USER MANUAL BF 31-4T ATIKA

Three different types of hair tools including a manual tool, a mechanical tool, and a mesh tool (no text or symbols visible)

Original instructions – Safety instructions – Spare parts

Anlassposition: Choke close

You may not start to operate the machine until you have read these operating instructions, observed all the instructions given and installed the machine as

described!

Keep the instructions in a safe place for future use.

Contents

Extent of delivery 23

Symbols on the machine 24

Symbols for brushcutter / grasstrimmer 24

Symbols for hedge trimmer 24

Symbols for power pruner 24

Symbols original instructions 25

Operating times 25

Proper use 25

Residual risks 25

– Behaviour in an emergency situation 26

Vibrations (hand arm vibrations) 26

Safety advices 26

– Personal protective equipment 26

- Safety instructions – before working 26

- Safety instructions – operating 27

- Safety instructions – while working 27

- General safety instructions 27

- Safety instructions for the brushcutter / grasstrimmer 27

- Safety instructions for the hedge trimmer 28

– Safety instructions for the power pruner 28

- Safe handling with fuels 29

Description of device / spare parts 29

Assembly 29

- Assembling/disassembling 29

- Mounting the handle 30

- Mounting the carrying strap 30

Assembling the brushcutter / grasstrimmer 30

- Mounting the protective hood 30

- Cutting blade assembly 30

- Mounting the thread spool 30

Assembling the power pruner 30

- Installing the guide bar and the saw chain 30

- Clamping of saw chain 30

Preparing for startup 31

- Fuelling 31

- Mixing 31

- Fuelling of the device 31

Preparing for startup - power pruner

- Chain lubrication 31

- Filling up saw chain oil 31

- Checking the chain lubrication 32

Start-up

- Starting the machine 32

- Starting with cold engine 32

- Stopping the engine 32

- Starting with warm engine 32

Work instructions

Working with the brushcutter 33

Working with the grasstrimmer 33

Working with the hedge trimmer 33

Working with the power pruner 34

- Work instructions - saw techniques 34

Maintenance and cleaning

- Cleaning the air filter 35

- Cleaning/replacing the fuel filter 35

- Checking/replacing the spark plug 35

— Silencer 35

- Checking the ignition spark 35

— Lubricate the gearbox 35

— Adjusting the carburetor (idle speed) 36

Maintenance the brush cutter 36

- Cutting blade 36

Maintenance the grasstrimmer 36

— Thread spool 36

— Thread knife 36

Maintenance hedge trimmer 36

- Adjusting the cutting device 36

Maintenance of the power pruner 36

— Adjusting the chain lubrication 36

— Saw chain and guide bar 36

— Sharpening of saw chain 37

- Cleaning the guide bar 37

- Chain wheel 37

- Cleaning 37

Transport 37

Storage 37

Guarantee 37

Technical specifications 38

Maintenance and cleaning schedule 39

Possible faults 40

EC Declaration of Conformity 41

Extent of delivery

After unpacking, check the contents of the box for

▶ completeness

▶ possible transport damage.

Report any damage or missing items to your dealer, supplier or the manufacturer immediately. Complaints made at a later date will not be acknowledged.

- 1 Drive unit (1)

• 1 Attachment tool - brushcutter (28)*

• 1 Attachment tool - power pruner (49)*

• 1 Attachment tool - hedge trimmer (44)*

• 1 Safety guard (30)*

• 1 Cutting blade (38)*

- 1 Handle (3)

• 1 Carrying strap (7)

• 1 Guide bar (50)*

• 1 Saw chain (52)*

• 1 Chain protection (53)*

• 1 Knife protection (46)*

• 1 Thread spool (39)*

• 1 Fuel mixing can (27)

- Accessories bag

- Original instruction

- Assembly and operating instruction sheet

- Warranty declaration

* Depends on the variant.

Symbols on the machine

Petrol and oil are a fire hazard and can explode. Fire, open light and smoking are prohibited.

Warning of hot surfaces.

Danger of burning!

Do not touch hot engine parts. Such parts may remain hot for a short time even after the machine has been stopped.

Fuel, fuel mixture

Engine switched off (STOP)

Engine started I

Starting position

Operating position

Engine start

This product complies with European regulations specifically applicable to it.

Guaranteed sound power level L_WA 110 dB (A), measured according to regulation 2000/14/EG.

Symbols for the brushcutter/ grass trimmer

Read and follow the operating instructions and safety advices before starting up the machine.

Wear hardhat, eye and ear protection.

Wear protective gloves.

Wear safety shoes.

Keep bystanders away. Safety distance at least 15 m.

Danger – objects may be thrown out at high speed.

Be aware of kickback.

Max. speed of cutting tool 6200 rpm

Max. speed of cutting tool 6200 rpm

Symbols for the hedge trimmer

Read and follow the operating instructions and safety advices before starting up the machine.

Wear hardhat, eye and ear protection.

Wear protective gloves.

Wear safety shoes.

Keep bystanders away. Safety distance at least 15 m.

Do not operate the high hedge shear near cables, power or phone lines.

Keep a safety distance of 10 m to overhead power lines when working with the high hedge shear.

25 mm

Cutting length 400 mm

Length of sword 425 mm

Symbols for the power pruner

Read and follow the operating instructions and safety advices before starting up the machine.

Wear hardhat, eye and ear protection.

Wear protective gloves.

Wear safety shoes.

Keep bystanders away. Safety distance at least 15 m.

Do not operate the power pruner near cables, power or phone lines.

Keep a safety distance of 10 m to overhead power lines when working with the power pruner.

Length of guide bar 310 mm

Maximum cutting length 260 mm

Saw chain oil

Adjust the chain lubrication

Mind the running direction of the chain links

Symbols original instructions

	Potential hazard or hazardous situation. Failure to observe these instructions may lead to injuries or cause damage to property.
	Important information on proper handling. Failure to observe these instructions may lead to malfunction.
	User information. This information helps you to use all the functions optimally.
	Assembly, operation and servicing. Here you are explained exactly what to do.
	Important notes for environmentally compatible conduct. Failure to observe these instructions may lead to environmental damage.
	Please refer to the attached assembly and operating instruction sheet for references to figure numbers in the text.

Operating times

Please observe as well the regional regulations for noise protection.

Proper use

General:

• The intended usage also includes compliance with the operating, servicing and repair conditions prescribed by the manufacturer and following the safety instructions included in the instructions.
• Any other use is deemed not to be use as prescribed. The manufacturer is not liable for any type of damage resulting from this: the user bears the sole risk.
• Unauthorised modifications on the device exclude a liability of the manufacturer for damages of any kind resulting from it.
• Only persons who are familiarised with the device and informed about possible risks are allowed to prepare, operate and service this device. Repair works may only be carried out by us or by a customer service agent nominated by us.

For the brushcutter / grasstrimmer:

• This machine may only be used for mowing grass and for cutting shrubbery and brushwood in private households.
• This gras trimmer is designed for cutting grass and similar soft vegetation and for trimming lawn edges in private and hobby garden areas which are not accessible with an lawnmower.
• The device is not allowed to be used in public gardens, parks, sports centres or at roadsides as well as in agriculture and forestry.

- This device is not allowed to be used for cutting or chopping:

• hedges, shrubs and bushes,
• flowers,
• in terms of composting.

Otherwise, there is a risk of injury.

- Always use genuine cutting tools. Any use of other metallic cutting tools is prohibited.

For the hedge trimmer:

• This hedge trimmer is designed for cutting branches and young shoots on hedges and shrubs in house and hobby gardens. Do not cut branches the diameter of which exceeds 24 mm.
• As hedge shears for the private house and hobby garden are considered such devices that are not applied in public facilities, parks, and sports facilities as well as in the agriculture and silviculture.
• The device shall not be used for cutting grass, grass borders or in order to chop for composting. Otherwise, there is a risk of injury.

For the power pruner:

• The power pruner is only suitable for cutting branches on standing trees. Do not cut branches the diameter of which exceeds 255 mm.
• The power pruner is not suitable to cut down trees, sapplings or shrubs.
• Do not use the power pruner for sawing building materials and plastics.
• The power pruner is only suitable for private use in gardens and allotments.
• The power pruner is not suitable for forestry works (pruning branches in the forest).

Residual risks

Even if used properly, residual risks can exist even if the relevant safety regulations are complied with due to the design determined by the intended purpose.

Residual risks can be minimised if the “Safety advices” and the “Intended usage” as well as the whole of the operating instructions are observed.

Observing these instructions, and taking proper care, will reduce the risk of personal injury or damage to the equipment.

General:

• Warning! This device generates an electromagnetic field during operation. Such a field may affect active or passive medical implants under certain circumstances. To reduce the risk of serious injuries we recommend persons who carry medical implants to consult their doctor and the manufacturer of the medical implant before operating this device.
• Health impairment resulting from exposure to hand arm vibration if the machine is used too long or is not properly guided and maintained.
• Impairment of hearing when working on the machine for longer periods of time without ear protection.
• Risk of burns when touching hot parts.
• Carbon monoxide poisoning when using the product in closed or poorly ventilated rooms.
• Risk of fire.

For the brushcutter / grasstrimmer:

• Risk of injury at fingers and hands by contact with the cutting tool blade.
• Risk of injury at feet by contact with the cutting tool at a non-covered area.
  • Stones and soil may be thrown off.

For the hedge trimmer:

• Injury by catapulted parts.
• Breaking or catapulting of knife pieces.

For the power pruner:

• Risk of kickback when touching the guide bar tip with a hard object.
• Risk of injuries of fingers and hands by the tool (saw chain).
• Injury by catapulted workpiece parts.

In addition, in spite of all the precautionary measures taken, non-obvious residual risks can still exist.

Behaviour in an emergency situation

• Initiate all required first aid measures suited for the injury and seek qualified medical advice as quick as possible.
• Protect the injured person against further injuries and immobilise the injured person.

Vibrations (hand arm vibrations)

front handle: ahveq = 8.5 m/s²

rear handle: ahveq= 12.7 m/s²

measuring uncertainty K = 1.5 m/s²

The indicated vibration emission level has been measured according to a standardised test method and can be used to compare power tools.

It can also be used for an initial estimate of exposure.

Warning!

The vibration emission level can differ from the indicated value during actual use of the power tool depending on the manner of usage.

It is necessary to define safety measures to protect the operator that are based on an estimate of exposure at the actual conditions of usage (for this, all parts of the operation cycle have to be considered, e.g. times during which the power tool is cut off and times during which it is switched on but runs in no-load mode).

Safety advices

Observe the following advices in order to protect yourself and other persons against possible injuries.

Before starting this device, read and keep to the following advice. Also observe the preventive regulations of your professional association and the safety provisions applicable in the respective country, in order to protect yourself and others from possible injury.

Pass the safety instructions on to all persons who work with the machine.

Keep these safety instructions in a safe place.

⚠️ Repair works on the safety cut out must be carried out by the manufacturer or by companies appointed by the manufacturer respectively.

• Make yourself familiar with the equipment before using it, by reading and understanding the operating instructions.
• Do not use the machine for unsuitable purposes (see 'Normal intended use').
• Be careful what you do. Behave sensibly when working. Do not use the device when you are tired or under the influence of drugs, alcohol or medicaments. One moment of carelessness when using the device can result in serious injuries.
• Children and young persons under 18 years of age as well as persons who have not read the instruction manual are not allowed to operate this product.
• Do not allow other persons, especially children, to touch the tool or motor. Keep them away from your working area.
• Avoid to use this machine when persons are close to you, in particular children.
• Keep children, bystanders and animals at a distance (15m min.) from your working area.

Personal protective equipment

- Never work without suited protective equipment.

• Do not wear loose-fitting clothes or jewellery, they could be caught by movable parts.
  — Hairnet in case of long hair
• geprüfter Schutzhelm in Situationen, bei denen mit Kopfverletzungen gerechnet werden muss.
• Visor
• ear protection
• Protective jacket with striking colour
  — Cut-proof trousers and gloves
• Anti-slipping cut-proof boots (safety shoes) with steel-toes
  – Fire extinguisher and spade (sparks may occur during working)
• First-aid material
  — Mobile telephone if required

Safety instructions – before working

Carry out the following checks before the initiation and regularly during the working process. Observe the relevant sections in the operating instruction manual:

• Is the device assembled completely and properly?
  • Is the device in good and safe condition?
• Are the handles clean and dry?
• Before starting your work make sure that:
• no other persons, children or animals stay within the working area,
  — you can always step back without any barriers,
• your standing area is free from foreign objects, brushwood and branches,

– you have always a secure standing position.

• Is workplace free of risks to stumble? Keep your workplace in an orderly condition! Untidiness can result in accidents. Risk of stumbling.
  • Take environmental influences into consideration:

• Do not work under insufficient light conditions (e.g. fog, rain, snow flurry or twilight). You can not see anymore details within the falling area – risk of accident.

• Do not use this machine near inflammable liquids or gases. Risk of fire!
• The operator is responsible for accidents or risks which occur to other persons or their properties.

Safety instructions – operating

• Never saw with only one hand. Hold the device always firmly with both hands.
• Always apply the carrying strap when working with this machine.
• Never work

– with stretched arms
— on hardly accessible places
— above shoulder height
- standing on a ladder, a staging or a tree.

• Always work on nonskid and flat ground.
Avoid abnormal posture. Provide a safe standing position and keep at any time the balance.
- Frequently change the working position to prevent a one-sided work position.
- To have a break stop the machine and place it so that nobody is at risk. Secure the device against unauthorized access.

Safety instructions – while working

• Never work alone. Keep acoustic and visual contact to other persons at all times to allow immediate first aid in emergency cases.
• Immediately stop the engine at imminent danger or in emergency cases.
• Never leave the device running unattended.
• This device chain saw produces harmful substances. Never start the product in closed

rooms or poorly ventilated areas risk of carbon monoxide poisoning. Provide for a sufficient change of air when working in wells, trenches or confined spaces. There is the risk of carbon monoxide poisoning or death by suffocation.

• Immediately stop working when you feel unwell (e.g. headache, dizziness, nausea, etc.). Otherwise there is an increased risk of accidents.
• Do not overload the machine! You work better and safer in the given performance range.
• Take breaks when working so that the engine can cool down.
• Do not place a hot machine in dry grass or onto inflammable objects.
• Never touch the silencer and the engine while the machine is running or shortly after it was stopped. Danger of burning!

Vibrations

⚠️ If persons who have blood circulation problems are too often exposed to vibrations damages to the nervous system or to blood vessels may occur.

You can reduce vibrations

• by thick and warm working gloves,
• shorter working time (have longer breaks).

See a doctor if your fingers swell, you don't feel well or your fingers become numb.

General safety instructions

- Maintain the machine carefully:

• Follow the maintenance instructions and the instructions for tool exchange.
• Keep handles dry and free of oil and grease.

- Only mount cutting tools that are designed for this machine.

The use of other tools and other accessories may present a risk of injury to you.

- Check the machine for possible damage:

• Before further use of the machine the safety devices must be checked carefully for their proper and intended function. Only operate the device with complete and correctly attached safety equipment and do not alter anything on the device that could impair its safety.
• Check whether movable parts function perfectly and do not stick or whether parts are damaged. All parts must be correctly installed and fulfil all conditions to ensure perfect operation of the machine.

• Damaged safety devices and parts must be properly repaired or exchanged by a recognized, specialist workshop; insofar as nothing else is stated in the instructions for use.
  – Damaged or illegible safety labels have to be replaced.

• Do not allow any tool key to be plugged in!
  Before switching on, check always that all tools are removed.

• Store unused equipment in a dry, locked place out of the reach of children.

Do not carry out repair operations on the machine other than those described in section "Maintenance" but contact the manufacturer or authorized customer service centres.

⚠️ Repairs to the machine must be carried out by the manufacturer or one of his customer service points.
⚠️ Use only original spare parts, accessories and special accessory parts. Accidents can arise for the user through the use of other spare parts. The manufacturer is not liable for any damage or injury resulting from such action.

Safety instructions for the brushcutter / grasstrimmer

- Before trimming, remove all foreign objects (e.g. stones, branches, wires, etc.). While working watch out for further foreign objects.

• Make sure that the cutting tool has no contact with the ground before starting the device.
• Before starting the engine, make sure that your hands and feet are kept at a safe distance to the cutting tool.
• Caution! The cutting tool may after-run. Do not try to slow down it by the hand.
• Start cutting only when the cutting tool has reached the full rotational speed.
• Never bring the cutting tool in contact with rigid objects (stones, trunks).
• Stop the machine and remove the spark plug connector when
• the cutting tool comes in contact with stones, nails or other foreign objects
  – carrying out repair work.
  – performing maintenance and cleaning work.
• Eliminating faults.
• transporting or storing
  — replacing the cutting tool
  — leaving of machine (also for short-term interruption)

Safety instructions for the hedge trimmer

• Remove unconditionally any foreign objects out of the hedge (e.g. wires) as these can damage the knives of the hedge trimmer.
  • Take special care when operating close to overhead cables.
• Keep hands and feet away from the cutting device when it moves.
• If you release the throttle trigger the cutting device will after-run for a short time
• If you release the throttle trigger the cutting device will after-run for a short time
• Be sure that the cutting device already moves before you start cutting.
• Do not use a blunt, broken or otherwise damaged cutting device.
• Never get in contact with the running cutting device with metallic fences or the ground.
• Stop the engine and allow the machine to come to a stop when

— the cutting tool hits a foreign object,
— abnormal operating noise is noticed,
– the machine causes abnormal vibration.
⇒ Then, pull off the spark plug connector from the spark plug and take the following actions:
— check the machine for damages,
– check for loose parts and tighten them if necessary,
- replace damaged parts by equivalent parts or have them repaired.

- Stop the engine and pull the spark plug connector:

— to remove jammed material,
- to eliminate faults,
- for work breaks,
— before leaving the hedge trimmer.

Safety instructions for the power pruner

• Persons who work with the power pruner must exhibit on request a training certificate appropriate to the intended use and be familiar with the use of the power pruner and personal protective equipment.
• Only use a suited guide bar/saw chain combination as described under “Technical data”. Incorrect combinations increase the risk of kickbacks.
  • Is the oil tank filled (chain lubrication)?
  Check the oil level on a regular basis. Top up saw chain oil without delay to prevent the saw chain from running dry.
  • Is saw chain clamped correctly?
  Observe the points in paragraph "Clamping saw chain".
  • Is saw chain sharpened correctly?
  Use only well sharpened saw chains as edgeless saw chains increase not only the risk of backstrokes but also charge the motor.
• Do not use any cracked saw chains or such that have changed their shape.
• Securely support the power pruner when switching it on and hold it with both hands. Chain and guide bar must stand free.
• Start cutting only when the saw chain has reached the full number of revolutions.
• Do not attempt to hit an already existing cut.
• Do not use the power pruner for lifting or moving of wood.
• Saw splintered wood with care. There is risk of injury by wood pieces carried away.
• Operate the power pruner only with safe standing position.
• Frequently change the working position to prevent a one-sided work position.
• Make sure that the wood is free of foreign object (nails etc).
• Be careful at the end of a sawing cut. As soon as the power pruner leaves the wood the force of weight changes. There is risk of accident for legs and feet.
• Remove the power pruner only with running saw chain out of the cut.
• If the saw chain gets jammed in the wood, stop it immediately. Use a wedge to free the guide bar.
• Never touch wire fences or the ground with the running saw chain.
• Switch off the power pruner between the cuts when several cuts are carried out.
• Before leaving the power pruner for work breaks bring it in a safe condition (cover the chain guard) and put it on a place where nobody is endangered. Secure the power pruner against unauthorized access.
• Stop the machine and remove the spark plug connector when
• Contacting the power pruner with soil, stones, nails or other foreign substances

  Check immediately chain and guide bar.

• Carrying out repair work.
• Performing maintenance and cleaning work.
• Eliminating faults.

• Transport

• Clamping again the chain

• Chain change
  — Leaving of machine (also for short-term interruption)

Safety instructions - Safe handling with fuels

Fuels and fuel vapours are inflammable and may cause serious injury on the skin or when inhaled. Therefore be careful and provide sufficient ventilation when handling with fuels.

• Do not smoke and avoid open flames when fuelling.
• Wear gloves when fuelling.
• Do not fuel in closed rooms.
• Stop the chain saw and allow it to cool down.
• Carefully open the tank cap to allow possible overpressure to relax.
• Avoid spilling of fuel or oil. Clean the device immediately when you have spilled fuel or oil. Change your clothes immediately when you have spilled fuel or oil on them. Make sure that no fuel can come into the soil.
• Carefully close the tank cap after fuelling and check that it does not get loose during operation.
• Check that there is no leakage on the tank cap and fuel lines. If there are leaks this product may not be started.
• Never use a device with damaged ignition cable and spark plug connector.
• Only transport and store fuels in containers approved and identified for this.
• Keep children away from fuels.
• Do not handle and store fuels close to combustible and highly inflammable materials as well as sparks and open flames.
• Go away at least three metres from the fuelling place to start the chain saw.

Description of device

Pos.	Denomination Order number
1	Drive unit
2	Clamping screw 386126
3	Handle, cpl. 386105
4	Handle
5	Lower handle
6	Rubber sleeve
7	Carrying strap 386104
8	Throttle lever lock
9	Throttle trigger
10	ON/OFF switch
11	Priming pump
12	Choke lever
13	Cranking handle 386148
14	Air filter cover	386150
15	Air filter	386149
16	Spark plug connector
17	Spark plug 380856
18	Silencer	386155

19	Tank cap	386153
20	Fuel filter	386152
21	Tank	386103
22	Installation wrench
23	Allen key, size 4
24	Allen key, size 5
25	Open-end wrench, size 8/10
26	Round file 386182
27	Fuel mixing can	364520
28	Brushcutter attachment tool
29	Safety label	386156
30	Safety guard	386102
31	Safety guard holder
32	Holder
33	Protective cover
34	Angular gear
35	Hexagon nut	386121
36	Cover	386120
37	Spacer washer	386119
38	Cutting blade	386118
39	Thread spool	386129
40	Thread spool holder	386131
41	Thread spool cover	386132
42	Spring 386133
43	Thread knife	386122
44	Hedge trimmer attachment tool
45	Cutting device
46	Cutting tool guard	386114
47	Handle	386115
48	Safety label	386116
49	Pruner attachment tool
50	Guide bar (sword)	386157
51	Safety label	386159
52	Saw chain	386158
53	Chain protection 386151
54	Cover	386163
55	Fixing nut 386164
56	Chain wheel
57	Chain stretching screw
58	Chain stretching pin
59	Oil tank lock	386160
60	Protective cap	386184
61	Zerk fitting	386174
62	Accessories bag Installation tools	386183

Assembly

Please note the attached assembly instruction sheet!

Assembling/disassembling

2 Remove the protective cap (60) and slide the brushcutter (28), hedge trimmer (44) or pruner (49) attachment tool in the holder (a) of the drive unit (1) as shown.
→ ⚠️ Make sure that it engages with a click.

GB

→ Firmly tighten the clamping screw (2).
To disassemble the attachment tool loosen the hand screw. Press on the button (b) and pull the attachment tool out of the holder.
→ Reattach the protective cap (60).

Mounting the handle

→ Put the drive unit (1) on a level surface.
3 Remove the screws (c) together with the spring rings and washers.
4 Slide the lower handle (5) in the rubber sleeve (6) on the tube shaft of the drive unit (1).
Slide the handle (4) in the lower handle and secure both parts using the screws, spring rings and washers.

Mounting the handle

5 Hook the carrying strap (7) in the suspension eye (d).

Assembling the brushcutter / grasstrimmer

Mounting the protective hood

Remove the 4 screws (e) together with the spring rings, washers and nuts from the protective hood holder (31). Loosen the hexagon socket screw (f) and fold up the holder (32).
→ Slide the protective hood (30) on its holder (31).
7 Fold down the holder (32) and secure the protective hood using the screws, washers and nuts. Tighten the hexagon socket screw (f) again.

Mounting the cutting blade (brushcutter)

8 Align the hole in the protective cover (33) with the hole on the angular gear (34) and lock the drive shaft using the Allen key (23).
8 / Remove the hexagon nut (35) using the wrench (22).

Left-hand thread

9 Remove the cover (36) and the spacer washer (37).
9 Put on the cutting blade (38).
The further assembly is now done in reverse sequence.

Assembling the thread spool (grasst rimmer)

8 Align the hole in the protective cover (33) with the hole on the angular gear (34) and lock the drive shaft using the Allen key (23).
8 | 9 Remove the hexagon nut (35) using the wrench (22).

Left-hand thread!

9 Remove the cover (36) and the spacer washer (37).
Screw the thread spool (39) on the drive shaft.
→ ⚠ Left-hand thread!

Assembling the power pruner

Installing the guide bar and the saw chain

Risk of injury!

Wear protective gloves when working on the guide bar and the saw chain.

10 Place the power pruner on a level surface.
Remove the securing nut (55) and remove the cover (54).
11 Turn the chain stretching screw (57) anticlockwisely until the chain stretching pin (58) is at the rear end of the thread.
12 Put the saw chain over the clutch (52) on the chain wheel (50) and insert it in the circumferential guiding groove of the guide bar.
⚠️Attend to the correct running direction of the chain links.
13 Place the guide bar (50). The chain stretching pin (58) must engage in the provided chain stretching hole (g) in the guide bar.
When assembling, pay attention that the chain links are lying correctly within the guide slot and on the chain wheel (56).
10 Remount the cover (54) and tighten the securing nut (55) hand-tight.
Stretch the saw chain as described in section „Stretching the saw chain”.

Clamping of saw chain

Risk of injury!

Stop the engine and wear protective gloves whenever working on the guide bar and on the saw chain.

14 Loosen the retaining nut (55) by max. 1 turn.
14 Slightly lift the guide bar tip and turn the chain stretching screw (57) clockwise until the correct chain tension is reached.
15 The saw chain is correctly stretched when it can be lifted in the centre of the chain guide by appr. 3 – 4 mm.
Turn the chain stretching screw anti-clockwise when the saw chain is stretched too much.
⚠️ Check that the chain links are positioned correctly in the guiding groove of the guide bar.
→ Re-tighten the locking nut (55).

Check the saw chain tension

→ before start of work
→ after the first steps
→ during sawing regularly all 10 minutes

Only with a correct clamped saw chain and a sufficient lubrication you can influence the durability.

Pay attention to the following:

→ a new saw chain must be restretched more frequently.
→ in case of heating of chain to operating temperature it expands and needs to be reclamped.

After finishing the sawing works release tension of saw chain as in case of cooling too high tensions would emerge in the saw chain.

if chain flackers or comes out of the guide clamp it again immediately.

Preparing for startup

Fuelling

Utmost care is required when handling fuel and oil. Keep away smoke and open flames (risk of explosion).

This product is operated by a mixture from regular gasoline (unleaded) and two-stroke engine oil.

Petrol: Octane number at least 91 ROZ unleaded

• Do not fill in leaded gasoline, diesel or other non-approved fuels.
• Do not use gasoline having a smaller octance number than 91 ROZ. This may lead to severe engine damages due to increased engine temperatures.
• If you frequently operate the product at high speeds, you should use gasoline with a higher octane number.

The use of unleaded gasoline is recommended for environment protection reasons.

Two-stroke engine oil:

acc. to JASO FC or ISO EGD specifications

- Do only use two-stroke engine oil for air-cooled engines.

Mixing

Ratio of mixture 40:1

Gasoline Two-stroke engine oil
1 litres 0.025 litres
2 litres 0.050 litres
5 litres 0.125 litres
10 litres 0.250 litres

• Measure the oil quantity accurately as a small deviation of it has a large effect on the ratio of mixture in particular for small fuel quantities.
• Do not change the ratio of mixture. This will lead to more residues of combustion, a higher fuel consumption, a decrease of output or damages to the engine.

Mix petrol and oil in the supplied fuel mixing can (27).

• Fuels have only a limited shelf-life. Outdated fuels and fuel mixtures may result in starting problems. Therefore, mix only that quantity of fuel which you can use within a month.
• Only store fuels in containers approved and identified for this. Keep fuel containers in a dry and safe area.
• Make sure that fuel containers are kept out of the reach for children.

Make sure to dispose of fuel remainders and liquids d for cleaning according to relevant regulations and in an environmentally compatible manner.

Fuelling of the device

• Stop the engine and allow it to cool down.
• Wear protective gloves.
• Avoid eye and skin contact.
• Strictly follow the instructions under "Safe handling with fuels".

→ Clean the area around the filler neck. Contamination in the tank may result in malfunction.
→ Carefully open the tank cap (19) to allow possible overpressure to relax.
→ Shake the container once more before pouring the fuel mixture into the tank.
Carefully fill the fuel mixture up to the lower edge of the filler neck. Avoid spilling of fuel or oil. Clean the device immediately when you have spilled fuel or oil. Make sure that no fuel can come into the soil.
Carefully close the tank cap after fuelling and check that it does not get loose during operation.
→ Check that there is no leakage on the tank cap and fuel lines. If there are leaks this product may not be started.
→ Clean the tank cap and the area around it.

Go away at least three metres from the fuelling place start the chain saw.

Preparing for startup power pruner

Chain lubrication

The power pruner is not delivered filled with saw chain adhering oil.

Never operate the power pruner without functioning chain lubrication. Any use without chain saw oil may result in damage of the chain saw and guide bar.

The durability and cutting power of the chain depends on the optimal lubrication. During operation the saw chain is automatically wetted with oil.

Filing up saw chain oil

Stop the engine and wear protective gloves. Avoid eye and skin contact.

Put the power pruner on a suitable base.
17 Unscrew the oil tank lock (59).
Fill the oil tank with bio-degradable chainsaw oil (order no. 400144). For easier filling use a funnel.
When filling observe that no dirt reaches the oil tank.
→ Screw on the oil tank lock again.

Never use recycled oil or used oil. The guarantee expires when using oil which is not allowed for saw chains.

Checking the chain lubrication

⚠️ Never operate the power pruner without functioning chain lubrication.

Check the function of the automatic chain lubrication by switching on the power pruner and holding it with the spike in direction of a carton or paper on the ground.

Do not get in contact with the ground with the chain. Keep a safe distance of 20 cm.

If an increasing oil track is caused when checking it the oil automatic works faultless.

If there is no oil track despite full oil tank

11 clean the oil flow canal (h) and clean the upper chain clamping boring (g)
40 adjust the chain lubrication as described under "Adjusting the chain lubrication".

If this is not successful please contact the customer service.

Start-up

⚠️ You may not start to operate the machine until you have read these operating instructions, observed all the instructions given and completely and properly assembled the machine!

Before each use, check

• the machine for possible damage:
• loose fastenings

18 Make sure that the ON/OFF switch, the throttle lock-out switch, the throttle trigger and the machine properly work.

The engine of the machine is supplied without gasoline and oil in it. Fuel the device as described under "Fuelling".

Starting the machine

This machine is equipped with a centrifugal clutch. The cutting tool can start rotating after the start. Place the machine therefore on a solid ground for starting. Firmly hold the machine and make sure that neither the cutting tool nor the throttle lever come into contact with fixed objects.

Always keep your hands and feet at a safe distance to the cutting tool.

19 Put the machine on the ground.
Have a safe standing position.

⚠️ Make sure that the cutting tool has no contact with the ground.

Starting with cold engine

18 Firmly press on the fuel pump (11) several times until petrol (gasoline)/foam is visible in the priming pump.

→ Put the choke lever (12) to the position N.
Put the ON/OFF switch (10) to ☐
Press the throttle lock-out switch (8) and operate the throttle trigger (9) at the same time.
19 Grasp the cranking handle (13) and slowly pull the cranking rope until a resistance is felt. Then, pull quickly and firmly.

Do not fully pull out the cranking rope and slowly guide the cranking handle back to make sure that the cranking rope is correctly wound up.

Repeat this operation until the engine starts.

18 Put the choke lever (12) to the position when the engine has started.

The engine will idle when you release the throttle trigger.

⚠ The cutting tool may not move in idle mode. Risk of injury!

i Immediately stop the operation when the cutting device moves while the throttle is disengaged. The idle speed must be reduced. (See "Maintenance → adjusting the carburetor")

Stopping the engine

18 Release the throttle trigger (9).

Put the ON/OFF switch (10) to the position

Starfing with warm engine

Start the device as described under "Starting with cold engine", but leave the choke lever in its operating position 141 and do not operate the throttle trigger.

Working instructions

You may not start to operate the machine until you have read these operating instructions, observed all the instructions given and installed the machine as described!

20 21

⚠️ Always apply the carrying strap (7) when working with this machine.

Adjust the carrying strap so that a convenient and safe carrying of the machine is ensured.

The quick acting closure (A) is located at the front.
The quick acting closure can be opened with the left hand.

The hip pad (B) should rest on the hip.

Immediately replace a damaged carrying strap.

Always keep your hands and feet at a safe distance to the cutting tool.

Working with the brush cutter

⚠️ Kickback – backstroke

When working with metal blades, a kickback of the whole machine or a sudden pull forwards may occur if fixed objects (trees, branches, stones or the like) are hit. Such a kickback occurs abruptly without advance warning and may result in loss of control of the machine and hazards to the operator and bystanders. There is a particular hazard in badly visible and overgrown areas.

20 To keep the control in case of kickback

• Always hold the machine firmly with both hands when working.
• Make sure that you have a safe stand. Keep your feet conveniently spread and be always alert to a possible kickback.
• Do not overestimate your abilities and always keep your balance when working.
• The cutting blade should have reached its full speed before cutting.

When brushcutting, stones and debris may be thrown up and cause serious injuries. Make sure that the protective hood is safely mounted.

⚠️ Failure to install rotating parts (cutting blades) correctly may result in severe accidents. Check the cutting blade for secure seating before starting your work.

Mowing

• Incline the machine slightly forward and uniformly move it from right to left with adequate speed. This way, the cut material falls on the already mowed area.
• Cut higher grass and denser growth in several passes. For this, shorten the upper portion of the material to be cut at first by moving the device to the right. Then, move the device to the left and cut the lower portion of the material to be cut.
• When working on slopes mow in stripes. Mow a stripe parallel to the slope. Move then back on the mowed area and mow the next stripe.
• Adjust the engine speed and cutting height to the prevailing conditions. If the engine speed is too low, scrub can entangle in the cutting tool or the cutting tool may get stuck in the scrub.

⚠️ If grass, scrub or other objects entangle in the cutting tool or if the device vibrates abnormally, immediately stop the engine and check the machine.

• A blocked angular gear may cause coupling damage.
• Never remove jammed material while the cutting blade is still rotating. Wait until the cutting blade stands still.
• If the cutting blade is dull, broken or bent, replace it by a genuine spare part.

Working with the grasstrimmer

Trimming

• Incline the machine slightly forward and uniformly move it from left to right with adequate speed.
• You will get the best trimming results when you cut dry grass.
• Do not guide the cutting thread directly at walls and paving stones. Otherwise it will prematurely wear off.
• Cut higher grass and denser growth in several passes to prevent the spool head from becoming blocked.

⚠️ A blocked spool head may cause coupling damage.

- Adjust the engine speed and cutting height to the prevailing conditions. If the engine speed is too low, scrub can entangle in the cutting tool or the cutting tool may get stuck in the scrub.

⚠️ If grass, scrub or other objects entangle in the cutting tool or if the device vibrates abnormally, immediately stop the engine and check the machine.

• A blocked spool head may cause coupling damage.
• The cutting thread is after-running once the lawn trimmer has been cut off. Therefore wait until the thread is stationary before you restart the product.
• When the thread spool is empty replace it by a genuine thread spool.

Thread follow-up

During trimming, the cutting thread wears (becomes shorter) or it may tear off so that it can no longer cut grass.

Shortly press the machine against solid ground. This will extend the cutting thread (by approx. 4 cm). If the cutting thread exceeds the maximum cutting diameter it will be shortened by the integrated knife within the protective hood.

Working with the hedge trimmer

Always keep your hands and feet at a safe distance to the cutting tool.

• 2 bu can use the hedge trimmer to trim high and wide hedges as well as low hedges.
  22 The hedge trimmer head (m) can be adjusted within a working angle range of 145°. Adjust the hedge trimmer head to the correct working position before starting your work.
  Press the release lever (n) and the locking lever (o) and turn the hedge trimmer head to your desired position.
  Leave hold of the release and locking levers. The hedge trimmer head engages.
• Always hold the machine firmly with both hands when working.

• Best time for hedge trimming:

⇒ Leaved hedge: June and October
⇒ Conifer hedge: April and August
⇒ Quickly growing hedge: from May and then every 6

w e e k

• Pay attention to breeding birds in the hedge. If so, put off hedge trimming or leave this area out.
• The maximal diameter to cut depends on the wood's type, age, moisture and hardness.
  Therefore cut very thick branches using branch shears to your desired length before trimming the hedge.
• Due to its double sided knives the hedge trimmer can be guided forward and backward or by oscillating movements from one to another side.
• At first cut the sides of the hedge and then the upper edge.
• Cut the hedge from the bottom up.
  • ⊙ | 23 Cut the hedge in trapezium shape.
• Stretch a guide over the complete length of the hedge when you want to shorten the upper edge of the hedge evenly.
• Trim in several passes if you have to cut down a large portion of the hedge.

Working with the power pruner

⚠️ Kickback - backstroke

What is saw backstroke? Saw backstroke is the sudden strike upwards or backwards of the running power pruner in direction of the operator.

This happens when

• the guide bar tip gets in contact with the sawing material (unintended) or other hard objects.
  — the saw chain is jammed at the guide bar tip.

The power pruner reacts uncontrolled and frequently causes heavy injuries of the operator.

How to avoid saw backstroke?

24 Always hold the power pruner firmly with both hands.
- Start cutting only with running saw chain.
- For better control saw with the lower edge of the guide bar. Place the power pruner as horizontally as possible when contacting wood.
- Never saw with the guide bar tip.
- Sawing with the upper guide bar edge may cause a saw backstroke if the saw gets jammed or hits a hard object in the wood.
• Always work with a sharp and stretched saw chain.

General conduct when pruning

• 25 Keep bystanders away. The safety distance is 2.5-times the length of the branch to be cut, but at least 15 m.
• Keep a safety distance of 10 m to overhead power lines.
• Plan an escape route from falling branches in advance. This escape route must be free from obstacles to ensure retreating without danger.
• Position yourself outside the range of falling branches.

Work instructions (saw techniques)

• Do not cut thin branches or bosks. The power pruner is not suitable for those works.

• Cut larger branches into several sections to avoid splintering and breaking.

• Do not cut any branches where their diameter is greater than the cutting length of the device.

• Do not stand directly underneath a branch to be cut.
• Watch out especially for falling branches.
• Also look out for branches snapping back.

Always wear a helmet in order to protect yourself against perches falling down.

Step cut

26 For horizontal branches without being top heavy The branch section falls down in a controlled manner without tipping over.

① Set the first cut from below, approx. one third of the branch diameter.
② The second cut is made on the same level as the first cut or moved further toward the inside (negative breaking step).
③ Remove the remaining branch section.

Step cut error!

27 If the cut is made offset toward the outside (positive breaking step) and exceeded, the power pruner can be pulled along.

Maintenance and cleaning

Before each maintenance and cleaning work

• Stop the engine.
• Wait until the cutting device does not longer move.
• Remove the spark plug connector.

- Wear protective gloves in order to avoid injury to the hands.

- Do not carry out maintenance work close to open flames. Risk of fire.

⚠️ Improper maintenance or any failure to eliminate faults before starting can cause operating trouble which can result in serious injuries and damages to the machine.

Maintenance and repair work other than those described in this chapter is only allowed to be carried out by service staff.

For maintaining and cleaning, removed security devices must unconditionally be mounted properly and proved again.

Only use genuine spare parts. Other than genuine parts may result in unpredictable damages and injury.

Maintenance

The cutting tool will not come to a standstill immediately after cut-off. Before starting any service work wait until all parts are stationary.

To guarantee a long and reliable usage of the product carry out the following maintenance works regularly.

Check the device for obvious defects such as

- loose fastening elements

• worn or damaged components
  – deformed, broken or damaged cutting device
  – leaks from the fuel tank cap or fuel lines
• correctly assembled and faultless covers and protective devices.

Before each use or after each impact or falling, this machine needs to be checked for damages and leakages.

① Necessary repair works or maintenance have to be carried out before using the machine.

Cleaning the air filter

Clean the air filter from dust and dirt on a regular basis to prevent

• starting problems
  — loss of output,
  – too high fuel consumption.

Clean the air filter every 8 operating hours, or more frequently in dusty environments.

18 Put the choke lever to the position No prevent dirt from entering the carburetor.
28 Pull off the air filter cover (14).
Remove the air filter (15).
Wash the air filter in a luke warm soapy solution.
Do not puff/blow out dirt particles, otherwise there is a risk of eye injury.
Allow the air filter to dry well and reinsert it.

i Damaged air filters must be replaced without delay.

Cleaning/replacing the fuel filter

Check the fuel filter if required. A contaminated fuel filter restricts the fuel supply.

29 Open the tank cap (19) and pull the fuel filter (20) through the opening using a wire hook.
Slight contamination:
Pull the fuel filter from the fuel line and clean it in petroleum ether.
⇒ Bad contamination:
Replace the fuel filter.

Checking/replacing the spark plug

• Do not touch the spark plug or the spark plug connector while the engine is running. High voltage!
• Risk of burning on the hot engine.
• Wear protective gloves.

Check the spark plug and the spark gap on a regular basis. For this proceed as follows:

Allow the engine to cool down.

30 Pull the spark plug connector (16) from the spark plug (17).
Remove the spark plug using the supplied wrench (22).

The spark gap must be 0.6 to 0.7 mm.

→ Clean the spark plug when it is contaminated. Install the spark plug in reverse order.

Do not overtighten the spark plug.

Replace the spark plug:

• every 100 hours or each season (whichever case comes first)
• when the insulating body is damaged,
• when the electrodes show excessive erosion, when the electrodes show excessive dirt or oil.
  Use the following spark plug type:
  Torch L8RTC, NGK-BPMR 7 A, BOSCH WSR6F, OREGON O-PR15Y, Champion RCJ 6Y

Checking the ignition spark

→ Remove the spark plug (17).

Firmly connect the spark plug connector (16).

31 Use an insulated pair of tongs to press the spark plug against the engine body (away from the spark plug hole).

Put the ON/OFF switch to the position [1]. Pull the cranking rope.

i If there is no spark visible between the electrodes, the spark plug may be defective.

Silencer/exhaust outlet

32 Check the silencer (18) on a regular basis

i Clean the exhaust outlet on a regular basis.

Do not clean the silencer when the engine is hot. Danger of burning!

Lubri cate the ge arbox

33 / 34 / 35

i Lubricate the gearbox every 8 to 25 operating hours. Use SHELL ALVANIA RL3, for example, or an equivalent grease brand.

→ Put the grease gun onto the zerk fitting (61).
Force some grease into the zerk fitting.

Adjusting the carburetor (idle speed)

The carburetor is factory-set to the correct idle speed so that the correct fuel-air mixture is fed to the engine.

In the cases below the carburetor (idle speed) has to be corrected:

• Speed too high (cutting tool continues to move in idle speed)
• Erratic running or lack of acceleration (idle speed too low)
• Adjustment to weather conditions and temperatures

An incorrect carburetor adjustment results in severe engine damages. Do not continue working with the machine in such a condition.

i Contact a specialist workshop and have the carburetor adjustment done.

Maintenance of the brushcutter

Cutting blade

⚠️ Safe and efficient working is only possible with a correctly sharpened and intact cutting blade.

Therefore, check the cutting blade for dull edges, bents, cracks or other damages on a regular basis.

Have dull cutting blades sharpened by a specialist/service workshop.

Both sides of the cutting blade may be used. Turn round the cutting blade once and continue to work with the brushcutter until both sides of the cutting blade are dull-edged.

⚠️ Replace damaged cutting blades by new ones.

Maintenance of the grasstrimmer

Replacing the thread spool

36 Press on both locking tabs (j) on the thread spool holder (40) and remove the thread spool cover (41).
Remove the thread spool (39) from the thread spool holder.
Remove dirt and grass residues.
37 Thread the ends of the cutting threads of the new thread spool into the provided openings (k) in the thread spool holder (40).
Insert the thread spool together with the spring (42) in the thread spool holder (40). Make sure that the cutting threads are not caught and pull them approx. 9 cm out of the spool.
36 Put the thread spool cover (41) on the thread spool (39). The cutouts on the thread spool cover need to be aligned with the locking tabs (j). Press the thread spool cover down until in snaps into place.

Replacing the thread knife

38 Unscrew the screws and remove the old thread knife (43).

Screw on the new thread knife as shown.

Do not overtighten the screws.

Maintenance of the hedge trimmer

Check the hedge trimmer after each application for
— wear and tear, in particular sliding play of the cutting device
– Sufficient lubrication of the cutting device.

Adjusting the cutting device

Readjust the sliding play if cut material is clamped between the blades or the play has increased due to normal wearing of the cutting device after a longer period of use.

To obtain good cutting results the free motion between the blades and the sword must be correctly adjusted.

For this proceed as follows:

39 Loosen the nuts (E) on the top surface of the cutting device.
Slightly tighten the screws (F) on the underside (if required loosen them previously).
Turn the screw back anticlockwisely by a quarter up to a half turn.
Use a screwdriver to hold the screw and firmly tighten the nuts.
The sliding play is correctly adjusted if the washer under the screw head can just be freely moved back and forth by hand.
Lubricate the cutting device using environmental-compatible lubricating oil.

If the play is too small or insufficient lubrication, this may cause a great extent of heating and thus damage to the product.

Maintenance of the power pruner

Adjusting the chain lubrication

The chain lubrication is factory-set. Depending on the type of wood and working techniques the amount of oil may vary and has to be corrected.

40

Adjust the chain lubrication using the adjusting screw (I) which is located below the product.

Anticlockwise turning large amount of oil (MAX) Clockwise turning small amount of oil (MIN)

The chain lubrication is correctly adjusted when the saw chain throws off small amounts of oil during operation.

Saw chain and guide bar

Saw chain and guide bar are exposed to a great extent of wearing. Replace the chain saw and the guide bar without any delay if their proper function is no longer ensured.

→ "Installing the guide bar and the chain saw".

Sharpening of saw chain

You can only work safely and well with a sharp and clean saw chain. Damaged or incorrectly sharpened saw chains increase the risk of kickbacks.

The saw chain has to be sharpened if

→ only wood dust is thrown out instead of shavings
→ you have to press the chain saw through the wood during cutting
Inexperienced users: Have the saw chain sharpened by a specialist/service workshop.

If you sharpen the saw chain by yourself, note the values below and use the supplied round file. (Additional accessories are available from specialist shops.)

41/ 42/ 43

Saw chain type Oregon 91 P0
Round file ∅ 5,5 mm (7/32")
Depth gauge distance T 0,64 mm (.025")
Sharpening angle α	25°
Breast angle β	60°
Planing tooth length a min. 3 mm

Only remove a little amount of material when sharpening.

You can also sharpen your saw chain yourself by using our electric sharpener KSG 220 A (article-no.: 302360).

Cleaning the guide bar

44

• Check and clean the oil outlets (G) of the guide bar and the guiding groove (H) on a regular basis.
• Remove any burr using a flat file.
• Turn round the guide bar after each chain exchange/sharpening to avoid single-side wearing.

i Immediately replace a damaged guide bar.

Chain wheel

The demand of the chain wheel is particularly great. Check regularly the teeth of the chain wheel for wear or damages.

11 Clean the chain wheel (56) and the guide bar fixing device using a brush.

A worn or damaged chain wheel reduces the durability of the saw chain and should therefore immediately be exchanged by the customer service.

Cleaning

i Clean the machine and its accessories thoroughly after each application so that the faultless function is kept.

• Clean all movable parts on a regular basis.
• Clean the case with a soft brush or a dry cloth.
• Do not clean the machine under running water or using a high-pressure cleaner.
• Do not use solvents (gasoline, alcohol, etc.) for plastic parts, otherwise such parts may be damaged.
• Keep the handles free of oil and grease.

Water, solvents and polishing agents shall not be applied.

- 32 Make sure that the ventilation slots (i) for the engine cooling are free (risk of overheating).

Transport

Before each transport

Switch off device.

— Wait until the cutting device does not longer move.

Attach the protective cover for the cutting tool.

• Carry the product with the handle.
• When transporting the product within a car put it in the boot or on a separate loading area. Secure the machine against tipping over, damages and fuel spillage.

Storage

• Keep unused machines with attached covers on blades and swords in a dry and closed area out of the reach of children. Do not store them close to a cooker, oven or hot-water apparatus with permanent flame or other spark-generating devices.
• Allow the engine to cool down before storing the machine.
• Before extended storage, please observe the following to increase the service life of the device and to ensure smooth operation:

→ Thoroughly clean the device.
→ Oil all moving parts with environmentally compatible oil.

Do not use grease.

→ Empty the fuel tank completely.
⇒ Operate the engine until the carburetor is empty.
→ Check the machine for perfect condition to ensure a safe use of it after a longer period of storage.

Guarantee

Please note the attached guarantee declaration.

Maintenance and cleaning schedule

Maintenance work	Before each use	After each use	Every 8 Std.	Every 25 Std.	Every 100 hours	If required / damaged	Each season
Fuelling	■
Lubricate the gearbox			■ ■
Check the cutting blade		■					■
Replace the cutting blade						■
Check the thread spool		■
Replace the thread spool						■
Replace the thread knife						■
Adjust the cutting device						■
Lubricate the cutting device		■				■
Check the guide bar		■					■
- Clean/turn round		■					■
- Replace						■
Check the chain wheel			■
- Have it replaced						■
Check the saw chain tension	■					■
Check the saw chain	■						■
- Have it sharpened						■
- Replace						■
Check the chain lubrication	■
Clean the oil tank				■			■
Throttle trigger / throttle lock-out switch / ON/OFF switch - Functional test	■
Throttle trigger / throttle lock-out switch / ON/OFF switch - Have it replaced						■
Cranking rope - Functional test	■
Cranking rope Have it replaced						■
Check the fuel and oil tank caps Replace	■
						■
Clean fuel filling filter				■		■ ■
Clean the fuel filter				■			■
Replace air filter						■
Cleaning the air filter			■				■
Replace air filter						■
Spark plug Check the spark plug connector			■				■
Replace the spark plug					■ ■
Clean the silencer			■				■
Check the carburetor in idle speed (cutting tool may not move)	■						■
Have this adjusted						■
Check the machine	■						■
Clean the machine		■					■
Replace the safety label						■

Technical specifications

Drive unit type BAE 30
Year of construction See last page
Max. engine output at a certain speed 1.0 kW
Cubic capacity 29.7 cm3
No-load speed n0 2800 ± 200min	-1
Max. engine speed 8500 min	-1
Ignition system electronic ignition - CDI
Spark plug TORCH L8RTC or equivalent
Fuel tank capacity 450 ml
Ratio of mixture (fuel/two-stroke oil) 40:1
Spark gap 0.6 – 0.7 mm
Measured sound power level LWA 109.8 dB (A) (according to regulation 2000/14/EG)
Guaranteed sound power level LWA	114 dB (A) (according to regulation 2000/14/EG)
Sound pressure level LPA 95 dB (A)
Measuring uncertainty K 3.0 dB (A)
Hand arm vibration	5.5 m/s2
Brushcutter / grasstrimmer	K = 1.5 m/s2
Hedge trimmer 11.2 m/s2	K = 1.5 m/s2
Power pruner Front handle: 8.5 m/s	2
	Rear handle: 12.7 m/s2
	K = 1,5 m/s2
Weight (without fuel/oil and attachment tool)	4,5 kg
Brushcutter / grasstrimmer type	BFG 30
Engine speed with cutting tool	8500 / 7500 min-1
Max. speed of cutting tool	6400 / 5600 min-1
Cutting diameter	230 x 1,6 mm x 4 teeth / ∅ 420 mm - double thread
Weight (without fuel/oil and attachment tool)	6.3 kg
Hedge trimmer type	BHS 30
Engine speed with cutting tool	7500 min-1
Max. cutting length	400 mm
Length of sword (Length of the cutting blade)	425 mm
Weight (without fuel/oil and attachment tool)	6.7 kg
Power pruner	BHE 30
Max. engine speed with cutting tool	7500 min-1
Guide bar (sword)	Oregon – 100SDEA318
Max. cutting length	255 mm
Saw chain type	Oregon – 91 P0 x 40
Pitch / drive link thickness	9.525 mm (3/8") / 1.27 mm (.050")
Chain wheel	7 x 9.525 mm
Chain oil tank capacity	150 ml
Weight (without fuel/oil and attachment tool)	7.5 kg
Engine driven garden maintenance set
Engine driven garden maintenance set	BMGS 30= BAE30 + BFG 30 + BHS 30 + BHE 30
Brushcutter + grasstrimmer	BFSGT 30= BAE 30 + BFG 30
Hedge trimmer	BHH 30= BAE 30 + BHS 30
Power pruner	BKSH 30= BAE 30 + BHE 30
Brushcutter + grasstrimmer + Power pruner	BFGH 30= BAE 30 + BFG 30 + BHE 30

Possible faults

Before each fault elimination:

• Switch off device.
• Wait until the cutting device does not longer move.
• Remove the spark plug connector.
• Wear gloves.

After each fault clearance, put into operation and recheck all security installations.

Fault code Possible cause Corrective action
Motor does not start	Incorrect starting sequenceAir filter contaminated.Fuel filter fouledNo fuel supplyFault in the fuel lineCranking mechanism defectiveEngine flooded.Spark plug connector not placed on.No ignition spark.Engine defective.Carburettor defective	Observe the correct starting sequenceClean or replace the air filterClean or replace the fuel filterFill the fuel tank.Check the fuel line for kinks or damagesContact the customer serviceScrew off, clean and dry the spark plug. Then pull the cranking rope several times and reinstall the spark plugPlace on the spark plug connector.a) Clean or replace the spark plug.b) Check the ignition cable.c) Fault cannot be eliminated?Contact the customer serviceContact the customer serviceContact the customer service
Engine starts and is stalled immediately	Incorrect idle adjustment	Contact the customer service
Engine is running, cutting device does not move	Cutting device blocked (jammed material)Internal faultClutch defective	Stop the engine and remove the objectManufacturer or responsible customer service must be calledManufacturer or responsible customer service must be called
Device works with interruptions	Carburretor incorrectly adjustedSpark plug fouledInternal faultON / OFF switch defective	Contact the customer serviceClean or replace the spark plug. Check the spark plug connectorContact the customer serviceContact the customer service
Smoke Incorrect fuel mixtureCarburretor incorrectly adjustedMachine overload.Air filter contaminatedCarburretor incorrectly adjustedSilencer blocked	Carburretor incorrectly adjustedMachine overloaded.Air filter contaminatedCarburretor incorrectly adjustedSilencer blocked	Use two-stroke oil, ratio of mixture 40:1Contact the customer serviceDo not excessively press during trimming/mowingClean or replace the air filterContact the customer serviceClean the outlet of the silencer
The brushcutter does not work with full output	Cutting blade dull or damagedDevice overloaded as grass too high.	Have the cutting blade sharpened or replace itTrim the grass in several passes.
The grasstrimmer does not work with full output	Cutting thread too short/broken.Device overloaded as grass too high.	Follow up the cutting thread.Trim the grass in several passes
Cutting thread is not followed up.	No more thread on the spool.Cutting thread entangled.	Replace the thread spool.Recoil the cutting thread.
Cutting device gets hot	Missing lubrication → frictionNot enough playCutting blades are blunt	Oil the cutting deviceAdjust the sliding playHave the cutting device sharpened
Power pruner picks, vibrates or does not saw correctly	Chain edgelessChain wornChain not correctly stretchedChain not assembled correctly (teeth face to wrong direction)	Chain must be regrinded or exchangedExchange chainCheck and adjust chain tensionAssemble chain again
Saw chain gets hot	No oil in the tankOil flow canal blockedChain tension too highChain edgeless	Refill oilClean oil flow canalAdjust chain tensionChain must be regrinded or exchanged
No saw chain lubrication	No oil in the tankOil flow canal blocked	Refill oilClean oil flow canal

EC Declaration of Conformity

according to Directive: 2006/42/EG

We

ATIKA GmbH

Josef-Drexler-Str. 8 – 89331 Burgau – Germany

herewith declare under our sole responsibility that the products:

are conform with the above mentioned EC directives as well as with the provisions of the guidelines below:

2000/14/EG, 2014/30/EC.

Following harmonized standards have been applied:

EN ISO 11806-1:2011 (Brushcutter / grass trimmer)

EN ISO 10517:2009+A1:2013 (Hedge trimmer)

EN ISO 11680-1:2011 (Power pruner)

conformity assessment procedure: 2000/14/EC - Appendix V

Measured level of the acoustic output L_WA : 109.8 dB(A).

Guaranteed level of the acoustic output L_WA : 114 dB(A).

Duly authorised person for the compilation of technical documents:

ATIKA GmbH – Technical department – Josef-Drexler-Str. 8 – 89331 Burgau – Germany

Burgau, 10.08.2016

i.A. f~ h~

i.A. G. Koppenstein, Engineering design management

Torch L8RTC, NGK-BPMR 7 A, BOSCH WSR6F, OREGON O-PR15Y, Champion RCJ 6Y

Torch L8RTC, NGK-BPMR 7 A, BOSCH WSR6F, OREGON O-PR15Y, Champion RCJ 6Y

Torch L8RTC, NGK-BPMR 7 A, BOSCH WSR6F,

OREGON O-PR15Y, Champion RCJ 6Y

Torch L8RTC, NGK-BPMR 7 A, BOSCH WSR6F,

OREGON O-PR15Y, Champion RCJ 6Y

Ontstekingsvonk controleren

Vibrationer (Hand-arm-vibration)

Främre handtag: ahveq= 8,5 m/s²

Bakre handtag: ahveq= 12,7 m/s²

Torch L8RTC, NGK-BPMR 7 A, BOSCH WSR6F, OREGON O-PR15Y, Champion RCJ 6Y

Handwritten signature or scribble on a line, possibly from a document or form

i.A. G. Koppenstein, Designledning

D Baujahr
GB Year of construction
Année de construction
E Año de fabricación
Anno di costruzione
NL Bouvwjaar
s Tillverkningsår

ATIKA GmbH

Josef-Drexler-Str. 8, 89331 Burgau • Germany

Tel.: [phone] • Fax: [phone]

E-mail: [e-mail] • Internet: www.atika.de

Close-up of a textured surface with parallel fibrous patterns (no text or symbols visible)
