AD 4620 - Hand blender ADLER - Free user manual and instructions

Product type	Immersion blender
Brand	Adler
Model	AD 4620
Rated power	500 W
Supply voltage	220-240 V, 50/60 Hz
Number of speeds	2 (I and II)
Maximum operating time	15 seconds (hard foods: 10 seconds)
Pause before reuse	3 minutes
Included accessories	Mixing shaft, chopper (bowl + blade + lid), whisk (gear unit + whisk), beaker
Main functions	Mix, chop, whisk
Recommended uses	Sauces, soups, mayonnaises, baby food, milkshakes, meat, cheese, onions, herbs, cream, egg whites, sponge cakes
Safety instructions	Do not immerse the motor unit; unplug before cleaning; do not use hot oil/fat; do not crush ice, bones, nuts; blades are very sharp
Cleaning	Wipe the motor unit with a damp cloth; wash accessories with soapy water; do not use abrasive pads
Maintenance	Do not use steel wool; dry thoroughly after washing
Repairability	Entrust to a professional service center; do not repair yourself
Children compatibility	Use possible from 8 years under supervision; cleaning by children over 8 years under supervision
Warranty	Different conditions for commercial use (see manual)
Environment	Do not dispose with household waste; recycle at a collection point

Frequently Asked Questions - AD 4620 ADLER

How to use the immersion blender?

Attach the mixing shaft to the motor unit by turning until it locks. Place the shaft into the container, then press the speed button I or II. Hold the blender with one hand and the container with the other.Do not exceed 15 seconds of continuous operation.

Can I crush ice with this appliance?

No, the appliance is not designed to crush ice, bones, nuts or coffee. These uses may damage the motor or blades.

What is the maximum continuous operation time?

The maximum duration is 15 seconds for regular foods and 10 seconds for hard foods. After each use, let the appliance cool down for at least 3 minutes.

How to clean the appliance?

Always unplug the appliance before cleaning. Wipe the motor unit with a slightly damp cloth and polish with a dry cloth. Wash the accessories (shaft, whisk, blade, bowl) with soapy water, rinse and dry. Never immerse the motor unit.

Is the appliance suitable for children?

Yes, from 8 years under the supervision of a responsible adult. Children must not play with the appliance. Cleaning can be done by children over 8 years only under supervision.

What to do if the appliance does not work?

First check the power outlet and the cable. If the cable is damaged or the appliance does not start, do not repair it yourself. Entrust it to an authorized professional service center.

Can I use the chopper for bones?

No, the chopper is intended for foods like meat, cheese, onions and herbs. Do not use for bones or very hard foods.

How to attach the accessories?

For the mixing shaft: align and turn until it locks onto the motor unit. For the chopper: place the blade on the bowl, add food, close the lid by turning, then attach the motor unit. For the whisk: attach the whisk to the gear unit, then the motor unit on top.

What is the power of the appliance?

The rated power is 500 W with a voltage of 220-240 V and a frequency of 50/60 Hz.

Can the appliance be used for hot foods?

No, never use for hot oil or fat. The immersion blender is suitable for lukewarm or cold foods. Using with hot liquids may cause splashing and damage the appliance.

USER MANUAL AD 4620 ADLER

White ADLER brand stand mixer with whisk, plastic cup, and side bowl (no visible text or symbols)

AD 4620

SAFETY CONDITIONS IMPORTANT INSTRUCTIONS ON SAFETY OF USE PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

The warranty conditions are different, if the device is used for commercial purpose.

1. Before using the product please read carefully and always comply with the following instructions. The manufacturer is not responsible for any damages due to any misuse.
2. The product is only to be used indoors. Do not use the product for any purpose that is not compatible with its application.
3. The applicable voltage is 220-240V, 50/60Hz. For safety reasons it is not appropriate to connect multiple devices to one power outlet.
4. Please be cautious when using around children. Do not let the children to play with the product. Do not let children or people who do not know the device to use it without supervision.

5.WARNING: This device may be used by children over 8 years of age and persons with reduced physical, sensory or mental capabilities, or persons without experience or knowledge of the device, only under the supervision of a person responsible for their safety, or if they were instructed on the safe use of the device and are aware of the dangers associated with its operation. Children should not play with the device. Cleaning and maintenance of the device should not be carried out by children, unless they are over

8 years of age and these activities are carried out under supervision.

1. After you are finished using the product always remember to gently remove the plug from the power outlet holding the outlet with your hand. Never pull the power cable!!!

2. Never put the power cable, the plug or the whole device into the water. Never expose the product to the atmospheric conditions such as direct sun light or rain, etc.. Never use the product in humid conditions.

3. Periodically check the power cable condition. If the power cable is damaged the product should be turned to a professional service location to be replaced in order to avoid hazardous situations.

4. Never use the product with a damaged power cable or if it was dropped or damaged in any other way or if it does not work properly. Do not try to repair the defected product yourself because it can lead to electric shock. Always turn the damaged device to a professional service location in order to repair it. All the repairs can be done only by authorized service professionals. The repair that was done incorrectly can cause hazardous situations for the user.

5. Never put the product on or close to the hot or warm surfaces or the kitchen appliances

like the electric oven or gas burner.

1. Never use the product close to combustibles.

2. Do not let cord hang over edge of counter or touch hot surfaces.

3. Never leave the product connected to the power source without supervision. Even when use is interrupted for a short time, turn it off from the network, unplug the power.

4. In order to provide additional protection, it is recommended to install residue current

device (RCD) in the power circuit, with residual current rating not more than 30 mA. Contact professional electrician in this matter.

1. The exchange of accessories may only be carried out with the device switched off.
2. The blades are very sharp. The highest caution is offered. Before replacing the mixers, unplug the power cord from the wall outlet.
3. Only use original accessories that are included in the scope of supply.
4. Do not cover the ventilation openings in the housing during operation.
5. For washing the case, do not use any heavy cleaning agents because they can be used to remove graphical information symbols, e.g. Signs, warning photograms, etc.

6. Never use the appliance for hot oil or grease (hot products).

7. Never touch with wet hands.

8. The appliance is not intended for crushing ice, bone and other hard products or for grinding nuts and coffee.

9. During the mixing process, never place your hands or cutlery into the container.

10. Observe the maximum uninterrupted operating time of the unit of 15 seconds. After the continuous operating time of 15 seconds, wait 3 minutes before turning the unit back on. Exceeding the operating time of the appliance and the absence of sufficient breaks can lead to irreversible engine damage.

11. When the appliance is dirty unplug it from the mains before cleaning.

12. Before first use, wash thoroughly and dry the appliance (see: Cleaning and maintenance).

PRODUCT DESCRIPTION

1. BLENDER

a) ON/OFF switch, I speed b) ON/OFF switch, II speed c) motor part

d) blending shaft (removable)

1. CHOPPER

a) lid b) chopping blade c) chopper bowl d) anti-slip rubber ring

1. WHISK

a) gearbox b) whisk

1. BEAKER

USING THE DEVICE

The hand blender is perfectly suited for preparing dips, sauces, soups, mayonnaise and baby food as well as for mixing and milkshakes.

1. Attach the blending shaft (1d) to the motor part (1c). Turn it until it is locked.

2. Place the blending shaft into the beaker (4). Then press the button I speed (1a) or II speed (1b).

During processing, always hold the blender with one hand and the beaker (4) in the other hand.

1. After use, unplug the device from a power socket. Remove blending shaft (1d) from the motor part (1c).

USING CHOPPER AND WHISK

Chopper: Chopper is perfectly suited for food, such as meat, cheese, onion, herbs, etc.

1. Always place the chopper bowl (2c) on the flat, dry surface. Place the chopping blade (2b) on the center pin of the chopper bowl (2c).

2. Place the food in the chopper bowl (2c).

3. Cover the chopper bowl (2c) with the lid (2a). Press and turn it until it locks.

4. Attach the motor part (1c) to the chopper's lid (2a). Turn it until it locks.

5. Press desired speed button (1a) or (1b).

During processing, hold the blender with one hand and the chopper bowl with the other hand.

1. After use, unplug the device from a power socket. Detach motor part (1c) from the lid (2a). Open the lid (2a) and carefully take off the chopping blade (2b).

Whisk: Use the whisk only for whipping cream, beating egg whites and mixing sponges and ready-mix desserts.

1. Attach the whisk (3b) to the gearbox (3a). Turn it until it locks.

2. Attach the motor part (1c) to the assembled whisk.

3. Press desired speed button (1a) or (1b).

During processing, hold the blender with one hand and the beaker (4) with the other hand.

To avoid spreading always mix more liquid contents in the beaker (4).

1. After use release the speed button and remove whisk attachment from the motor part (1c). Unplug the device from a power socket.

CLEANING AND MAINTENANCE

Never put motor part (1c) into water and keep away from wet. Before cleaning always switch off device and unplug from the power socket.

1. Wipe the outside of the motor part (1c) with only a slightly moistened cloth and polish with a soft dry cloth.
2. Wash the detachable accessories in soap water, such as blender shaft, whisk, chopper blade.
   Do not use scouring pads for the plastic materials. Rinse them with clear water and dry them.
3. Do not clean with any abrasive scouring pad or steel wool, as this will damage the finish of the appliance.

TECHNICAL DATA

Nominal power: 500W Voltage:220-240V, 50/60Hz

Max operating time: 15s, hard food- no longer than 10s

Time break before the re-use of device: 3min

Please transfer cardboard packaging to waste paper. Pour the polyethylene bags (PE) into the plastic container Worn device should be returned to the appropriate point storage because it is dangerous in the device ingredients may pose a threat to the environment. The electrical device should be handed over to limit its reuse and use. If in the device there are batteries you have to take out and give to the point stored separately.

(DE) DEUTSCH

PRODUCT BESCHRIJVING

Grid of handwritten Chinese characters in a grid layout, possibly a form or checklist with checkboxes and a central logo.
