USER MANUAL DO1132IB DOMO

△PRODUCTSPECIFIEKE WAARSCHUWINGEN

PROBLEM EN OPLOSSING

Chere cliente, cher client,

All of our products are always submitted to a strict quality control before they are sold to you.

Should you nevertheless experience problems with your device, we sincerely regret this.

In that case, we kindly request you to contact our customer service.

Our staff will gladly assist you.

[phone]

[e-mail]

Monday-Thursday:8.30-12.oo and 13.00-17.00

Friday: 8.30-12.00 and 13.00-16.30

This appliance has a two year warranty period. During this period the manufacturer is responsible for any failures that are the direct result of construction failure. When these failures occur the appliance will be repaired or replaced if necessary. The warranty will not be valid when the damage to the appliance is caused by wrong use, not following the instructions or repairs executed by a third party. The guarantee is issued with the original till receipt. All parts, which are subject to wear, are excluded from the warranty. If your device breaks down within the 2-year warranty period, you can return the device together with your receipt to the shop where you purchased it.

The guarantee on accessories and components that are liable to wear-and-tear is only 6 months.

The guarantee and responsibility of the supplier and manufacturer lapse automatically in the following cases:

If the instructions in this manual have not been followed.
- In case of incorrect connection, e.g. electrical voltage that is too high.
In case of incorrect, rough or abnormal use.
In case of insufficient or incorrect maintenance.
In case of repairs or alterations to the device by the consumer or non-authorised third parties.
- If the customer used parts or accessories that are not recommended or provided by the supplier / manufacturer.

SAFETYINSTRUCTIONS

When using electrical appliances, basic safety precautions should always be taken, including the following:

• Read all instructions carefully. Keep this manual for future reference.
• Make sure all packaging materials and promotional stickers have been removed before using the appliance for the first time. Make sure children cannot play with the packaging materials.

• This appliance is intended to be used in household and similar applications such as:

• staff kitchen areas in shops, offices and other working environments;

-farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.

• Children should be supervised to ensure that they do not play with the appliance.
• This appliance can be used by children aged from 16 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children unless they are older than 16 or supervised.
• Keep the appliance and its cord out of reach of children younger than 16 years.
• All repairs should be carried out by the manufacturer or its aftersales service.
• Any injury or damage caused by failure to comply with these rules are at your own risk. Neither the manufacturer, importer, or the supplier may be held liable.

ELECTRICALWARNINGS

• In order to avoid a hazard this appliance must not be supplied through an external switching device, such as a timer or a separate remote control, or connected to a circuit that is regularly switched on and off by the utility.
• The appliance must be disconnected from its power source when not in use, during service and when replacing parts. Allow to cool before putting on or taking off parts, and before cleaning the appliance. To disconnect, turn controls to "OFF" or "o" position, then remove the plug from the wall. Never pull the cord or appliance to remove the plug from the socket.
• Before use, check carefully that the electric tension and frequency of the power net at your home match the indications on the rating label of the appliance.
• The appliance must be plugged into an appropriate outlet that is installed and grounded in accordance with local installation regulations.

• Do not let the power supply cord hang over the edge of a counter, or touch hot surfaces.

• Keep the power cord away from hot parts and don't cover the appliance.

• Unwrap the cord completely to prevent overheating of the cord. Do not allow the power cord supply to run underneath or around the unit.
• Do not operate this appliance with a damaged cord or plug or in the event the appliance malfunctions or has been damaged in any manner. Return the appliance to the DOMO Service Department or its service agent for examination, repair, or electrical or mechanical adjustment. Do not try to repair the appliance yourself.

INSTALLATION

• Do not place near flammable materials, gases or explosives.
• Do not use or store this appliance outdoors.
• Always use the appliance on a steady, dry and level surface.
• Never place this appliance near a gas stove or electrical stove or in a place where it may come into contact with a warm appliance.

USE

• Do not use this appliance for other than intended use.
• Only use the appliance for domestic use. The manufacturer cannot be held responsible for accidents that result from improper use of the appliance or not following the instructions described in this manual.
• Never leave the appliance unattended while it is functioning.
• Do not operate the appliance with wet hands.
• The use of accessories that are not recommended or sold by the manufacturer can cause fire, electrical shock or injuries. Only use the utensils delivered with the appliance.

CLEANING AND MAINTENANCE

• To protect against electrical shock or burns, do not immerse unit, cord, or plug in water or other liquid.
• Failure to maintain this appliance in a clean condition could adversely affect the life of the appliance and possibly result in a hazardous situation.

△PRODUCT-SPECIFICWARNINGS

• To avoid frost injuries, do not touch the evaporator and/or the cooling fins while the appliance is in operation.
• Do not use water of unknown quality or water that contains unsafe microbes.
• Do not clean the ice maker with flammable liquids. The vapours can cause fire or explosion.
• Do not tilt the appliance more than 45^ . If the appliance is laid flat, return the appliance to a completely upright position and wait 2 hours before turning it back on.
• If the ice maker is brought in from a cold environment during the winter, do not use for a few hours. Allow it to warm to room temperature before use.
• Do not use the appliance in temperatures below 10^ C and above 32^ C .
• Never put flammable, explosive and/or corrosive items in the ice maker.
• Never use the ice maker if flammable gas is leaking.
• Unplug the ice maker from the power socket before moving it to avoid causing damage to the cooling system.
• The ice maker makes use of flammable gas and refrigerant and must therefore be disposed of according to local regulations.
• Do not damage the cooling circuit.
• Keep the ventilation openings clear and make sure they are not blocked or obstructed.
• Do not use mechanical appliances or other aids to speed up the defrosting process.
• Do not place portable power strips or portable power supplies at the back of the appliance.
• Do not place other electrical appliances inside this one, unless recommended by the manufacturer.
• Other appliances must not be connected to the same power socket. Make sure the plug is fully inserted into the power socket.
• Arrange the power cable to prevent children from pulling on it or people tripping over it.
• Do not attempt to disassemble, repair, modify, or replace any part of the item.

• When putting the appliance in its position, make sure the power cable does not become pinched or damaged.

• Place the appliance at least 15cm away from other objects to ensure a proper ventilation around the appliance.

• Do not switch the appliance on and off too frequently. Always wait for at least 5 minutes to prevent damage to the compressor.

Caution: risk of fire / flammable materials
This appliance uses a flammable refrigerant. If the refrigerant is leaked and exposed to an external ignition source, there is a risk of fire.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

1. Water tray
2. Freeze fingers
3. Ice shovel
4. Full basket sensor
5. Transparent lid 1
6. Ice basket
7. Water tank
8. Drain hole with plug
9. Compressor
10. Control panel
    11.Scoop 5

CONTROL PANEL 6 7

1. Indicator light 'ice basket full'
2. Indicator light 'water reservoir empty'
3. Indicator light for 'large ice cubes' 10
4. Indicator light for 'small ice cubes' 9
5. On/off button

12
13
14
15
16

8 11

BEFORE THE FIRST USE

• Make sure all packaging materials and promotional stickers have been removed before using the appliance for the first time.
  Before using the ice cube maker for the first time: wait 2 hours after putting the appliance in place and leave the lid open for at least 2 hours. This way the refrigerant can settle.
  Clean the appliance before using it for the first time. See: "cleaning and maintenance".

USE

1. Place the ice cube maker on a flat and stable surface and make sure that the ventilation openings are not blocked. Make sure the drainage hole on the bottom of the unit is closed.
2. Open the lid and take out the ice basket so you can pour water into the water tank. It is recommended to use spring water or mineral water. Do not use hot water, the recommended water temperature is between 8 and 25^ .

Caution: Make sure that the water level is lower than the maximum indication. If the water tank is filled above the MAX indication, drain the excess water through the drain hole at the bottom of the ice cube maker. Open the drainage hole on the underside of the appliance above a collecting container or a sink.

1. Place the basket back into the appliance and close the transparent lid.
2. Plug the power cord into a socket. The 'small ice cubes' indicator light will start flashing.
3. Wait a few seconds until the water tray is in the start position behind the cold fingers. Press the on/off button firmly to turn the appliance on.
4. The 'small ice cubes' and 'large ice cubes' indicator lights will flash alternately. You are now in the selection mode to choose the size of the ice cubes. When the light of the desired ice cube size flashes on, press the on/off button to confirm your selection.
5. The indicator lamp will illuminate steadily and the ice-making cycle will start.
6. A cycle lasts 6-8 minutes on average, depending on the ambient temperature. When a cycle is complete, the ice cubes will be in the ice basket. The next cycle will start automatically. To stop the appliance, press the power button. Pull the plug out of the power socket.

Clean the appliance after each use. Empty the water reservoir before storing the appliance. Open the drainage hole on the underside of the appliance above a collecting container or a sink.

During the first 3 cycles, the ice cubes may be smaller and more irregular in size. When the ice basket is full, immediately remove the ice from the ice basket.

If the 'water reservoir empty' indicator lamp lights up, there is not enough water left in the water reservoir. Fill the water reservoir with water and press the on/off button to restart the machine.

If the 'ice basket full' indicator light flashes, the machine will stop working. Empty the ice basket. If there is no more ice near the sensor, the appliance will restart automatically.

CLEANING AND MAINTENANCE

To protect against electrical shock or burns, do not immerse unit, cord, or plug in water or other liquid.

• Switch off the appliance and unplug before cleaning. Also remove all ice cubes.

• Drain all water from the water tank through the drain hole at the bottom of the ice cube maker. Open the drainage hole on the underside of the appliance above a collecting container or a sink. To do this, you can slide the appliance forward, so the front protrudes 55 - 60mm over the front of the worktop.

• Regularly clean the ice basket, the water tank, the water tray, the freeze fingers and the ice shovel. Use a soft cloth with warm water and maybe cleaning vinegar to clean the inside of the appliance. Rinse thoroughly before using the appliance again.

There is a water supply filter at the bottom of the water tank. Pull the tab to remove it for cleaning.
- Clean the outside with a damp cloth and mild detergent if necessary.
- Do not use any chemical products or products containing acids, gasoline or oil. Do not use boiling water.
- Replace the water in the water tank at least once a day to guarantee clean ice cubes. When not using the appliance, always drain the water from the water tank. Always use clean water when using the ice cube maker.

RINSETHE LINES

It is recommended that the appliance lines be rinsed once a week or if the appliance has been idle for a long time.

1. Make sure the drainage hole on the bottom of the appliance is closed; then fill the water tank with clean water.
2. Plug the power cord into a socket. Wait a few seconds until the water tray is in the start position behind the cold fingers. Press the on/off button firmly to turn the appliance on.
3. Keep pressing the on/off button for several second until all indicator lights turn on.
4. The cleaning cycle starts. The lines will be rinsed for a period of 6 minutes.
5. When the cleaning cycle is finished, the appliance will stop automatically. The 'small ice cubes' and 'large ice cubes' indicator lights will flash alternately.

DESCALING

Descale the appliance regularly to avoid calcification and to maintain a well operating appliance. Use a descaling product for example coffee makers, or use a solution of 1/2 vinegar and 1/2 water.

1. Fill the water tank with the product/solution (do not exceed the maximum level) and switch on the appliance. The appliance will now pump water into the water tray.
2. Wait until the water container is filled with water. Look carefully through the transparent lid; if you can no longer see water running through the water bowl, press the on/off button. The appliance switches off and will release the product/solution from the ice tray. Do not make ice cubes with the appliance if there is still descending solution in the pipes. Exposure of the cooling fins to a descending product for a prolonged period could cause damage to the fins.
3. Repeat this cycle a few times with the descending product/solution.
4. Afterwards, fill the water tank with clean water and repeat the procedure until the smell of the descending product/solution has disappeared completely.
5. Rinse the pipes with clean water, see "rinse the lines".

POSSIBLE PROBLEMS AND THEIR SOLUTIONS

PROBLEM POSSIBLE SOLUTION
“Ice basket full” indicator lamp is on. · The ice basket is full. Empty it. · The sensors are dirty. Clean both sensors. · The sensors are broken. Contact the after-sales department.
All indicator lights flash simultaneously. · The ice scoop is blocked. Clear the blockage. · The motor is broken. Contact the after-sales department.
The appliance stops working. · The ice scoop is not in the correct position. Remove the ice from the scoop and press the power button. If the appliance does not work after restarting, please contact the after-sales department.
Indicator lamp “water reservoir empty” lights up.	· Is the water reservoir empty? Fill the water reservoir with water. · There’s air in the pump. Restart the appliance with the on/off button. · The water supply is blocked. Clean the filter on the bottom of the water tank.
There are no indicator lights on. · There is no power applied to the appliance. Check the plug is placed in the socket. · Check that no fuse has tripped in your fuse box.
The ice is too big and there are bits of broken ice sticking to it.	· It is possible that ice from a previous cycle has ended up in the water tray. Turn off the appliance and remove the ice from the water tray. · The water in the reservoir is too cold. The recommended temperature is between 8 and 25°C.
The appliance goes through the cycle, but no ice comes out.	· The ambient temperature or the water temperature is too high. Do not use the appliance at a temperature higher than 32°C and fill the tank with cold water. · The compressor or the ventilation motor is broken. Contact the after-sales service. · There is insufficient coolant in the appliance. Contact the after-sales service.
The appliance works, but the water gets warm.	· Contact the after-sales service.
The ice basket is full, but the indicator light is not lit.	· The operation of the sensors is blocked by sunlight. Move the appliance. · The sensors are broken. Contact the after-sales department.
The appliance and the air around the apppliance become warm.	· This is normal. The temperature of the compressor can be up to 90°C.

The compressor makes a lot of noise. Check that the voltage indicated on the appliance

corresponds to the voltage of the electricity grid in your home.

This symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it must be brought to the applicable collection point for recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

The packaging is recyclable. Please treat the packaging ecologically.
