USER MANUAL 5786 ELTA

— 2 —PREPARATIONS BEFORE USINGBattery Installation1. Open Battery Compartment cover.2. Insert 2 batteries (LR6, “AA” size, or equivalent)in the correct polarity as indicated.(Heavy duty batteries are recommended.)3. Close the cover properly.*Inorder to operate the player on batteries the optional AC/DC adaptor must bedisconnected from the DC 4.5V jack.AC/DC Adaptor*Before connection, make sure the AC voltage of the adaptor must correspond to yourlocal AC outlet voltage.1. Plug the DC output of the adaptor to the DC 4.5V Jack.2. Connect the adaptor (4.5V/600mA with polarity ) to a power outlet.DISC PLAYINGThis CD player is designed to play the 8cm and 12cm compact disc without usingadaptor.Hold SwitchSet the HOLD button to “ON” position, all the buttons will be locked. Before operation, be sureto set the switch to “OFF” position, for normal operation.Getting Start1. Insert the headphone/earphone plug to PHONE JACK.2. Push the OPEN switch to right side, and then the door open, put a disc into theCD compartment with label side upward.3. Push the disc gently around the centre area until it clicks so that the disc fitsinto the pivot.(To remove the disc : Pick up the disc, holding the edge, while pressing thepivot gently.)4. Close the door and press the PLAY/PAUSE button once.5. The Display will show the total number of tracks of the disc, then begin to play thefirst track. General Operation Play/Pause Buttons — Press once to start playback in the original order.Press again to stop the disc play temporarily.Stop Button — Press once to stop playback.Press again to turn off power Skip / Search Buttons — Press once to skip to next track or back to previous track .— Press continuously to search forward or backward .Directory UP / ASP Button — ASP ON/OFF (For CD)Directory UP (For MP3 Disc).

Downloaded from www.Manualslib.com manuals search engineDIGITAL ANTI-SHOCK OPERATION The DIGITAL ANTI-SHOCK PROTECTION function uses semiconductor memory to preventthe second from skipping when the unit is subjected to shocks and vibration during play.When the PLAY/PAUSE button is pressed and the power turns on, the “ASP” appear and thedigital Anti-Shock Protection function turns on automatically.It will give approximately 40 seconds for CD and 120 seconds for MP3(128 Kbps bit rate) ofprotection against interruption of sound output, if the player is subjected to shocks of more than40 seconds duration, some interruption of sound output will occur, this is normal and to beexpected, the sound will resume once the player has stabilized from the shock.To turn this function off, press the ASP/DIR UP button once, the “ASP” indicator will disap-pear, press again the “ASP” appear in the display.

COMPACT DISC CASSETTE ADAPTOR

The cassette adaptor allow you to use your portable CD player with your car stereo cassettesystem or portable audio cassette system.1. Place the cassette adaptor so the cord extends out from the cassette player when the cassetteis inserted. Insert the cassette adaptor in the same direction as you would insert an audiocassette tape.2. Insert the cassette adaptor stereo plug into the headphone jack of the CD player.3. Turn on the cassette player. Press play on the cassette player4. Press play on the CD player.5. Set the volume of the CD player to a mid-level. Adjust the volume of the cassette player. Notes

• The cassette adaptor has the play head on one side only. If you insert the cassette an no soundis heard, try turning the cassette over or pressing the reverse button of the cassette player to— 5 —change direction.• The car cassette adaptor may not be compatible with all makes and models of cassetteplayers. DC cigarette lighter power adaptor Use the DC cigarette lighter power adaptor to conserve battery life when using the CD player ina car.1. Plug the adaptor into the car cigarette lighter.2. Plug the pin into the 4.5V DC jack of the unit

BBS (BASS BOOST SYSTEM) FUNCTION

Set the BBS switch to on position to enhance the bass effect.

When the battery indicator appears on the display, please prepare for replace the newbatteries.— 4 —B. Intro ScanDuring PLAY mode• Press the MODE/PROG button four times.• The INTRO indicator will appear in the display.• Press the PLAY button to play the first 10 seconds of each file on the disc.NOTE - To cancel INTRO SCAN simply press the MODE/PROG button until the INTROindicator disappears.C. Random PlayDuring PLAY mode• Press the MODE/PROG button five times.• The SHUF will appear in the display.• Press the PLAY button, all the files on a disc to be played in a random sequence and afterall files are played, system will stop automatically.NOTE - To cancel RANDOM PLAY simply press the MODE/PROG button until the SHUFdisplay disappears. PROGRAM PLAY (FOR CD ) 1. In stop mode, press the MODE/PROG button to make program memory.2. “ PGM 00 01” will be displayed, “00” means track number to memory and “01” meansprogram number.3. Press or button to select the desired track.4. Press the MODE/PROG button to enter the track into memory, the program numberswhich will be increment one step.* The program no. “01” has become “02” on the display.5. Repeat step 3 and 4 until memory is full. (64 tracks)6. Press button to start the program play.7. To stop the program play, press the STOP button.8. For program play in step “ 7 ” , press the MODE/PROG button & button.

9. To check the program memory, in program play mode, press the or button.

10. To erase the program memory, open the door or turn off the power.

PROGRAM PLAY (FOR MP3 DISC) 1. In stop mode, press the MODE/PROG button to make program memory.2. “ PGM 000 01 ” will be displayed. “ 000 ” means file number, “01” means program number.3. Press the DIR UP/ ASP button to select the desired directory, the display will become “ 00101 01 ” , “ 01 ” means directory number. 4. Press or button to select the desired file.5. Press the MODE/PROG button to enter the directory and file into memory.The program number which will be increment one step.* The program no.“01” has become “02” on display.6. Repeat step 3 to 5 until memory is full (64 files ).7. Press button to start the program play.8. To stop the program play, press the STOP button.9. For program play in step “ 8 “, press the MODE/PROG button & button.

10. To check the program memory, in program play mode, press the or button.

11. To erase the program memory, open the door or turn off the power .* If you do not need to select directory, only select files, the above step 3 can pass.— 3 — Various Playing Modes MODE/PROG Button — There are 3 kind of function : (FOR CD)A. Repeat PlayDuring PLAY mode• Press the MODE/PROG button once to play current track repeatedly.

• The repeat indicator 1 will appear in the display. During PLAY mode• Press the MODE/PROG button twice to play the entire disc repeatedly.
• The repeat indicator ALL will appear in the display. NOTE - To cancel REPEAT simply press the MODE/PROG button until the repeat indicatordisappears.B. Intro ScanDURING PLAY mode• Press the MODE/PROG button three times.• The INTRO indicator will appear in the display.• Press the PLAY button to play the first 10 seconds of each track on the disc.NOTE - To cancel INTRO SCAN simply press the MODE/PROG button until the INTROindicator disappears.C. Random PlayDURING PLAY mode• Press the MODE/PROG button four times.• The SHUF indicator will appear in the display.• Press the PLAY button, all tracks on the disc will be played in random sequence. After allthe tracks have been played the system will stop automatically.NOTE - To cancel RANDOM PLAY simply press the MODE/PROG button until the SHUFdisplay indicator disappears.MODE/PROG Button — There are 3 kind of function : (FOR MP3 DISC)A. Repeat Play1. During PLAY mode• Press the MODE/PROG button once to play the current track repeatedly.
• The repeat indicator 1 will appear in the display.

2. During PLAY mode• Press the MODE/PROG button twice to play the current DIRECTORY repeatedly.

• The repeat indicator will appear in the display.

3. During PLAY mode• Press the MODE/PROG button three times to play the ENTIRE DISC repeatedly.

• The repeat indicator ALL will appear in the display. NOTE - To cancel REPEAT simply press the MODE/PROG button until the repeat indicatordisappears. Downloaded from www.Manualslib.com manuals search engineTROUBLE SHOOTING GUIDE Cleaning the Disc When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center out. Note - Do not use solvents such as benzine, thinner, commercially available cleaners or anti- static spray intended for analogue discs. ** Should you experience difficulties in the use of this player please refer to the following chart before contacting your dealer or the place of purchase. “ The product function maybe reset when it is subjected to Fast Transients like Electrostatic Discharge Disturbance or EFT/Burst. Just follow the instruction described in this manual to set the function again for normal operation. ” — 6 — MAINTENANCE Cleaning the Lens If the lens becomes dusty, clean it with camera lens blower. Be careful not to scratch the surface of the lens. Cleaning the Cabinet From time to time, clean the cabinet with a soft dry cloth. For more stubborn stains, slightly moisten the cloth with water or a mild detergent solution. Never use benzene, alcohol or other solvents as they may damage the finish of the cabinet. SPECIFICATIONS Output Power : 20mW (32 ) Freq. Response : 100 ~ 20000 Hz Power Source : 2 xUM-3 or “AA” size batteries 4.5V(600mA)AC-DC adaptor Dimensions : 146mm(W) x 146mm(D) x 27mm(H) ** For improvement purposes, specification and design are subject to change without notice. ** — 7 — — 8 — The triangular symbol with the lightning Bolt warns the user to the presence of dangerous non- isolated voltage on the inside of this device which may cause an electric shock. WARNING

TECHNICIANS. The triangular symbol with the exclamation highlights important points of which the user should refer to the manual regarding maintenance and repair. Do not use the appliance while driving in traffic. Road traffic demands a higher degree of concentration. The use of headphones and loud music may distract your attention from traffic. You may not hear noises around you. Accidents may happen through inattentiveness. Beware of small pieces and batteries, do not swallow them. It may be hazardous to your health and lead into suffocation. Please, Make sure to keep small devices and batteries out of the reach of children. Important advice regarding hearing protection Caution:You care for your hearing, and so do we. Therefore, use caution while using this appliance. Our recommendation: Avoid high volumes. Children should be supervised while using headphones; make sure that the appliance is not set to high volume Caution! High volumes may cause irreparable damage to children’s ears.

TO SET A SAFE VOLUME LEVEL

• When a person continuously listens to loud music, his/her ears will become used to loud sounds and give the impression that the volume is lower than it actually is.

• Sounds regarded as normal might be harmful in reality.

• To protect yourself, set the volume to a low level.

• Increase the volume only slowly, until you may listen clearly and without problems.

• Hearing damage is accumulative and cannot be reversed.

• Consult a physician if your ears are troubling you. Downloaded from www.Manualslib.com manuals search engineFRENCH

• L’indicateur répète ALL apparaîtra sur l’écran. NOTE - Pour annuler REPEAT appuyez sur le bouton MODE/PROG jusqu’à ce que l’indicateur de répétition disparaisse. Only use the appliance for its intended purpose. Please keep this instruction manual for further reference Instructions on environment protection Do not dispose of this product in the usual household garbage at the end of its life cycle; hand it over at a collection point for the recycling of electrical and electronic appliances. The symbol on the product, the instructions for use or the packing will inform about the methods for disposal. The materials are recyclable as mentioned in its marking. By recycling, material recycling or other forms of re-utilization of old appliances, you are making an important contribution to protect our environment. Please inquire at the community administration for the authorized disposal location. Do not obstruct the ventilation of the device. Make sure, that no curtains, newspapers, furniture or any other type of object are blocking the ventilation system of the apparatus. The ventilation system must be clear of objects at all times! Overheating may lead into serious damage of the device and reduce its performance and lifespan. Heat and warmth Do not expose the appliance to direct sunlight. Make sure that the appliance is not subject to direct heat sources such as heaters or open fire. Make sure that the ventilation slots of the appliance are not covered. Moisture and cleaning This appliance is not waterproof! Do not immerse player in water. Do not allow player to come in contact with water. If water gets inside the player it may cause serious damage. Do not use cleaning agents that contain alcohol, ammoniac, benzene or abrasives as these could damage the player. For cleaning, use a soft, moistened cloth. — 9 — — 10 — — 11 — Downloaded from www.Manualslib.com manuals search engineB.Regard d’introduction Durant le mode PLAY (Lecture)
