- Commandes (Fig.15):

Carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations. The appliance has been designed for use in the ducting version (air exhaust to the outside - Fig.1B), filtering version (air circulation on the inside - Fig.1A) or with external motor (Fig.1C).

SAFETY PRECAUTION

1. Take care when the cooker hood is operating simultaneously with an open fireplace or burner that depend on the air in the environment and are supplied by other than electrical energy, as the cooker hood removes the air from the environment which a burner or fireplace need for combustion. The negative pressure in the environment must not exceed 4Pa (4x10-5 bar). Provide adequate ventilation in the environment for a safe operation of the cooker hood.

Follow the local laws applicable for external air evacuation.

Before connecting the model to the electricity network:

• Control the data plate (positioned inside the appliance) to ascertain that the voltage and power correspond to the network and the socket is suitable. If in doubt ask a qualified electrician.
• If the power supply cable is damaged, it must be replaced with another cable or a special assembly, which may be obtained direct from the manufacturer or from the Technical Assistance Centre.

2. Warning!

In certain circumstances electrical appliances may be a danger hazard.

A) Do not check the status of the filters while the cooker hood is operating.
B) Do not touch bulbs or adjacent areas, during or straight after prolonged use of the lighting installation.
C) Flambé cooking is prohibited underneath the cooker hood.
D) Avoid free flame, as it is damaging for the filters and a fire hazard.
E) Constantly check food frying to avoid that the overheated oil may become a fire hazard.
F) Disconnect the electrical plug prior to any maintenance.
G) This appliance is not intended for use by young children or infirm persons without supervision.
H) Young children should be supervised to ensure they do not play with the appliance
I) There shall be adequate ventilation of the room when the rangehood is used at the same time as appliances burning gas or other fuels.
L) There is a risk of fire if cleaning is not carried out in accordance with the instructions.

This appliance conforms to the European Directive EC/2002/96, Waste Electrical and Electronic Equipment (WEEE). By making sure that this appliance is disposed of in a suitable manner, the user is helping to prevent potential damage to the environment or to public health.

The symbol on the product or on the accompanying paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to a suitable electric and electronic appliance recycling collection point. Follow local guidelines when disposing of waste. For more information on the treatment, re-use and recycling of this product, please contact your local authority, domestic waste collection service or the shop where the appliance was purchased.

INSTALLATION INSTRUCTIONS

Assembly and electrical connections must be carried out by specialised personnel.

Electric Connection:

This is a class I, appliance and must therefore be connected to an efficient earthing system.

• The appliance must be connected to the electricity supply as follows:

BROWN = L line

BLUE = N neutral

YELLOW/GREEN = 1 earth.

The neutral wire must be connected to the terminal with the N symbol while the YELLOW/GREEN, wire must be connected to the terminal by the earth symbol.

When connecting the appliance to the electricity supply, make sure that the mains socket has an earth connection. After fitting the ducted cooker hood, make sure that the electrical plug is in a position where it can be accessed easily. If the appliance is connected directly to the electricity supply, an omnipolar switch with a minimum contact opening of 3mm must be placed in between the two; its size must be suitable for the load required and it must comply with current legislation.

• The minimum distance between the support surfaces of the cooking pots on the cooker top and the lowest part of the cooker hood must be at least 65~cm . If a connection tube composed of two parts is used, the upper part must be placed outside the lower part. Do not connect the cooker hood exhaust to the same conductor used to circulate hot air or for evacuating fumes from other appliances generated by other than an electrical source. Before proceeding with the assembly operations, remove the anti-grease filter(s) (Fig.2) so that the unit is easier to handle.
  We recommend the use of an air exhaust tube which has the same diameter as the air exhaust outlet hole. If a pipe with a smaller diameter is used, the efficiency of the product may be reduced and its operation may become noisier.

In the case of assembly of the appliance in the suction version prepare the hole for evacuation of the air.

- Wall mounting:

• Trace the bottom side of the hood on the wall Fig.3A (while considering minimum distance from the hob).
• Position the fastening template on the wall, paying attention that the line coincides with that traced in the previous paragraph.
• Mark and drill fastening holes (Fig.3B).
  -Fix the 7 anchors and the 6 screws C without tightening them completely (Fig.3B).

• Position the appliance at the wall (Fig.4).

• Make sure the 2 J levelling screws are tightened completely (Fig.5).

• Align the appliance horizontally using the two levelling screws J (Fig.5).
• Once the adjustment has been made, fasten the hood permanently using the screws C and D (Fig.4).
• For easy accessibility to the motor unit in the case of assistance, after having levelled and fixed the appliance definitively, we recommend that the brackets are removed (Fig.5).
• When carrying out the fixing operations, use only screws and screw anchors suited to the type of wall (e.g. reinforced concrete, plasterboard etc.).
• If the screws and screw anchors are supplied with the appliance, make sure that they are suited to the type of wall to which the hood must be fixed.

Fixing the decorative telescopic flue:

• Arrange the electrical power supply within the dimensions of the decorative flue. If your appliance is to be installed in the ducting version or in the version with external motor, prepare the air exhaust opening.
• Adjust the width of the support bracket of the upper flue (Fig.7).
• Then fix it to the ceiling using the screws A (Fig.7) in such a way that it is in line with your hood and respecting the distance from the ceiling indicated in Fig.6.
• Connect the flange F to the air exhaust hole using a connection pipe (Fig.8).

• Insert the upper flue into the lower flue.

• Put the bottom telescopic flue in place on the hood, extract the top telescopic flue until the bracket and fix it with the screws B (Fig.9).

• To transform the hood from a ducting version into a filtering version, ask your dealer for the charcoal filters and follow the installation instructions.
  -Warning: The cooker hood may be installed with the air exhaust outlet at the rear, by removing bracket X with the motor and rotating it, as illustrated in Fig.10.

The wall mounting bracket Y should also be removed and fixed as illustrated in Fig.10, using the same screws.

By means of an air exhaust pipe, connect the flange F to the air exhaust hole already set-up. To close it in a cleaner fashion, you can mount the cover M (Fig.11).

Ducting version:

-Remove the grid E and the cable gland H from the cover M (Fig.12A - Fig.12B).
- Pass the power supply cable through the slot in the canopy M, as indicated in Fig.12B.
- Taking the grommet H , position it between the power cable and the slot.
- Fit the carbon filters inside the cooker hood (Fig.13).
- Secure the fairing M, taking care to ensure that it is correctly hooked on the securing pins (Fig.11).

USE AND MAINTENANCE

We recommend that the cooker hood is switched on before any food is cooked. We also recommend that the appliance is left running for 15 minutes after the food is cooked, in order to thoroughly eliminate all contaminated air.
The effective performance of the cooker hood depends on constant maintenance; the anti-grease filter and the active carbon filter both require special attention.
- The anti-grease filter is responsible retaining the grease particles suspended in the air, therefore it is subject to

clogging with variable frequency according to the use of the appliance.

• To prevent the danger of possible fires, at least every 2 months one must wash the anti-grease filters by hand using non-abrasive neutral liquid detergents or in the dishwasher at low temperatures and on short cycles.
• After a few washes, colour alterations may occur. This does not give the right to claim their replacement.
• The active carbon filters are used to purify the air that is sent back into the room and its function s to mitigate the unpleasant odours produced by cooking.

• The non-regenerable active carbon filters must be replaced at least every 4 months. The saturation of the active charcoal depends on the more or less prolonged use of the appliance, on the type of kitchen and on the frequency with which anti-grease filter is cleaned.

• Regenerable active charcoal filters must be washed by hand, with non-abrasive neutral detergents, or in the dishwasher at a maximum temperature of 65^ (the washing cycle must be complete without dishware). Remove excess water without damaging the filter, remove the plastic parts, and let the mat dry in the oven for at least 15 minutes approximately at a maximum temperature of 100^ . To keep the regenerable charcoal filter functioning efficient this operation must be repeated every 2 months. These must be replaced at least every 3 years or when the mat is damaged.

• Before remounting the anti-grease filters and the regenerable active charcoal filters it is important that they are completely dry.
  Clean the hood frequently, both internally and externally, using a cloth dampened with denatured alcohol or neutral liquid detergents that are non abrasive.

• The lighting system is designed for use during cooking and not for the prolonged general lighting of the room. The prolonged use of the lighting system significantly decreases the average duration of the bulbs.
• Attention: The non compliance with the hood cleaning warnings and with the replacement and cleaning of the filters entails risk of fires. One therefore recommends keeping to the suggested instructions.

- Replacing halogen light bulbs (Fig.14):

In order to replace the dichroic lamps, carefully remove the lamp from the lamp holder with the help of a small flat screwdriver or a similar tool.

PLEASE NOTE! In doing this operation, please take care not to scratch the hood.

Replace the bulbs with new ones of the same type.

Controls (Fig.15):

Power key (A) = Opens and closes the door. Upon opening, both the light and the motor, at speed 1, switch on.

For safety reasons, if while being opened or closed the door encounters some type of resistance, it locks up. In order to unlock it, press the "A" key again. The door will complete one or two openings in order to return to the initial setting.

Speed Key (B) = Switches the motor on/off and increases its speed.

Each time the key is pressed briefly, the motor increases speed from 1 to 2 to 3 and then shuts off. At each speed only the LED indicating the speed set turns on.

The appliance is equipped with intense speed. To activate it, press the "B" key for about 2 seconds, no matter what motor speed the hood is in. The active function is indicated by the speed 3 LED that will be flashing. The intense speed lasts 15 minutes and then the hood goes back to the last setting. In order to deactivate the function before the defined time limit,

press the "B" key.

It is possible to adjust light intensity at three levels: high, medium and low by pressing the "C" multiple times.

Timer key (D) = Set the appliance operational time for 15 minutes.

When the appliance is on speed 1, 2 or 3, the Timer function is activated by pressing the "D" key. When active, the "E" LED turns on. After 25 minutes the hood motor and lights shut off. If the door is open, it is closed.

The Timer function cannot be activated with intense speed. To deactivate the Timer function before it ends, press the "A" key.

Filters LED (H) = After 30 hours of work, the LED indicator of the filters turns on without flashing. In that event, the anti-grease and long-lasting active carbon filters, if present, must be cleaned. The function is reset (with the suction hood off) by pressing the "B" key for 5 seconds. Afterwards the LED indicator of the filters will turn off and regulation restarts from zero.

After 120 hours of work, the "H" LED starts to flash permanently. This means that the standard active carbon filters must be replaced, if present. The function is reset (with the suction hood off) by pressing the "B" key for 5 seconds. Afterwards the LED indicator of the "H" filters will turn off and regulation restarts from zero.

Clean air warning light (G) = The function makes it possible to have a constant air recirculation in the room.

This is activated, with the hood off, by pressing the Timer key "D" for 5 seconds. The motor switches on at speed 1 for 10min each hour. The function is active when warning light ^^ is on. During motor operation the warning light G^ flashes.

The function deactivates by pressing any button with the exception of the ones for the lights.

Cleaning LED (F) = During cleaning of the glass, to avoid activating the controls by accident, they can be deactivated for 30 seconds. To disable them, press the "A" key for about 3 seconds. When the function is active, the "F" LED starts to flash. The function can only be activated with the hood off.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR EVENTUAL DAMAGES CAUSED BY BREACHING THE ABOVE WARNINGS.
