| Hood type | Inclined wall-mounted decorative hood |
| Color | Black |
| Width | 90 cm |
| Max air flow (booster) | 740 m³/h |
| Sound level min. / max. | 52 dB / 65 dB |
| Number of speeds | 4 (3 speeds + 1 booster) |
| Energy class | A+ |
| Smart technology | 6th SENSE - automatic detection of steam and smoke |
| 6th SENSE automatic modes | 3 modes: simmer, boil, fry |
| Control type | Touch |
| Grease filter | Dishwasher safe |
| Filter saturation indicator | Yes |
| Lighting | Integrated LED |
| Operating modes | External venting + recycling |
Frequently Asked Questions - WHVS92FLTK - WHVS 92F LT K/1 WHIRLPOOL
How does the 6th SENSE technology of the WHVS92FLTK work?
The 6th SENSE technology automatically detects smoke and vapors produced during cooking and adjusts the extraction speed without manual intervention. You choose from 3 cooking modes: simmer, boil, and fry. The hood returns to normal mode once cooking is finished.
How many extraction speeds does this hood have?
The hood has 4 extraction speeds: 3 normal speeds and 1 intensive booster speed. The booster mode reaches a maximum flow rate of 740 m³/h and is used occasionally to quickly remove intense smoke.
How do I clean the grease filter of the WHVS92FLTK?
The grease filter is dishwasher safe. Remove it by pressing the release system, then run a low-temperature cycle. Cleaning every 2 weeks is recommended depending on usage intensity.
How do I know when the grease filter needs to be cleaned?
The hood is equipped with a grease filter saturation indicator that lights up on the control panel. After cleaning, reset the counter by holding the dedicated button for a few seconds (see the provided manual for the exact procedure).
Can the hood operate without an external exhaust duct?
Yes, the WHVS92FLTK can operate in recirculation mode. The air is filtered through an active charcoal filter (sold separately) before being reintroduced into the kitchen. This mode is useful in homes where creating a duct is not possible.
When should the charcoal filter be replaced in recirculation mode?
In recirculation mode, plan to replace the active charcoal filter every 3 to 6 months depending on usage frequency. A saturated filter reduces extraction efficiency and allows odors to spread in the kitchen. Only use compatible Whirlpool filters.
Is the WHVS92FLTK hood quiet?
The noise level ranges from 52 dB at minimum speed to 65 dB in booster mode. Normal speeds allow for discreet operation suitable for table conversation. The booster mode is intended for short and occasional use.
What to do if the hood is not extracting properly?
First, check the condition of the grease filter: if it is saturated, clean it in the dishwasher. In recirculation mode, also check the charcoal filter. Ensure that the exhaust duct is not blocked. If the problem persists after these checks, contact Whirlpool customer service.
At what height should the hood be installed above the cooking plates?
Whirlpool recommends a minimum height of 65 cm above a gas stove and 45 cm above electric or induction hobs. Always follow the distances indicated in the installation manual to ensure safety and effective extraction.
Is the LED lighting of the hood replaceable by the user?
The WHVS92FLTK is equipped with integrated LED lighting. Integrated LED modules are generally not user-replaceable. In case of lighting failure, contact Whirlpool customer service or an authorized technician.
