VG MK 1 B - Oven Venga - Free user manual and instructions

Brand	Venga
Model	VG MK 1 B
Product type	Electric oven with hotplates
Power supply voltage	220-240 V
Frequency	50/60 Hz
Estimated total power	3000 W
Number of hotplates	2
Oven functions	Lower heat, upper heat, combined heat
Maximum oven temperature	250 °C
Included accessories	Baking tray, grid, crumb tray, handle
Maintenance	Clean with a soft cloth and non-abrasive products. Do not immerse.
Safety	Do not use an extension cord of less than 16 A. Minimum distance of 10 cm from walls. Do not leave unattended.

Frequently Asked Questions - VG MK 1 B Venga

How do I clean the inside of the oven?

Before cleaning, unplug the appliance and let it cool completely. Wipe the tray and grid with absorbent paper or a soft cloth. For stubborn residues, apply a little cooking oil, wait 5 to 10 minutes, then rub with absorbent paper. Do not use abrasive products or steel wool. Never immerse the appliance in water.

What is the maximum oven temperature?

The maximum oven temperature is 250 °C. Use the thermostat (D) to set the desired temperature.

Can I use an extension cord?

Yes, but the extension cord must have a rating of at least 16 amps. Make sure it does not hang or drag on the ground to avoid any risk of accident.

How to use the hotplates?

Turn the thermostat (A or B) to the right to turn on the hotplate. Use pots with a flat bottom suitable for electric hotplates. The diameter of the pot must not be smaller than that of the hotplate. After use, set the thermostat back to 0 and unplug the appliance.

What to do in case of malfunction?

Immediately disconnect the appliance and have it checked by a qualified competent service (manufacturer's after-sales service or authorized person). Do not attempt to repair it yourself.

What types of utensils to use on the hotplates?

Use only pots or pans with double bottom specially designed for electric hotplates. Their diameter must match that of the hotplates to avoid heat loss.

How to install the crumb tray?

Place the crumb tray at the bottom of the oven before use. It collects crumbs and makes cleaning easier.

Why does the appliance emit an odor during first use?

It is normal for a slight odor to be released during the first use. To remedy this, run the appliance empty for a few minutes: for the oven, set the selector to the combined position and the thermostat to maximum (250 °C); for the hotplates, heat them fully for about 10 minutes. This helps to set the protective layer.

How to set the oven thermostat?

After selecting a function with the selector (C), turn the thermostat (D) to the desired temperature, from 0 to 250 °C. The indicator light turns on and off when the temperature is reached.

Can the oven and hotplates be used at the same time?

Yes, each function is independent. You can use the oven and hotplates simultaneously. Make sure the total power does not exceed the capacity of your electrical installation.

USER MANUAL VG MK 1 B Venga

1. Small cooking plate
2. Big cooking plate
3. Control panel
4. Grilling rack
5. Baking tray
6. Door handle
7. Carrying handle for baking tray and rack
8. Crumb tray

F

IAqOTIANT SAFEGAATDS

Please read these instructions carefully before using the appliance, and always follow the safety and operating instructions.

Important: People (including children) who are not able to use the appliance in a safe way, due to their physical, sensorial or mental capacity or their lack of experience or knowledge, must never use the appliance except if they are supervised by a person responsible for their safety or if they previously received instructions concerning the safe use of the appliance. Close supervision is necessary to prevent children from using the appliance as a toy.

Check that yosr mainz noltage correzpondz to that zated on the appliance.
Nener leane the appliance snzspernized when in sze.
zrom time to time check the cord for damage. Neher size the appliance if cord or appliance zhowz any zignz of damage. ShoId the cord be damaged, it mzt be replaced by a competent qsalified zernice*). All repairz zhosld be made by a competent qsalified zernice*).
enly sze the appliance for domeztic psrpozej and in the way indicated in theze inztrctionz.
Neher immerzte the appliance in water or any other liqsid for any reason whatzoen. Neher place it into the dizhwazher.
Nener size the appliance near hot zsrfacez.
Before cleaning, always snplsg the appliance from the power zspply.
Neher size the appliance ostzide and alwayz place it in a dry environment.
Nen er size acezzoriz that are not recommended by the prodscer. They cosld conzitiste a danger to the szer and rizk to damage the appliance.
Nenr mone the appliance by pilling the cord. Make zre the cord cannot get caght in any way. Do not wind the cord around the appliance and do not bend it.
To anoid fire, the right and left zide of the appliance mst be at a distance of at least 10 cm from wall or other object and the space above the appliance mst be free a well. Make zre there iz enoigh air circulation. Pst the appliance on a heat-reizant ztable zrface (not on a narnizhed table or on a table cloth).
Make zse the appliance haz cooled down before cleaning and toring it.
Make zire the cord nener comez into contact with the hot part of the appliance.
enly cook conzsmable food. Neher place the following materializ in the onen: paper, cardboard or plastic...
If yos want to toazt bread in yosr onen, please do not pazz 10 minstez szing yosr toazter az otherwise yosr bread will be bsmed and the appliance might catch fire.
It iz abzolstely necezzary to keep thiz appliance clean at all timez az it comez into contact with food.
The temperatise of the accezzible zsrfacez, zsch az the door of the onen, may be nery high when the appliance iz in sze. Neher tosch thoze zsrfacez dsring sze nor before the appliance haz totally cooled down, and only handle the knobz. Sho'sld the zymbol be indicated on a certain zsrface, yos need to be carefsl when handling the prodscct. Thiz zymbol meanz: CAUTIeN, thiz zsrface may get nery hot dsring sze.
Make zre the hot part of the appliance nener come into contact with inflammable materialz, zsch az csrainz, cloth, etc. when it iz in sze, az a fire might occsr. Alzo make zre not to coner the appliance and do not pst anything on top of it. Make zre nothing come into contact with the heating element of the appliance.
Alwayz snpig the appliance when it iz not in sze, ezpecially zince it iz not eqsipped with an on/off zwitch.
Be extremely castiosz az oil and fat preparationz might catch fire if onerheated.

When sizing the appliance snder an extractor hood, make zre to obzerne the minimal distance adnized by the prodscer. It iz enen wizer to do sble thiz distance.
- Immediately snplsg the appliance if a crack appearz and make zre it iz controlled by a qualified competent electrician(*)
Yosr appliance mszt neher be zwitched on throgh an external timer or any kind of zeparate remote control zytem.

(*) Competent qualified zernice: after-zealez department of the producer or importer or any person who iz qualified, approoned and competent to perform thiz kind of repair in order to anoid all danger. In caze of need yos zhosld retsim the appliance to thiz zernice.

SHOTCOTD INSITACIONS

A short power apply cord iz provided to reduce the risk reztling from becoming entangled in, or tripping on a longer cord. Extension cord may be sized if care iz exercised in their size. Please pay attention to the following:

The diameter of the extension card miszt correpond to the one of the power cord of the appliance, in other word, it miszt be zsitable for at leazt 16 ampere. Extension cordz for a lower amperage cosld onerheat.
The longer cord zhosld be arranged zo that it will not drape oner the cosnter top or table top, where it can be piled on by children or tripped oner.

BEFORE ASE

Unpack the appliance and aceezoriez, then wazh and wipe thee acezzoriez.
It is normal if zome smoke or zmell emanatez from the appliance when sizing it for the first time. Therefore, we adnize yos to sze yosr appliance empty once before the firstsze. If

yos want to sze the onen, pst the fsnction selector zwitch (C) in position the temperatsre knob (D) to the maximm position (250) for abost 10 minstez. This way, the inizible protectine coating of the heating elementz will be bsmed. If yos want to sze the cooking platez, preheat them dsring 10 minstez by tsming their temperatsre knob to the maximm position.

just like with a traditional cooker, the functions of this appliance can be used individually (thus oven only or cooking plates only) but you can also use both functions simultaneously.

ASING THE OVEN

Operation

• When sizing for the first time, clean the surface of the tray with a damp cloth and wipe dry. Then grease the tray with butter, margarine or cooking oil.
• Pst the crsmb tray on the bottom of the onen canity.
  Pst the baking tray or the rack at the dezired lenel inzide the onen.
• Plsg the snit into the power zispply zocket.
  To tsrn on the oen, tsrn the fction zelector zwitch (C) of the control panel to the desired position:
  only the lower heating element heatz sp to bake or reheat a preparation withost roazling it.
• only the supper heating element heatz sp in order to roazt the preparation.
  both heating elementz will heat sp to bake and roazt the preparation.

The indicator lamp of the zwitch will light sp.

10

VgMK1B-101221

After yos harezel the fnsion selector zwitch to the dezired position,regulate the temperatise of the fsnace by mean of the thermoztat (D).
- When the food is ready, pst the fnsction zelector zwitch in "0" position. The pilot light goez ost.
- Carefully open the glazz door, preferably sizing an onen glone.
- Be nery careful when remoning the rack or the tray. Thee partz become nery hot drsing sze and yos might get bsmed. Uze the zspplied, zeparate handle.
Unplsg the appliance after size.

ASING THE COOKING qZATES

Make zse the temperatire knobz (A and B) are in the 0 position. Plsg in the appliance.
Alwayz sze flat-boltomed zasepanz, which make good contact with the cooking plate. The zasepan bazez zhosld ideally be of the zame ziSe az the cooking platez.
To heat sp the cooking plate, tsm their temperatire knobz (zee pictse on page 4) to the right.
Dse to the cooking platez' conztrction,rezidal heat will remain after zwitching off.Thiz may be szed to keep food warm for a zhort period.
After size, tsn the temperatire knob to "0" and snplsg the appliance.

CLEANING AND CATE

Before cleaning, snplg the appliance from ostlet and allow it to cool down.

Inside cleaning of the oven

Wipe the baking tray, the rack and the crumb tray with abzorbent paper towel or a zoft cloth. To remove baked on food, posr a little cooking oil on the food and allow to zland for fine to ten minstez.
Thiz hoslz zoften the food and allow it to be remoned with aborbent paper towel or a zoft cloth. If the abone method failz to remove the food, then we zsgezt wiping the trayz with a damp cloth and a little detergent.
- Neher Size abrażine prodścź or zteel wool. Neher immerź the appliance in water and make zsre no water or damp can enter the appliance. Neher clean the appliance with a team cleaner.
Make zre no water zplaazhez on the glazz door when the latter iz zill hot.

Outside cleaning of the oven and cooking plates

• Wipe clean with a zoft dry cloth.
• Do not sze zsteel wool, zcosring padz or abrañine cleanerz.
• Alwayz keep the cooking platez dry; dampnezz can cose ze rzt zpotz. Some zpecial productz are alzo anailable for cleaning the cooking platez.

Do not immerse in water or any other liquid.

qTOECTION OF THE ENVITONAENT - DITECHIVE 2002/96/EC

In order to prézerne osr environnement and protect hman health, the waze electrical and electronic eqispiment zhosld be dizpozed of in accordance with specific rsez with the

implication of both szplierz and szerz. zor thiz reazon, az indicated by the zymbol -the rating label or on the packaging, yosr appliance zhosld not be dizpozed of az sznorted mnsicipal wazte. The szer haz the right to bring it to a mnsicipal collection point performing

waste reoery by mean of reze, recycing or size for other application in accordance with the directine.
