USER MANUAL 37702 SILVERCREST

Cleanerworld GmbH Am Schützenbaum 19, 97953 Königheim (Germany) Telefon: 01805 212784 Fax: 01805 212785 Garantie Garantiekarte Firma und Sitz des Verkäufers: Serviceadresse: Telefon Hotline: Email: Hersteller- / Importeurbezeichnung: Produktbezeichnung: Produkt- / Herstellerkennzeichnungsnummer: Name des Käufers: PLZ/Ort: Straße: Tel.Nr. / email: Unterschrift: Fehlerbeschreibung:14 English Dear Customer, Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use or subsequent owners. Danger Immediate danger that can cause severe injury or even death. 몇 Warning Possible hazardous situation that could lead to severe injury or even death. Caution Possible hazardous situation that could lead to mild injury to persons or damage to property. The packaging material can be recycled. Please do not place the packaging into the ordinary refuse for disposal, but arrange for the proper recycling. Only use the steam cleaner for private house- hold applications. The unit is meant for steam cleaning and can be used with appropriate ac- cessories as described in these operating in- structions. Especially mind the safety instructions during use. When unpacking the product, make sure that no accessories are missing and that none of the package contents have been damaged. If you detect any transport damages please contact your service partner. Î Illustrations on fold-out page! Î Illustrations on Page 2 1 Remove the safety cap (A4) from the device. Fill the boiler with a maximum of 1.2 litres of fresh tap water. 2 Screw in safety cap. 3 Insert the steam plug (B6) into the appliance connector (A1). 4 Insert the mains plug (A7) into a socket. Both indicator lamps (A2/A3) must illumi- nate. Contents General information 14 Description of the Appliance 14 Safety instructions 15 Operation 16 How to Use the Accessories 18 Maintenance and care 19 Troubleshooting 20 Technical specifications 21 Disposal information 21 CE declaration 21 Warranty 22 General information Hazard levels Environmental protection Proper use Description of the Appliance A1 Appliance connector with cover A2 Control light (orange) – line voltage is on A3 Indicator lamp (orange) - heating A4 Safety cap A5 Holder for accessories A6 Parking holder A7 Mains cable with mains plug A8 Transport wheel (2x) A9 Steering roller B1 Steam gun B2 Unlocking button B3 Steam lever locking (child control) Front – steam lever blocked Middle – reduced steam amount Back – maximum steam amount B4 Steam lever B5 Steam hose B6 Steam plug C1 Detail nozzle C2 Round brush D1 Manual nozzle D2 Terry cloth cover E1 Extension tubes (two tubes) E2 Unlocking button F1 Floor nozzle F2 Retaining clip F3 Floor cleaning cloth H1 Steam iron H2 Temperature controller H3 Switch - steam ironing H4 Indicator lamp - steam iron heating H5 Steam plug Quick ReferenceEnglish 15 5 The orange indicator lamp (A3) goes out af- ter approximately 8 minutes. 6 Connect the required accessories to the steam gun (B1). The steam cleaner is ready to use. Danger The appliance may not be used in areas where a risk of explosion is present. If the appliance is used in hazardous areas the corresponding safety provisions must be observed. Never use the appliance in pools containing water. The device should not be used to clean elec- trical appliances such as oven, exhaust, mi- cro-wave, televisions, lamps, hair-dryer, electrical heating systems, etc. Check the condition of the appliance and ac- cessories for damage before use. Other- wise, the appliance must not be used. Please check in particular the power cord (A7), the safety lock (A4), and the steam hose (B5). If the power cord is damaged, please ar- range immediately for the exchange by an authorized customer service or a skilled electrician. Please arrange for the immediate exchange of a damaged steam hose. You may only use a steam hose that is recommended by the manufacturer. Never touch the mains plug and the socket with wet hands. Never use the appliance to clean objects containing hazardous substances (e.g. as- bestos). Never touch the steam jet from a short dis- tance with your hands and never direct the steam jet to persons or animals (risk of scalds). 몇 Warning The appliance may only be connected to an electrical supply which has been installed in accordance with IEC 60364. The appliance may only be connected to al- ternating current. The voltage must corre- spond with the type plate on the appliance. In wet rooms, e.g. bathrooms, connect the appliance to sockets with a series connected RCD adapter. Unsuitable extension cables can be hazard- ous. Only use a splashproof extension cable with a minimum section of 3x1 mm². The connection between power cord and ex- tension cable must not lie in water. If couplings of the power cord or extension cable are replaced the splash protection and the mechanical tightness must be ensured. The operator must use the appliance cor- rectly. When working with the appliance, he must consider the local conditions and pay due care and attention to other persons, in particular children, who are nearby. This device is not intended for use by per- sons (including children) with reduced phys- ical, sensory or mental abilities or lacking experience and/or knowledge, unless they are supervised by a person responsible for their safety or are instructed by these per- sons on the use of the device. Children should be supervised, to ensure that they do not play with the device. Never leave the appliance unattended when it is in operation. Be very careful while cleaning tiled walls with sockets. Caution Make sure that the power cable or extension cables are not damaged by running over, pinching, dragging or similar. Protect the power cable from heat, oil, and sharp edges. Never fill solvents, solvent-containing liquids or undiluted acids (e.g. detergents, benzene, paint thinner, and acetone) into the water reservoir as these substances affect the ma- terials used on the appliance. The appliance must provide of a stable ground. The steam switch (B4) must not be locked during the operation. Protect the appliance from rain. Do not store outside. Safety instructions16 English Caution Safety devices protect the user and must not be modified or bypassed. The pressure controller keeps the boiler pres- sure during the operation as constant as possi- ble. The heating is turned off if the maximum operating pressure of 4 bar is reached in the boil- er and is reactivated in case of a pressure drop in the boiler due to steam tapping. If the boiler thermostat fails and the appliance overheats, then the safety thermostat turns off the appliance. Please contact your local CUSTOMER SERV- ICE to arrange for the reset of the safety thermo- stat. The safety lock seals the boiler against the steam pressure that builds up in the boiler. If the pressure controller is defect and the steam pres- sure in the boiler rises, a pressure control valve in the safety lock opens, and steam is emitted through the lock to the outside. Please contact your local CUSTOMER SERV- ICE before you put the appliance into operation again. Steam CAUTION - Danger of scalding Î Illustration Insert steering roller (A9) and transport wheels (A8) and lock them. Î Tightly insert the steam plug (B6) into the ap- pliance connector (A1). The plug must click into place audibly. To detach: Press the cover of the appliance connector to the bottom and disconnect the steam plug from the appliance connector. Î Illustration Connect the required accessories to the steam gun (B1). Insert the open end of the accessory on the steam gun and push onto the steam gun until the unlocking button (B2) of the steam gun locks into place. Î Illustration Use the extension pieces (E1) if necessary. To do so, connect one or both extension pieces to the steam gun (B1). Insert the re- quired accessories on the free end of the ex- tension piece. Danger Hot water may drip out of the accessory parts while you are detaching them! Never detach ac- cessory parts while steam streams out - risk of scalding! Î Push the steam lever locking (B3) to the front (steam switch blocked). Î Illustration To detach the accessory parts, press the un- locking button (B2 or E2), and pull the items apart. Note: If you always use usual commercial dis- tilled water it is not necessary to descale the boil- er. Caution Do not use condensation water from the drier! Do not fill in detergents or other additives! Î Remove the safety cap (A4) from the device. Î Empty remaining water from boiler. Î Fill the boiler with a maximum of 1.2 liters of fresh tap water. Safety Devices Pressure controller Safety thermostat Safety lock (A4) Symbols on the machine Operation Attaching the Accessories Removing the Accessories Fill up with waterEnglish 17 Note: You can cut down the heating-up time by using warm water. Î Screw the safety cap (A4) back onto the de- vice. Î Place the unit securely on a firm surface. Caution The appliance must not be carried during clean- ing. Î Insert the mains plug (A7) into a socket. Both indicator lamps (A2/A3) must illumi- nate. Caution Do not turn the appliance on without water in the boiler. Otherwise, the appliance may overheat (see Help with faults). Î The orange indicator lamp (A3) goes out af- ter approximately 8 minutes. The steam cleaner is ready to use. Î Push the steam switch lock (B3) to the back. Note: If you push the lock forward, the steam switch cannot be actuated (child control). Î While operating the steam switch (B4), direct the steam gun at a separate piece of cloth until the steam is emitted evenly. Note: The heating of the steam cleaner is turned on in regular intervals during the op- eration of the appliance in order to maintain the pressure in the boiler at a constant level. When the heating is turned on, the orange indicator lamp (heater) lights up. Î Use the steam switch (B4) to regulate the discharged steam. Î The lock of the steam switch (B3) also allows for steam volume regulation. – Switch in front position: no steam (child con- trol) – Switch in middle position: reduced steam amount – Switch in back position: maximum steam amount Water needs to be filled into the boiler, if the steam volume decreases during work and no more steam is emitted in the end. Note: The safety lock (A4) cannot be opened as long as slight pressure remains in the boiler. Î Push the steam lever (B4) until steam dis- charge stops. Now, the boiler of the appli- ance is unpressurized. Î Disconnect the mains plug (A7) from the socket. Î Remove the safety cap (A4) from the device. Danger A residual amount of steam may be emitted when you open the safety lock. Be careful when opening the safety lock, there is a risk of scald- ing. Î Fill the boiler with a maximum of 1.2 liters of fresh tap water. Danger If the boiler is hot, there is the risk of scalding as the water may splash back during the filling proc- ess! Do not fill any detergents or other additives into the boiler! Î Screw the safety cap back onto the device. Î Insert the mains plug into a socket. Î The orange indicator lamp (A3) goes out af- ter approximately 8 minutes. The steam cleaner is ready to use. Î Disconnect the mains plug (A7) from the socket. Î Press the cover of the appliance (A1) con- nector to the bottom and disconnect the steam plug (B6/H5) from the appliance con- nector. Î Illustration – Put the extension pipes (E1) into the large acessory compartments (A5). – Insert the manual nozzle (D1) and detail noz- zle (C1) onto each extension pipe. – Put the round brush (C2) into the medium acessory compartments. – Hook the floor nozzle (F1) into the parking position (A6). – Wrap the steam hose (B5) around the exten- sion pipes and insert the steam pistol (B1) into the floor nozzle (F1). Turning on the Appliance Adjusting the Steam Quantity Refilling Water Turning Off the Appliance Storing the Appliance18 English Prior to treatment with the steam cleaner, always check the reaction of the textiles in an inconspic- uous location: Steam heavily at first, then let dry and then check for colour or shape changes. Be careful when you clean kitchen and living room furniture, doors, parquet, lacquered or plastic-coated surfaces. The wax, furniture polish, plastic surfaces or paint can come loose or stains can be created. Therefore, always clean these surfaces with a steamed cloth only. Caution Never direct the steam jet at glued edges as the edge band may loosen. Do not use the steam cleaner on unsealed wooden or parquet floors. In case of low outside temperatures, especially in the winter, warm up the window pane by slight- ly steaming the entire glass surface. This will prevent tensions on the surface which might lead to glass breakage. Caution Do not direct steam onto the sealed locations of the window frame to prevent damage. You can use the steam gun without any addition- al accessories, e.g.: – to remove odours and wrinkles from hanging clothes by steaming them at a distance of 10 to 20 cm. – to remove dust from plants. Here, keep a dis- tance of 20-40 cm. – for moist dusting, by briefly steaming the cloth and wiping the furniture with it. The closer this nozzle is to the contaminated ar- ea, the higher the cleaning effect, as the temper- ature and the steam are highest at the nozzle output. Especially suited for cleaning fittings, drains, sinks, toilets, blinds and heaters. Moisten stubborn limescale with vinegar, and allow to re- act for approximately 5 minutes. Attach the round brush directly to the detail noz- zle. Especially well-suited for hard to access lo- cations, such as fittings or drains. Caution Not suited for the cleaning of sensitive surfaces. Pull the terry cloth (D2) cover over the manual nozzle. Especially well-suited for small washable areas, shower stalls, mirrors or furniture cloth material. Suited for all washable wall and floor coverings, e.g. stone floors, tiles and PVC floors. Work slowly on very dirty surfaces to allow the steam to act on the dirt for a longer period of time. Note:Detergent residue or care emulsions that are still present on the surfaces to be cleaned, can lead to smears when steam cleaned. How- ever, these will disappear with repeated cleaning procedures. Î Illustration Attach the floor cloth to the floor nozzle. 1 Fold the floor cloth (F3) the long way and place the floor nozzle (F1) on top of it. 2 Open holding clamps (F2). 3 Place the cloth ends into the openings. 4 Close the holding clamps. Caution Do not insert fingers between the clamps. Î Illustration During work breaks: Hook the floor nozzle (F1) into the parking position (A6). How to Use the Accessories Important application instructions Cleaning of Textiles Cleaning of Coated or Lacquered Surfaces Cleaning of Glass Steam gun (B1) Detail nozzle (C1) Round brush (C2) Manual nozzle (D1) Floor nozzle (F1) Parking the floor nozzleEnglish 19 몇 Warning Hot steam iron and hot steam escaping!Point out to other people the possible risk of being scalded or burned. Never direct the steam jet at people or animals (risk of scalding). Do not touch any electrical leads or combustible objects with the hot steam iron. Î Firmly insert the steam plug (H5) into the ap- pliance connector (A1). The locks of the steam plug must lock into the cover of the appliance connector. All fabrics can be steam ironed. Delicate imprints or fabrics should be ironed on the reverse or ac- cording to the manufacturer’s specifications. Î Insert the mains plug (A7) into a socket. Both indicator lamps (A2/A3) must illumi- nate. Î Adjust the temperature control (H2) of the steam iron within the notched range (•••/ MAX). Î Once the indicator lamp (H1) on the steam iron has switched itself off, the steam iron is ready for use. Note:The sole plate must be hot to prevent the steam from condensing on the sole plate and dripping onto the garment to be ironed. Î Press the switch (H3) on the iron. – Steaming at intervals: Press the switch to the front. A steam burst is emitted while the switch is being pressed. – Continuous steaming: Press the switch to the back. The switch locks and steam is con- tinuously emitted. To release, press the switch to the front. Î Direct the first burst of steam at a separate piece of cloth until the steam is emitted even- ly. Î You can hold the iron in an upright position to apply steam to curtains, dresses, etc. Note:Even if you iron without steam, there must be water in the boiler. Î Adjust the temperature control (H2) of the steam iron according to the garment you want to iron. Danger Always disconnect the mains plug (A7) and allow the steam cleaner to cool down before perform- ing any maintenance work. Rinse the steam cleaner boiler at the latest after 5 boiler fillings. Î Fill the boiler with water and shake it strong- ly. This dissolves lime scaling residing on the boiler bottom. Î Empty water out. Note: If you always use usual commercial dis- tilled water it is not necessary to descale the boil- er. As limescale builds up on the boiler walls, we recommend to descale the boiler in the following intervals (RF=reservoir fillings): Note: Please contact your Conservancy Board or the local water supply company to inquire about the hardness of your water. Î Disconnect the mains plug (A7) from the socket. Î Completely empty the steam boiler. 몇 Warning Use commercial decalcifier for decalcifying the unit. Caution Use caution when filling and emptying the steam cleaner. The descaling solution can have an ag- gressive effect on delicate surfaces. Î Pour the descaling solution into the boiler and allow it to react for approximately 8 hours. 몇 Warning Do not screw the safety cap (A4) on the appli- ance during the decalcifying. Do not use the steam cleaner as long as there is decalcifying agent in the boiler. Î Empty the descaling solution after 8 hours. A small amount of the solution will remain in the boiler. Therefore, you should rinse the Steam iron (H1) Steam ironing Dry ironing

• •• Cotton, linen Maintenance and care Rinsing the boiler Descaling the boiler Degree of hardness ° dH mmol/l RF I soft 0- 7 0-1,3 55 II medium 7-14 1,3-2,5 45 III hard 14-21 2,5-3,8 35 IV very hard >21 >3,8 2520 English boiler two to three times with cold water to re- move any residues of the descaler. Note: The floorcloth (F3) and the terry cloth cov- er (D2) have been pre-washed and can be used immediately for working with the steam cleaner. Î You can wash dirty floorcloths and terry cloth covers in the washing machine at 60°C. Do not use a liquid softener as this would affect the ability of the cloths to pick up dirt. You may tumble dry the cloths. 몇 Warning Do not use abrasives, glass or universal clean- ers! Never immerse the appliance in water. Î Clean the appliance and accessory parts made of plastic with a commercial plastic cleaner. Often, failures have simple causes and you can do the troubleshooting yourself using the follow- ing overview. If you are in doubt or if the failure is not listed here please contact the authorized customer service. Danger Always disconnect the mains plug (A7) and allow the steam cleaner to cool down before perform- ing any maintenance work. Repair works may only be performed by the au- thorized customer service. Î Descale the steam boiler. Î Turn off the appliance. Î See "Refilling Water" Page 17 Steam switch is secured with the lock / child- proof lock. Î Push the steam switch lock (B3) to the back. During longer breaks from ironing, the steam in the steam line can condense. Î Direct the first burst of steam at a separate piece of cloth. Î Set the thermostat to level •••. Î Rinse or decalcify the steam boiler. UK helpline: 0844 8710705 IE helpline: 01-4097777 info@cleanerworldgmbh.co.uk Care of the Accessories Cleaning the device Troubleshooting Long heating-up time Steam boiler is decalcified. No steam No water in the steam boiler. Steam lever (B4) cannot be pressed anymore After breaks during ironing, water drops will come out of the steam iron. Steam iron "spits out" water! ServiceEnglish 21 Subject to technical modifications! Do not use worn out appliance; first put it out of use; then arrange for its proper disposal as scrap. Old appliances contain valuable materials that can be recycled. Please arrange for the proper recycling of old appliances. Please dispose your old appliances using appropriate collection systems. We hereby declare that the machine described below complies with the relevant basic safety and health requirements of the EU Directives, both in its basic design and construction as well as in the version put into circulation by us. This declaration shall cease to be valid if the machine is modified without our prior approval. The undersigned act on behalf and under the power of attorney of the company management. Cleanerworld GmbH Am Schützenbaum 19 97953 Königheim (Germany) Technical specifications Power connection Voltage 220-240 1~50/60

H. Moritsch Head of Development22 English The warranty period is 3 years and begins on the date of purchase. In order to file a warranty claim, you must present the sales receipt as well as complete a warranty card. Therefore, make sure you keep the sales receipt and the warranty card in safe place! The manufacturer warrants the rectification of defects that can be traced back to flaws in mate- rial or workmanship. The manufacturer will choose to repair, replace or refund the money for the product. The warranty does not cover dam- ages caused by an accident, an unexpected inci- dent (e.g. lightning, water, fire, etc.), improper use, or transport, disobeying the safety and maintenance instructions or other improper processing or modifications. The warranty period can only be extended if this is intended by a legal standard. In countries, where a (mandatory) war- ranty and/or a spare parts storage or replace- ment warranty is demanded by law, the minimum legal requirements apply. After the warranty period has elapsed, you may still send the defective device to the service ad- dress to be repaired. Repairs made after the warranty period has elapsed, are subject to re- pair costs. LIDL see page 20 of Operating Instructions see page 20 of Operating Instructions see page 20 of Operating Instructions Cleanerworld GmbH Am Schützenbaum 19 97953 Königheim (Germany) Fon: +49 1805 212784 Fax: +49 1805 212785 Steam Cleaner Set 37702 1.512-300.0, 1.512-301.0, 1.512-302.0, 1.512-303.0, 1.512-304.0, 1.512-305.0, 1.512-306.0
