USER MANUAL SSNR 12 B3 SILVERCREST
DE AT CH
SHIATSU-NACKENMASSAGEKISSEN/ SHIATSU-RÜCKENMASSAGEKISSEN
Operation and safety notes
NL BE
SHIATSUNEKMASSAGEKUSSEN/ SHIATSURUGMASSAGEKUSSEN
Electronics Co., Ltd., 91350211737865674J, Nr. 19, XingLin North 3rd Road, Bezirk Jimei, Xiamen, Fujian, China
Intended use......Page 15
Scope of delivery....Page 15
Description of parts....Page 15
Technical data......Page 15
Safety advice......Page 16
Before use......Page 17
Operation Page 18
Warming function....Page 18
Switch off the product....Page 18
Cleaning and care....Page 18
Storage Page 18
Disposal Page 19
Warranty Page 19
Warranty claim procedure......Page 19
Service Page 20
| List of pictograms used | |||
 | Observe caution and safety notes! Danger Risk of electric shock! | ||
 | Only use in dry indoor rooms. Fire hazard! | ||
 | Alternating current/voltage | Hz | Hertz (mains frequency) |
 | Direct current/voltage Do not use bleach. | ||
 | The cover is machine-washable.Set the washing machine to a delicate wash cycle at 30 °C. | Do not dry in a tumbler dryer. | |
 | WARNING: Do not use this product near water. | Do not iron. | |
 | Short-circuit proof safety transformer Do not dry clean. | ||
 | Polarity of the output terminal Safety class II | ||
 | SMPS (Switch mode power supply unit) (switching power supply) | Outward rotation | |
 | Inward rotation Light and heat function | ||
 | Protection against contact with the fingers | t_a | Highest rated ambient teperature |
 | CE mark indicates conformity with relevant EU directives applicable for this product. | Do not use the AC-DC adapter if the pins of the plug are damaged. | |
 | Safety informationInstructions for use | ||
Shiatsu Neck Massage Cushion/ Shiatsu Back Massage Cushion SSNR 12 B3
- Introduction
We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They
contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.
Intendeduse
The product is only designed for massaging the neck and back and legs of people with warming function and shiatsu style (shi = finger, astu = pressure in Japanese). The product is only for indoor household use. It is not intended for medical or commercial purposes and is not a substitute for medical treatment. Any other form of use is not permitted and may result in injury or damage of the product. The manufacturer accepts no liability for any damage caused by improper use.
- Scope of delivery
Immediately after unpacking, please check the package contents for completeness and whether the product and all parts are in good condition. Remove all packaging materials before use.
1 Shiatsu neck massage cushion/back massage cushion
1 AC-DC adapter
1 Cover
1 Instruction manual
• Description of parts
1 Massage cushion
2 Massage heads
3 Control handset
4 Socket
5 Power button
6 Outward rotation button
7 Inward rotation button
8 Light and heat function button
9 AC-DC adapter
10 Connection plug
11 Cover
12 Velcro strap
●Technicaldata
AC-DC adapter 9 for HG10452A
Manufacturer's name or
trade mark, commercial
registration number
and address: Xiamen Keli
Electronics Co., Ltd., 91350211737865674J, No. 19, XingLin North 3rd Road, Jimei District, Xiamen, Fujian, China
Model identifier: SW-0796
Input voltage: 100-240V \~
Input AC frequency: 50/60 Hz
Output voltage: 12.0V ---
Output current: 1.2A
Output power: 14.4W
Average active
efficiency: 84.0%
Efficiency at low
load (10%): 78.1%
No-load power
consumption: 0.10W
Protection class: II/回
Input current: 0.7A
Highest rated
ambient temperature: 40 °C
Protection degree: IP20
AC-DC adapter 9 for HG10452B
Manufacturer's name or
trade mark, commercial
registration number
and address: Xiamen Keli
Electronics Co., Ltd., 91350211737865674J,
No. 19, XingLin North
3rd Road, Jimei District, Xiamen, Fujian, China
Model identifier: KL-AD-120100
Input voltage: 100-240V \~
Input AC frequency: 50/60 Hz
Output voltage: 12.0V ===
Output current: 1.0A
Output power: 12.0W
Average active
efficiency: 83.0%
Efficiency at low
load (10%): 76.8%
No-load power
consumption: 0.10W
Protection class: II/
Input current: 0.7 A
Highest rated
ambient temperature: 40 °C
Protection degree: IP20
Shiatsu Neck Massager Cushion/Back Massager Cushion
Rated input: 12.0 V
Rated power: 14.4 W (HG10452A)
12.0W (HG10452B)
Polarity:
Duration of use: max. 15 min (automatic
shut-off)
Safety advice
Read all safety advices and instructions. Non-observance of the safety advices and instructions may cause electric shock, fire and/or bad injuries.
KEEP ALL SAFETY NOTICES AND INSTRUCTIONS FOR FUTURE REFERENCE!
WARNING!
DANGER TO LIFE
AND RISK OF ACCIDENT FOR INFANTS AND CHIL-
DREN! Never leave children unsupervised with the packaging materials. The packaging material poses a suffocation hazard.
Children frequently underestimate the dangers.
Please always keep the product out of the reach of children.
⚠️ CAUTION! This product is not a toy for children! Children are not aware of the dangers associated with handling electrical products.
This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Do not allow children to clean or perform user maintenance without supervision.
⚠️ CAUTION! The appliance has a hot surface. Persons insensitive to heat must be careful when using the appliance.
⚠ WARNING! Avoid the hazard of life by electric shock!
- Do not insert needles or pointed objects into the massage cushion 1.
■ Never immerse the product, or the AC-DC adapter 9 into water or any liquid.
■ Never touch the product, or the AC-DC adapter 9 with wet or damp hands or use it in very humid environments.
■ Only use the provided AC-DC adapter 9 as described in Technical Data section.
■ Make sure that the details on the rating label are in conformity with your mains voltage.
In the event of malfunctions, remove the AC-DC adapter 9 from the mains socket.
- Do not open the product or attempt to repair it yourself. Defective products should only be repaired by qualified personal.
■ Always remove the AC-DC adapter 9 from the mains socket after each use and before cleaning the product.
- Keep the power cord away from hot surfaces, sharp edges and mechanical forces.
■ Never let the power cord become a trip hazard, ensure no one can get tangled in it or step on it.
- Allow the product to cool down before moving it to a different location.
WARNING! HAZARD OF FIRE!
Do not operate the product close to or below curtains, wall
cupboards or other inflammable materials.
- Do not use the product on swollen, burnt, inflamed, diseased or injured regions of the skin and body areas. If in doubt, obtain medical advice before using the product.
■ Never use the product if you have injuries or pain in the neck/back or spine.
No action is needed from users to shift the product between 50 Hz and 60 Hz. The product adapts itself for both 50 Hz and 60 Hz.
- Before use
Note: Remove all packaging material from the product.
□ Always keep the cover 11 on the massage cushion 1 before use. Only the cover 11 is intended to be washed according to "Cleaning and care" section.
Place the massage cushion 1 on a chair and fasten it to the back of the chair with the velcro strap 12. Alternatively, place the massage cushion 1 on a sofa without using the velcro strap 12.
☐ connect the connection plug 10 to the socket 4 at the back of the massage cushion 1.
Plug the AC-DC adapter 9 into the mains socket.
Sit on the chair and ensure the massage cushion 1 is in the desired position.
- Operation
Switch on the massage cushion by pressing the power button 5 on the control handset 3. The blue light indicator switches on.
Press the outward rotation button to start the rotation of the massage heads 2. The blue light indicator switches on above the button.
To reverse the rotation direction, press the inward rotation button 7. The other blue light indicator switches on instead.
Note: Never use the massage cushion 1 for more than 15 minutes. A longer massage may lead to tension caused by overstimulation of the muscles.
● Warming function
To complement the massage with the warming function, press the light and heat function button 8 to turn on the heat function. The red light indicator switches on.
Note: The warming function can only be activated when the massage heads 2 are in operation.
- Switch off the product
To switch off the product, press the power button 5. All indicators go off and the massage heads 2 stop rotating. The product switches off automatically after 15 minutes.
To turn off completely, disconnect the AC-DC adapter 9 from the mains socket.
- Cleaning and care
DANG P/ONING! LIFE BY ELECTRIC SHOCK! Disconnect the AC-DC adapter 9
from the mains socket and unplug the connection plug 10 from the socket 4 before cleaning.
WARNING! Level more se the product, or AC-DC adapter 9 into water.
■ Ensure the massage cushion 1 is completely dry before connecting the AC-DC adapter 9.
Do not use abrasive, aggressive or chemical cleaning agents to clean the massage cushion 1. It could damage the product.
■ Never allow any liquid to enter the massage cushion 1.
☐ Use a damp lint-free cloth to clean the product. Use a little mild detergent on the cloth if necessary.
Clean the cover 11 in accordance with the cleaning symbols on the label. It is machine-washable. Set the washing machine to a delicate wash cycle at 30°C.
Note: Failure to observe the following warnings may damage the cover 11.
Do not bleach. Do not use any cleaning agents containing bleach (such as heavy duty detergents).
Do not tumble dry.
Do not run.
Do not dry clean.
Storage
Let the massage cushion completely cool down before storage.
Do not place other objects on top of the massage cushion 1.
☐ If the product is not used for a certain period of time, store the product in a clean and dry location.
●Disposal
The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibre-board/80–98: composite materials.
Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.
The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment. The Triman logo is valid in France only.
- Warranty
The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.
The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.
Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.
Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.
This warranty becomes void if the product has been damaged, or used or maintained improperly.
The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.
● Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
Please have the till receipt and the item number (IAN 435821_2304) available as proof of purchase. You will find the item number on the rating plate, an engraving on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
Service
GB Service Great Britain
Tel.: 0800 0569216
E-Mail: owim@lidl.co.uk
IE Service Ireland
Tel.:1800200736
E-Mail: owim@lidl.ie
