USER MANUAL PEMH 2400 C4 PARKSIDE

QR code image with a central logo, likely linking to a digital resource or website.

PDF ONLINE

parkside-diy.com

ELEKTRO-MESSERHÄCKSLER/ELECTRIC KNIFE SHREDDER/BROYEUR ÉLECTRIQUE DE VÉGÉTAUX À LAMES PEMH 2400 C4

DE AT CH

ELEKTRO-MESSERHÄCKSLER

Bedienungsanleitung

Translation of the original instructions

FR BE

GB/IE User manual Page 23

Intended use.... Page 25

Scope of delivery ...... Page 26

Parts description. Page 26

Technical data. Page 26

General safety instructions.... Page 27

Preparation Page 27

Operation Page 28

Cleaning, maintenance and storage. Page 29

Fitting the collection bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 30

Behaviour in emergency situations. Page 30

Residual risks Page 30

Before first use.... Page 30

Unpacking the product. Page 30

Assembly Page 31

Mounting the chassis....Page 31

Fitting the collection bag ...... Page 31

Fitting the pushing element ...... Page 31

Operation.... Page 31

Switching on/off Page 32

Emptying the collection bag. Page 32

Removing blockages ...... Page 32

Overload protection Page 32

Restart lock. Page 32

Working instructions ...... Page 33

Cleaning and maintenance Page 33

Cleaning Page 33

Maintenance Page 33

Turning the blades Page 34

Changing the blade plate....Page 34

Storage Page 35

Replacement parts/Accessories. Page 35

Troubleshooting Page 35

Disposal Page 36

Warranty.... Page 36

Warranty claim procedure. Page 36

Service Page 37

EU declaration of conformity.... Page 38

List of pictograms used
	Read the instruction manual.Familiarise yourself with the controls and the correct use of the product.		Wear eye and hearing protection!
			Wear protective gloves!
	DANGER! - Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)		Wear protective, slip-resistant footwear!
			Do not expose the product to rain.
	WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)		CAUTION! - Danger from ejected parts!Keep your distance from the feed hopper and ejection chute.Keep by-standers well away.
	CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)		DANGER! - Rotating cutting blades!Keep your hands and feet away from the openings while the product is running.
			Do not use as a step!
	NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)		Before touching components, wait until they have come to a standstill.
	Protection class II (double insulation)		Alternating current/voltage
	Warning! Switch the product off and remove the mains plug before changing settings, cleaning the product or if the cord is damaged.	Guaranteed sound power level L_WA indicated in dB.
		IPX4	Splash-proof
	The person responsible for the product should be able to check whether the mains supply is interrupted at any time by taking a quick look.		Opening the housing lock
			Closing the housing lock
	CE mark indicates conformity with relevant EU directives applicable for this product.		Safety information Instructions for use

ELECTRIC KNIFE SHREDDER

● Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This electric knife shredder (hereinafter referred to as ‘product’ or ‘power tool’) is suitable for shredding green cuttings, bushes and shrubs with branch thicknesses of up to 40 mm.
The product must not be filled with stones, glass, metal, bones, plastics or fabric waste.

• Protect the product from rain and moisture.
  ■ Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage.
  The manufacturer is not liable for any damages caused by improper use.
  The operator or user of the product is responsible for any accidents or personal injury and/or material damage to third parties or their property.
  ■ The product is exclusively intended for domestic use.
  ■ The product is not intended for commercial use or for similar uses.
• Observe all applicable local safety regulations, standards and ordinances. The use of noise emitting power tools may be restricted to certain times by national or local regulations.

- Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 Electric knife shredder
2 Wheel + wheel cover + assembly materials
1 Axle
2 Chassis
1 Collection bag
2 Holder (collection bag)
1 Pushing element
1 Holder (pushing element)
1 Hex key with angled cross head screwdriver
1 User manual

Parts description

Before reading, unfold the pages containing the illustrations and familiarise yourself with all functions of the product.

Figure A:

1	Pushing element
2	Holder (pushing element)
3	Feed hopper
4	Upper housing
5	Holder (collection bag) (×2)
6	Collection bag
7	Wheel (×2)
8	Wheel cover (×2)
9	Mains cord with mains plug
10	Cord-strain relief
11	Axle
12	Chassis (×2)

13 Ejection chute
14On/off switch
15Housing lock
16 Hex key with angled cross head screwdriver
17Handle

Figure B:

18	Screw + Washer (×2)
19	Sleeve (×2)
20	Washer, curved (×2)

Figure C:

21Screw

(×2)

Figure F:

22	Blade guard (metal)
23	Screw (flange)
24	Access hole
25	Blade	(×2)
26	Screw	(×4)
27	Blade plate
28	Flange
29	Screw (blade guard)	(×6)

- Technical data

Electric knife shredder	PEMH 2400 C4
Rated voltage U:	220–240 V~,50 Hz
Rated power P:	2,400 W (P40)*
Protection class:	II(double insulation)
Protection type:	IPX4
No-load rotation speed n0:	4,500 min-1
Branch thickness:	max. ∅ 40 mm**
Volume (collection bag):	approx. 45 L
Weight (without accessories):	approx. 8.6 kg

Noise emission value:

Sound values were determined according to noise measurement method EN 50434:2014.

Noise values were determined in accordance with the standards and regulations specified in the declaration of conformity.

Sound pressure level L_pA : 91.2 dB
Uncertainty K_pA : 3.0 dB
Sound power level L_WA :
Measured:	98.9 dB
Uncertainty K_wA :	2.47 dB
Guaranteed:	101 dB

General safety instructions

IMPORTANT

READ CAREFULLY BEFORE USE.

KEEP FOR FUTURE REFERENCE.

Read the instructions carefully.

CAUTION!

When using power tools, observe the following basic safety measures for the prevention of electric shocks and the risk of injury and fire.

• Familiarise yourself with all parts and correct operation of the product before you start working with it.
  ■ Make sure that you can immediately switch off the product in an emergency. Improper use of the product may lead to serious injury.
  Children, individuals with limited physical, sensory or mental capabilities, as well as those who have insufficient experience or knowledge or are not familiar with the instructions must never be permitted to use the product. Local regulations may specify an age restriction for the user.
  If the mains cord of this product is damaged, it must be replaced by the manufacturer or their representative to avoid safety hazards. Contact the service centre.
  The product must never be used if people and especially children or pets are nearby.
• Cleaning and user maintenance must not be carried out by children.
• Do not use the product at altitudes over 2000 m.
• Only use extension cords that are suitable for outdoor use.

● Preparation

■ Wear hearing protection and safety goggles. Wear these at all times while operating the product. There is a risk of hearing damage and eye injuries.
■ Always wear sturdy shoes and full-length trousers during operation of the product. Do not operate the product in bare feet or with open sandals. Avoid wearing clothing that hangs loose or with hanging cords or ties. These could get caught in the feed hopper and lead to serious injuries.

• Only use the product out in the open (i.e. not against a wall or other rigid object) and only while standing on a solid, level surface.
• Do not use the product on a paved, gravelled surface where ejected material could cause injury.
  Before putting into operation, always visually inspect the product, the cutting tools, the screws of the cutting tools and other fastening materials to ensure they are secure, and that the housing is undamaged and the safety equipment and protective guards are in place. Damaged or worn parts are to be replaced as a set to ensure the product remains balanced. Damaged or illegible stickers must be replaced.
• Only connect the product to a socket outlet with a residual current device (RCD) with a rated residual current of no more than 30 mA.
  Prior to use, always check the mains cord and extension cord for signs of damage or wear and tear. If the cord is damaged during use, it must be disconnected from the supply network immediately. DO NOT TOUCH THE CORD BEFORE IT HAS BEEN DISCONNECTED FROM THE MAINS SUPPLY. Do not use the product if the cord is damaged or worn.

Operation

Pay attention, be aware of what you are doing and take the utmost care when working with the product. Do not use the product if you are tired or you are under the influence of drugs, alcohol or medication.
■ Before switching on the product: The feed hopper must be empty.
- Keep your head and body away from the feed hopper.

• Do not allow hands or other body parts or clothing to enter the feed hopper or ejection chute, or to be in the vicinity of moving parts.
  ■ Ensure you are standing securely and do not lose your balance. Avoid an abnormal body posture. Do not lean forward. When material is being fed in, never stand on a higher level than the base of the product.
  ■ Have a secure footing at all times (especially on sloping terrain).
  ■ Walk at a steady pace, do not run.
  ■ Always stay outside the ejection zone of the ejection chute when operating the product.
• Do not use the product in the rain and poor weather, especially when there is a risk of lightning, to reduce the risk of lightning strikes. Only work in daylight or where there is sufficient illumination.
• When inserting material, make sure that it does not contain any foreign objects (e.g. metal, stones, bottles, cans).
  ■ Make sure that no processed material accumulates in the ejection chute; this could prevent the material from being ejected correctly and cause it to bounce back through the feed opening.
  If the product becomes clogged, turn off the mains supply. Disconnect the product from the mains supply before starting to clean it out.
• Do not operate the product with damaged or defective safety equipment or protective guards, of if the safety equipment, e.g. the collection bag, are not in place.
• Do not operate the product with a damaged or worn out mains cord. Ensure that you do not connect a damaged cord to the mains supply or touch a damaged cord before

it has been disconnected from the mains supply.

• Keep the extension cord away from dangerous moving parts to prevent damage.
• Keep the ventilation holes free of waste and other deposits to protect the motor from damage or fire.
• Do not overload your product. Only work within the power range indicated. Observe the maximum indicated branch thickness. Do not use your product for purposes for which it is not intended.
• Only turn off the product once the feed hopper is fully emptied otherwise the product may become clogged and, under some circumstances, may not start again.
• Do not use the product if the on/off switch cannot be operated properly. Damaged switches must be replaced by our service centre.
  Only use splash-proof extension cords approved for outdoor use. The strand cross-section of the max. 75 m long extension cord must be 2×1.5 mm ^2 (H07RN-F). Always roll out cord drums completely before use. Check the extension cord for damage.
• Do not tilt the product while the motor is running.
• Never transport the product while the drive is running.
• Never use the mains cord to pull the plug out of the outlet or to pull the product. Protect the mains cord from heat, oil and sharp edges.
• Switch off the product and disconnect the plug from the mains outlet. Make sure that all moving parts have come to a complete stop: -When leaving the product. -If the mains cord or extension cord is damaged or entangled.

-Before removing obstructions or loosening blockages.

- Before checking the product, cleaning it or performing maintenance work on it.

If foreign bodies enter the cutting tools, or if the product generates unusual noises or vibrates unusually, immediately turn off the mains supply and allow the product to come to a standstill. Disconnect the product from the mains supply and perform the following steps before switching the product on again and operating it:

-Search for signs of damage.
-Replace damaged parts.
- Check for loose parts and tighten them if necessary.

● Cleaning, maintenance and storage

• Replace worn or damaged parts in the interests of safety. Use only original spare parts and accessories. Using externally produced parts results in the immediate loss of any warranty claim.
• Switch the drive off, disconnect the product from the mains supply and allow the product to cool off if you want to clean, adjust, store the product or to exchange an accessory part.
  ■ Store the product out of reach of children.
• When maintaining, be aware that parts can always still move even if the mains supply is switched off by the locking function or protective equipment.
  ■ Never try to circumvent the locking function of the protective equipment.
• Do not try to repair the product yourself unless you have professional training. All work not mentioned

in these instructions may only be performed by our service centre.

• Do not touch any of the dangerous moving parts before you have unplugged the product from the mains supply and that the moving parts have come to a complete standstill.
  If the mains cord of this product is damaged, it must be replaced by the manufacturer, their customer service or by a similarly qualified person in order to avoid hazards. Contact the service centre.

● Fitting the collection bag

■ Switch off the product before attaching or removing the collection bag.

● Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

■ Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
- Switch the product off and disconnect it from the mains if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

Residual risks

Even if you operate and handle this product properly, some residual risks will remain. Due to its construction and build, this product may present the following hazards:

Cut injuries

■ Eye damage if suitable eye protection is not worn.
■ Hearing damage if suitable hearing protection is not worn.
Injuries and material damage caused by loose parts of the running power tool that are unexpectedly ejected from the product due to sudden damage, wear or incorrect insertion.
Injuries caused by moving parts or hot surfaces.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

Before first use

● Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

Assembly

- Mounting the chassis

NOTE

▶ Tool required:
-Hex key with angled cross head screwdriver 16

Assembling the chassis

(Fig. B)

NOTE

▶ First assemble one wheel ^7 completely. Then repeat the assembly with the other wheel.

1. Insert the curved washer 20 onto the axle 11 with the curvature facing outwards.
2. Push the axle 11 into the chassis 12.
3. Push the sleeve 19 onto the axle 11 with the curvature pointing towards the chassis 12.
4. Push the wheel 7 (without wheel cover 8) onto the sleeve 19.
5. Fasten the wheel 7 with the screw and washer 18 (required tool: Hex key with angled cross head screwdriver 16).
6. Place the wheel cover 8 on the wheel 7. The wheel cover must engage firmly.
7. Assemble the second wheel 7 in the same way.

Attaching the chassis

(Fig. C)

1. Place the product upside down on the feed hopper 3.
2. Place the left and right chassis 12 in the positions provided on the right and left of the housing.
3. Secure the chassis 12 with the screws 21 (required tool: Hex key with angled cross head screwdriver 16).

● Fitting the collection bag

1. Insert the 2 holders 5 in the positions provided on the right and left of the housing (Fig. D).

2. Hook the 2 straps of the collection bag 6 onto the holder 5.

● Fitting the pushing element

1. Press the holder 2 onto the handle 17.
2. Press the pushing element 1 into the holder 2.
3. Slide the holder 2 (with the pushing element 1) to the side so that the on/off switch 14 is not covered.

Operation

⚠ WARNING! Risk of injury!

Switch off the product and disconnect the mains plug before carrying out any maintenance or cleaning work. Wait until all moving parts have come to a complete standstill.
Long branches can rebound when fed in. Keep a sufficient distance from the product.

NOTE

Only connect the product to a socket outlet with a residual current device (RCD) with a rated residual current of no more than 30 mA.
▶ Only use extension cords that are suitable for outdoors.

NOTE

The product has a safety switch. The housing lock 15 must be screwed tight and hand-tightened. Otherwise the product cannot be started.
After a power failure, the product will not start automatically when the mains voltage is restored (see "Restart lock").

- Switching on/off

WARNING!

Unplug the product from the mains socket when you leave it unattended or when you have finished working on it.

Switching on:

☐ Press the on/off switch 14 to position I.

Switching off:

☐ Press the on/off switch 14 to position O.

● Emptying the collection bag

NOTE

▶ Empty the collection bag 6 in good time. Note that the collection bag under the ejection chute 13 fills unevenly.

1. Switching off: Press the on/off switch 14 to position O.
2. Pull the mains plug 9 out of the socket.
3. Wait until all moving parts have come to a complete standstill.
4. Remove the collection bag 6.
5. Empty the collection bag 6.
6. Hook the 2 straps of the collection bag 6 onto the holder 5.

- Removing blockages

1. Switching off: Press the on/off switch 14 to position O.
2. Pull the mains plug 9 out of the socket.
3. Wait until all moving parts have come to a complete standstill.
4. Release the housing lock 15 by unscrewing the housing lock.
5. Tilt the upper housing 4 forwards (Fig. E). Alternatively: You can also remove the upper housing vertically upwards and put it to one side (Fig. E). You have access to the blades 25.
6. Remove the blockage in the product.
7. Refit the upper housing 4.
8. Close the housing lock 15 by fully tightening the housing lock.

Overload protection

NOTE

If the product is overloaded, e.g. by branches that are too thick, it switches off automatically.

1. Press the on/off switch 14 to position O.
2. Pull the mains plug 9 out of the socket.
3. Let the product cool down.
4. Connect the mains plug 9 to the socket.
5. Press the on/off switch 14 to position I. The product starts.

- Restart lock

NOTE

After a power failure, the product will not start automatically when the mains voltage is restored

1. Press the on/off switch 14 to position O.

2. Press the on/off switch 14 to position I. The product starts.

● Working instructions

NOTE

- Do not shred soft, damp material such as kitchen waste. Compost it instead.

☐ Preparation: Remove soil and stones from roots before shredding to prevent the blades 25 becoming blunt sooner than necessary.
☐ Fill the feed hopper 3 with the material to be shredded. When feeding branches into the product, hold them until they feed in automatically. The material is drawn in and shredded.
☐ If necessary, use the pushing element 1.
☐ Be guided by the possible feed speed of the product. Do not overload the product.
☐ To prevent clogging, alternate the shredding of branches with thin twigs and wilted garden waste that has been stored for several days.
☐ Pick up a few dry branches at the end and use them to help clean the product.
☐ Only switch off the product when all shredded material has passed through the blade area. Otherwise, the blade may become blocked when restarting.

● Cleaning and maintenance

⚠️ CAUTION! Risk of injury and risk of damage to the product!

Switch off the product and disconnect the mains plug before carrying out any maintenance or cleaning work. Wait until all moving parts have come to a complete standstill.
Some parts are very sharp and movable. Wear protective gloves for all maintenance and cleaning work.
You should have any repair and maintenance work that is not described in this user manual carried out by our Service Centre (see “Service”). Only use original parts.

Cleaning

⚠ WARNING! Risk of electric shock!

Do not spray the product with water

⚠ NOTICE! Risk of damage to the product!

Do not use any cleaning agents or solvents. You may irreparably damage the product. Chemical substances may attack the plastic parts of the product.

□ Clean the product with a damp cloth or a brush.

Maintenance

☐ Check the product for obvious defects such as loose, worn or damaged parts before each use.

- Turning the blades

⚠️ CAUTION! Risk of injury and risk of damage to the product!

For safety reasons, sharpening and blade replacement may only be carried out by specialised workshops or qualified personnel.

NOTE

Tools required:
-Hex key with angled cross head screwdriver 16
-Screwdriver*
-Torque wrench*

Releasing the blades

(Fig. F)

1. Pull the mains plug 9 out of the socket.
2. Release the housing lock 15 by unscrewing the housing lock.
3. Tilt the upper housing 4 forwards (Fig. E).
   Alternatively: You can also remove the upper housing vertically upwards and put it to one side (Fig. E). You have access to the blades 25.
4. Block the blade plate 27 e.g. with a screwdriver. Guide the screwdriver through the access hole 24 and carefully rotate the blade plate until you reach one of the 2 blocking openings.
5. Guide the screwdriver through the blade plate 27 to block it.
6. Loosen the 2 screws 26 (required tool: Hex key with angled cross head screwdriver 16 ).
7. Remove the blade 25 upwards.

Fitting the blades

(Fig. F)

NOTE

The blades ^25 have 2 cutting edges and can be turned around.
Always replace and turn the blades 25 in pairs.
Always use the new screws ^26 supplied when mounting new blades ^25 .

☐ Mounting the blade 25: Tighten the screws 26 to a tightening torque of 16 N m (required tool: Torque wrench).

● Changing the blade plate

(Fig. F)

NOTE

Tools required:
-Open-end spanner*
-Screwdriver*
- Pliers*

1. Pull the mains plug 9 out of the socket.
2. Release the housing lock 15 by unscrewing the housing lock.
3. Tilt the upper housing 4 forwards (Fig. E). Alternatively: You can also remove the upper housing vertically upwards and put it to one side (Fig. E). You have access to the blades 25.
4. Use a screwdriver to loosen the 6 screws 29 of the blade guard 22 .
5. Remove the blade guard 22.
6. Hold the blade plate 27 firmly, e.g. with pliers.
7. Loosen the screw 23 from the flange 28 anti-clockwise using an open-end spanner.
8. Remove the screw 23 and the flange 28.

9. Remove the blade plate 27.

10. Install the new blade plate 27 in reverse order.

Storage

⚠ WARNING! Risk of fire!

Do not store the product with a full collection bag.

• In hot weather, the clippings will start to ferment due to heat development.
  –Dry clippings are highly flammable.

□ Always store the product and its accessories

-clean,
-dry,
-protected against dust,
-out of the reach of children.

● Replacement parts/Accessories

□ Customers can obtain compatible replacement parts and accessories via www.optimex-shop.com.
□ Have the order number ready for your order.
☐ You can only place orders online.
□ Contact the Lidl service hotline (see „Service“) for further information.

Part Order number
1Pushing element	99947905401

● Troubleshooting

Problem Possible cause Solution
Motor not running. No mains supply. Check the socket, mains cord 9, mains plug and fuse.
Housing lock 15 not closed.	Tighten housing lock 15 by hand.
Garden waste is not drawn in.	Shredding material too soft. Push through using wood or shred dry branches.
	Blade plate 27 is blocked. Remove blockage (see “Removing blockages”).
	Shredding material in ejection chute 13. Pull out the mains plug 9, wait for the blades 25 to stop, remove the chopped material from the ejection chute 13.
Product does not shred satisfactorily.	Blades 25 are blunt. Check blades 25, turn (see “Turning the blades”), grind or replace if necessary.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 479054_2410) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

PDF ONLINE parkside-diy.com

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 479054_2410 takes you to the operating instructions for your item.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

● EU declaration of conformity

EU DECLARATION OF CONFORMITY (No 479054\_2410)

IAN: 479054_2410

Product identification:

"PARKSIDE" Electric knife shredder

Model Number: HG13084

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2000/14/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 60335-1:2012/A15:2021

EN 50434:2014

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A2:2024

EN 61000-3-3:2013/A2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018

Conformity Assessment procedure / name&adress notified body where appropriate: Annex V, 2000/14/EC

Measured sound power level on an equipment representative for this type: 98.9 dB(A)

Guaranteed sound power level for this equipment: 101 dB(A)

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 11.04.2025

Place

Date

ppa. Budrei ppa. T. Laier ppa. Jens Buchheim ppa. Dr. Thorsten Maier

Authorised Signatory Authorised Signatory

EN

CE

- Activer/désactiver

⚠ AVERTISSEMENT !

● Changer la plaque porte-lames

(Fig. F)

REMARQUE

⚠ WAARSCHUWING! Brandgevaar!

⚠️ ADVARSEL! Brandfare!
