking the product, check if the delivery is complete and if all parts are in good condition. Remove all packing materials before use.
Ceramic Diffuser (HG10428A):
(Fig. A, B & E)
1 Ultrasonic aroma-therapy diffuser
1 Remote control
1 Power adaptor
1 Measuring cup
1 Instruction manual
Flame Effect Diffuser (HG10428B)
(Fig. C, D & E)
1 Ultrasonic aroma-therapy diffuser
1 Remote control
1 Power adaptor
1 Measuring cup
1 Instruction manual
Safety instructions
BEFORE USING THE PRODUCT, PLEASE FAMILIARISE YOURSELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, PLEASE ALSO INCLUDE ALL THE DOCUMENTS!
In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance
with the safety instructions, no liability is accepted!
DANGER TO LIFE AND RISK OF ACCIDENTS FOR INFANTS AND CHILDREN! Never leave children unsupervised with the packaging materials. The packaging material poses a suffocation hazard.
Children frequently underestimate the dangers.
Always keep children away from the packaging material.
WARNING! DANGER TO LIFE! Batteries, the battery cover, the probe cover or small parts can be swallowed, which may represent a danger to life.
If a battery, battery cover, probe cover or small parts have been swallowed, medical help is required immediately.
This product can be u by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.
Children shall not play with the product.
Cleaning and user maintenance shall not be made by children without supervision.
Avoid electric shock
WARNING! Keep the product dry.
WARNING! If the product falls into the water, immediately disconnect the power adaptor 6/25 from the socket outlet before reaching into the water.
WARNING! Never touch the power adaptor 6/25 with moist or wet hands.
WARNING! Never submerge the product or the supply cord with the power adaptor 6/25 in water or any other liquid and never rinse these under running water.
For additional protection, the installation of a residual current device (RCD) having a rated residual operating current not exceeding 30mA is advisable in the electrical circuit supplying the bathroom. Ask your installer for advice.
Only use the original power adaptor 6/ 25 supplied for mains operation.
Disconnect the power adaptor 6/25 from the socket outlet
-if a malfunction occurs,
-before you clean the product,
-during a thunderstorm
-before filling / emptying the water tank 4/23 and
-after each use.
When doing so, remove the power adaptor 6/ 25 directly from the socket and do not pull it out using the supply cord.
Avoid risk of injury
Place the product only on flat surfaces, so that tipping over is excluded.
Never tilt or empty the product during operation.
Do not empty the product through the mist outlet 1/21.
Do not use the product if you detect any kind of visible, external damage. Never use a damaged product.
If liquid gets into the product, check before using the product once more.
If you notice that the supply cord, power adaptor 6/25, housing or another part has become damaged, the product can no longer be used.
Repairs should only be carried out by a specialist. Improper repairs may result in considerable danger to the user.
The light source contained in this product shall only be replaced by the manufacturer or his service agent or a similar qualified person.
Do not use defective attachments with the
product as these could have sharp edges.
Defective components must always be replaced with original spare parts.
The appliance is only to be used with the recommended vapourizing medium. The use of other substances may give rise to a toxic or fire risk.
Connect the supply cord to the product before connecting the power adaptor 6/25 to the socket outlet.
Lay the supply cord so nobody will step on or trip over it.
WARNING! KEEP OUT OF REACH OF CHILDREN!
Swallowing can lead to chemical burns,
perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion. Seek medical attention immediately.
DANGER TO LIFE!
Keep batteries/ rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention. Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION!
Never recharge nonrechargeable batteries. Do not short-circuit batteries/rechargeable batteries and/or open
them. Overheating, fire or bursting can be the result.
Never throw batteries/ rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/ rechargeable batteries.
Do not short-circuit the terminals.
Risk of leakage of batteries/rechargeable batteries.
Avoid extreme environmental conditions and temperatures, which could affect batteries/ rechargeable batteries, e.g. radiators/direct sunlight.
If batteries / rechargeable batteries have leaked, avoid contact with skin, eyes and mucous
membranes with
the chemicals! Flush
immediately the affected
areas with fresh water and
seek medical attention!
Wear Protective GLOVES! Leaked or damaged batteries/ rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable batteries, immediately remove them from the product to prevent damage.
Remove batteries/ rechargeable batteries if the product will not be used for a longer period.
Risk of damage of the product.
Only use the specified type of battery/ rechargeable battery!
Insert batteries/rechargeable batteries according to polarity marks (+) and (-) on the battery/rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery/rechargeable battery and in the battery compartment [41] before inserting!
Remove exhausted batteries/rechargeable batteries from the product immediately.
Avoid damage to property
Protect the product from moisture, drops of water and splashing water.
Ensure that the supply cord does not get stuck in cupboard doors and that it is not pulled over hot surfaces. This could damage the supply cord's insulation.
Do not place the product on hot surfaces, near hot surfaces or near an open fire.
To prevent impermissible heating, do not cover the power adaptor 6/25 and the product during use.
Do not use any corrosive or abrasive cleaning agents.
Only fluids shall be used meeting the national health requirements.
No action is needed from users to shift the product between 50 and 60Hz The product adapts itself for both 50 and 60Hz
Be aware that high humidity levels may encourage the growth of biological organisms in the environment.
- Do not permit the area around the product to become damp or wet.
If dampness occurs, use the product intermittently.
Do not allow absorbent materials, such as carpeting, curtains, drapes, or tablecloths, to become damp.
Unplug the product before filling and cleaning.
Never leave water in the water tank 4/23 when the product is not in use.
Empty and clean the product before storage. Clean the product before next use. Clean the water tank 4/23 every 3 days.
The water 423 is treated with 100% silver phosphate glass as an antibacterial agent to inhibit the growth of bacteria.
WARNING! Micro-organisms that may be present in the water or in the environment where the product is used or stored, can grow in the water tank 4/23 and be
blown in the air causing very serious health risks when the water is not renewed and the water tank 4 / 23 is not cleaned properly every 3 days.
Empty the water tank 4/23 and refill every 3 days.
Beforerefilling: Clean the water tank 4/23 with fresh tap water or cleaning agents.
Remove any scale, deposits, or film that has formed on the sides of the water tank 4/23 or on interior surfaces. Wipe all surfaces dry.
Parts description
Ceramic Diffuser (HG10428A):
(Fig. A & B)
1 Mist outlet
2 Upper cover
3 Splash proof cover
4 Water tank with LED
5Base
6 Power adaptor
7 Measuring cup
8 Remote control
9Power button
10 LED ON/OFF button
11 Mist button
12 Timer button
13 LED color button
14 Sleep mode button
15 Timer indicator light
16 Power button
17 LED ON/ OFF & color button
18 Timer button
19 Maximum water level
20 Ultrasonic disc
Flame Effect Diffuser (HG10428B):
(Fig. C & D)
21 Mist outlet
22 Upper cover
23 Water tank with LED
24 Base
25 Power adaptor
26 Measuring cup
27 Remote control
28Power button
29 LED ON/ OFF button
30 Mist button
31 Timer button
32 LED brightness button
33 Flickering flame effect button
34 Timer indicator light
35Power button
36 LED ON/ OFF & brightness button
37 Timer button
38 Maximum water level
39 Ultrasonic disc
Ceramic Diffuser (HG10428A) & Flame
Effect Diffuser (HG10428B):
(Fig. E)
8/27 Remote control
40 Battery
41 Battery compartment
Technical data
Ceramic Diffuser (HG10428A) & Flame
Effect Diffuser (HG10428B):
Power adaptor 6/25
Manufacturer's Manufacturer's name:
name or Guangdong
trade mark, Huachuangxing Power
commercial Supply Co., Ltd
registration
number and
address
Manufacturer's
commercial
registration number:
91440606MA53CYD26J
Manufacturer's address:
No.27 Fudong Road,
Dongfeng Village, Leliu
Street, Shunde District,
Foshan City, Guangdong
Province, China.
Model identifier: HCX1201-2400500E
Input voltage: 100 - 240V
Input AC
frequency: 50 - 60Hz
Output voltage: 24.0 V
Output current: 0.5 A
Output power: 12.0 W
Average active
efficiency: 86.0%
Efficiency at low
load (10%): 78.8%
No-load power
consumption: 0.07 W
Protection class: II/
Input current: 0.5 A
Protection
degree: IP20
ULTRASONIC AROMATHERAPY DIFFUSER
Rated voltage: 24 V
Rated current: 0.5 A
Battery
(Remote Control): 3V, CR2025,
Lithium
- Ceramic Diffuser (HG10428A)
Operation
Insert the cable plug of the power adaptor 6 into the plug socket of the base 5 of the diffuser.
Place the product on a level and stable surface.
Remove the upper co2 and the splash proof cover 3 from the water tank with LED 4.
Fill the water tank with L4 by using the measuring cup 7 with clean tap water at room temperature.
值 NOTES:
Do not fill in water above the maximum water level [19] in the water tank with LED [4].
- Do not fill in water at temperature higher than 60^ to avoid damage to the product.
Re-attach the upper cov 2 and the splash proof cover 3 to the water tank with LED 4.
Connect the power adap 6 to a socket outlet.
- Switching on the product
Switching on can be operated by the base 5 of the diffuser and the remote control 8.
Switching on: Press the power butt or 16 once. The product will generate mist until all water is used up.
When the water in the water tank with LED 4 is almost used up, the water tank with LED 4 flashes 3 times in red. Then, the product is switched off.
Timer control
Timer can be operated by the base 5 of the diffuser and the remote control 8.
Timer control works only when the water is present in the water tank with LED 4. The product will generate mist until all the water is used up.
Press timer butt12 or 18 repeatedly:
Press timer button
Timer indicator light 15 Operation time
12 or 18
OX All OFF (default) Unlimited
| 1X | 1H ON | 1 hour |
| 2X | 2H ON | 2 hours |
| 3X | 3H ON | 3 hours |
4X All OFF Unlimited
Mist Control
- Mist control can be operated by the remote control [8] only, not the base [5] of the diffuser.
Mist control works only when the water is present in the water tank with LED 4. The product will generate mist until all the water is used up.
Press mist butt11 repeatedly, mist level will change gently:
Press mist button 11
Mist level
0x High (default)
1x Medium
2x Low
3x High
LED ON/OFF & color control
LED ON/OFF & color control can be operated by both the remote control 8 and the base 5 of the diffuser.
LED ON/OFF & brightness control works only when the water is present in the water tank with LED 4.
Press LED ON/OFF & color butt17 from the base 5 of the diffuser:
Press LED ON/ OFF & color button
Water tank with LED 4
0x
Color changes automatically from white, red, yellow, green, light blue, dark blue, violet and repeat (default)
1x Static color combination
Hold for 2 seconds OFF
Note: After turn off LED color, press once LED ON/OFF & color button [17], the LED color will change automatically again and repeat (default)
Press LED ON/OFF butt10 or LED color button 13 repeatedly on the remote control8:
Press LED ON/OFF button 10 & LED color button 13
0xLED color button
Water tank with LED 4
Color changes automatically from white, red, yellow, green, light blue, dark blue, violet and repeat (default)
1 x LED color button 13Static color combination
1xLEDON/OFFbutton 10
OFF
Note: After turn off LED color, press once LED ON/OFF button [10], the LED color will changes automatically again and repeat (default)
Sleeping Mode
Sleeping mode can be operated by the remote control 8 only, not the base 5 of the diffuser.
- Sleeping mode works only when the water is present in the water tank with LED 4. The product will generate mist until all the water is used up.
Press the sleep mode button 14 to operate Sleeping mode
1x Sleeping mode ON: The LED is switched
OFF high mist mode runs for approx.
30 minutes. low mist mode runs approx.
30 minutes. the product is switched
OFF.
2x Sleeping mode OFF
- Switching off the product
Switching off can be operated by the base 5 of the diffuser and the remote control 8.
Switching off: Press the power butt or 16 one more time after switching on.
Disconnect the power adap6 from the socket outlet.
- Disconnect the cable of the power adaptor 6 from the plug socket of the base 5 of the diffuser.
Remove the upper co 2 and the splash proof cover 3 from the water tank with LED 4.
Remove water from the water tank with LED 4.
ATTENTION! To avoid damage, do not discard the water through the mist outlet 1.
Flame Effect Diffuser (HG10428B)
Operation
Insert the cable plug of the power adaptor [25] into the plug socket of the base [24] of the diffuser.
Place the product on a level and stable surface.
Remove the upper co22 from the water tank with LED 23.
Fill the water tank with L23 by using the measuring cup 26 with clean the tap water at room temperature.
值 NOTES:
- Do not fill in the water above the maximum water level [38] of the water tank with LED [23].
- Do not fill in water at temperature higher than 60^ C to avoid damage to the product
Re-attach the upper cov22 to the water tank with LED 23.
Connect the power adap25 to a socket outlet.
- Switching on the product
Switching on can be operated by the base 24 of the diffuser and the remote control 27.
Switching on: Press the power butt28 or 35 once. The product will generate mist until all the water is used up.
When the water in the water tank with LED23 is almost used up, the water tank with LED23 flashes 3 times. Then, the product is switched off.
Timer control
Timer control can be operated by the base 24 of the diffuser and the remote control 27.
Timer control works only when the water is present in the water tank with LED [23]. The product will generate mist until all the water is used up.
Press timer butt31 or 37 repeatedly:
Press timer button ① Timer indicator light 34 Operation time 31 or 37
OX All off (default) Unlimited
| 1X | 1H ON | 1 hour |
| 2X | 2H ON | 2 hours |
| 3X | 3H ON | 3 hours |
4X All OFF Unlimited
Mist Control
- Mist control can be operated by the remote control 27 only, not the base 24 of the diffuser.
- Mist control works only when the water is present in the water tank with LED [23]. The product will generate mist until all the water is used up.
Press mist butt30 repeatedly, mist level will change gently:
Press mist button 30
Mist level
OX High (default)
LED ON/OFF & brightness control
LED ON/OFF & brightness control can be operated by both the remote control [27] and the base [24] of the diffuser.
LED ON/OFF & brightness control works only when the water is present in the water tank with LED 23.
Press LED ON/ OFF & brightness button 36 repeatedly on the base 24 of the diffuser.
Press LED ON/OFF & brightness button 36LED ON/OFF and Brightness mode
| 0x High (default) |
| 1x Medium |
| 2x Low |
| 3x High |
| Hold for 2 seconds OFF Note: After turn off LED light, press once LED ON/ OFF & brightness button 36, the LED brightness will change to high (default) |
| Press LED ON/ OFF butt29 or LED brightness button 32 repeatedly on the remote control 27: |
| Press LED ON/ OFF button 29 & LED brightness button 32LED ON/ OFF and Brightness mode |
| 0x ON and High Brightness (default) |
| 1x LED brightness button 32Medium brightness |
| 2x LED brightness button 32Low brightness |
| 3x LED brightness button 32High brightness |
Press LED ON/ OFF button 29 & LED brightness button 32LED ON/ OFF and Brightness mode
1xLEDON/OFFbutton 29
OFF
Note: After turn off LED light, press once LED ON/OFF button [29], the LED brightness will changes to high (default)
LED Flickering mode
LED Flicking mode can be operated by the remote control 27 only, not the base 24 of the diffuser.
LED Flicking mode works only when the water is present in the water tank with LED 23.
Press flickering fame effect butt33 repeatedly:
Press flickering flame effect button 33 to operate LED Flickering mode
1xLEDFastflickeringmodeison
2x LED Slow flickering mode is on
3x OFF the LED flickering mode
Switching off the product
Switching off can be operated by the base [24] of the diffuser and the remote control [27].
Switching off: Press the power butt28 or 35 one more time after switching on.
Disconnect the power adap25 from the socket outlet.
- Disconnect the cable of the power adaptor [25] from the plug socket of the base [24] of the diffuser.
Remove the upper co22 from the water tank with LED 23.
Remove the water from the water tank with LED[23].
ATTENTION! To avoid damage, do not discard the water through the mist outlet [21].
- Ceramic Diffuser (HG10428A) & Flame Effect Diffuser (HG10428B): (Fig. E)
Replacing the battery
Replace the battery 40 of the remote control 8/27 as soon as the signal reception weakens.
Slightly press side lock of the battery compartment 41 to pull the battery compartment 41 out of the remote control 8/27 (Fig. E).
Remove the old batte40
Insert a new batte40 (type CR2025) with correct polarity.
Push the battery compartme41 shut.
Cleaning and care
DANGER! Risk of electric
shock! Disconnect the power adaptor 6/25 from the socket outlet before cleaning the product. Never touch the power adaptor 6/25 with moist or wet hands. Always keep the power adaptor 6/25 and supply cord dry.
WARNING! Never immerse the
product in water or other liquids. Never hold the product under running water.
- Do not use any corrosive or abrasive cleaning agents.
Clean the product with a damp cloth. If any stubborn stains remain, place a few drops of mild detergent on the damp cloth and clean it again.
Clean the ultrasonic d20 or 39 regularly by using a slightly moistened cotton bud.
Dscaling
Descale the product if visible deposits occur or if the steam output is restricted.
Use a standard commercial liquid.
descaling agent.
Fill the water tank with LED 4/23 to the maximum water level 19/38 with descaler.
Wait according to the instructions of the descaler.
Pour the dirt away. Clean the water tank with LED 4/23 with a soft and slightly damp cloth.
Ceramic Diffuser (HG10428A):
Rinse the upper cov2, splash proof cover 3 and water tank with LED 4 with running water. Dry them before putting them on the diffuser.
Flame Effect Diffuser (HG10428B)
Rinse the upper cov22 and water tank with LED 23 with running water. Dry them before putting them on the diffuser.
Note: Empty and clean the product before storage.
Clean the product before next use. Clean the water tank 4/23 every 3 days.
Storage
Store the product in the original packaging when it is not in use.
Store the product at a dry location out of the reach of children.
Troubleshooting
= Fault
= Possible cause
= Action
The product does not work.
= Water has been used up.
= Disconnect the product from the socket outlet. Re-fill water in the water tank with LED 4/23.
The mist cannot be released properly.
The upper cover 2/22 or the splash proof cover 3 is not assembled properly.
= Re-attach the upper cover 2/22 or the splash proof cover 3 to the water tank with LED 4/23.
= No mist cannot be released.
= Too much water inside the the water tank with LED 4/23.
= Do not fill in the water above the maximum water level [19]/[38] of the water tank with LED [4]/[23].
Disposal
The packaging is made of environmentally friendly materials, which may be disposed of through your local recycling facilities.
Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.
Product:
The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.
Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal authority for more details of how to dispose of your wornout product.
To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.
Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.
Environmental damage through incorrect disposal of the batteries / rechargeable batteries!
Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.
Warranty
The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.
The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.
Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.
Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our discretion - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.
This warranty becomes void if the product has been damaged, or used or maintained improperly.
The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, recharge-able batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.
Warranty claim procedure
To ensure quick processing of your claim, observe the following instructions:
Make sure to have the original sales receipt and the item number (IAN 440798_2301) available as proof of purchase.
You can find the item number on the rating plate, an engraving on the product, on the front page of the user manual (bottom left), or as a sticker on the rear or bottom of the product.
If functional or other defects occur, contact the service department listed below either by telephone or by e-mail.
Once the product has been recorded as defective you can return it free of charge to the service address that will be provided to you. Ensure to enclose the proof of purchase (sales receipt) and a short, written description outlining the details of the defect and when it occurred.
Service
GB Service Great Britain
Tel.:08000569216
E-Mail: owim@lidl.co.uk
IE Service Ireland
Tel.:1800200736
E-Mail: owim@lidl.ie
Dongfeng Village, Leliu
Street, Shunde District,
Foshan City, Guangdong
Province, China.
Identificant du
modele:HCX1201-2400500E
Tension
WAARSCHUWING! LEVENSGEVAAR!
De batterijen, het
Adres van fabrikant: No.27 Fudong Road, Dongfeng Village, Leliu Street, Shunde District, Foshan City, Guangdong Province, China.
Modelaandui-ding:HCX1201-2400500E
lngangsspan- ning:100-240V\~
AC-ingangsfrequency:50-60Hz
1xLED AAN/UIT-knop 29
UIT
NOS REKAWICE OCHRONNE!
Dongfeng Village, Leliu
Street, Shunde District,
Foshan City, Guangdong
Province, China.
Identityfikator
modelu: HCX1201-2400500E
Napięcie
3x WYlacZONY tryb migotania diod LED
Wyłuczanie produktu
Fudong Road, Dongfeng
Village, Leliu Street,
Shunde District, Foshan
City, Guangdong
Province, China.
Identifikace
modelu: HCX1201-2400500E
Vstupni napeti: 100-240 V~
Vstupní
frekvence
stridavého
proudu: 50-60 Hz
Vystupni napeti: 24,0 V ---
Vystupni proud: 0,5 A
Vystupni vykon: 12,0 W
Prüměrná aktivné
ucinnost: 86,0%
Učinnost pri
nizkém zatízení
(10%):78,8%
Spotreba
energie bez
zatiženi: 0,07 W
Trida ochrany: II/
Vstupni proud: 0,5 A
Stupeč ochrany: IP20
ULTRAZVUKOVY AROMA DIFUZER
Fudong Road, Dongfeng
Village, Leliu Street,
Shunde District, Foshan
City, Guangdong
Province, Cina.
Identifikator
modelu: HCX1201-2400500E
-性和 speed of the car.
Dirección del fabricante: No. 27 Fudong Road, Dongfeng Village, Leliu Street, Shunde District, Foshan City, Guangdong Province, China.
Identificador de
modelo: HCX1201-2400500E
Tensión de
entrada: 100-240 V~
Frecuencia de
entrada de CA: 50-60 Hz
Tensión de
salida: 24,0 V
Corriente de
salida: 0,5 A
Potencia de
salida: 12,0 W
Eficiencia activa
media: 86,0%
Eficiencia a baja
cargo (10%): 78,8%
Consumo de
energia en
vacio: 0,07 W
Clase de
protección: II/
Corriente de
entrada: 0,5 A
Grado de
protección: IP20
DIFUSOR ULTRASONICO CON AROMATERAPIA
Las pilas / baterías no deben eliminarse bajo con los residuos domesticos. EstasSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEO SEOEQ SEOEO SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEOEQ SEO EQ
Garantía
Dongfeng Village, Leliu
Street, Shunde District,
Foshan City, Guangdong
Province, Kina.
Model-
identification: HCX1201-2400500E
Indgangsspaen
ding: 100-240 V~
Vekselstrøm
sfrekvens pa
indgang: 50 - 60Hz
Udgangsspaen
ding: 24,0 V
Udgangsstrøm: 0,5 A
Dongfeng Village, Leliu
Street, Shunde District,
Foshan City, Guangdong
Province, Cina.
Identificativo del
modello: HCX1201-2400500E
Tensione in
ingresso: 100 - 240V
Frequenza CA
in ingresso: 50 - 60Hz
Tensione in
uscita: 24,0 V
Corrente in
uscita:0,5A
Potenza in
uscita: 12,0 W
Rendimento
medio in modulo
attivo: 86,0%
Efficienza a
basso carico
(10%): 78,8%
Consumo
Fudong Road, Dongfeng
Village, Leliu Street,
Shunde District, Foshan
City, Guangdong
Province, Kina.
Modell
| 1X | 1H ON | 1 Óra |
| 2X | 2H ON | 2 Óra |
| 3X | 3H ON | 3 Óra |
| 1X | 1H ON | 1 Óra |
| 2X | 2H ON | 2 Óra |
| 3X | 3H ON | 3 Óra |
