KBT 200 - Beard trimmer Koenic - Free user manual and instructions

Technical Features	Koenic KBT 200 beard trimmer, stainless steel blades, 20 adjustable cutting lengths, 60 minutes battery life, 8 hours charging time.
Usage	Designed for beard trimming and styling, cordless use, ergonomic for comfortable handling.
Maintenance and Repair	Blade cleaning with water, occasional lubrication recommended, no specified replaceable parts.
Safety	Use only on dry skin, avoid contact with water during use, keep out of reach of children.
General Information	2-year warranty, lightweight, compact design, ideal for travel.

Frequently Asked Questions - KBT 200 Koenic

How do I charge the Koenic KBT 200 beard trimmer?

To charge the Koenic KBT 200 beard trimmer, plug the supplied charging cable into the device and connect it to a power outlet. Make sure the charging indicator lights up to show that the battery is charging.

How do I clean the Koenic KBT 200 beard trimmer?

To clean your Koenic KBT 200 beard trimmer, remove the cutting head and rinse it under running water. Use the supplied cleaning brush to remove hairs. Make sure the device is unplugged during cleaning.

What is the battery life of the Koenic KBT 200 beard trimmer?

The battery life of the Koenic KBT 200 beard trimmer is about 60 minutes after a full charge. The charging time is about 90 minutes.

Can I use the Koenic KBT 200 beard trimmer in the shower?

No, the Koenic KBT 200 beard trimmer is not waterproof. It is recommended to use it on dry skin and not expose it to water to ensure proper functioning.

How do I adjust the cutting length on the Koenic KBT 200 beard trimmer?

To adjust the cutting length, use the guide combs supplied with the trimmer. Choose the comb corresponding to the desired length and attach it to the cutting head.

What should I do if the Koenic KBT 200 beard trimmer does not work?

If the trimmer does not work, first check that it is properly charged. If it still does not turn on, try resetting the device by unplugging it and plugging it back in after a few minutes.

Are the blades of the Koenic KBT 200 beard trimmer replaceable?

Yes, the blades of the Koenic KBT 200 beard trimmer are replaceable. You can order them from Koenic customer service or specialized stores.

Is the Koenic KBT 200 beard trimmer quiet?

The Koenic KBT 200 beard trimmer is designed to be relatively quiet, but a slight noise is normal during use.

USER MANUAL KBT 200 Koenic

PHASE GEN
Phase 1
Phase2/3/4/5/6/7/8/9/10/11/12/13/14/15/16/17/18/19/20/21/22/23/24/25/26/27/28/29/30/31/32/33/34/35/36/37/38/39/40/41/42/43/44/45/46/47/48/49/50/51/52/53/54/55/56/57/58/59/60/61/62/63/64/65/66/67/68/69/70/71/72/73/74/75/76/77/78/79/80/81/82/83/84/85/86/87/88/89/90

HOBTTOHCTS

KOENIC

Beard Trimmer

K3≥10

Summ 8-7
(1) C_H_2O - H_2 (2) H_2O (3) H_2O + CH_4 (4) H_2O + H_2 (5) H_2O + H_2O_2 (6) H_2O + H_2O_2 + CO_2 (7) H_2O + H_2O_2 + CO_2 (8) H_2O + H_2O_2 + CO_2 + CO (9) H_2O + H_2O_2 + CO_2 + CO (10) H_2O + H_2O_2 + CO_2 + CO (11) H_2O + H_2O_2 + CO_2 + CO (12) H_2O + H_2O_2 + CO_2 + CO (13) H_2O + H_2O_2 + CO_2 + CO (14) H_2O + H_2O_2 + CO_2 + CO (15) H_2O + H_2O_2 + CO_2 + CO (16) H_2O + H_2O_2 + CO_2 + CO (17) H_2O + H_2O_2 + CO_2 + CO (18)

• This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.

• Children shall not play with the product.

• Cleaning and user maintenance shall not be made by children unless they are supervised.
• Warning! Keep the product dry.

English

Safety instructions

1. Read this user manual thoroughly before first use and pass it on with the product. Pay attention to the warnings on the product and in this user manual. It contains important information for your safety as well as for the use and maintenance of the equipment.
2. Use the product only for its intended purpose and with recommended accessories and components. Improper use or wrong operation may lead to hazards.
3. Never leave the product unsupervised while it is switched on.
4. Never immerse electrical parts of the product in water during cleaning or operation. Never hold the product under running water.
5. Do not under any circumstances attempt (e.g. damage in power cord, product is dropped, etc.) to repair the product yourself. For servicing and repairs, please consult an authorised service agent.
6. Use this product in dry indoor areas only and never outdoors.
7. Never use, expose or put the product near to:

direct sunlight and dust;
- fire (fireplace, grill, candles), water (water splashes, vases, ponds, bath tube) or heavy moisture.

1. This product is not intended for commercial use. It is designed for household use only.
2. Clean the product and all other accessories after each use.
3. Follow the instructions in the chapter

Cleaning and care:

1. Only use the charging adapter provided to charge the product. The polarity of the adaptor must match the polarity of the product
2. Keep the lubricating oil out of the reach of children.

Battery

1. Caution! There is danger of explosion from improper replacement of the battery. Replace battery only with the same or equivalent type of battery.
2. Always exchange the entire set of batteries.
3. Make sure the battery are correctly inserted. Observe the polarity (+) plus / (-) negative on the battery and the housing. Improperly inserted battery can lead to leakage or, in extreme cases, a fire or an explosion.
4. Non-rechargeable batteries must not be recharged.
5. The connections must not be short-circuited.
6. Remove the batteries from the product before disposal.
7. Never expose batteries to excessive heat (e.g. bright sun, fire), and never throw them into fire. The batteries could explode.
8. Keep batteries out of reach of small children. If batteries have been swallowed, seek immediate medical attention.
9. If the batteries leak, remove them with a cloth and dispose of them accordingly. Prevent battery acid from coming into contact with skin and eyes. If you do get battery acid in your eyes, flush them thoroughly with lots of water and consult a physician immediately. If battery acid comes into contact with your skin, wash the affected area with lots of water and soap.

Congratulations!

Thanks for your purchase of KOENIC product Please read this manual carefully and keep it for future reference.

Intended use

The product is suitable for trimming dry beard only. Any other use may result in damage to product or injuries. This product is not intended for commercial use. It is designed for household use only.

Before first time use

Remove the product and accessories carefully from the original packaging. Inspect the delivery contents for completeness and damages. Should the delivery contents be incomplete or damaged, contact your sales outlet immediately.

Note

• For first time use, charge the product for at least 6 hours. The general charging time is about 4 hours which also depends on the condition of the battery.
• When the battery is fully charged, the product can be used for 45-50 minutes. The time may vary (depending on the battery condition).

Disposal

Do not dispose of this product as municipal waste. Return it to a designated collection point for the recycling of electrical and electronic equipment. Contact your retailer

or local authorities for more information.

Please dispose of batteries in an environmentally friendly manner Do not put batteries into the household waste.

Please use the return and collection systems in your community or contact the dealer where you purchased the product.

Content

1 x Beard trimmer
1 x Charging stand
1 x Charging adaptor
1xComb attachment
1 x Lubricating oil
1xCleaning brush
1 x User manual

Control elements

A Charging adaptor
B DC-IN socket
Charging stand
Cleaning brush
E Lubricating oil
F LED indicator
G Beard trimmer
ON/OFF switch
1 Battery compartment
1 Battery compartment release button
K Shaving head
Comb attachment

Technical Data

Beard trimmer

Battery operated: 3.6 V = =

Charging adaptor (MPS005-036030CG)

Rated input: 100 - 240 V~, 50/60 Hz

Rated output:3.6V = = ,0.3A

Battery

Re-chargeable :Ni-MH,type AA,1.2V

battery 1000 mAh

English

Insert/change rechargeable battery

1 Press down and hold the release button. Slide off the battery compartment cover. Insert the rechargeable battery. To close the battery compartment, slide back the cover while holding the release button pressed. Ensure the cover is locked correct.

Charging the battery

2 Connect the charging adapter to the DC IN socket on the charging stand and plug the power adaptor in a suitable power outlet. 3 Put the product on the charging stand. The LED indicator turns red and shows the battery is being charged. The indicator turn green, when the battery is fully charged.

Note

Ensure that the product is switched off before charging. Make sure that the on/off switch is switched down.

LED indicator

LED-Color Condition
No color During operation.
Red During charging.
Green Chargng completed. Fully charged.
Red	During operation, when the battery level is less than 20%.

Operation

Trim/cut beard-withcomb attachment

4 Slide the comb attachment on the blade and sure it's fit in correctly.
5 Set the desired cutting length by sliding the comb attachment. You can choose the lengths 0.5, 1.5, 2.5, 3.5, 4.5 and 5.5.
Switched on the beard trimmer. The LED indicator flashes one time in red.
Guide the beard trimmer slowly over the beard. Hold the trimmer in such a way that the comb is as flat as possible.

Note

Depending on the position of the product and the resulting angle, cutting lengths may differ.

Trim/cut beard - without comb attachment

8 Slide carefully the comb attachment upwards with thumb and moderate force.
Without comb attachment the beard can be cut to an even length of 0.3mm . Switch on the trimmer and hold the shaving head at the desired height of the beard.

Cleaning and care

Warning

When cleaning, never use solvents or abrasive materials, hard brushes, metallic or sharp objects. Solvents are harmful to human health and can attack plastic parts, while abrasive cleaning mechanisms and tools may scratch the surface(s).

10 After every use, please use the cleaning brush to thoroughly brush and blow out hair on the blades, attachment and the beard trimmer.

Clean the product's exterior surfaces with a slightly damp cloth and then dry them thoroughly.
Make sure that no water enters the product interior (for example, through the switch). Keep the product in a dry, cool location which is protected against moisture and direct sunlight. Keep this product out of the reach of children.

Cleaning the shaving head

Switch off the product and take out the battery. Push the shaving head with your thumb until it is detached from the enclosure and take it off. Brush the shaving head and the product's interior with the cleaning brush.

Caution

Do not knock on the shaving head, this can damage it.

Note

You can rinse out the shaving head under water. Then dry it with a soft cloth.

When the shaving is clean and completely dry, fit the shaving head onto the product. Ensure it's firmly fit in.

Lubrication oil

In order to improve the cutting length, apply 1-2 drops of the oil onto the shaving head. This is particularly recommended after cleaning. Wipe off excess oil with a cloth.

Troubleshooting

If there are any problems during operation, please refer to the following table. If problems cannot be solved as indicated under Solution, please contact your manufacturer.

Problem Possible causes Solution
Product does not work • Interrupted power supplyBatteries empty	• Check the power supply• Re-charge batteries
LED indicator does not light on during charging batteries	• No power supply• Power cord is not connected to product or charging standDevice is not correctly put on the charging stand	• Check the power supply• Check the power cord connection• Put product correctly on the charging stand
Shaving head is not working smoothly	• Impurities accumulated on the shaving head	• Clean and add 1-2 drops oil onto the shaving head
