USER MANUAL PASS 4 A1 PARKSIDE

Operation and safety notes Translation of the original instructions

FR BE

4 V TOURNEVIS ÉLECTRIQUE SANS FIL

GB/IE Operation and safety notes Page 42

Intended use. Page 46

Scope of delivery ...... Page 47

Parts list ...... Page 47

Technical data. Page 47

General safety instructions ...... Page 51

General power tool safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 52

Safety guidelines for screwdrivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 58

Vibration and noise reduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 59

Behaviour in emergency situations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery charger safety warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Residual risks ...... Page 61

Before use.... Page 61

Charging the battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 63

Operation...... Page 64
Switching the product on/off....Page 64
Changing rotary direction.... Page 65
Changing screw bits/the magnetic bit holder..... Page 65
Tightening and loosening the screw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Manual operation.... Page 66
Setting the torque.... Page 67
Cleaning and maintenance ...... Page 68
Before cleaning and maintenance ..... Page 68
Cleaning Page 68
Maintenance Page 69
Transportation. Page 69
Storage.... Page 69
Disposal Page 69
Warranty.... Page 71
Warranty claim procedure. Page 72
Service Page 73
EU declaration of conformity .... Page 74

List of pictograms used
	DANGER! – Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)
	WARNING! – Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)
	CAUTION! – Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)
	NOTICE! – Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)
Li-lon	Lithium-lon battery
	No-load speed
min-1	Revolutions per minute
	Danger – risk of electric shock!
	Alternating current/voltage
	Direct current/voltage
	Symbol for a Protection Class II product
	Use the product in dry indoor spaces only.
	This symbol means that the user manual must be observed when using the product.
	Protect the rechargeable battery from heat and continuous intense sunlight.
	Protect the rechargeable battery from fire.
	Protect the rechargeable battery from water and moisture.
	Safety information Instructions for use
	CE mark indicates conformity with relevant EU directives applicable for this product.

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is designed for loosening and tightening screws.
Always use the correct accessory tools according to the intended use. Observe the technical requirements of this product (see “Technical data”) when purchasing and using attachments and screw bits.
■ Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage.
The manufacturer is not liable for any damages caused by improper use.
The product is not intended for commercial or similar uses.

- Scope of delivery

1 4V Cordless rod screwdriver Magnetic bit holder

1 USB cable 1 Storage box
16 Screw bits (25 mm) 1 User manual
8 Screw bits (50 mm)

Parts list

(Fig. A)

1 Bit holder	7 USB cable
2 Torque adjustment ring	8 Charger *
3 On/off switch	9 USB port (Type A)
4 Rotational direction switch	10 Screw bit (25 mm)
5 Charging status/battery level LED	11 Screw bit (50 mm)
6 USB port (Type C)	12 Magnetic bit holder
	13 Storage box

- Technical data

4V Cordless rod screwdriver

Model: HG11772
Rated voltage: 4 V	=== (direct current)
Rechargeable battery (built-in): Lithium-Ion
Number of cells: 1
Capacity:	1.5 Ah
No-load speed n0: 360 min	-1
Torque:	Max. 5 N m (driven by motor)Max. 7 N m (driven by hand)
Bit holder: 6.35 mm (1/4")

24 Screw bits

Screw bit Icon Length		length		Quantity	Size/Specification
Slotted bits SL	L		50 mm 1	× 1.0 × 5.5 mm
Pozidriv bits PZ	PZ		25 mm	2 × PZ2
				1 × PZ3
			50 mm 2	× PZ2
Phillips bits PH	PH		25 mm	1 × PH1
				3 × PH2
				1 × PH3
			50 mm 1	× PH2
Torx bits T			25 mm	1 × T15
				2 × T20
				2 × T25
				2 × T30
				1 × T40
			50 mm	1 × T15
				1 × T20
				1 × T25
				1 × T30

Use only the following charger* to charge the product:

Information Value
Manufacturer's name or trade mark, commercial registration number and address	OWIM GmbH & Co. KGHRA 721742Stiftsbergstraße 1,74167 Neckarsulm,GERMANY
Model identifier HG06825 (VDE	plug),HG06825-BS (BS plug)

Information Value Unit
Input voltage 100–240 V~
Input AC frequency 50/60 Hz
Output voltage 5.0 V		---
Output current 1.7 A
Output power 8.5 W
Average active efficiency 78.2 %
No-load power consumption < 0.1	W
Input current	0.3 A
Protection class	II/☐ (double insulation)
Connection type	USB (Type A)
Charging time	approx. 60	min

Recommended ambient temperature

While charging: +4 °C to +40 °C
During operation: 0 °C to +40 °C
During storage: 0 °C to +50 °C

Noise emission value

⚠ WARNING! Risk of injury!

The vibration and noise emissions during actual use of the power tool can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed.
Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the power tool is switched off and when it is running idle in addition to the trigger time).

NOTE

The declared vibration tool value and the declared noise emission value have been measured in accordance with a standard test method and may be use for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the power tool is typically as follows:

Sound pressure level L_pA : 60.2 dB
Sound power level L_WA : 68.2 dB
Uncertainty K_pA/WA : 3 dB

Vibration emission value

Vibration total values (triaxial vector sum) determined according to EN 62841:

Screw driving

Vibration emission value ah: < 2	5 m/s2(0.867 m/s2)
Uncertainty K: 1.5 m/s	2

General safety instructions

BEFORE USING THE PRODUCT, FAMILIARISE YOURSELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, ALSO INCLUDE ALL THE DOCUMENTS!

In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

Children and persons with limitations

⚠ WARNING! DANGER OF DEATH AND ACCIDENTS FOR TODDLERS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation.

Children frequently underestimate the dangers. Always keep children away from the packaging material.

● General power tool safety warnings

⚠ WARNING! READ ALL SAFETY WARNINGS, INSTRUCTIONS, ILLUSTRATIONS AND SPECIFICATIONS PROVIDED WITH THIS POWER TOOL.

- Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

■ Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce the risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the in uence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting of the power tool. Ensure the switch is in the o -position before connecting to a power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your nger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the

power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits, etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Battery tool use and care

CAUTION! Risk of explosion!

▶ Never charge non-rechargeable batteries!

CAUTION! Risk of explosion!

Protect the rechargeable battery from heat, for example from continuous exposure to sunlight, fire, water and moisture. There is a risk of explosion.

a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
c) When the battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack that is damaged or modified for a tool. Damaged or modified batteries exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperatures. Exposure to fire or temperatures above 130 °C may cause an explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.

Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorised service providers.

● Safety guidelines for screwdrivers

a) Hold the power tool by the insulated gripping surfaces when performing an operation where the fastener may contact hidden wiring. Fasteners contacting a “live” wire may turn exposed metal parts of the power tool “live” and could give the operator an electric shock.

b) Secure the workpiece. A workpiece securely held by a clamping device or vice is much safer than one held in the hand.

c) Hold the power tool firmly. High reaction moments can occur for brief periods while tightening and loosening screws.

d) Switch the power off immediately if the tool blocks while in use. Be prepared for high reaction moments as these can cause kickback.

e) While working on the appliance, transporting it or storing it, always set the rotation direction switch to the central position (lock position). This prevents the power tool from starting up unintentionally.

● Vibration and noise reduction

To reduce the impact of noise and vibration emission, limit the time of operation, use low vibration and low-noise operating modes as well as wear personal protective equipment.

Take the following points into account to minimise the vibration and noise exposure risks:

■ Only use the product as intended by its design and this user manual.
■ Ensure that the product is in good condition and well maintained.
■ Use the correct accessory tools for the product and ensure they are in good condition.
- Keep a tight grip on the handles/grip surface.
- Maintain this product in accordance with this user manual and keep it well lubricated (where appropriate).
- Plan your work schedule to spread any high vibration tool use across a longer period of time.

● Behaviour in emergency situations

■ Familiarise yourself with the use of this product by means of this user manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.
■ Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
- Switch the product off and disconnect it from the mains if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

● Battery charger safety warnings

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Cleaning and user maintenance shall not be made by children without supervision.

• Do not charge non-rechargeable batteries. Disregarding this instruction is hazardous.
• Protect the electrical parts against moisture. Do not immerse such parts in water or other liquids to avoid electrical shock.
• Never hold the product under running water. Pay attention to the instructions provided for cleaning, maintenance and repair.

The product is suitable for indoor use only.

- Residual risks

NOTE

This product produces an electromagnetic field during operation! This field may, under some circumstances, interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, persons with medical implants should consult their doctor and the medical implant manufacturer before operating this product!

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

■ Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
■ Danger of injury and property damage caused by flying objects.

Before use

Before and after each use, check the product and the screw bits 10/11 for wear and damage.
☐ If required, exchange the screw bits 10/11 for new ones (see "Changing screw bits/magnetic screw bit holder").

☐ Observe the technical requirements for the screw bits 10/11 (see “Technical data”).
☐ Checking the battery level: Press and hold the on/off switch 3. The charging status/battery level LED 5 lights up. After releasing the on/off switch, the charging status/battery level LED remains on for approx. 5 seconds.

Battery status LED when charging			Battery level*
Red Green Red/Green
Lights up Off Off < 100 %
Off Lights up Off 100 %
Off Off Flashing			Temperature protection
Flashing Off Off			Voltage/Current protection

Battery status LED when using			Charging status*
Red Green Red/Green
Lights up Off Off < 30 %
Off Lights up Off ≥ 30 %
Off Off Flashing			Temperature protection
Flashing Off Off			Voltage/Current protection
Battery status LED when charging and using			Charging status*
Red Green Red/Green
Lights up Off Off < 30 %
Off Lights up Off ≥ 30 %
Off Off Flashing			Temperature protection
Flashing Off Off			Voltage/Current protection

● Charging the battery

(Fig. B)

CAUTION! Risk of injury!

This product has a built-in rechargeable battery which cannot be replaced by the user. The removal or replacement of the rechargeable battery may only be carried out by the manufacturer or his customer service or by a similarly qualified person in order to avoid hazards. When disposing of the product, it should be noted that this product contains a rechargeable battery.

NOTE

The built-in battery is supplied partially charged.
Li-Ion batteries can be charged at any time without adversely affecting their service life. Interruption of the charging process does not damage the battery.

NOTE

Never charge the product when the ambient temperature is below +4 °C or above +40 °C. The storage climate should be cool and dry and the ambient temperature should be between 0 °C and +50 °C.
The product warms up slightly whilst charging.

1. Connect the USB cable 7 to the USB port (Type A) 9 of the charger 8 (not included). Connect the other end to the USB port (Type C) 6 of the product.
2. Connect the charger 8 to a mains socket.
3. The charging status/battery level LED 5 show the charging status (see “Before operation”).
4. To stop charging the product, disconnect the charger 8 from the product and mains outlet.
5. Remove the USB cable 7 from the USB port 6 of the product.

Operation

- Switching the product on/off

(Fig. C)

☐ Switching on the product: Press and hold the on/off switch 3.
□ Switching off the product: Release the on/off switch 3.

● Changing rotary direction

(Fig. C)

NOTICE! Risk of product damage!

Do not use the rotational direction switch 4 while the product is in operation.

☐ Setting the rotary direction: Set the rotation direction switch 4 in various positions.

Rotation direction switch position	Rotary direction
a - Forward Clockwise (tightens screw)
b - Middle	The product is off and secured against accidental switch-on.The spindle is locked.
c - Backward Anti-clockwise (loosens screw)

● Changing screw bits/the magnetic bit holder (Fig. D)

NOTE

A built-in magnet on the bottom of the bit holder 1 holds the inserted screw bit 10/11 and the magnetic bit holder 12.
Screw bits ^10/11 are labelled according to their dimensions and their shape. The screw bit has to snugly fit in the screw head.

☐ Pull out the screw bit 10/11. Insert another type of screw bit into the bit holder 1.
☐ For a longer reach: Insert the magnetic bit holder 12 into the bit holder 1. Insert a screw bit 10/11 into the magnetic bit holder.

● Tightening and loosening the screw

(Fig. F)

Tightening the screw

1. Driving a screw into a workpiece: Set the rotational direction switch 4 to the position a (forward).
2. Tightening the screw: Hold the product and press it down.

Loosening the screw

1. Driving a screw out of a workpiece: Set the rotational direction switch 4 to the position c (backward).
2. Loosening the screw: Hold the product and press it down with enough pressure. The tip of the screw bit 10/11 has to be engaged with the screw head.

- Manual operation

(Fig. G)

NOTE

The product can be used as manual screwdriver.

Tightening the screw

1. Driving a screw into a workpiece manually: Set the rotational direction switch 4 to the position b (middle).
2. Tightening the screw: Turn the product in clockwise direction.

Loosening the screw

1. Driving a screw out of a workpiece manually: Set the rotational direction switch 4 to the position b (middle).
2. Loosening the screw: Turn the product in anti-clockwise direction.

- Setting the torque

(Fig. E)

NOTE

The values in the following table are for reference only. Do not rely solely on these values if high precision work is required.
The listed driving torque value is measured by the static load test method. This is the maximum torque, corresponding to level 1 to Max, to drive a screw into wood.

1. Align the △ mark of the torque adjusting ring 2 to one of the 5 torque positions:

Level Torque N m Screws Material
1	Low	0.1	Short screwsSmall diameter	Soft
2 0.4
3	Medium	0.8	Long screwsMedium diameter	Medium hard
4 1.2
Max High 5			Long screwsLarge diameter	Hard

1. The product stops driving the screw once the preset torque level has been reached.

● Cleaning and maintenance

Before cleaning and maintenance

1. Set the rotation direction switch 4 to the position b (middle). This prevents the product from accidentally switching on.

2. Remove the following parts from the product:

-USB cable 7 - Screw bit 10/11
- Magnetic bit holder 12 (if inserted)
(see “Changing screw bits/magnetic bit holder”).

Cleaning

⚠️ NOTICE! Risk of product damage!

▶ Never allow fluids to get into the product.
The product must always be kept clean, dry and free from oil or grease.
Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.

NOTE

▶ Regular and proper cleaning ensures safe use of the product and prolongs its life.

☐ Clean the product with a dry cloth. Use a soft brush for areas that are hard to reach.

Maintenance

Before and after each use: Check the product and the screw bits [ ]/ [ ] for wear and damage.
☐ If required, exchange the accessories (see “Changing screw bits/magnetic bit holder”).
☐ Observe the technical requirements for the accessories (see “Technical data”).

- Transportation

□ Transport the product in the storage box [ ].
☐ Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles.
☐ Secure the product to prevent it from slipping or falling over.

Storage

1. Set the rotation direction switch [4] to the position b (middle). This prevents accidentally switching on the product.
2. Store the product out of reach of children and in a dry indoor location protected from direct sunlight, preferably in the storage box [ ].

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries,

tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 484715_2501) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 484715_2501 takes you to the operating instructions for your item.

PDF ONLINE parkside-diy.com

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

● EUdeclarationofconformity

EU DECLARATION OF CONFORMITY (No. 484715\_2501)

IAN:

484715_2501

Product identification:

"PARKSIDE" Cordless Screwdriver

Model Number:

HG11772

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 62841-1:2015/A11:2022

EN 62841-2-2:2014

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021

EN 61000-3-3:2013/A2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

Directive 2011/65/EU

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 05.05.2025

Place Date

Ippa. Jena Buchheim Authorised Signatory Ippa. Dr. Thorptén Maier Authorised Signatory

EN
