USER MANUAL HV 7168 SEVERIN

• Nur mit einem funktionstüchtigen Akku ist das Gerät wieder einsatzbereit. Falls kein funktionstüchtiger Akku eingesetzt wurde, Gerät nicht in Betrieb nehmen. 10 Entsorgen Geräte und Akkus, die mit diesem Symbol gekennzeichnet sind, müssen getrennt vom Hausmüll entsorgt werden. Diese Geräte und Akkus enthalten wertvolle Rohstoffe, die wiederverwertet werden können. Eine ordnungsgemäße Entsorgung schützt die Umwelt und die Gesundheit Ihrer Mitmenschen. Gerät und den ausgebauten Akku separat zur Entsorgung an die entspre- chenden Sammelstellen geben. Ihre Gemeindeverwaltung oder Ihr Fachhändler gibt Auskunft zur ordnungsgemäßen Entsorgung.16 GaranTiE 11 Garantie Von den nachfolgenden Garantiebedingungen bleiben die gesetzlichen Gewährleistungsrechte gegenüber dem Verkäufer und eventuelle Verkäufergarantien unberührt. Sollte eine Reparatur erforderlich werden, setzen Sie sich telefonisch oder per E-Mail mit unserem Kundendienst in Verbindung. Die Kontaktdaten nden Sie im Anhang dieser Gebrauchsanleitung. Wenden Sie sich im Garantiefall alternativ auch direkt an den Händler. Zusätzlich gewährt SEVERIN eine Herstellergarantie von zwei Jahren ab Kaufdatum. In diesem Zeitraum beseitigen wir kostenlos alle Mängel, die nachweislich auf Material- oder Fertigungsfehlern beruhen und die Funktion wesentlich beeinträchtigen. Weitere Ansprüche sind ausgeschlossen. Von der Garantie ausgenommen sind: Schäden, die auf Nichtbeachtung der Gebrauchsanleitung, unsachge- mäße Behandlung oder normalen Verschleiß zurückzuführen sind, ebenso leicht zerbrechliche Teile wie z. B. Glas, Kunststoff oder Glühlampen. Die Garantie erlischt bei Eingriff nicht von SEVERIN autorisierter Stellen. Wenn Ihnen diese Tabelle nicht weiterhilft, wenden Sie sich an unseren Kundendienst. Die Kontaktdaten nden Sie im Anhang dieser Gebrauchsanleitung oder auf www.severin.de.17 GaranTiE18 Thank you! Dear Customers, We hope you will enjoy your high-quality SEVERIN product and thank you for placing your trust in us. Gb19 About this instruction manual This instruction manual includes important tips for your safety and the use of the appliance. Failure to observe the instruction manual can result in personal injuries or damage to the appliance. Keep the instruction manual in a safe place. When passing the appliance on to a third party, also include the instruction manual. Read the instruction manual completely before initial use of the appliance. Illustrated Quick Start Guide included This instruction manual comes with an Quick Start Guide that provides you with additional tips for the use and care of the appliance. If needed, this instruction manual and the Quick Start Guide can be downloaded online free of charge at www. severin.de. Contents 1 Technical data p. 20
• 2 Safety instructions p. 21
• 3 Installing and charging the appliance p. 26
• 4 Vacuum cleaning p. 27
• 5 Cleaning and maintaining the appliance p. 28
• 6 Storing the appliance p. 30
• 7 Spare parts/accessories p. 30
• 8 Troubleshooting by yourself p. 30
• 9 Removing/replacing the rechargeable battery p. 32
• 10 Disposal p. 32
• 11 Warranty Gb20 TEchnical DaTa 1 Technical data Item number: HV 7168 Lithium-ion battery: 25.2 V / 2,500 mAh Mains adapter: 30 V DC / 0.8 A 24 W Power: 400 W Dust capacity: 400 ml Suction power: 23 kPa Runtime: approx. 10 min (Power mode) / approx. 30 min (Middle mode) / approx. 60 min (Eco mode) Marking on the appliance: The appliance complies with all EU directives that are binding for CE certication. The appliance and its rechargeable battery must be disposed of separately from household waste at a proper disposal site. Scope of delivery Vacuum cleaner Mains adapter Wall mount including fastening material Floor nozzle with rotating brush roller 2-in-1 tool Crevice nozzle21 safETy insTrucTions 2 Safety instructions Certain groups of persons This appliance may only be operated by children over the age of 8 and by persons with reduced physical, sensory or mental capacities or a lack of experi- ence and/or knowledge if they are supervised or have been instructed about the safe use of the appliance and are aware of the dangers associated with its use. Children are not allowed to play with the appliance or stand or sit on it. Cleaning and user maintenance may not be performed by children without supervision. Children under the age of 8 must be kept away from the appliance and the mains adapter. The packaging material must not be used for play purposes. There is a risk of suffocation. Connecting the appliance safely The appliance is charged with electrical current. Thus, there is a risk of electric shock. Therefore: Check the appliance and mains adapter for possible damage before use. Never operate a defective appliance or an appliance with a defective mains adapter. Only connect the mains adapter to sockets which match the specications on the mains adapter type plate.22 safETy insTrucTions Never attempt to repair the appliance or its mains adapter yourself. To prevent hazards, repairs to the appliance and the mains adapter may only be made by our customer service. Arrange repair of a defective appliance with a specialist dealer or contact SEVERIN customer service (see contact information in appendix to this instruction manual or at www.severin.de). Do not immerse the appliance or mains adapter in water or other liquids, or treat with liquids. Keep the appliance and the mains adapter away from rain and wet conditions. Do not operate the appliance and mains adapter outdoors or in rooms with high humidity. Do not handle the appliance or mains adapter with wet hands. When un- plugging the mains adapter from the socket, always pull directly on the plug. Make sure that the cable of the mains adapter is not kinked, pinched or run over and that it does not come in contact with sources of heat, humidity and sharp edges. Make sure that the cable of the mains adapter does not become a trip hazard. Before cleaning or servicing the appliance and before changing acces- sories, switch off the appliance and make sure that the mains adapter is not connected.23 safETy insTrucTions Safety when handling rechargeable batteries If rechargeable batteries are handled improperly, there is a risk of injury and explosion. Never replace the rechargeable battery with other rechargeable batteries or other non-rechargeable batteries. Only use identical rechargeable batteries. Never short-circuit rechargeable batteries, i.e. never touch both poles at the same time, especially not with objects that conduct electricity. Store recharge- able batteries so that they cannot be short-circuited by other rechargeable batteries or metal objects during storage. To charge the rechargeable battery, only use the mains adapter included in the delivery. Never charge the rechargeable battery with another mains adapter. Only use the mains adapter included in the delivery to charge the rechargeable battery of this appliance. At the end of its life span, remove the rechargeable battery as described. Then take the rechargeable battery to an appropriate collection point nearby without delay, thus ensuring safe and environmentally-appropriate disposal. Never dispose of the rechargeable battery in household waste. Before removing the rechargeable battery, make sure that the mains adapt- er is unplugged from the socket. Never take the rechargeable battery apart, expose it to high temperatures or throw it onto res. In case of improper handling, liquid can escape from the rechargeable bat- tery. Do not use the rechargeable battery if it is damaged or if it is leaking liquid. If liquid has escaped, avoid contact with the liquid. In case of contact with the liquid, rinse it off immediately with copious amounts of water. In case of after effects (irrespective of type), consult a doctor.24 safETy insTrucTions Rotating brush roller The appliance contains a powered brush roller. This can cause injuries. There- fore, note the following: Before cleaning or maintaining the appliance, make sure that the appliance is switched off and is not on charge. Ensure that parts of your body can never get under the brush roller. Do not vacuum near cables, wires and long fringes. On the one hand, there is a danger that the cable's insulation will be damaged. On the other hand, these objects can get caught in the brush roller and thereby damage the appli- ance. LED lighting LEDs are installed in the oor nozzle. These illuminate the work area in front of the oor nozzle. Do not look into the LEDs during operation. It is not possible to exchange the LEDs. Intended use The appliance must only be used domestically. The appliance may only be used for cleaning on level, normally-soiled surfac- es, short-pile carpets or upholstery that can withstand exposure to the rotating brush without sustaining damage. Any other use is deemed improper and is forbidden.25 safETy insTrucTions In order to prevent injuries, res and damage, the appliance must not be used to vacuum: People, animals and plants. Always keep appliance away from all body parts, hair and clothing. Do not vacuum near the head. Glowing, burning or smouldering particles (such as ash, coal, charcoal, cigarettes, matches). Explosive or highly ammable substances or toners. Water and other liquids, e.g. wet carpet cleaning agents. Sharp objects, such as glass splinters, nails or construction waste. The following is also forbidden: Independent alteration or repair of the appliance or its mains adapter. Inserting objects into the appliance's openings. The specially provided accessories are the exception to this rule. Use, storage or charging outdoors. If the appliance is defective Have a defective appliance repaired by a specialist dealer or customer service (see contact information in the appendix to this instruction manual or at www.severin.de).26 insTallinG anD charGinG ThE appliancE 3 Installing and charging the appliance For additional installation tips, see Quick Start Guide Installation. Installing the wall mount 1. Select an attachment location within drilling range of a socket.2. Hold the wall mount to the wall, aligned in a vertical position.3. Mark the drilled holes with a pencil.4. Drill the holes (approximately 8 mm Ø).5. Insert the dowels included in the delivery into the holes.6. Fasten the wall mount using the screws included in the delivery. Charging the rechargeable battery The rechargeable battery needs to be charged before rst use. It is best to charge the rechargeable battery before each use, especially after the appliance has not been used for a while. This increases the service life of the rechargeable battery and ensures the longest possible cleaning cycles.1. Plug the connector for the mains adapter included in the delivery into the connection socket on the rechargeable battery.2. Connect the mains adapter included in the delivery to a socket. The LEDs on the rechargeable battery start to ash. The charging process starts. The more the LEDs ash, the more advanced the charging process is. The LEDs go out once the rechargeable battery is fully charged. The charging process takes around 3 hours when the rechargeable battery is empty.3. Disconnect the mains adapter from the socket.4. Disconnect the mains adapter’s connector from the connection socket on the appliance.TIP: The operating time with a fully charged rechargeable battery is approx. 10 minutes (in Power mode), approx. 30 minutes (in Middle mode) or approx. 60 minutes (in Eco mode). For further information, see also illustrated Quick Start Guide. p. 32

Vacuum clEaninG 4 Vacuum cleaning For further tips, see Quick Start Guide Operation. Vacuuming with the oor nozzle TIP: The oor nozzle can also be used without the suction tube in order to vacuum furniture, for instance. In this regard, make sure that the surface can withstand the load of the brush roller without sustaining damage. Vacuuming in Eco mode The appliance vacuums at the lowest power in Eco mode. The appliance consumes less energy and the oper-ating time of the rechargeable battery is extended. The brush roller on the oor nozzle rotates.1. Attach the oor nozzle to the suction tube.2. Press the On/off switch to switch on the appliance. The appliance vacuums in Eco mode. The LEDs on the rechargeable battery light up. The LEDs on the oor nozzle illuminate the work area in front of the oor nozzle. 3. Vacuum the oor.4. Press the On/off switch to switch off the appliance.5. Empty and clean the dust container (“Emptying the dust container” on page 28). Vacuuming in Middle or Power mode The appliance vacuums at medium power in Middle mode. The appliance vacuums at full power in Power mode. The brush roller on the oor nozzle rotates.1. Attach the oor nozzle to the suction tube.2. Press the On/off switch to switch on the appliance. The appliance vacuums in Eco mode. The LEDs on the rechargeable battery light up. The LEDs on the oor nozzle illuminate the work area in front of the oor nozzle. 3. Press the mode selector switch to select the operating mode. Press 1x to activate Middle mode. Press 2x to activate Power mode. Press 3x to activate Eco mode again.4. Vacuum the oor.5. Press the On/off switch to switch off the appliance.6. Empty and clean the dust container (“Emptying the dust container” on page 28).28 clEaninG anD mainTaininG ThE appliancE Vacuuming with the 2-in-1 tool or crevice nozzle TIP: The 2-in-1 tool or the crevice nozzle can also be used without the suction tube in order to vacuum furniture, for instance. 1. Attach the 2-in-1 tool or crevice nozzle to the suction tube.2. Press the On/off switch to switch on the appliance. The appliance vacuums in Eco mode. The LEDs on the rechargeable battery light up.3. If necessary, press the mode selector switch again to select a different operating mode. Press 1x to activate Middle mode. Press 2x to activate Power mode. Press 3x to activate Eco mode again.4. Vacuum the oor.5. Press the On/off switch to switch off the appliance.6. Empty and clean the dust container (“Cleaning the dust container and cyclone unit” on page 29).TIP: The LEDs start to ash independently of the attachment when the battery charge is running low. The appliance switches off automatically when the battery charge is too low. Charge the rechargeable battery (“Charging the rechargeable battery” on page 26). 5 Cleaning and maintaining the appliance For additional information on all cleaning and maintenance tasks, see illustrated Quick Start Guide. Cleaning the appliance 1. Make sure that the appliance is switched off and is not on charge.2. Wipe the housing with a slightly damp cloth and then rub it dry.TIP: Do not use any sharp, abrasive cleaning agents or hard brushes for cleaning. Emptying the dust container The dust container can only hold a limited quantity of dirt. For this reason, empty the dust container after each cleaning procedure or if the dust reaches the MAX mark.1. Make sure that the appliance is switched off and is not on charge.2. Open the ap on the underside of the dust container.3. Empty the dust container into a waste bin.4. Close the ap on the underside of the dust container again.29 clEaninG anD mainTaininG ThE appliancE Cleaning the dust container and cyclone unit The cyclone unit should be cleaned if the suction power decreases when the rechargeable battery is fully charged.

1. Make sure that the appliance is switched off and is not on charge.

3. Remove the cyclone unit from the dust container and knock it out over a waste bin and remove any dirt

with a soft brush as necessary.

4. Remove the foam ring from inside the cyclone unit.

5. Clean the foam ring under running water and then leave it to dry.

6. Rinse out the dust container with clear water and then let it dry.

7. Next, put the foam ring and cyclone unit together and insert in the dust container.

8. Install and secure the dust container.

Cleaning the exhaust lter The exhaust lter cannot be washed. The exhaust lter may only be cleaned when it is dry. To clean it, knock it out and brush it carefully.

1. Unlock and remove the exhaust lter.

2. First knock out the exhaust lter and then brush it carefully with a soft brush (e.g. with the furniture brush

3. Reinsert the exhaust lter in the device and press on it until it audibly locks in place.

If the lter is damaged or deformed, replace the lter with a new one (“7 Spare parts/accessories” on page 30). Cleaning the brush roller Soiling may prevent the brush roller from rotating freely. Clean the brush roller regularly. For additional informa- tion, see illustrated Quick Start Guide Cleaning.

1. Make sure that the appliance is switched off and is not on charge.

2. Disconnect the oor nozzle from the suction tube.

3. Unfasten the stop catch for the brush.

4. Remove the stop catch.

5. Remove the brush.

6. Remove any hairs and dirt from the brush; if necessary, use tweezers or scissors and do so carefully.

7. Re-insert the brush and secure it with the stop catch.30

sTorinG ThE appliancE 6 Storing the appliance Store the appliance and accessories in a cool, dry place out of the reach of children. The additional attachments can also be stored on the wall mount. 7 Spare parts/accessories You can easily order spare parts or accessories online at www.severin.de in the Service Spare Parts Shop menu. Order number Accessories/spare part 9815-048 Foam ring of the cyclone unit 1958-048 Brush roller 9818-048 Rechargeable battery 9820-048 Mains adapter 9816-048 Exhaust lter 8 Troubleshooting by yourself To ensure that you do not encounter any problems, it is important to empty the dust container regularly and take this opportunity to check the lters and clean them if they are dirty. However, if you do encounter any problems with the appliance, use the following table to determine whether you can solve the problem yourself. Before troubleshooting, switch off the appliance and disconnect the power plug from the socket. Problem Possible cause/solution Appliance cannot be switched on. The rechargeable battery has not been inserted correctly. Reinsert the rechargeable battery into the appliance (“9 Removing/replacing the rechargeable battery” on page 32). The rechargeable battery is completely discharged. The LEDs on the rechargeable battery are no longer illuminated. Switch off the appliance and charge the rechargeable battery (“Charging the rechargeable battery” on page 26).31 TroublEshooTinG by yoursElf Problem Possible cause/solution Appliance cannot be charged (LEDs do not light up). The rechargeable battery has not been inserted correctly. Discon- nect the mains adapter. Reinsert the rechargeable battery into the appliance. Connect the mains adapter again (“9 Removing/replac- ing the rechargeable battery” on page 32). The mains adapter is not plugged in correctly: Check whether the mains adapter’s connector and the mains adapter are connected rmly to their sockets (“Charging the rechargeable battery” on page 26). The rechargeable battery is fully charged but the appliance is hardly picking up any dirt. The dust container needs to be emptied or the cyclone unit needs to be cleaned (“Emptying the dust container” on page 28, “Clean- ing the dust container and cyclone unit” on page 29). Operating duration is becoming ever shorter. The brush roller is soiled and needs to be cleaned (“Cleaning the brush roller” on page 29). The cyclone unit is soiled and needs to be cleaned (“Cleaning the dust container and cyclone unit” on page 29). The brush roller rotates slowly or irregularly. The brush roller is soiled and needs to be cleaned (“Cleaning the brush roller” on page 29). If this table does not help, please contact our customer service. The contact information can be found in the appendix to this instruction manual or at www.severin.de.32 rEmoVinG/rEplacinG ThE rEcharGEablE baTTEry 9 Removing/replacing the rechargeable battery Before any tasks involving the rechargeable battery, switch off the appliance and disconnect the power plug from the socket.

1. Push the rechargeable battery stop catches together.

2. Remove the rechargeable battery from the rechargeable battery compartment.

3. If necessary, replace the rechargeable battery with a new one (“7 Spare parts/accessories” on page 30)

and insert it in the rechargeable battery compartment.

4. Close the rechargeable battery compartment.
