Product typeSubmersible pump for clean and lightly loaded water
BrandFuxtec
ModelFXRTP350
Power350 W
Supply voltage230 V / 50 Hz
Maximum flow rate5200 l/h
Maximum delivery head11 m
Maximum immersion depth7 m
Maximum liquid temperature35 °C
Maximum particle size5 mm
Protection ratingIPX8
Power cable length10 m
Dimensions (L × W × H)400 × 200 × 130 mm
Weight4.3 kg
Float switchYes, for automatic start/stop
Multifunction hose connectionIncluded
Accessories suppliedConnection piece, universal adapter, 2 O-rings, instruction manual
Housing materialReinforced plastic (standard model)
UseDrainage, tank emptying, rainwater pumping, chlorinated water
Required safety deviceResidual current circuit breaker 30 mA
MaintenanceRinse with clean water after use, check float every 3 months
WarrantyCE conformity, subject to manufacturer's conditions
RecyclingDo not dispose of with household waste, take to recycling center

Frequently Asked Questions - FXRTP350 Fuxtec

What is the maximum immersion depth of the FXRTP350 pump?
The maximum immersion depth is 7 meters. Never immerse the pump beyond this depth.
What liquids can the pump handle?
The pump is suitable for drinking water, rainwater, chlorinated water, and lightly loaded water (particles up to 5 mm). Do not pump flammable, corrosive, or abrasive liquids.
How to install the pump correctly in a basin?
Place the pump on a flat and stable surface. Tilt it at 45 degrees during immersion to reduce air pockets. Ensure the float switch can move freely.
What to do if the pump does not start?
Check that the pump is plugged in and the residual current circuit breaker has not tripped. Ensure the float switch is not blocked. If the problem persists, contact an electrician.
Why does the flow rate decrease?
Clean the suction slots and the impeller. Check that the outlet hose is not obstructed and its diameter is sufficient. The delivery head must not exceed 11 m.
Can the pump operate continuously?
No, the pump is not designed for continuous operation. It is intended for intermittent use (emptying, drainage). Let it cool down after 20-30 minutes of use.
How to maintain the pump after use?
Rinse it with clean water after each use. For permanent installation, check the float operation every 3 months. Protect it from frost.
What accessories are supplied with the pump?
The delivery includes: a connection piece, a universal adapter, two O-rings, and the instruction manual. No hose is provided.
What electrical protection is mandatory?
The pump must be connected to a circuit protected by a 10/30 mA residual current circuit breaker. Use an outdoor extension cable with a minimum cross-section of 1.5 mm² fully unrolled.
What to do if the pump suddenly stops?
Unplug the pump and let it cool down for 20-30 minutes. Check that the inlet is not blocked, the liquid temperature is below 35°C, and the supply voltage is 230 V.
