USER MANUAL PBH 1550 C1 PARKSIDE

PDF ONLINE www.lidl-service.com

Black Parkside electric drill press tool with visible screwdriver and handle (no text or symbols on device body)

BOHR- UND MEISSELHAMMER/ HAMMER DRILL/MARTEAU PERFORATEUR BURINEUR PBH 1550 C1

DE AT CH

BOHR- UND MEISSELHAMMER

User manual Translation of the original instructions

FR BE

MARTEAU PERFORATEUR BURINEUR

VRTACÍ A SEKACÍ KLADIVO

GB/IE User manual Page 24

List of pictograms used ...... Page 25

Introduction Page 26

Intended use....Page 26

Scope of delivery....Page 26

Description of parts Page 26

Technical data Page 27

Safety instructions.... Page 28

General power tool safety warnings Page 28

Hammer safety warnings....Page 30

Additional safety information....Page 31

Behaviour in emergency situations....Page 31

Residual risks ...... Page 31

Before first use Page 32

Unpacking the product. Page 32

Accessories Page 32

Preparation Page 32

Control elements Page 32

Selecting a tool Page 33

Attaching/removing an SDS-Plus tool Page 33

Adjusting the auxiliary handle Page 34

Setting the depth stop Page 35

Operation Page 35

Selecting the operating mode ...... Page 35

Adjusting the chisel position....Page 35

Adjusting the speed Page 35

Switching on/off Page 35

Transport Page 36

Cleaning, maintenance and storage Page 36

Cleaning. Page 36

Maintenance Page 36

Storage Page 37

Replacement parts/Accessories.... Page 37

Troubleshooting Page 37

Disposal Page 38

Warranty Page 38

Warranty claim procedure....Page 38

Service Page 39

EU declaration of conformity....Page 40

List of pictograms used
	Read the instruction manual.	∅	Diameter
		n_0	No-load speed
[3477]	DANGER! - Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)	[6X149]	Drilling
		[1YW42]	Hammer drilling
[7280]	WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)	[1W124]	Chiselling
		[2670]	Adjusting chisel position
[1CA4]	CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)	[CCC27]	Wear ear protection!
			Wear eye protection!
[6840]	NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)	[10W172]	Wear dust protection!
	Alternating current/voltage	[7E24]	Symbol for a Protection Class II product
	Do not use the hammer drill function when the keyed chuck 13 is attached.	[14628]	Not suitable for children under 3 years
[8430]	Greasing the tool Not suitable for gearb	[6X77]
[0775]	Use the product in dry indoor spaces only.	[13K2]	Safety information Instructions for use
		[0807]
	CE mark indicates conformity with relevant EU directives applicable for this product.		Fold-out page with product illustrations

HAMMER DRILL

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is designed for:

• Drilling in rock, wood and metal
• Chiselling in concrete, stone and plaster
• Impact drilling in masonry

Always use the correct type of bit and accessories according to the intended use. Observe the technical requirements of this product (see "Technical data") when purchasing and using accessory tools!
■ Use the product in dry indoor spaces only.
■ Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage.
The manufacturer is not liable for any damages caused by improper use.
The operator or user of the product is responsible for any accidents or personal injury and/or material damage to third parties or their property.
The product is exclusively intended for domestic use.
The product is not intended for commercial use or for similar uses.

- Observe all applicable local safety regulations, standards and ordinances. The use of noise emitting power tools may be restricted to certain times by national or local regulations.

- Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 Hammer drill
1 Keyed chuck (SDS-Plus, ∅ 13 mm)
1 Drill chuck key
1 Auxiliary handle
1 Depth stop
1 Pointed chisel (SDS-Plus, length: 250 mm)
1 Flat chisel (SDS-Plus, length: 250 mm)
3 Drills (SDS-Plus, ∅ 12/16/18 mm)
1 Key for housing cover
1 Lubrication grease
1 Storage case
1 User manual

• Description of parts

Before reading, unfold the pages containing the illustrations and familiarise yourself with all functions of the product.

(Fig. A)

1 SDS-Plus chuck
2 Dust cap
3 Locking sleeve
4 Holder for auxiliary handle

5 Function selection switch
6 Retaining knob (function selection switch)
7 Housing cover
8 On/off switch
9 Handle
10LED display
11 Speed control
12 Mains cord with mains plug
13Keyed chuck
14 Drill chuck opening
15 Drill chuck key
16 Auxiliary handle
17 Lubrication grease
18 Depth stop
19 SDS-Plus drill
20 SDS-Plus chisel
21Key (housing cover)
22 Storage case
(Fig. B)
23Loop
24Locking lever (depth stop)
25Grip

• Technical data

Hammer drill	PBH 1550 C1
Model numbers
- VDE plug: HG11292
- BS plug: HG11292-BS
Rated voltage U: 230–240 V ~,50 Hz
Rated output P: 1,550 W
No-load rotation speed n0: 0–800 min -1
Impact rate: 0–3,900 min	-1

Impact energy: 5 joule
Mains cord length: 3 m
Protection class: II/	☐ (double insulation)
Weight (incl. auxiliary handle): 4.9 kg
Chuck capacity:	1.5-13 mm
Drill diameter (∅)
- Wood:	40 mm
- Concrete/brick:	32 mm
- Metal:	13 mm

Noise emission value

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the product is typically as follows:

Sound pressure level L_pA :	96.2 dB
Uncertainty K_pA : 3.0 dB
Sound power level L_WA :	104.2 dB
Uncertainty K_WA :	3.0 dB

Total vibration value

Total vibration values (triaxial vector sum) determined in accordance with EN 62841:

Vibration - Main handle
a_h,HD :	17.353 m/s ^2
a_h,CHeq :	15.692 m/s ^2
a_h,CH :	17.375 m/s ^2
a_h,NL :	7.274 m/s ^2
Uncertainty K:	1.5 m/s ^2
Vibration - Auxiliary handle
a_h,HD :	11.585 m/s ^2
a_h,CHeq :	11.767 m/s ^2
a_h,CH :	12.446 m/s ^2
a_h,NL :	5.832 m/s ^2
Uncertainty K:	1.5 m/s ^2

WARNING!

Wear hearing protection!

NOTE

The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

WARNING!

The vibration and noise emissions during actual use of the product can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed. Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the product is switched off and when it is running idle in addition to the trigger time).

Safety instructions

● General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.

A moment of inattention while operating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

e) Maintain power tools diligently. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use.

Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts.

This will ensure that the safety of the power tool is maintained.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

● Hammer safety warnings

WARNING!

Wear hearing protection! Exposure to loud noise can lead to hearing loss.

Wear a dust mask.

WARNING!

Drilling and chiselling operations may deal with materials which can produce harmful or toxic dust. It presents a health hazard for the person operating the power tool and anyone else in the vicinity.
Ensure that you are not likely to hit power, gas or water supply lines when you are working with the power tool. If necessary, check with a service line detector before you start to cut or drill into a surface.

Safety instructions for all operations

■ Wear ear protectors. Exposure to noise can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
- Hold the power tool by insulated gripping surfaces, when performing an operation where the cutting accessory or fasteners may contact hidden wiring. Cutting accessory or fasteners contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.

Safety instructions when using long drill bits with rotary hammers

Always start drilling at low speed and with the bit tip in contact with the workpiece. At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal injury.
■ Apply pressure only in direct line with the bit and do not apply excessive pressure. Bits can bend, causing breakage or loss of control, resulting in personal injury.
● Additional safety information
Use suitable detectors to determine if there are hidden supply lines or contact the local utility company for assistance. Contact with electric cables can cause fire and electric shock. Damaging gas lines can lead to explosion. Breaking water pipes causes property damage.
■ Always wait until the power tool has come to a complete stop before placing it down. The application tool can jam and cause you to lose control of the power tool.
- Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure than by hand.
Do not touch any application tools or adjacent housing components shortly after operation. These can become very hot during operation and cause burns.
The application tool may jam during drilling. Make sure you have a stable footing and hold the power tool firmly with both hands. Otherwise you could lose control of the power tool.

- Hold the power tool firmly with both hands and make sure you have a stable footing. The power tool can be more securely guided with both hands.

Original accessories/auxiliary equipment

WARNING!

Do not use accessories not recommended by /// PARKSIDE: This may result in electric shock or fire.
- Only use the accessories and additional equipment that are specified in the operating instructions and compatible with the product.
● Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

■ Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
■ Switch the product off if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

■ Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.

Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
■ Danger of injury and property damage caused by flying objects.

Before first use

● Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

Accessories

WARNING!

Do not use accessories not recommended by /// PARKSIDE'. This may result in electric shock or fire.

To operate this product safely and correctly, the following accessories, i.e. tools and accessory tools, are necessary:

□ SDS-Plus insertion tool
□ Suitable personal protective equipment

Accessories and accessory tools are available through your authorised dealer. When buying always consider the technical requirements of this product (see "Technical data"). If you are not certain, ask a qualified specialist and get advice from your trusted dealer.

● Preparation

⚠ WARNING! Risk of injury due to unintentional start-up!

Do not insert the mains plug12 into the socket-outlet until the product is fully prepared for use.

Control elements

NOTE

Familiarise yourself with the control elements before using the product for the first time.

Speed control 11

☐ Using the speed control 11 you can choose between 6 speed levels.

Level Speed
1	Lowest speed
6	Highest speed

Function selection switch 5

⚠️ NOTICE! Risk of product damage!

Only operate the function selection switch 5 when the product has stopped.

1. Unlock the function selection switch 5 by pressing the retaining knob 6.
2. Rotate the function selection switch 5 into the desired position. The retaining knob 6 audibly locks into place.

Symbol	Function
	Drilling (hammer mechanism OFF)
	Hammer drilling (hammer mechanism ON)
	Chisel position adjustment
	Chiselling

On/off switch 8

☐ Switching on: Press and hold the on/off switch 8.
□ Switching off: Release the on/off switch 8.

LED display 10

Symbol	Meaning
(green)	The product is ready for operation.
(red)	The carbon brushes are worn out (see “Troubleshooting”).

- Selecting a tool

⚠️ NOTICE! Risk of product damage!

Only use the hammer drilling function when the keyed chuck 13 is not fitted.
When a chisel20 is inserted, you may only operate the product using the chiselling function.

☐ For hammer drilling, use an SDS-Plus drill 19.
☐ For chiselling, use an SDS-Plus chisel 20.
☐ For drilling without impact in wood, metal and plastic, use the keyed chuck 13. You can insert cylindrical SDS-Plus drills with a diameter of 1.5 mm to 13 mm into the keyed chuck.

- Attaching/removing an SDS-Plus tool

⚠️ NOTICE! Risk of product damage!

Use the keyed chuck13 for normal drilling only, not for hammer drilling.

NOTE

The directional information (clockwise/counter-clockwise) in this section should be interpreted as meaning that the user is positioned behind the product.

☐ The SDS-Plus tool and the keyed chuck 13 have some radial play due to the system. This has no effect on the accuracy of the drill hole.
Before working, clean the SDS-Plus tool and grease the insertion end slightly with the lubrication grease 17 (approx. 0.5 g to 1 g).
☐ Ensure the dust cap 2 is not damaged when inserting a tool. The dust cap largely prevents drilling dust from entering the SDS-Plus chuck 1 during operation.

Have a damaged dust cap 2 replaced immediately. We recommend to have this done by our Service Centre (see "Service").

Attaching the SDS-Plus tool

(Fig. C)

1. Unlocking the SDS-Plus chuck 1: Pull the locking sleeve 3 backwards.
2. Insert the SDS-Plus tool rotatingly into the SDS-Plus chuck 1.
3. Clamping the SDS-Plus tool: Release the locking sleeve 3.
4. Check that the SDS-Plus tool is firmly secured by pulling on it.

Removing the SDS-Plus tool

(Fig. C)

CAUTION! Risk of burns!

Attachment tools, especially drills, can become very hot. Wear protective gloves whenever appropriate.

1. Unlocking the SDS-Plus chuck 1: Pull the locking sleeve 3 backwards.
2. Remove the SDS-Plus tool.

Fitting the keyed chuck 13

(Fig. D)

1. Unlocking the SDS-Plus chuck 1: Pull the locking sleeve 3 backwards.
2. Insert the keyed chuck 13 rotatingly into the SDS-Plus chuck 1.
3. Clamping the keyed chuck 13: Release the locking sleeve 3.
4. Check that the keyed chuck 13 is firmly secured by pulling on it.

Inserting a round shank attachment tool

1. Insert the drill chuck key 15 into one of the holes on the keyed chuck 13.
2. Opening the keyed chuck 13: Turn the drill chuck key 15 counter-clockwise.
3. Push the attachment tool as far as possible into the drill chuck opening 14.
4. Clamping the attachment tool: Turn the drill chuck key 15 clockwise.

Removing a round shank attachment tool

CAUTION! Risk of burns!

Attachment tools, especially drills, can become very hot. Wear protective gloves whenever appropriate.

1. Insert the drill chuck key 15 into one of the holes on the keyed chuck 13.
2. Opening the keyed chuck 13: Turn the drill chuck key 15 counter-clockwise.
3. Remove the attachment tool.

Removing the keyed chuck 13

(Fig. D)

1. Unlocking the SDS-Plus chuck 1: Pull the locking sleeve 3 backwards.
2. Remove the keyed chuck 13.

- Adjusting the auxiliary handle

NOTE

You can rotate the auxiliary handle 16 by 360^ around the product and move it to any desired position.
The directional information (clockwise/counter-clockwise) in this section should be interpreted as meaning that the user is positioned behind the product.

Attaching the auxiliary handle 16

(Fig. B)

1. Turn the grip 25 of the auxiliary handle 16 counter-clockwise. This extends the loop 23 .
2. Slide the loop 23 of the auxiliary handle 16 behind the locking sleeve 3.
3. Position the loop 23 in the holder for the auxiliary handle 4.
4. Turn the grip 25 of the auxiliary handle 16 clockwise to tighten the loop 23.

Removing the auxiliary handle 16

(Fig. B)

1. Turn the grip 25 of the auxiliary handle 16 counter-clockwise. This extends the loop 23 .

2. Remove the auxiliary handle 16 from the product by pulling the loop 23 over the locking sleeve 3.

- Setting the depth stop

(Fig. B)

1. Press and hold the locking lever 24 for the depth stop 18.
2. Push the depth stop 18 into the small opening on the auxiliary handle 16. The teeth on the depth stop must point downwards.
3. Position the depth stop 18 so that the distance between the tip of the drill and the tip of the depth stop corresponds to the desired drilling depth.
4. Fix the depth stop 18 by releasing the locking lever 24.

Operation

Operate the product only with a mounted auxiliary handle 16. Hold the product with both hands by the handle 9 and the auxiliary handle while working.
Use clamps or another practical way to secure and support the workpiece to a stable platform.

Holding the workpiece by your hand or against the body leaves it unstable and may lead to loss of control.

- Selecting the operating mode

■ Only operate the function selection switch 5 when the product has stopped.

Symbol	Function
	Drilling (hammer mechanism OFF)
	Hammer drilling (hammer mechanism ON)

Symbol	Function
	Chisel position adjustment
	Chiselling

- Adjusting the chisel position

1. Set the function selection switch 5 to (chisel position adjustment).
2. Turn the SDS-Plus chisel 20 in the SDS-Plus chuck 1 to the required position.
3. Set the function selection switch 5 to T (chiselling).

- Adjusting the speed

☐ You can adjust the speed while the product is in operation. Set the speed control 11 to the desired level.

Rotational speed	Drill diameter	Materials
Low Large		Hard materials (e.g. metal)
High Small		Soft materials (e.g. wood)

- Switching on/off

⚠ WARNING! Risk of injury due to unintentional continuous operation of the product!

Before connecting the mains plug 12 to a socket-outlet, check that the on/off switch 8 works properly and returns to the OFF position when released.

Switching on

1. Connect the mains plug 12 to a socket-outlet.
2. Press and hold the on/off switch 8.

Switching off

1. Release the on/off switch 8.
2. Wait until the product has stopped before placing it down.
3. Remove the mains plug 12 from the socket-outlet if you are leaving the product unattended or if you have finished working.

- Transport

☐ Switch off the product and remove the mains plug 12 from the socket-outlet. Make sure that all moving parts have come to a complete stop.
□ Remove the attachment tool.
□ Always carry the product by the handle 9.

● Cleaning, maintenance and storage

WARNING! Risk of electric shock! Risk of injury due to unintentional start-up!

Protect yourself when performing maintenance or cleaning work. Switch off the product and remove the mains plug 12 from the socket-outlet.
Have any repair and maintenance work that is not described in these instructions carried out by our Service Centre.
▶ Only use original replacement parts.

Cleaning

⚠ WARNING! Risk of electric shock!

▶ Never spray the product with water.

⚠️ NOTICE! Risk of product damage!

Chemical substances may attack the plastic parts of the product. Do not use any cleaning agents or solvents.

□ Keep the ventilation slots, motor housing and handles of the product clean. Use a damp cloth or brush to do this.

□ Clean the SDS-Plus chuck 1. To do this, pull the locking sleeve 3 backwards and remove the dust cap 2 towards the front.

Maintenance

☐ Check the product before each use for obvious defects such as loose, worn or damaged parts.
☐ Regularly grease the insertion end of the SDS-Plus tool slightly with the lubrication grease 17 (approx. 0.5 g to 1 g).
□ Grease the SDS-Plus tool again when there is hardly any grease left on the shaft.
□ Greasing the SDS-Plus tool ensures smooth operation and a longer service life.

Replenishing the grease in the gearbox

(Fig. E)

⚠️ NOTICE! Risk of product damage!

The lubrication grease ^17 included in the delivery is not suitable for gearboxes.

NOTE

▶ Replenish the grease after approx. 50 working hours or when the impact power decreases.

1. Opening the housing cover 7: Turn the housing cover counter-clockwise with the key 21.

2. Fill in the grease. A gear grease for central lubrication is suitable.

3. Closing the housing cover 7: Turn the housing cover clockwise with the key 21.

Mains cord 12

Before each use: Check the mains cord 12 for damage.
If the mains cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Storage

□ Always store the product and its accessories

• clean,
• dry,
• protected against dust,
• in the storage case 22,
• out of the reach of children.

● Replacement parts/Accessories

□ Customers can obtain compatible replacement parts and accessories via www.optimex-shop.com.
□ Have the order number ready for your order.
☐ You can only place orders online.
□ Contact the Lidl service hotline (see „Service“) for further information.

Part Order number
Keyed chuck 13	99944980101
Drill chuck key 15	99944980104
Auxiliary handle 16	99944980103
Lubrication grease 17	99944980102

● Troubleshooting

Problem Possible cause Solution
The product does not start. No	mains power supply Check the socket-outlet, mains cord with mains plug 12, and the fuse and have them repaired by a qualified electrician, if necessary.
	The on/off switch 8 is defective.	Contact our Service Centre (see “Service”).
	The carbon brushes are worn out.
	The motor is defective.
The drilling performance is poor.	The drill is blunt. Replace the drill or grind its tip, if possible.
The product works with interruptions.	Internal loose contact	Contact our Service Centre (see “Service”).
	The on/off switch 8 is defective.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

The product and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

To ensure quick processing of your claim, observe the following instructions:

Make sure to have the original sales receipt and the item number (IAN 449801_2310) available as proof of purchase.

You can find the item number on the rating plate, an engraving on the product, on the front page of the instruction manual (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, contact the service department listed below either by telephone or by e-mail.

Once the product has been recorded as defective you can return it free of charge to the service address that will be provided to you. Ensure to enclose the proof of purchase (sales receipt) and a short, written description outlining the details of the defect and when it occurred.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

CE

● EU declaration of conformity

EU DECLARATION OF CONFORMITY (No 449801\_2310)

IAN: 449801_2310

Product identification:

"PARKSIDE" Hammer Drill

Model Number: HG11292

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 62841-1:2015/A11:2022

EN IEC 62841-2-6:2020/A11:2020

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021

EN 61000-3-3:2013/A2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 20.11.2023

Place

Date

ppa. Stefan Haensel

Authorised Signatory

Authorised Signatory

EN

VRTACÍ A SEKACÍ KLADIVO

• Úvod
