USER MANUAL PSTD 800 F5 PARKSIDE

Black Parkside Power jacks kit with visible screw base and handle (no text or symbols on device body)

Jigsaw / Pendelhubstichsäge / Scie sauteuse pendulaire PSTD 800 F5

DE AT CH

Pendelhubstichsäge

Translation of the original instructions

NL BE

Decoupeerzaag

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Service-Center....15

Importeur.... 15

Scope of delivery/accessories......17

Overview.... 18

Description of functions....18

Technical data....18

Safety information....19

Meaning of the safety information...... 19

Pictograms and symbols.... 19

General Power Tool Safety

Warnings....19

Safety information for reciprocating saws....20

Residual risks....21

Preparation....21

Control elements....21

Attaching and removing the slide shoe.... 22

Attaching and removing the saw blade.... 22

Using the parallel guide.... 22

Bevel cuts.... 23

External dust extraction.... 23

Attaching and removing the protective cover.... 23

Attaching and removing the splinter guard....23

Operation.... 23

Information on sawing.... 23

Switching on and off....24

Transport....24

Cleaning, maintenance and storage..... 24

Cleaning....24

Maintenance.... 24

Storage.... 24

Disposal/environmental protection.....25

Troubleshooting.... 25

Service.... 25

Guarantee.... 25

Repair service.... 26

Service Centre 27

Importer....27

Spare parts and accessories.... 27

Translation of the original EU declaration of conformity....28

Exploded view.... 151

Introduction

Congratulations on purchasing your new jigsaw (hereafter referred to as device or power tool).

You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device.

The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following uses:

• Sawing plastic, wood and light metal with firm support
• Sawing straight and curved cuts as well as mitre cuts (only wood and plastic) of up to 45°
• Only operate in dry areas.

Please note the information on saw blade types.

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use.

The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

- Jigsaw

• 1 Wood saw blade T144D HCS, Swiss made
• 1 Hex key
• Splinter guard (pre-assembled)
• Slide shoe (pre-assembled)
  • Guard cover (pre-assembled)
• Suction nozzle (pre-assembled)
• Reducer piece
• Parallel guide
  • Translation of the original instructions

Overview

The illustrations for the device can be found on the front and back fold-out page.

1 Rotary wheel

2 Lock button

3 On/Off switch

4 Handle (Insulated gripping surface)

5 Hex key

6 Holder (Hex key)

7 Power cord

8 Reducer piece

9 Suction nozzle

10 Notch

11 Slide shoe

12 Switch (dust blower function)

13 Footplate

14 Hexagon socket screw

15 Pendulum stroke switch

16 Guide roller

17 Wood saw blade

18 Mount (Parallel guide)

19 Retaining screw

20 Guard cover

21 Chuck

22 LED work light (not visible)

23 Release (Chuck)

24 Button (LED work light)

25 Splinter guard

26 Recess in slide shoe

27 Parallel guide

Description of functions

With the jigsaw, the saw blade clamped on one side cuts via a stroke movement. With

the pendulum stroke, the guide roller moves the saw blade forwards during every up-stroke in addition to the vertical saw movement.

Please refer to the descriptions below for information on how the operating elements work.

Technical data

Jigsaw ...... PSTD 800 F5

Rated voltage U 230 V\~, 50 Hz

Rated input power P 800 W

Length Power cord 3 m

Protection class ..... □ II ( double insulation )

Weight 2.2 kg

Idle stroke rate 0–3100 min ^-1

Stroke length 22 mm

Blade thickness .... ≤1.6 mm

Cutting depth

- wood ....≤ 80 mm

-metal ≤ 8mm

Bevel cutting

-45^;-30^;-15^;0^;15^;30^;45^

Sound pressure level ( L_pA )

94.1 dB; K_pA=5 dB

Sound power level (LWA)

- Measured ....102.1 dB; K_WA=5 dB

Vibration (ah)

- wood ....5.737 m/s²; K=1.5 m/s²

- metal ....6.079 m/s ^2 ; K=1.5 m/s ^2

Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity.

The specified total vibration value and the stated noise emission value have been measured according to a standardised test method and can be used to compare one power tool with another. The specified total vibration value and the stated specified noise emission value can also be used for a provisional assessment of the load.

⚠ WARNING! The vibration and noise emissions may deviate from the specified values during actual use of the power tool, depending on how the power tool is being used.

Try to keep the exposure to vibrations as low as possible. An example of a measure to reduce vibration exposure is limiting the working hours. All parts of the operating cycle have to be considered while doing so (for example, times when the power tool is

switched off and times when it is switched on but running without any load).

Safety information

This section deals with the basic safety instructions for using the device.

Meaning of the safety information

⚠️ DANGER! If you do not observe this safety instruction, an accident will occur. The result of which is severe bodily injury or death.

⚠ WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.

⚠️ CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.

NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols

Symbols on the device

Read the instruction manual

Protection class II (double insulation)

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

Symbols used in the instruction manual

Use protective gloves

General Power Tool Safety Warnings

⚠ WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

1. WORK AREA SAFETY

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

2. ELECTRICAL SAFETY

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Un-modified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.

f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. PERSONAL SAFETY

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while op-

erating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

4. POWER TOOL USE AND CARE

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery

pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

5. SERVICE

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

Safety information for reciprocating saws

- Hold the power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessories contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.

• Use clamps or another practical way to secure and support the workpiece to a stable platform. Holding the workpiece by your hand or against the body leaves it unstable and may lead to loss of control.
• If the power cord of this device is damaged, it must be replaced by the manufacturer or their representative to avoid safety hazards. contact the service centre.
• Only use accessories recommended by PARKSIDE. Unsuitable accessories may cause electric shock or fire.

Further safety instructions for reciprocating saws

• Keep hands away from the sawing area. Do not reach underneath the workpiece. Upon contact with the saw blade there is a risk of injury.
• Only when the power tool is turned on should the sawing blade be moved against the workpiece. Otherwise, there is a risk of kickback if the attachment tools jam in the workpiece.
• Make sure that the footplate is secure during sawing. A tilted saw blade may break or cause a kickback.
• After you have finished work, turn the power tool off and do not pull the saw blade out of the cut until it has come to a standstill. In this way you will avoid any kickback and can safely put down the power tool.
• Use only undamaged saw blades in perfect condition. Bent or blunt saw blades can break, adversely affect the cut or cause kickback.
• Do not brake the saw blade after switching the device off by applying side pressure. The saw blade may be damaged, break or cause a kickback.
• Do not touch any objects or the ground with the saw running. There is a risk of kickback.
• Hold the power tool tightly with both hands while working and ensure a secure footing. The power tool is guided more securely with both hands.

• Switch the appliance off immediately if the sawing blade jams. Force apart the saw cut and pull the saw blade out carefully. This can lead to loss of control over the power tool.

• Use suitable detectors to determine if there are hidden supply lines or contact the local utility company for assistance. Contact with electric cables can cause fire and electric shock. Damaging gas lines can lead to explosion. Breaking water pipes causes property damage.

• Always wait until the power tool has come to a complete stop before placing it down. The application tool can jam and cause you to lose control of the power tool.

Residual risks

There will always be residual risks even if you operate this device according to the instructions. The following hazards may occur in connection with the type and design of this device:

• Hearing damage if suitable ear protection is not worn.
• Health injuries resulting from the effect of hand/arm vibration in the event that the tool is used over a longer period of time or is not used and maintained properly.
• Cutting injuries

WARNING! Danger due to electromagnetic field generated while the tool is in operation. Under certain circumstances, this field may negatively affect active or passive medical implants. In order to reduce the danger of serious or fatal injuries, we recommend that individuals who wear medical implants should consult their doctor and the manufacturer of the implant before operating the tool.

Preparation

⚠ WARNING! Risk of injury due to unintentional start-up. Do not insert the plug into the outlet until the device is fully prepared for use.

Control elements

Familiarise yourself with the operating elements before using the device for the first time.

- On/Off switch (3)

• Switching on: Press
• Switching off: Release

• Pendulum stroke switch (15)

Set pendulum movement of the saw blade in 4 positions:

• 0 - no pendulum motion
• 1 - small pendulum motion
• 2 - medium pendulum motion
• 3 - large pendulum motion

- Rotary wheel (1)

Set the stroke rate in 6 levels.

- Switch (dust blower function) (12)

Blower function for chip-free cutting line

DISABLE enable

• LED work light (22)

You can use the button (24) to switch the LED work light on and off.

Attaching and removing the slide shoe

When working on scratch-sensitive workpieces, working with the slide shoe (11) is recommended.

Assembling the slide shoe (Fig. A)

1. Place the slide shoe (11) on the front of the footplate (13).
2. Press the notches (10) on the back of the slide shoe over the footplate (13).

Disassembling the slide shoe (Fig. A)

1. Press the slide shoe (11) on the notches (10) away from the footplate (13).
2. Pull the slide shoe (11) forward, away from the footplate (13) and off.

Attaching and removing the saw blade

⚠️ CAUTION! Risk of injury when touching the saw blade. Wear protective gloves when handling the saw blade.

Requirements

• The saw blade has a T-shank mount (single lug shank) like the supplied saw blade (17).
• The saw blade is suitable for the respective material. The scope of delivery for the device includes a large-toothed saw blade for wood.

- The chuck is free of splinters or other material residue.

Installing the saw blade (Fig. B)

1. Turn the release of the chuck (23) as far as possible. Keep the release of the chuck fixed in this position.
2. Place the saw blade (17) into the chuck (21). When inserting the saw blade, make sure that the back of the saw blade is in the notch of the guide roller (16).
3. Release the release of the chuck (23) los.
4. Make sure that the saw blade (17) is attached correctly and the teeth are pointing in the cutting direction.

Removing the saw blade (Fig. B)

Hold the device in a way that no persons in the vicinity are injured by the ejected saw blade.

1. Hold the saw blade (17) firmly.
2. Turn the release of the chuck (23) as far as possible.

The saw blade (17) is ejected. If the saw blade is not ejected: Hold the release of the chuck and pull the saw blade from the chuck.

1. Release the release of the chuck (23) los.

Using the parallel guide

The parallel guide can be fitted on both sides of the tool.

Fitting the parallel guide

1. Loosen the retaining screws (19) if necessary.
2. Push the parallel guide (27) into the holders (18).
3. Retighten the retaining screws (19).

Removing the parallel guide

1. Loosen the retaining screws (19).
2. Pull the parallel guide (27) out of the holders (18).

Adjusting the parallel guide

1. Loosen the retaining screws (19).
2. Set the scale on the parallel guide (27) so that you can read the desired cutting width on the footplate (13) marking.
3. Retighten the retaining screws (19).
4. Make a test cut, check the cutting width and correct the position of the parallel guide (27) if necessary.

Bevel cuts

Notes

• You can set the following cutting angles: -45^ ; -30^ ; -15^ ; 0^ ; 15^ ; 30^ ; 45^
• To set a cutting angle of 45^ , remove the protective cover (20) and the tension tear protection (25).

Tools required

- Hex key (5)

Procedure (Fig. D)

1. Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop.
2. Press the catch at the bottom of the suction nozzle (9, Fig. E) and remove the suction nozzle.
3. Loosen the hexagon socket screws (14) with the Allen key (5).
4. Pull the footplate (13) slightly backwards.
5. Set the footplate (13) to the desired position.
6. Push the footplate (13) forward into one of the notches.
7. Tighten the hexagon socket screws (14) with the Allen key (5).

External dust extraction

Requirements

• The protective cover (20) is fitted.

Connecting external dust extraction (Fig. E)

1. Disable the dust blower function (12).
2. Slide the suction nozzle (9) as far as it will go into the guide rail between the device and footplate (13).
3. Connect a suitable dust extraction (not included) to the suction nozzle (9).
4. If the external dust extraction does not fit, use the additional reducer piece (8).

Removing external dust extraction (Fig. E)

1. Remove the dust extraction from the suction nozzle (9) or reducer piece (8).

2. Remove the reducer piece (8).

3. Remove the suction nozzle (9):

4. Remove the dust extraction from the suction nozzle (9) or reducer piece (8).

5. Remove the reducer piece (8).

6. Remove the suction nozzle (9):

7. Press against the suction nozzle inside the recess in the footplate (13).

8. Pull the suction nozzle backwards.

Attaching and removing the protective cover

Attaching the protective cover

1. Press the two holders on the protective cover (20) into the recesses on the tool housing.

The protective cover clicks into place.

You can fold the fitted protective cover up by 65^ .

Removing the protective cover

1. Carefully press the two holders on the protective cover (20) apart.
2. Pull the protective cover to the front.

Attaching and removing the splinter guard

Attaching the splinter guard

1. Press the splinter guard (25) into the recess in the slide shoe (26).

Removing the splinter guard

1. Press the splinter guard (25) out of the recess in the slide shoe (26).

Operation

Information on sawing

Selecting a stroke rate

The stroke rate can be adjusted in steps with the rotary wheel (1). Start with a low stroke rate. As a rule of thumb:

Material Stroke rate

Hard Low

Soft High

Selecting the pendulum motion

The larger the pendulum motion, the faster your progress.

The optimal pendulum motion can be established through practice; the following settings are recommended:

• For thin material, hard material (e.g. metal) or for cutting curves: Level 0
• Fine and clean cutting edges can be achieved with little or no pendulum motion: Level 0 or 1.
• Soft material (wood, plastic, etc.): level 2 or 3

Plunge sawing

Requirements

• Soft materials such as wood, aerated concrete, plasterboard etc.
• Mitre angle: 0^
  • Maximum stroke rate selected (level 6)
• Short saw blade mounted

Procedure (Fig. F)

1. Place the device with the front edge of the footplate (13) on the workpiece. The saw blade (17) does not touch the workpiece.
2. Turn the device on. Wait until the maximum stroke rate has been reached.
3. Press the saw blade (17) into the workpiece until the footplate (13) rests on the workpiece.
4. Continue sawing along the cutting line.

General Information

With this order, you work safely with the sabre saw and achieve a good result:

1. Clamp the workpiece. Use a clamping device for small workpieces.
2. Draw a line to specify the direction in which the saw blade is guided.
3. Hold the device securely by the handle.
4. Set the stroke rate.
5. Set the mitre angle.
6. Set the stroke strength.
7. Turn the device on.
8. Wait until the device has reached its full stroke rate.
9. Place the footplate on the workpiece.
10. Slowly move the device along the marked line, pressing the footplate firmly down onto the workpiece.
11. Do not apply too much pressure in the cutting direction. Let the device do the work.
12. Before shutting down the device, switch it off and wait for it to come to a complete standstill.

Switching on and off

Switching on

1. Insert the plug in the socket.
2. Set the stroke rate using the rotary wheel (1).
3. Press the On/Off switch (3).
4. Lock the On/off switch (3): Press the lock button (2) when the On/off switch is pressed all the way down.

The lock button locks.

Switching off

1. On/Off switch locked: Press the On/off switch (3).
   The lock button (2) unlocks.
2. To turn it off, release the on/off switch (3).
3. Do not pull the sawblade out of the cut until it has come to a standstill.
4. Pull the device plug out of the wall outlet if you are leaving the device unattended or if you have finished working.

Transport

Notes

• Turn off the device.
• Make sure that all moving parts have come to a complete stop.
• Pull out the mains plug.
• Remove the attachment tool.
  • Always carry the device by the handle (4).

Cleaning, maintenance and storage

⚠ WARNING! Electric shock! Risk of injury due to unintentional start-up. Protect yourself when performing maintenance or cleaning work. Switch off the device and disconnect the mains plug from the socket. You should have any repair and maintenance work that is not described in these instructions carried out by our Service Centre. Only use original replacement parts.

Cleaning

WARNING! Electric shock! Never spray down the device with water.

NOTICE! Risk of damage. Chemical substances may attack the plastic parts of the machine. Do not use any cleaning agents or solvents.

- Keep the ventilation slits, motor housing and handles of the machine clean. Use a damp cloth or brush to do this.

Maintenance

The device is maintenance free.

Storage

Always store the device and accessories:

• clean

• dry

• protected against dust
  • out of the reach of children

Disposal/environmental protection

The device, accessories and packaging should be properly recycled.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be dis-

posed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured.

Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.

This does not affect accessories enclosed with the old devices or tools without any electrical components.

Troubleshooting

The following table will assist you in fixing faults:

Problem Possible cause Error correction
Device does not start	No mains power supply Check	the socket, mains connection cable, plug and fuse and have them repaired by a qualified electrician if necessary.
	On/Off switch (3) is broken Contact the service centre.
	Defective motor Contact the service centre.
tions	Internal loose contact Contact the service centre.Device works with inte
	On/Off switch (3) is broken Contact the service centre.
Poor sawing performance	Saw blade (17) unsuitable for the workpiece to be processed	Use a suitable saw blade (17)
	Saw blade (17) blunt Use a new saw blade (17)
	Incorrect sawing speed Adjust sawing speed
Saw blade quickly becomes blunt	Saw blade (17) unsuitable for the workpiece to be processed	Use a suitable saw blade (17)
	Too much pressure applied Reduce the pressure
	Sawing speed too high Reduce the sawing speed

Service

Guarantee

Dear Customer,

This product is provided with a 3 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights

are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or re-

place – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred. If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery. The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts or to cover damage to breakable parts.

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

• Please have the receipt and product number (IAN 480694_2410) ready as proof of purchase for all enquiries.
• Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the

sticker on the back or underside of the product.

- Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

PDF ONLINE parkside-diy.com

You can view and download these and many other manuals on parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 480694_2410.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

- We can only work on devices which are sent in properly packed and with postage paid.

Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.

• The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.
  • We will dispose of defective devices you ship to us free of charge.

Service Centre

Service Great Britain

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 480694_2410

Service Malta

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 480694_2410

Importer

Please note that the address below is not a service address. Contact the service centre named above first.

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 27

Pos. nr. * Name Order No.
5 1 Hex key 91110088
8, 9 50, 51 Reducer piece, Suction nozzle 91110473
11, 13 37–40, 47, 48 Slide shoe, Footplate 91110471
17 41	Wood saw blade (T144D HCS, Swiss made)	13800406
20 34	Guard cover	91110470
25 49	Splinter guard	91110472
27	— Parallel guide	91110474
—	— Metal saw blade (HSS)	13800403

*Exploded view, , p. 151

Translation of the original EU declaration of conformity

Product: Jigsaw

Model: PSTD 800 F5

Serial number: 000001-148600

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2006/42/EC • 2014/30/EU • 2011/65/EU & (EU) 2015/863

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 62841-1:2015/A11:2022 • EN 62841-2-11:2016/A1:2020

EN IEC 63000:2018 • EN IEC 55014-1:2021 • EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021 • EN 61000-3-3:2013/A2:2021

IEC 62471:2006 • EN 62471:2008

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction...... 29

Garantie (France)....40

Service-Center....42

Importateur.... 42

désactiver activer

Consignes relatives au sciage

Choisir la vitesse

Service-Center....55

Importeur.... 55

← activeren → activer

Service-Center....68

Importador.... 68

Service-Center....81

Importatore....81

Ricambi e accessori.... 81

Service-Center....93

Dovozce....93

QR code image with a central logo, likely linking to a digital resource or website.

PDF ONLINE parkside-diy.com

Service-Center....145

Importør.... 145

25 Anti-splintsystem

26 Udsparing i glidesko

27 Parallelanslag

QR code image with a central logo, likely linking to a digital resource or website.

PDF ONLINE parkside-diy.com

FSC www.fsc.org MIX Paper | Supporting responsible forestry FSC® C152850
