USER MANUAL CBBT 3.7 A1 Cien BEAUTY

Operation and safety notes Translation of the original instructions

NL BE

HAAR- EN BAARDTRIMMER

Website: www.optimex-shop.com

Intended use Page 26

Parts description...... Page 27

Technical data Page 27

Scope of delivery...... Page 27

Safety notes Page 28

Safety instructions for batteries/rechargeable batteries...... Page 33

Charging the product......Page 35

Before first use......Page 35

Oiling the blades....Page 36

Operation......Page 36

Switch On and Switch Off Page 36

Removing / reattaching the hair trimmer attachment...... Page 36

Changing the comb attachment ...... Page 37

Cutting hair Page 37

Cleaning with the cleaning brush....Page 38

Ordering replacement parts ...... Page 38

Cleaning and care......Page 38

Storage Page 38

Troubleshooting......Page 39

Disposal Page 39

Warranty Page 40

Warranty claim procedure ...... Page 41

Service......Page 41

EU declaration of conformity....Page 42

List of pictograms used
	Read the instruction manual		Safety information Instructions for use
	Observe the warnings and safety information!		Protection class III
	Volt For indoor use only
	USB type C connector		CE mark indicates conformity with relevant EU directives applicable for this product.
	Direct current/voltage

Hair & Beard Trimmer

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intendeduse

This product is only intended for cutting human hair. Only use the product on dry hair. This product is only intended for private household use and must not be used for commercial purposes. The product may only be used indoors. All other uses are considered improper and can lead to property damages or personal injuries. The manufacturer accepts no liability for damages caused by improper use.

WARNING! DANGER OF DAMAGE TO PROPERTY!

Do not use the product on artificial hair or animal hair.
- Verify the product is complete and undamaged immediately after unpacking.
■ Only use OEM parts.

• Do not place the product on hot surfaces, near hot surfaces or near an open fire.
  To prevent impermissible heating during use and charging, do not cover the USB cable 10, the power supply (not included in delivery) and the product.
• Do not use any corrosive or abrasive cleaning agents.

WARNING! To charge the rechargeable battery, use only a Class II power supply (not included in delivery) approved for use with household appliances.

SELV output: DC 5 V, max. 1 A.

Partsdescription

1 Long hair comb attachment (10.5-20 mm)
2 Short hair comb attachment (0.5-10 mm)
3 Rotaryknob
4 Hair trimmer attachment
5 Hair and beard trimmer unit
6 ON/OFF slide switch
6a Safety button
7 LED indicator
8 USB Type C socket
9 USB Type A connector
10 USB cable (Type A to C)
11 USB Type C connector
12 Storage bag
13 Blade oil
14 Cleaning brush

●Technicaldata

Hair & Beard Trimmer: HG12970

Input: 5 V

Battery: 1 x 3.7 V Li-Ion, 600 mAh

Emissions sound pressure level: <70 dB(A), K=3 dB(A)

Protection class:

Scope of delivery

1 Hair & Beard Trimmer
1 Hair trimmer attachment
1 Long hair comb attachment (10.5-20 mm)
1 Short hair comb attachment (0.5-10 mm)

1 USB cable
1 Blade oil
1 Cleaning brush
1 Storage bag
1 Set of instructions

Safety notes

WARNING! DANGER TO LIFE AND RISK OF ACCIDENTS

FOR INFANTS AND CHILDREN! Never leave children unattended with the packaging material or the product. There is a danger of suffocation.

This product may be used by children aged 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or those lacking experience and/or knowledge, as long as they are supervised or instructed in the safe use of the product and they understand the associated risks. Do not allow children to play with the product. Never allow children to clean or maintain this product unsupervised.

! Defact the no-d-held
part from the USB cable 10 before cleaning it.
- Clean the product (see "Cleaning and care").

Avoid the risk of fatal injury from electric shock

WARNING! Keep the product dry.
WARNING! Do not use this product near bathtubs, showers, basins or other vessels containing water.

WARNING! If the product falls into the water, immediately remove the USB cable from the power supply (not included in delivery), before you reach into the water.

WARNING! Never touch the USB cable 10 with moist or wet hands, especially when you plug it into the socket or pull it out of the socket.

WARNING! Never submerge the product or the USB cable 10 in water or any other liquid and never rinse this/these under running water.

WARNING!

Do not use the product

while bathing.

For additional protection, the installation of a residual current device (RCD) having a rated residual operating current not exceeding 30 mA is advisable in the electrical circuit supplying the bathroom. Ask your installer for advice.

■ Remove the USB cable 10 from the power supply (not included in delivery)

• if a malfunction occurs,
• before you clean the product,
• if you have not used the product for a long time,

- during a thunderstorm and

- after each use.

When doing so, remove the USB Type A connector 9 directly from the socket and do not pull it out using the USB cable 10.

Avoid risk of injury

• Do not change the accessories while the product is switched on.
• Do not use the product, if you detect any kind of visible, external damage. Never use a damaged product.
  If liquid gets into the product, check before using the product once more.
  If you notice that the USB cable 10, housing or another part has become damaged, the product can no longer be used.
• Repairs should only be carried out by a specialist. Improper repairs may result in considerable danger to the user. This will also make any warranty claims void.

• Do not use defective attachments with the product as these could have sharp corners.
  ■ Defective components must always be replaced with original spare parts. Only by using original spare parts can you ensure that safety requirements are met.
  For loading, connect the USB cable 10 to a power source which is well within reach.

• Never use the product unsupervised and only use it in accordance with the information stated on the type plate.
  ■ Connect the USB cable 10 to the product before inserting it into the power source.
  ■ The tips of the attachments are sharp.
  ■ Switch off the product before attaching or switching the attachments, as well as before cleaning.
  ■ La y the USB cable 10 so nobody will step on or trip over it.

• Do not use the product, if you have an open wound, cut, sunburn or blister.

Avoid the danger of damage to property

Electrical products may pose a hazard to animals. Animals can also damage the product. Always keep animals away from electrical products.
■ Protect the product from moisture, drops of water and splashing water.
■ Ensure that the USB cable 10 does not get stuck in cupboard doors and that it is not

pulled over hot surfaces. This could damage the USB cable's 10 insulation.

• Keep the blade oil 13 out of reach of children. Do not ingest the blade oil 13, do not get it into your eyes. Keep it in a safe place if it is not being used.
  ■ ATTENTION! Risk of product damage! Do not expose the product to direct sunshine or heat. The ideal ambient temperature is between +5 °C and +40 °C. Extreme low high temperature may damage the battery or the product.

Safety instructions for batteries/rechargeable batteries

■ for the purpose of recharging the batteries, only use a protection class II power supply (not provided) approved for use with household products. SELV output: DC 5 V, max. 1 A.

■ DANGER TO LIFE! Keep batteries/re-chargeable batteries out of reach of children.

If accidentally swallowed, seek immediate medical attention.

DANGER OF EXPLOSION!

Never recharge non-rechargeable batteries. Do not short-circuit batteries/re-chargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.
- Do not exert mechanical loads to batteries/rechargeable batteries.

Risk of leakage of batteries/rechargeable batteries

• Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.
  If batteries/rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES!

Leaked or damaged batteries/

rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

This product has a built-in rechargeable battery which cannot be replaced by the user. This product contains a battery which is non-replaceable. When disposing of the product, it should be noted that this product contains a rechargeable battery.

● Charging the product

Note: Charge the product for 90 minutes before using it for the first time and for subsequent charging processes.

Note: Connect the USB Type C connector 11 to the USB type C socket 8 on the product. Connect the USB Type A connector 9 of the USB cable 10 to a suitable USB Type A socket of a protection class II power supply (not provided), that is approved for use with household products and has a SELV output of DC 5 V, max. 1 A. Connect the power supply (not provided) to the mains socket.

Note: The LED indicator 7 will turn red, when the battery is nearly drained.

Note: In order to lengthen the service life of the rechargeable battery, it is recommended that the product is used regularly and without long storage periods.

Note: After a quick charge for 5 minutes the product can be used for approx. 5 minutes.

Note: When the battery is fully charged, the LED indicator 7 flashes white. When the battery is fully charged, the product can be used for approx. 60 minutes.

Before first use

WARNING! DANGER OF ELECTRIC SHOCK! The hair and beard trimmer unit 5 is not waterproof and therefore must not be used in the bathtub/shower.

Please do not use the product, if you have an open wound, cut, sunburn or blister.

The product is only intended for use on dry hair and in dry, indoor spaces.

☐ The product can be used cordless only.

- Oiling the blades

It is recommended, that you oil the blades before first use and after cleaning to guarantee complete functionality (see Fig. A).

□ Always switch off the product before oiling the blade.
□ Apply one or two drops of blade oil 13 between the blades and distribute them evenly.
☐ Wipe off any excess oil with a cloth.
☐ You can also use any acid-free oil (such as sewing machine oil).

Operation

- Switch On and Switch Off

Switching on the product:

☐ Press the safety button 6a. Simultaneously, slide up the slide switch 6.

Switching off the product:

☐ Slide down the slide switch 6

Note: For all applications, hold the hair and beard trimmer unit 5 with an angle of 45^ to your skin (see Fig. B).

Removing/reattaching the hair trimmer attachment 4

WARNING! RISK OF INJURY! Switch off the hair and beard trimmer unit 5, before you attach or remove the attachments.

To remove the hair trimmer attachment 4 (see Fig. C) use your thumbs to push it outward from the hair and beard trimmer unit 5

To attach the hair trimmer attachment 4, put the lower flap of the attachment into the slot in the hair and beard trimmer unit 5. Press the upper part of the hair trimmer attachment 4 against the hair trimmer unit 5, until it audibly locks into place and sits firmly in position (see Fig. D).

Changing the comb attachments 1, 2

WARNING! RISK OF INJURY! Switch off the hair and beard trimmer unit 5, before you attach or remove the attachments.

☐ To attach the comb attachments 1, 2, carefully slide the appropriate comb attachment over the hair trimmer attachment 4. Press the lower part of the comb attachments 1, 2 firmly, until they lock into place (see Fig. E).

To remove the comb attachments 1, 2, loosen the comb attachment at its lower end and pull it off the hair and beard trimmer unit 5 (see Fig. F).

Cutting hair (Hair trimmer attachment 4)

Note: The hair to be dressed must be dry. The cutting length may deviate depending on the cutting angle.

Place a sheet or cape (not provided) around throat and neck to prevent cut-off hair from dropping into the collar.

With both comb attachments 1, 2, start with a longer cutting length and then, in the course of the cutting process, use shorter cutting lengths step by step. To adjust the cutting length of the comb attachments 1, 2 set the respective rotary knob 3 to the desired length marking (10.5-20 mm on the long hair comb attachment 1 and 0.5-10 mm on the short hair comb attachment 2) (see Fig. G).

☐ Start by cutting the hair in the neck or on the sides and cut towards the center of the head. Then, cut the front section of the hair towards the center of the head.

☐ Hold the hair and beard trimmer unit 5 in such a way, that the respective comb attachment 1, 2 lies as flat as possible on the head. Move the hair and beard trimmer unit 5 evenly through the hair.

□ Hold the hair and beard trimmer unit 5 with the respective comb attachment 1, 2 gently in such a way, that the flat area above the rotary knob 3 lies on the head (see Fig. H).

□ Cut against the direction of hair growth.

In order to catch all the hair, move the hair and beard trimmer unit 5 several times through each section of the hair.

Comb the hair repeatedly and well.

In order to achieve a straight cutting line for cutting lengths, the hair and beard trimmer unit 5 should be passed through the hair several times from different directions.

- Cleaning with the cleaning brush 14

☐ Switch the product off using the ON/OFF slide switch ☐ 6. If the hair trimmer attachment ☐ 4 or one of the comb attachments ☐ 1, ☐ 2 is attached on the product, remove it before cleaning as described in the chapter "Operation". Remove the attachment by pressing the attachment with your thumbs from the front (see Fig. C, F).

☐ Remove the hair remnants from the attachment using the cleaning brush 14.

- Ordering replacement parts

Replacements for the following parts can be ordered online:

Long hair comb attachment (10.5-20 mm) 1

Short hair comb attachment (0.5–10 mm) 2

Hair trimmer attachment 4

Item number: 480299_2410

Website: www.optimex-shop.com

- Cleaning and care

■ Never immerse the product, the USB cable 10 and the power supply (not included in delivery) in water or other liquids or rinse under running water.

■ Always switch off the product before cleaning it.

■Thecombattachments 1, 2 and the hair trimmer attachment 4 can be cleaned with water. Do not use any other liquids.

Note: Let them dry before using again.

- Do not use aggressive or abrasive cleaning agents.

☐ Wipe down the product with a slightly damp cloth.

If you are not using the product for extended periods, store it in the storage bag ^12

Storage

CAUTION! DANGER OF DAMAGE TO PROPERTY! Never store the product in the storage bag 12 whilst the product is charging. Risk of overheating!

Store the clean and dry product and its accessories in the storage bag 12 provided.

Note: Do not put the product to direct sunshine or heat. The ideal ambient temperature is between -10 °C and +60 °C. Extreme low or high temperature may damage the battery or the product.

Store everything in a clean, dust-free and dry place.

Note: We recommend to charge the product every 6 months.

- Troubleshooting

Error Cause Solution
The product does not work.	The battery may not be charged.	Recharge the product.
Trimming is difficult. Hair may be stuck inside the blades.		Clean the hair trimmer attachment 4 and the product and oil it if necessary.
The rechargeable battery cannot be charged or the battery performance is very poor.	The rechargeable battery has reached the end of its service life.	The product with the built-in rechargeable battery must be properly disposed of.
The product cannot be recharged.	The ambient temperature in the charging location is too high.	Move the product away from direct sunshine or heat.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

The product incl. accessories, manual and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

This product has a built-in rechargeable battery that cannot be replaced or removed by the user. When disposing of the product, it must be noted that this product contains a rechargeable battery.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.

The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

For this product, the rechargeable battery is also covered by its warranty period.

- Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 480299_2410) available as proof of purchase.

You will find the item number on the rating plate, an engraving on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product. If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail: [e-mail]

● EU declaration of conformity

EU DECLARATION OF CONFORMITY (No 480299\_2410)

IAN: 480299_2410

Product identification: "Cien BEAUTY" Hair & Beard Trimmer

Model Number: HG12970

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N" / Parts

Directive 2006/42/EC

EN 60335-2-8:2015+A1:2016+A2:2022+

A11:2022+A12:2022

EN 60335-1:2012+A11:2014+A13:2017+

A1:2019+A14:2019+A2:2019+A15:2021+

A16:2023

EN 62233:2008

EN ISO 12100:2010

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019+A1:2021

EN 61000-3-3:2013+A1:2019+A2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm

Place

27.01.2025

Date

ppa. Brussel ppa. Stefan Haensel

Authorised Signatory

ppa.Budnei

Ipa. Jens Buchheim

Authorised Signatory

Site internet : www.optimex-shop.com

Website: www.optimex-shop.com

NOSTE OCHRANNÉ RUKAVICE

Página web: www.optimex-shop.com

ADVARSEL! ADVARSEL!

Honlap: www.optimex-shop.com

Tisztítás és ápolás
