GEPP 1100 NA - Surface pump EINHELL - Free user manual and instructions

Product type	Submersible pressure pump
Brand	Einhell
Model	GEPP 1100 NA
Power supply	220-240 V ~ 50 Hz
Power consumption	1100 W
Max flow rate	6000 L/h
Max delivery head	45 m
Max immersion depth	12 m
Max water temperature	35 °C
Discharge connection	33,3 mm (1") threaded
Protection type	IPX8
Dry running protection	Yes, automatic shut-off with restart cycles
Integrated check valve	Yes
Automatic operation	Yes, shut-off at pressure ≥ 2.5 bar, restart at pressure < 2.5 bar
Application	Clear water
Maintenance	Clean with clear water, check every 3 months
Wear parts	Rotor

Frequently Asked Questions - GEPP 1100 NA EINHELL

What is the power of the GEPP 1100 NA pump?

The power consumption is 1100 W at a voltage of 220-240 V ~ 50 Hz.

What is the maximum flow rate of the pump?

The maximum flow rate is 6000 L/h (liters per hour).

What is the maximum immersion depth?

The maximum immersion depth is 12 m. The pump must be immersed at least 12 cm underwater.

Can the pump run dry?

No, the pump is protected against dry running. It stops automatically when there is no water and tries to restart in cycles (10 s run, 5 s stop) until it is submerged again.

How to clean the pump?

Disconnect the mains plug, then clean the device with clear water. For the impeller, unscrew the 8 screws of the lower housing (see fig. 2a-2e) and clean it without placing the pump on the impeller.

What to do if the pump does not start?

Check the mains voltage, the pressure side seal and the inlet filter. If the problem persists, consult the error search plan in the manual.

What type of water can be pumped?

The pump is designed for clear water at a maximum temperature of 35 °C. Do not use with aggressive, abrasive, fuel or chemical liquids.

Is the pump suitable for use in swimming pools?

No, the device is not suitable for use in swimming pools, paddling pools or water features where people or animals may be present.

What is the maximum water temperature?

The maximum water temperature is 35 °C. Beyond that, the motor protection may trigger a shutdown.

How to install the pump correctly?

Attach the pump to a rope by the handle and lower it into the well or tank. Make sure it is immersed at least 12 cm and about 30 cm from the bottom. Connect the pressure hose to the 33,3 mm connection. Plug into a 220-240 V safety socket with 30 mA RCD.

USER MANUAL GEPP 1100 NA EINHELL

PRODUKTINFORMATIONEN

PREISINFORMATIONEN

VERFUGBARKEITEN

TRACK & TRACE

Danger! - Read the operating instructions to reduce the risk of inquiry

This equipment can be used by children of 8 years and older and by people with limited physical, sensory or mental capacities or those with no experience and knowledge if they are supervised or have received instruction in how to use the equipment safely and understand the dangers which result from such use. Children are not allowed to play with the equipment. Unless supervised, children are not allowed to clean the equipment and carry out user-level maintenance work.

GB

Danger!

When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating instructions and safety regulations with due care. Keep this manual in a safe place, so that the information is available at all times. If you give the equipment to any other person, hand over these operating instructions and safety regulations as well. We cannot accept any liability for damage or accidents which arise due to a failure to follow these instructions and the safety instructions.

1. Safety regulations

Danger!

Read all safety regulations and instructions. Any errors made in following the safety regulations and instructions may result in an electric shock, fire and/or serious injury. Keep all safety regulations and instructions in a safe place for future use.

Danger!

The pump must be powered via an earthquake circuit breaker (RCD) with a rated fault current of no more than 30mA according to VDE 0100 Part 702 and 738).

The equipment is not designed for use in swimming pools and paddling pools of any kind or other bodies of water in which people or animals may be present during operation. It is prohibited to operate the equipment if a person or animal is in the danger area. Ask your electrician!

Before you put the equipment into operation, arrange for a specialist to check that the earthing, protective multiple earthing or residual-current operated circuit-breaker circuit comply with the safety regulations of the power supply company and work correctly.
The electrical plug-in connections must be protected from wet conditions.
If there is a risk of flooding, place the plug-in connections in an area which is safe from flooding.
- Strictly avoid pumping aggressive liquids and abrasive substances.
- Protect the equipment from frost.
- Protect the equipment from dry running.

Take suitable measures to keep the equipment out of the reach of children.

2. Layout and items supplied

2.1 Layout (Fig. 1)

1. Delivery connection approx. 33.3mm (1") female thread
2. Handle
3. Intake cage

2.2 Items supplied

Please check that the article is complete as specified in the scope of delivery. If parts are missing, please contact our service center or the sales outlet where you made your purchase at the latest within 5 working days after purchasing the product and upon presentation of a valid bill of purchase. Also, refer to the warranty table in the service information at the end of the operating instructions.

• Open the packaging and take out the equipment with care.
• Remove the packaging material and any packaging and/or transportation braces (if available).
  Check to see if all items are supplied.
• Inspect the equipment and accessories for transport damage.
  If possible, please keep the packaging until the end of the guarantee period.

Danger!

The equipment and packaging material are not toys. Do not let children play with plastic bags, foils or small parts. There is a danger of swallowing or suffocating!

• Submersible pressure pump
  Original operating instructions

3. Proper use

The equipment you have purchased is designed to pump water with a maximum temperature of 35^ . This equipment must never be used for other liquids, especially not for engine fuels, cleaning agents and other chemically-based products!

GB

The equipment can be used wherever you want to move water, e.g. in the house, in the garden, and for many other applications. It must not be used to operate swimming pools!

If you want to use the equipment in bodies of water with a natural, muddy bottom, place the equipment in a slightly elevated position, e.g. on bricks.

The equipment is not designed for continuous operation, e.g. as a circulating pump in a pond. In this case the equipment's anticipated life will be greatly shortened because the equipment was not designed for continuous loading.

The equipment is to be used only for its prescribed purpose. Any other use is deemed to be a case of misuse. The user / operator and not the manufacturer will be liable for any damage or injuries of any kind caused as a result of this.

Please note that our equipment has not been designed for use in commercial, trade or industrial applications. Our warranty will be voided if the machine is used in commercial, trade or industrial businesses or for equivalent purposes.

The water may be contaminated by escaping lubricating oil/lubricant.

4. Technical data

Mains connection. 220-240 V ~ 50 Hz

Power rating 1100 W

Max. pumping rate 6000 l/h

Maxdeliveryhead 45m

Max. submersion depth 12 m

Max. water temperature 35°C

Hose connection .approx. 33.3 mm (1") IG

Max. size of foreign bodies: Clear water

Protection type. IPX8

5. Before starting the equipment

Before you connect the equipment to the mains supply make sure that the data on the rating plate are identical to the mains data.

5.1 Installation

The equipment can be installed either:

Stationary with a rigid pipe line

or

Stationary with a flexible hose line
- Connect the delivery hose or pipe to the delivery connection (1) using a suitable connector.
The equipment must be fastened to a securing cable by the handle (Fig. 1/Item 2).

Notice!

Before you use the pump, clarify any possible special conditions which need to be fulfilled for the installation!

For example, additional safety measures may be needed if damage to property could result from a power failure, soiling or a defective gasket.

Examples of such safety measures:

Pumps running in parallel on a separately protected power circuit, moisture sensors for switching off the pumps, and similar safety arrangements. Be sure to consult a professional plumber if you have any doubt.

The maximum pumping rate is possible only with the largest possible line diameter; if smaller hoses or pipes are connected, the pumping rate will be reduced.

The pump shaft should be large enough.

5.2 Mains connection

Danger!

The equipment you have purchased comes with an earthing-pin plug. The equipment is designed for connection to a socket outlet with earthing contact for 220 - 240V 50Hz . Make sure that the socket-outlet is sufficiently fused (at least 6 A) and in good working order. Insert the power plug in the socket-outlet and the equipment is ready for operation.

GB

6. Operation

You can put the equipment into operation after you have thoroughly read the installation and operating instructions. Pay attention to the following points:

Make sure that the equipment is set up securely.
- Check that the discharge line is fitted correctly.
Make sure that the electrical connection is 220 - 240V 50Hz
- Check that the electrical socket-outlet is in good working order.
Make sure that no moisture or water can ever reach the power connection.
Make sure that the equipment does not run dry.
- To switch off the equipment, pull the power plug out of the socket outlet.

Note:

1. Lower the pump into the well or shaft by the securing cable.
2. Ensure that the pump is at least 12cm under the surface of the water and approx. 30~cm above the bottom.
3. Connect the mains plug to the socket.

The pump will start 3 seconds after the power cable has been plugged in.

6.1 Automatic mode

The pump builds up pressure (e.g. the water tap is closed) and then switches off automatically. Thanks to the integrated non-return valve, the pressure in the hose will be maintained until water is removed again.

When the pressure drops below 2.5 bar, the pump will switch on again automatically.

6.2 Dry-running protection

The pump will be switched off automatically when there is no longer any water for pumping.

Now the pump will check for water in cycles of 10 seconds ON / 5 seconds OFF (2x). In other words, the test cycle will be repeated after 1 hr, 5 hrs, 24 hrs, 24 hrs ....

As soon as the pump is immersed again in water to a depth of at least 12cm it will be ready for operation again.

7. Replacing the power cable

Danger!

If the power cable for this equipment is damaged, it must be replaced by the manufacturer or its after-sales service or similarly trained personnel to avoid danger.

8. Cleaning, maintenance and ordering of spare parts

Danger!

Unplug the power plug prior to any maintenance work.
- For mobile applications, the equipment should be cleaned with clear water after every usage.
- In stationary use, it is recommended to check every three months that the function is working properly.
Use a water jet to remove any lint or fibrous particles that may have become trapped in the housing.
- Remove sludge from the shaft bottom and clean the shaft walls every 3 months.

8.1 Cleaning the paddle wheel

If a lot of deposits collect in the housing, the bottom part of the equipment must be dismantled as follows:

1. Undo the 8 screws with a screwdriver (Fig. 2a).
2. The other cleaning steps are shown in Figs. 2b to 2e.
3. Clean the paddle wheel with clear water. Important! Do not put down or rest the equipment on the paddle wheel!
4. Assemble in reverse order.

8.2 Maintenance

There are no parts inside the equipment which require additional maintenance.

8.3 Ordering replacement parts:

Please quote the following data when ordering replacement parts:

Type of machine
Article number of the machine
Identification number of the machine
- Replacement part number of the part required For our latest prices and information please go to www.Einhell-Service.com

GB

9. Disposal and recycling

The equipment is supplied in packaging to prevent it from being damaged in transit. The raw materials in this packaging can be reused or recycled. The equipment and its accessories are made of various types of material, such as metal and plastic. Never place defective equipment in your household refuse. The equipment should be taken to a suitable collection center for proper disposal. If you do not know the whereabouts of such a collection point, you should ask in your local council offices.

10. Storage

Store the equipment and accessories in a dark and dry place at above freezing temperature. The ideal storage temperature is between 5 and 30^ . Store the electric tool in its original packaging.

11. Troubleshooting guide

Faults Cause	Remedy
Theequipment does not start	- Power supply not connected- There is a leak on the delivery side	- Check power supply- Clean the delivery side
Theequipment does not pump	- Intake sieve clogged- Discharge hose kinked	- Clean intake sieve with water jet- Unkink the hose
Theequipment does not cut out	- There is a leak on the delivery side -	Clean the delivery side
Insuffi-cient pumping rate	- Intake sieve clogged- Performance reduced due to heavi-ly contaminated and abrasive water impurities	- Clean intake sieve- Clean equipment and replace wear parts
The equipment swit-ches off after briefly running	- Motor circuit-breaker switches the equipment off due to excessive wa-ter contamination- Water temperature too high; motor circuit-breaker switches the equip-ment off	- Unplug power plug and clean equipment and shaft- Ensure that maximum permissible water temperature (35 °C) is not exceeded

GB

For EU countries only

Never place any electric power tools in your household refuse.

To comply with European Directive 2012/19/EC concerning old electric and electronic equipment and its implementation in national laws, old electric power tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g. by taking to a recycling depot.

Recycling alternative to the return request:

As an alternative to returning the equipment to the manufacturer, the owner of the electrical equipment must make sure that the equipment is properly disposed of if he no longer wants to keep the equipment. The old equipment can be returned to a suitable collection point that will dispose of the equipment in accordance with the national recycling and waste disposal regulations. This does not apply to any accessories or aids without electrical components supplied with the old equipment.

Please note that batteries and lamps (e.g. light bulbs) must be removed from the tool before it is disposed of.

The reprinting or reproduction by any other means, in whole or in part, of documentation and papers accompanying products is permitted only with the express consent of the Einhell Germany AG.

Subject to technical changes

GB

Service information

We have competent service partners in all countries named on the guarantee certificate whose contact details can also be found on the guarantee certificate. These partners will help you with all service requests such as repairs, spare and wearing part orders or the purchase of consumables.

Please note that the following parts of this product are subject to normal or natural wear and that the following parts are therefore also required for use as consumables.

Category Example
Wear parts* Impeller
Consumables*
Missing parts

• Not necessarily included in the scope of delivery!

In the effect of defects or faults, please register the problem on the internet at www.Einhell-Service.com. Please ensure that you provide a precise description of the problem and answer the following questions in all cases:

Did the equipment work at all or was it defective from the beginning?
Did you notice anything (symptom or defect) prior to the failure?
What malfunction does the equipment have in your opinion (main symptom)?

Describe this malfunction.

GB

Warranty certificate

Dear Customer,

All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that this equipment develops a fault, please contact our service department at the address shown on this guarantee card. You can also contact us by telephone using the service number shown. Please note the following terms under which guarantee claims can be made:

1. These guarantee terms apply solely to consumers, i.e. natural persons, who do not want to use this product in connection with either their commercial or other self-employed activities. These guarantee terms regulate additional guarantee services which the undermentioned manufacturer promises to buyers of its new products in addition to their statutory rights of guarantee. Your statutory rights of guarantee are not affected by this guarantee. Our guarantee is free of charge to you.

2. The guarantee services cover only defects due to material or manufacturing faults on the new product which you have bought in the European Union from the undermentioned manufacturer and are limited to either the rectification of said defects or the replacement of the product, whichever we prefer. Please note that only equipment under the brand name "Professional" has been designed for use in commercial, trade or professional applications. For all other products the guarantee is invalidated if the equipment is used within the guarantee period in commercial, trade or industrial applications or for other equivalent activities.

3. Our guarantee does not cover:

4. Damage to the equipment caused by failure to comply with the installation/assembly instructions or by unprofessional installation; damage caused by failure to comply with the operating instructions (e.g. connection to the wrong mains voltage or current type); damage caused by failure to comply with the maintenance and safety regulations; damage caused by exposing the equipment to abnormal environmental conditions; damage resulting from poor care and maintenance.

5. Damage to the equipment caused by misuse or incorrect applications (e.g. overloading the equipment or using non-approved attachments or accessories); damage caused by foreign bodies (e.g. sand, stones, dust, ...) getting inside the equipment. Damage in transit; damage caused by force or external influences (e.g. by dropping the equipment).

6. Damage to the equipment or parts of the equipment which is owed to use-related, normal or otherwise natural wear. For example, batteries and battery packs are manufactured with a cycle limit for design-related reasons. Wear is negatively influenced in particular by load demands and charging speeds as well as exposure to heat, cold, vibration and impact.

7. The guarantee is valid for a period of 2 years starting from the purchase date of the equipment. Guarantee claims must be submitted before the end of the guarantee period and within two weeks of the defect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains applicable to the equipment even if repairs are carried out or parts are replaced. In such cases, the work performed or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active for the work performed or for any replacement parts fitted. This also applies if on-site service is used.

8. To assert your guarantee claim, register the defective equipment at: www.Einhell-Service.com. You will need to provide proof of purchase of the new item of equipment. Equipment returned without such proof or without a rating plate are excluded from the guarantee services because of the lack of traceability. If the defect is covered by our guarantee, then either the item in question will be repaired immediately and returned to you or we will send you a new replacement.

9. If you have taken the equipment with you to a different EU country than where you bought it, we will arrange for a local service partner to provide the guarantee services. If you take the equipment outside the EU, the guarantee will not apply.

Of course, we are also happy to offer a chargeable repair service for any defects which are not covered or no longer covered by the scope of this guarantee. To take advantage of this service, please send the equipment to our service address. We draw attention to the restrictions of this guarantee concerning wear parts, consumables and missing parts as presented in the service information included in this operating manual.

Warrantor/Service:

Einhell UK Ltd, Unit 10, 1st Floor, Champion's Business Park, Arrowe Brook Road, Upton, Wirral, CH49 0UQ

F

Chere cliente, cher client,

NcnoB3oBAt yctpoCTBO MOKHO TaKHe BcEJa, KOrJa Tpe6yTeCH IpeKaUka BObl, HAnPmep,B DOMaIIHem XO3JICTBE, B CaIy N BO MHOrNX dpyrNX Cnyuax. 3aIpeueHo NcNoB3oBAt yctpoCTBO, bia6ceHHOB!

PnHNCIOBaaHHyCTPOHCTBA BBOOeMAX CECTEChHHbIM,HNCTbIM HOMHEoXIDMO yCTaHaBHbTbYCTPOHCTBO HA HeoJIbHOM BO3BbIeHHH,HanpHMeP Ha KHPINH.

YcTPOHCTBO He IpeHa3HaueHO
HCIOJIb3OBAHHra ERO B TeueHHe DHTeJIbHO
BpeMeHH, HApnmeR B KaueCTBe
IHPKyJIMHOHHo HAcoca B npdy. B pe3yIbTaTe
TAKOTIOHIOBJ3OBAHHa 3HAHTeJIbHO
COKpaAaETc CpOK ClyK6bl yCTpoHCTBa Ha
KOTOpBIO OHO paccHTaHO, TAK KAK KOHCTpyKuHH
ycTPOHCTBa HE IpeHa3HaHaeHa DIA HHTeJIbHOi
HarpyKn.
Pa3PeIIaETc HCIOJIb3OBAtB yCTpoHCTBO
TOJbKO IIO ERO IpeHa3HaHeHHo. JIo6oe
dpyRo BixOJaHee 3a 3TN paMKn PIPMHeHHe
CHTaETc HCIOJIb3OBAHHem HE IO HA3HaHeHHIO.

3a BO3HHKIIH Bpe3yIbTaTe 3TO10

MaTeHaJIbHbIyUepe6HINTPaBMJIIO6OroPOdaHEcEROTBETCTBEHHOCTBIOJIb3OBATEJIb/0IepaTOp，aHeIpoHNBOHTIE.

YyTHe,HTO KOHCTpyKUHa HaIHX yCTpoIHCTB
He IpeHa3HaueHa Dn HcIOJIb3OBaHHN B
IpOMbIIeHHbIX IeJAX,BpeMeCJIeHHOM INH
KyCTAHOM IpOH3BOJCTBE.MbHE He Hecem
HHKAKoI OTBeTCTBeHHOCTH NIO rapaTHINbIM
083aTeJIbCTBaM CJIyae IIpMHeHHH
yCTPOHCTBa Ha peMeCJIeHHbIX,KyCTaPbIX HIN
IpOMbIIeHHbIX PpeIpnHrTnx,A TAKKe IIN
IIOIO6HbIX IeJIe.

PnBbTeKaHH CMA3OuHOro MaCna/CMa3OuHOro MaTePhaMa MoKeT 3aqr3HrTcBcBoJa.

4. TexHnueChne daHHbIe

Iapametpy 3eKtpocetn .220-240B\~50T IOTpe6JIHemMA MOUHOCTb 1100Br MaKc.IPOH3BOIDTEJbHOCTb .6000J/

MaKc. Hanop 45M MaKc.Iy6HnHa IogpyKeHHa 12 M

MaKc.TempeatypoBoubl 35°C

IIOKIIIOHHe HIIaHa...OK.33,3 MM (1)IG

IIOCTOPOHHHe IpeMTeb MaKc.: ... CHCTaB Oda TIN3aHTb:

5. NpepeBBODOM B3KcnnyatauHIO

Y6eHTEcIpeepIIOKIOUHHeM，TTO daHHbHe HA TINIOBOI TaBnue COOTBETCTBYOT IapamETpam CetH.

5.1 HCTaIIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIaIa

HCTaJIbIyIyIyCtpoIcTBAOcyIeCTBJIeTcI:

CTaHIOHaHO C HcNoIb3OBAHHem JXeCTKOro TpyboIPOB0a

HIN
CtauuHApHo C r6KHM TpybOpBoGOM
PiOJCOeHnHTeK HanOpHOMy nATpy6ky (1) HAnOpHBn IHaIr HnHn HAnOpHyTO ty6y C IIOXODIM COeHHITeIbIHIM 3JIEMHTOM.
YCTPOIcTBHOeOxOJHMO3aKpeNITbHa pykoTKe C NOMOuBHO TPOCA (pHc.1,IO3.2).

RUS

Yka3aHHe!

Ipeep3KcPnayatauHacoca BbIaCHHTe BO3MOKHO HMeOuNecr CneuaJIbHbIe ycIOBna MOHTaHa!

Ecni, hAnpMep, oTHa3 NHTaHna, 3aRpa3HeHne HnI DepeKTHoe yNlOThHeNe MOry TNOcLyKnITb npNCHIO MaTePnAaBHO rOuεp6a, Heo6xOdmo npNtB dOnOIHNteJIbHbIe 3aUHTbIe MepbI. K TAnm Mepam OTHocrTc, hAnpMep, cJeDyUOuHme MepbI:

napaJIeBHOe NOKJIIOUeHHe HAcOCOB B OdHOJ 3eKTPnueCHo CEtN COTJeBHBIM npedoxpAHTeJIaM, NcNoJIb3ObaHne DaTCHIOB BIAJXoCTnIgAOTKIIIOUeHnA, aTaKHe NDoOBhIX npedoxpAHTeJBHX npuCnOco6JIeHn. B cIyae comHeHn OB3aTeJIbHO npoHOcYbTIpyIteCb co CneuaJIACrOM no CaHntapHOH TeHXnke.

MaKcHmAbHoE KOINueCTBO TpaHCnOpTnpyEmoR BoeuctBa MOKeT 6bItb OBeCneUeHO ToIbKo npMakcHmAbHo BO3MOKHO MnAmEtpe TpybOpBoDa, pNIOdkJIuOeHN WlaHROB HnT pybOpBoDa MehBwero pa3Mepa TpaHCnOpTnpyEmoe KOINueCTBO CHINXaeTcA.

XaxTa hacoca doJIHHa HmEt bIOCTaTOHbIe pa3Mepbl.

5.2 PookKoueHne H 3JeHTpocetH

Onachoctb!

Ipiho6peTHeHoe BAmu yCTpOINCTBO paCnoJIaeraT WTeNcEInbHO BnIHoC 3aunTHbIM KOHTAKOM YCTpOCTBO paccHTaHO HA NOKIOUeHne K WTeNcEInbHO PO3ETKe C 3auNTbIM KOHTaTOM C npamETpAMn \~220-240 B 50 Tc. YDOCTOBepTEcB TOM,TOY DnA WTeNcEInbHO PO3ETHNy UCTAHOBEN INPEOXPAHNTeB C DOCTaTOHNO CnIoN ToKa (MH.N.6 A) N oEcbNeHcero 6e3ynpeHoo CoCTOHNHE BCTABte WTeKep B PO3ETHy 3eKTPueChk O cTt,TEM CAMbIM yCTpOINCTBO rOTOBK pa6Ote.

6.06paueHne c yctpoiCTBOM

Iocne toro, kA K BblBnMaTeIbHo npOHTaTepeHbHeHbIe tyuKa3aHnno HcTaNJIaunn N3cNpyataunn Bbl MoHeTe nCNoJIb30BaTbUycToiCTBO pIn Co6IIOHeHN cJeDyOuXyCNOB:

• IpoBepbTe HaJeHHOCbYcTaHOBKn YcTpoMCTBa.

PpOBepeyctAHOBky HAnOpHOro Tpy60npBOdaHaJIeKaUIMM 6pa3OM.
- Y6eIITecb B TOM,чTO napaMeTpbl ПОДКИОЕНУЛЕКТРСЕТИ ~ 220-240 B 50 Tg.
- PpOBepePo3eKHy 3JIeKTPnuecHcN cETn Ha HADJExKaUee COCTOHHe.
PocneIeTe,HTo6bHnB KOem Cnyae BnaRa HIN BOa He NonaHn Ha 3JIeKTPnueckoe NOKnIOUeHne.
- N36eraIte pa60tby yctpoiCTBa BCyxyIO.
ДЯВыкю悔нуycTpOиCTBa bblbTe WTEkep n3 po3eTkn 3JIeKTPoCeTN.

Yka3aHne

1. OnyCTnte hacoc 3a KpeeneHHbI Tpoc B KOLOeU HJIN WaxTy.
   2.CneIeTe3aTeM，YTO6bHacoc6bln NorpyHHeBBOyMH.Ha12cmHaxOuINcHa ypoBHe pImepHo 30 cmOTdHa.
2. PocoeHHTe WTEKepe 3JIeKTPoNTaHnRA K po3eTke.

3anyck hacocapoicxoye3c noclen oNDKIOUeyH KabeIyNTAHN.

6.1 ATOMATUeCKn peKIM:

Hacoc co3daet daBleHne (HaNPmep, 3aKpbIT BOONPOBODhB KpaH) H 3aTEM ABTomATnueckn OTHUOaTcE.5NarOapra BCTpoEHOMy o6bPAHO MyaNaHy DaBLeHne B WlaHre COxPAHETc DO TORO BpemHe, NOHa CHObA He HAHTcOTOp BObl.

Pn nAeHn daBHeHn HnKe 2,56ap Hacoc CHOBA aBTOMaTHueCKn BkIHOaETcR.

6.2 3aunTa oT pa60tb BCxyu:

Hacoc abTomatueeckn OTKIIOUaetc npn OTCyTCTBn TpAHCNOpTnpyeMoJ KnIDKOCTN.

Hacoc npednHHMaet nonbTKy pa60tB HHTepBaIax dIJIeTbHcOte 10 c, KOtOpbie uepeyoTc nay3am nnTeIbHcOte 5 c. (2x). 3OTOn nIOBTOpaeTc uepe3 1 cac, 5 cacob, 24 caca, noCleJeDyUoJe 24 caca n Tak danee.

Hak ToJIbHO HAcOC CHOBa NOrpyKaETcB B Ody MNHMym Ha 12 cm, OH CHOBa FOToB K 3KcNlyaTaun.

RUS

7. 3aMeHa Ka6eIg NHTaHn 3JIeHTpocetN

Onachoctb!

Ecnn 6ydt nobpeHkabel nIHaHnO T3JIeKTPocettn 3TOrO yCTpoiCTBa,TO erOdoJKeH 3aMeHHTb h3rOTOBHTenb yCTPOiCTBa,ero Cnykb6a cepBnca HnI npryoe NIOc NOo6HoN KBAHnΦHkaqne nIraT OTO bI N3eKaTa b onachOCTei.

8.OuHCTHa,TexO6cLyKHBaHne H 3aKa3 3anachbIX deTaeJei

Onachoctb!

• Pered KaKdo pa6oToI NO TexHuecHomy 06CnyKnBaHHo Heo6xOaHMo BbIHMaTb WTeKepeN3 po3eTN 3JIeKtpocetN.
  IocneKaJdoROHCIOB3OBaHnB nepeHOCHOMpeHXIME Heo6XoIMO OCHNTb yCTpoICTBO pN IOMOUI NCTOIBObl.
  PnCtauHapHn HNCTaJIaIepeKoMeHdyETcAyePe3KaJdble3 MecaIpiOBepaTbHaJeKaUee cyHKuOHIOPOBaHne yCTpoiCTba.
  Bopc H BOJOKHnCTbIe YacTHCuI, co6paBwHeC8 B Kopnyce, HyKHO ydaNITb CTpye BObl.
  KaHdIbe 3 MeCAHa Heo6xOIMo ydaJIaTb nI co dHa WaxTbI, a TaKHe OChCTnTb CTeHNi WaxTbI.
  OuCTHTbNONJIaBKOBBIyBblKJIOUaTeJIb YICTO BDOONOT OTLOXKeHNI.

8.1 OunchTha IonaactHoro KoIeca

PnCNIHKOM60JIbIUXOTIOKHeHINBXKOPNcE HeoXOIMPOa3O6paTB HKNHOUqAcTb

yctpoiCTBa TaK, KaK 3TO OINcHo HnHe:

1. Ocna6bTe 8 BnHToB c NOMOuIbO OTBeptTHN (pnc.2a).
   2.Даьншиэ STanbl OINCTKIN NOKa3aHbI Hapnc.2b-2e.
2. OuCTnTe IOnaCTHOE KOLECO YIcTcO BODoB HmMaHne! 3aPpeUeHO CTaBtB yCTpoIcTbO Ha IOnaCTHOE KOLECO NIN OIHPaTB o Hero!
   4.C6opkaocyuueCTbIeTcBobpaTHoNocJeDoBaTeJIbHOCTH.

8.2 Texo6cnyHbHae

Bnytpn yctpojCTBa HET NHKaKnx DeTaJIe, HxkdaOuXcB TExHnueCkOM yxoJe.

8.3 3aKa3 3anacbIX DeTaeIe:

Pn3a3e 3anachbix DeTaneH Heo6xOIMO yKa3aTb CLeDyUOpne daHHbe;

TynycpoiCTBa
Homep apTnKyna ycTroNCTBa
- IdENTnФИКaциоHьн Homep yctpoiCTBa
Homep Heo6xOdmo3anachoi Ta
AKTyIbHbIe HehI INHΦOpMaIg HxOJaTcHa
CTpaHnue www.Einhell-Service.com

9. YtHnH3aun H BTOpHHe HcNoJIb3OBAHne

UcTpoCTBO NOCTABLAE TCA BYNAKOBKe
IINI PnpoDTBpaueHnIOBpeJdeHn Ipi
TPaHCnOpTnPOBHe.3Ta ynaHOBKa ABJIeTcR
CbIpBem INO3OTMy MOKeT 6bITb HcNOLb3OBAHa
BHOB bII Nn HApBaJIeHa HnOBTOpHyIO
nepebaOHTKy CbPb. YcTpoCTBO n erO
pInHaJIeXHocTHn HrTOBJeHb I3 pa3JIuHbIX
MaTePnAIOB, HApImep, MetaIIa NPiactMacc.
He Bbl6paCbIbAte DeEphThIbe YcTPOCTBa
BMecTe C 6blTOBbIM NTxODaMn.ДЯ npabNlHoH
yTNINIaUNYcTPOCTBO Heo6XOnIMo cTaTB NDOxOJaunnyHt npHEMa.Ecnbl Bbl He 3aHeTe,
rIe HaxOHTcNpyHKT npHema, yToCHNTE 3TO B
OprAhx KommyHaJIbHOr ynpaBLeHnra.

10. Xpachenne

XpaHHTe yCTpoIcTBO I erO npHaJIeJXHOCTN B TEMHOM, CYXOM I HeNoDBepKeHHOM BO3DeICTBNO MOP3A,tAKKHe HeIOCTyHOM 4nIaTeI MeCe. ONTMaIbHaTae TMpeHpatya XpaHHeH YAHOdITcMeJHy5°Cn30°C.

XpaHNTe 3JIeKTPoINHCTpymENT BOpINHaJIbHOYnAHOBKe.

RUS

11. Ta6nua noncha HeHcnpaBHOtei

TapaANTHnHOe CBnTeJIbCTBO

YbKaHaMaNOKyNaTeJIbHnUa,yBaKaEmbI NOKyNaTeJIb,

HaHn npOdykTbI npOxOaTtIaTeIbHeHmKoHTpOJI KaueCTBa.EcJIn 3TO yCTpoI CTBO BCE He 6yDeT
fHyHKUHOHPoBAt b63yPteHNO, Mbl pOcIMn B AcopNITCBa H aHaI cepBNCbH otJe no apDecy, yHa3AHHomBy 3OM
rapaHTnHOM TaHOme. Mbl TaHOe OXToHO OTBeHM Ha BaHI BonPOCbNo TEleFOHy, Homep KOTOPOr npBedeH HnKe.
PnnppeBbAHEnnrnapaHTnHbIX TepeOBAHm DeCTBYKT CNeDyUOHe ycLIOBn.

1. HactoIe npAraHnIeCTbYOT NcHIOUHTeBHO B OTHOHeHHNOL3BaTeJIe, T.E.ΦH3ueChHXHtI, KOtOpBe He HamepeBAIOCTcNcNoB3OBaTb HacToeue H3neBte B pAMHex CBOE npoFeccHOAHbHO HIN dpyroI camocToTeBJHOdTeBJHOCTn. HactoIe npAraBHn PergyIpyOTdoONHnTeBJHbYeUCOBMy OKa3aHnR rapaHTnHbIX yCNYr, KOTOpBE HnKeHnyOMnHyTb IpnO3BDOnTEb IO6cnEHNBAET oKynAtOJMa CBOX HOBIX yCTpOCTB V bONIOHEH KycOBIAm rapaHTn B COOTBcTBn C 3aKOHOM. 3TN rapaHTnBnIOBIOE 06a3aTeBJCTBa HE 3ATpaHbAOT Baun 3aOKHbNe rapaHTnBn Tpe6OBaHn. Haun rapaHTnBnHbY cynIry DnB Bac 6ecnIaNtBu.
2. TapaHTHnIbIe yCyIg paNpOcTpaHJIOCToIbKHO Ha DeEeKtI HOBO, npNopeTeHHORo HA TeppITOpIN EAponeckoro cok03a YcTPOICTBa HnHEyONMMyHTO pNO3BOuNTeJIa, KOtPOBIE Cb83AHIc HEDOCTATOM MATEPnIa IINI pNO3BOcDCTBeHHbIM 6paHOM, IN OPAHNHBAIOCTno HAWeHemy BbIOPOy UcTpaHEnEMaTKIN DEeKIOB IINI 3aMeHOY cTPOCTBAA.YUHTHe, YTO HAIINI YCTOPTcCTBA He NpeDHa3NaHEnBI JNIONo3BOAHN B pNOMbIeHHbIX cIeJX, B pEmecJIeHHOM pNO3BOcDCTBE n HApOeCEChOHALbHO OHCOHE, POnOTMY rapaHTHnIHb I DOBOT CHTaETCR HedeICTBntelbHIM, ECINYcTPOICTBO HCIOJIb3OBAJOCB B TEHeHne rapaHTNHOrO cPoKa HA KcTAPbIX, pNOMbIIeHHbIX pPeIpnTHINx II IN B pEmecJIeHHOM pNO3BOcDCTBE, a TAHKe NDBePraIOCb COIOCTABIMo Harpy3E. H npOduKyIiN IO TOpROBo MAPHO Professional He npImeHIOCTo ORpAHueHInB OTOHWEHN IcNOJIb3OBaBHn B pNOMbIIeHHbIX cIeJX, B pEmecJIeHHOM npO3BOcDCTBE n HApOeCEChOHALbHO OCHOBE.
3. Haua rapaHTnHe pacnpoctpaHReTcHa:

noBpeJHHeHn yCTPOCTBA, BO3HNuHE B pe3yIbATE HeoCLOHeHn pyKOBODCTBA NO MOHTaHy nHEnpAINbHOrO MOHTaKa, HecO6LIOHeHn pyKOBODCTBA NO 3KcNpyaTauHH (HanpIMep, ppi NDOHIOeHHN K CETn C HENpAINbHbIM HApRJeHEmn IIN pOOM ToKA), HecO6LIOHeHn Tpe6oBaHn KacatelbHO TexNHueChORO 06cLyHbAHn IN npAubnTexHHNBe3OanchoCTn BCNECTBme Bo3dEeTBn HA yCTPOCTBO aHOMaNbHbIX ycNOBn OKpyKaIOUe Cpebln HHeADNeHaIeero YXOda n TExNHueCHORO 06cLyHbAHn;

nOBpeJedHnryycTPOcTBa,BO3HNKUHeBpe3yIbTaTe HnepaBnIbHOrO nHEHaJIeJaUeIOHCNOIb3oBAHnra (HapIMEmpePepy3KaYCTPOcTBa IIN npIMeHHeHHe HdoNpyUeHbIX KNCIOB3OBAHIO HacaDOKnnnpHaJIeXHocTe),NONaAHnBaYCTPOcTBo NOCTOPOHHX npEMeTOB (HapIMEmpe,NECKaMHeN,bln H. T.I).NobpeJedHnprTpAChOpTnPoBe, npIMeHHeHnCIIbNn BHeuHHx Bo3dEChTBn (HapIMEmpe, NOBpeJedHnprNaDeHHn).
NOBPeHNDeHHYcTPOHCTBA HIN ERO CACTeN, CBA3AHHbIE C N3HOCOM B CBA3N C 3HCnPyTAuNeiO, O6bHbIM INIpyHM cTcETBENHbIM N3HOCOM. HanpImep, AkHyMnTApBbI INAHyMnTApBbI 6NOKINoDBPHEKHe bECTeBHOMHYNCHOCY HBBNDOC06EHHOCTKeONCtPyKmnn PACCHTaHBI HaOrpaHHeHHeO KOnHeCTBO N1HOB. HINx CpOH CNyHbI HeraTHBHO BnHrOHT, B aChTOCTHn, Tpe6yeMbI Harpy3N H ChOpocTb 3apKn, a TaKHe BO3dEhCTBNE BbICOKnx Hn3Knx TMnepaTp, BN6paun ydpabO.

1. RapaHTHnHbI cpoK coCTaBnHET 2 rOa n HauHaHaeTc CO dNHOkyHn yCTPOJCTBa.RapaHTHnHbI npaba He6oXoHMo pEybJIbTb Do hCTeEHnR cpoKa rapaHTHm B TEeHN bDyH HeJeIb NocLe TOro KaK 6yDeT 6hApUyHeHa HEnCnPaBHOCTb.3AbeHnHa raPapHTHnHOe oClykHBaHe NocLe hCTeEHnR cPOHa rapaHTHn He npHHMAOTc.Pp npeMOHTe 3aMeHe yCTPOJCTBa He npOdJIeBAeTcN He hNCuINeTc3 aHOBO rapaHTHnHbI cPOB OTHoHEHN YcTOPOCTBa HIn yCTaHOBJeHNbIX 3aNaCHbIX YAcTee. 3To yCIOBne DeIcTByET TaKHe npBbINOJIHeHN O6ClyKJBaHnHa MeCeTe.
   5.Длпрдьгнгггнгггнгггнгггнгггнгггнгггнгgнгgngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngngnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggnggngg. www.Einell-Service.com.PnirpoTobte KBNTaHuaNoO kynKneIuNpyDne DOHaTaTeBCTBaPnoOpBeTHeHH BAMnHOBOrOYcTPOrOBCTBA.OkA3aHnE rapaHTnHbIyXcJyRnpMHeHtBHO K yCToPbCTBAM,HaNPaBJeHHbIM Ha paccmOTpeHBe 630CoBTBCTbYkoUxNdoKa3aTeBCTBINHfPMMHNO TaBnHKn,NCNIOuAaTcB BBNDy HeOCTaTHaDAHHbIy Ind NdeHTnHfKaUuN TAHIX YcTOpCTB.EcIn NaHa a rapaHTnPa cpaNpOcTpaHReTcH a HEnCpABHOCTbycTOpCTBA,BbI HeMDoJIeN ONoUYrTOrOPEMOHTnPoBaHnO hN HOBo YEcTOpCTBO.
2. EcnBbIbe3nHcTpoNCTBO B cTpaHy Ebponenckoro co03a,OTInHyIO TcpanbI npno6peTHIN, Mbl OcyuIeCTBm rapaHTMHoe o6clyHNBaHHe neep3 aBOpTN3OBaHnHO CepbnCtnaphePA. Pnp BbIO3e yctpOCTBA 3a npedeJIbEponenckoro co03a He deNCTbyKTO rapaHTMhIbe 6o83aTeJIbCTBA.

Cama co6oB pa3yMeTcA, Mbl MoHem TaKHe yCTpaHnTb npn ONlAte 3aTpaT HeNCnPabHOCTNb yCTpoCTBa, KOToPbIe He BxOyT B o6bE rapAHnTHbX ycIg nn pnn nctehenn cpoKa rapaHTn.ДЯ STOrO Bam heo6xOdMBO bICnATb yCTpoCTbO hApDC HAe cnSykb6 CepBnCA. YTo KacaTeC 6bIcTPO3HaWBAIOuXcR, PACoDhIX DetanE n HeoDCtAOuX NCOMOHTOB, Mbl O6paauMaen BHIMAnHe O hr PpArHNe 30J rapaHTn corNaCHO INΦOpMaun O cepBnCHOM 6cbYHNBaHH HactoJIeero pyKOBODCTBa no 3KnLYaTaUN.

197022, Saint Petersburg, Professora Popova street 32, Liter D, office 310

SLO

Stimata clienta, stimate client

produsele noastre sunt supuse unui control de calitate riguros. Daca totusi vreodata acest aparat nu va functiona ireprosabil, ne pare foarte rau si va rugam sa va adresati centrului nosru service, la adresa indicata la finalul acestui certificat de garantie. Bineinteles ca va stam si la Telefon cu placere la dispositione, la numarul de service mentionat. Pentru revendicerca prentiuller de garantie trebuie tinut cont de urmatoarele:

Evnpwon yia to oepbic

Mark Wang
MarkWang/Product-Management/Andreas Weichselgartner/General

First CE:2017

Art-No.: 41.714.30 I-No: 21023 Subject to change without notice

Archive-File/Record: NAPR030262

Documents registrar: Patrick Willnecker Wiesenweg 22, D-94405 Landau/saar

* GB Submersive pressure pump - FPomme retuelle submersible - P Pomme premais ad immersions DKV Lyckyprump - S Dmaricar lyckpump - CZ Pomme iokovi terpedap - SKP Bonnimale ve serpedap - ML Dorpmelukpurp - E Bomba suermable a presion - FIN Uppopaneurpup - SLO Pompatia lacna crenata - N Bemeler nyrosanayratua - RPO pompe de presque submersibai - Off Bu62evoyo ovio tiscac - F Pomme de presque submersal - H/EBV PoHs Ionatia pumpe - RS Pompatia pupezaru zanitare - RT De Gomp - RPU Torponyehar harnahhau hao- hcc - EE Uputate upuvapur - IY teglandhima sialpaediklak - LT Pardinhamas ulshay - KBR Fonnapa ecapne nospes - UKR Prudencian harnahanhau hacc - MKDogapae nornachnnye

Declaration of conformity

We, Einhell UK Ltd

Champions Business Park, First Floor Unit 10, Arrowe Brook Rd, Upton, Wirral CH49 0AB, United Kingdom

declare the conformity to UK standards and legislation was assessed for:

Submersible pressure pump GE-PP 1100 N-A (Einhell)

UK legislation

Simple Pressure Vessels (Safety) Regulation

Electrical Equipment (Safety) Regulation

Radio Equipment Regulation

Personal Protective Equipment Regulation

The Ecodesign for Energy-Related Products and Energy Information Regulation

The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulation

Nolse Emisslon in the Environment by Equipment for use Outdoors Regulation

Annex V
Annex VI

Noise:measuredL wA = dB (A);guaranteed LWA = dB (A)
P = kW; L/0 = cm
UK Approved Body:

Supply of Machinery (Safety) Regulation

Annex IV

UK Approved Body:

UKTE Certificate No.:

Wirral, 2023.09.26

Tom Chambers, Managing Director Einhell UK Ltd.

Archive-File/Record: NAPR030262

Article Number:41.714.30 L-No.:21023

Subject to change without notice Wiesenweg 22, 94405 Landau/Isar, Germany

Documents registrar: Patrick Willnecker

EH 02/2024 (02)
