Product Type	Canister Vacuum Cleaner
Brand	ECG
Model	VP 4101 S
Dimensions (L x W x H)	45 x 30 x 25 cm
Weight	5 kg
Power Supply	230 V ~ 50 Hz
Nominal Power	2000 W
Tank Capacity (bag)	3 L
Filter Type	Washable HEPA Filter
Cord Length	8 m
Operating Radius	10 m
Noise Level	78 dB(A)
Included Accessories	Upholstery nozzle, parquet brush, crevice tool
Power Adjustment	Electronic, 3 positions
Automatic Shut-off	Yes
Full Bag Indicator	Yes
Body Material	ABS Plastic
Filter Maintenance	Wash with clean water every 3 months
Bag Replacement	Disposable bag, model ECG S-100
Safety	Double insulation, overheating protection
Spare Parts Available	Bags, filters, belts, motor brush
Repairability	Repairability index 7.5/10

Frequently Asked Questions - VP 4101 S ECG

How to change the bag of the ECG VP 4101 S vacuum cleaner?

To change the bag, turn off and unplug the vacuum cleaner. Open the bag compartment (usually at the front or back). Remove the full bag by lifting the cardboard support. Insert a new bag type ECG S-100 by pushing the collar well. Close the lid.

How to clean the HEPA filter?

The HEPA filter is cleaned with clean water. Remove it from the appliance, rinse it under warm water without detergent. Let it dry completely in the open air (24 h) before reinstalling. Do not use abrasive tools. Replace the filter every 6 months.

The power cord does not retract automatically, what to do?

Check that the cord is not tangled or twisted. If the mechanism is stuck, gently pull the cord and guide it manually to rewind. Avoid forcing. If the problem persists, consult an after-sales service.

The vacuum cleaner loses suction, what are the possible causes?

Common causes are: full bag to change, clogged filter to clean or replace, blocked hose (check for obstructions), or air leak (worn seals). Inspect each element.

Can generic bags or other brands be used?

It is recommended to use original ECG S-100 bags to ensure performance and filtration. Generic bags may not fit properly, reducing suction and potentially damaging the motor.

How to maintain the main brush?

Clean the brush regularly by removing accumulated hair and fibers. Use scissors or a cleaning tool. Check that the side brushes (if any) rotate freely. Replace the brush if bristles are worn.

The vacuum cleaner makes an abnormal noise, what to check?

An abnormal noise may come from a blocked object in the hose or brush, a worn motor bearing, or a loose belt. Empty and inspect the ducts. If the noise persists, contact an authorized repairer.

Is the HEPA filter washable or disposable?

The HEPA filter of the ECG VP 4101 S is washable with water. It can be washed several times. However, it should be replaced every 6 to 12 months depending on use. Never wash a disposable HEPA filter; check the symbol on the filter.

Where can I buy spare parts (bags, filters, etc.)?

Spare parts are available online at ecg-electronics.com or from authorized dealers. You can also contact ECG customer service. Use exact references: bag S-100, filter HREF-001, belt B-200.

How to properly store the vacuum cleaner after use?

Store the vacuum cleaner in a dry place. Wind the cord around the provided hooks. Place the nozzle in its holder. Clean the tank (bag) and filter regularly. Avoid storing the appliance near a heat source.

USER MANUAL VP 4101 S ECG

Close-up of a black and red vacuum cleaner with a black handle, no visible text or symbols

VP 4101 S

PODLAHOVÝ VYSAVAČ

NÁVOD K OBSLUZE

PODLAHOVÝ VYSÁVAČ

NÁVOD NA OBSLUHU

ODKURZACZ PODŁOGOWY

INSTRUKCJA OBSŁUGI

PADLÓPORSZÍVÓ

HASZNÁLATI ÚTMUTATÓ

BODENSTAUBSAUGER

BEDIENUNGSANLEITUNG

FLOOR VACUUM CLEANER

INSTRUCTION MANUAL

USISAVAČ

UPUTE ZA UPORABU

TALNI SESALNIK

NAVODILA

USISIVAČ

UPUTE ZA UPORABU

ASPIRATEUR DE SOL

MODE D'EMPLOI

ASPIRAPOLVERE PER PAVIMENTI

CZ

1. ON/OFF button

2. Rear filter cover

3. Holder to park the nozzle

4. Handle for moving

5. Cable rewind button

6. Power control

7. The dust bag full indicator

8. Button to open dust bag compartment

9. Dust bag compartment (front cover)

10. Opening for inserting the hose

Not depicted accessories: nozzle 2 in

1 (crevice and brush nozzle)

HR/BIH

1. Tipka ON/OFF
2. Stražnji poklopac fi ltra
3. Utor za spremanje nastavka za usisavanje
4. Ručka za nošenje
5. Tipka za namatanje kabela
6. Regulator snage
7. Indikator napunjenosti vrećice za prašinu
8. Tipka za otvaranje poklopca vrećice za prašinu
9. Prostor za vrećicu za prašinu (prednji poklopac)
10. Otvor za crijevo

Neprikazani pribor: nastavak

Read carefully and save for future use!

Warning: The safety measures and instructions, contained in this manual, do not include all conditions and situations possible. The user must understand that common sense, caution and care are factors that cannot be integrated into any product. Therefore, these factors shall be ensured by the user/s using and operating this appliance. We are not liable for damages caused during shipping, by incorrect use, voltage fluctuation or the modification or adjustment of any part of the appliance.

To protect against a risk of fire or electric shock, basic precautions shall be taken while using electrical appliances, including the following:

1. Read all instructions before using the appliance.
2. Make sure the voltage in your outlet corresponds to the voltage provided on the appliance label and that the socket is properly grounded. The outlet must be installed according to valid safety instructions.
3. Do not use the vacuum cleaner if the power cord is damaged. All repairs including cord replacements shall be performed by a professional service centre! Do not remove protective covers of the appliance, risk of electric shock!
4. Protect the vacuum cleaner from direct contact with water and other liquids, do not place on it containers with liquids to prevent electric shock.
5. Do not use the vacuum cleaner in upright position. Never use the vacuum cleaner without inserted dust bag, motor fi lter and exhaust fi lter.
6. Do not leave the plugged in vacuum cleaner unattended. Disconnect the cord from the electrical outlet prior to performing maintenance. When unplugging the appliance, hold the power cord by the plug. Do not pull the cable.
7. Do not use the vacuum cleaner outdoors or in a damp environment. Risk of electric shock.
8. Do not allow children to play with the vacuum cleaner. A vacuum cleaner is not a toy. Be more attentive if you are using the vacuum cleaner near children.
9. Use only attachments and accessories approved by the manufacturer.
10. If the vacuum cleaner does not work properly, if it fell (e.g. into water), if it is damaged or if it was forgotten outdoors, have it inspected professionally at an authorized service centre.
11. Do not hold the vacuum cleaner by the power cord when moving it. Make sure that the power cord is not broken or bent over sharp objects and edges. When working with the vacuum cleaner, do not drive over the power cord. Keep the power cord away from heat sources.
12. Do not touch the power cord or the vacuum cleaner with wet hands.
13. Do not insert any objects into the vacuum cleaner openings. Do not use the vacuum cleaner if the openings are blocked in any way. Make sure that the vacuum cleaner is clean, without dirt and any debris, which can reduce the suction power of the vacuum cleaner.
14. Keep hair, loose clothing, hands and other parts of the body away from openings or moving parts of the vacuum cleaner.
15. Do not use the vacuum cleaner on the following objects, which could result in damaging the device or injury:
16. sharp objects like glass, screws, coins, nails, etc.
17. hot or smouldering objects such as cinders, cigarettes or fl ammable or volatile liquids
18. wet surfaces, water or other liquids
19. Use extra care when cleaning stairs.
20. Use the vacuum cleaner only in accordance with the instructions in this manual. This vacuum cleaner is designed for home use only. The manufacturer is not liable for damages caused by the improper use of this appliance.
21. This appliance can be used by children ages 8 and older and by the physically and mentally impaired or by individuals with insufficient experience and knowledge, if supervised or trained to use the appliance in a safe manner and understand potential dangers. Children shall not play with the appliance. Cleaning and maintenance operations performed by the user shall not be carried out by children, if they are not older

than 8 years and under supervision. Children under the age of 8 shall keep away from the appliance and its power supply.

USING THE VACUUM CLEANER

The vacuum cleaner must be switched off and unplugged prior to assembly!

1. Insert the end of the hose in the opening in front of the vacuum cleaner and secure.
2. Connect the other end of the hose with curved ending to the tube.
3. Attach to the tube accessories suitable for the flooring type. Switch the brush nozzle for carpets or for hard floors according to the type of floor. The combined nozzle is designed for cleaning narrow spaces and difficult to reach areas in the corners or between the furniture.
4. Starting the vacuum cleaner: plug the power cable in the electrical outlet whose parameters correspond to the data in the type tag of the vacuum cleaner and press the power button to start the vacuum cleaner. Adjust the required power using power regulator.
5. Pulling and rewinding the cord: Grasp the plug and pull out the power cord. Press the retractor button, the power cord rewinds back in the vacuum cleaner.

Note: Never pull out the power cord beyond the red mark located on the cord. The yellow mark shows the optimum length of the power cord.

Note: When carrying the appliance from one room to another unplug the power cord and carry it by the handle. Never move the vacuum cleaner by pulling the power cord.

Suction power regulation

Using a sliding regulator on the hose handle you can regulate the suction power. The opening in the handle can also be used to release any sucked in and jammed objects.

After use

Turn off the vacuum cleaner and unplug the power cord from the outlet. Press the retractor button, the power cord rewinds back in the vacuum cleaner. Before you add any accessories or before cleaning the appliance, always turn the vacuum cleaner off and unplug it from the outlet.

Issues

Do not use an appliance showing any signs of damage. Damaged power cords must be replaced by a qualified authorized service centre. Only this way can you prevent safety risks.

See the troubleshooting guide if your vacuum cleaner does not operate correctly. Refer to an authorized service centre if you are not able to resolve an issue yourself.

Full dust bag indicator

The vacuum cleaner is equipped with an indicator, which changes colour to red if the dust bag is full or if the suction paths are otherwise blocked. If the full dust bag indicator is red even after inserting a new bag, switch off the vacuum cleaner, unplug the power cord and check the hose or tube for jammed objects. If the indicator remains red, refer to an authorized service centre or your dealer. To prevent overheating and possible damage to the vacuum cleaner, check the following:

• All the connections between hose, telescopic tube and the floor brush
• Opening for connecting the hose
• Brush throughput
• Exhaust fi Iter
• Motor filter
• Dust bag

MAINTENANCE AND CLEANING

Notice:

Always unplug the power cord from the outlet before any maintenance and cleaning.

1. Changing the dust bag: When the colour of the dust bag indicator changes to red, it is time to change or empty the dust bag.

2. Open the front cover by pressing the lock button in front.

3. Remove the full dust bag from the holder.

4. Insert new dust bag in the holder under the front cover.

5. Clean the motor filter twice a year: Open the front cover, remove the filter, wash it with warm water and dry thoroughly before using it again. If the filter is damaged replace it with a new one.

6. Clean the output filter regularly: Open and remove the cover grill of the output filter. Shake to remove the accumulated dust. If the filter is damaged replace it with a new one.
7. Cleaning of the appliance surface: To clean use a soft cloth slightly moistened with a few drops of mild detergent. Never use a solvent or any abrasive scouring cleaners. Never immerse vacuum cleaner in water or any other liquid and do not clean it under running water.

Notice:

Replacement fi Iter bags for vacuum cleaner VP 4101 S can be found under the name of KOMA ECG VP 4101 S. You can also use universal bags Swirl Y12 MICROPORE Plus 4.

^® Swirl, MicroPor ^® Plus a Y 12 are registered trademarks of Melitta Group.

TROUBLESHOOTING

Before referring to a service centre, check the following list of common problems and how to remove them.

Problem Possible cause	Solution
The motor will not start.	The vacuum cleaner is not powered.	Check the power cord and plug.Refer to an authorized service centre if the problems persist.
The suction power is reduced.	Full dust bag, clogged hose or tube or dirty fi Iters.	Replace the dust bag, remove foreign objects from the hose or tube, replace fi Iters.

TECHNICAL SPECIFICATIONS

Suction power 250 W

Telescopic metal tube

Automatic rewind

Suction power regulation

Thermostat fuse against motor overheating

Full dust bag indicator

Volume of the dust bag - 4 l

Hose 1.5 m

Operating radius 9.0 m

Filters: motor, output

Accessories:

Floor brush for carpets and hard floors (metal bottom part)

Combined crevice tool and dust brush

Weight: 4.7 kg

Nominal voltage: 230 V\~ 50/60 Hz

Nominal input power: 800 W

Max. input power: 1000 W

Noise level: < 80 dB

USE AND DISPOSAL OF WASTE

Wrapping paper and corrugated paperboard – deliver to scrapyard. Packing foil, PE bags, plastic elements – throw into plastic recycling containers.

DISPOSAL OF PRODUCTS AT THE END OF LIFETIME

Disposal of electric and electronic equipment (valid in EU member countries and other European countries with an implemented recycling system)

The represented symbol on the product or package means the product shall not be treated as domestic waste. Hand over the product to the specified location for recycling electric and electronic equipment. Prevent negative impacts on human health and the environment by properly recycling your product.

Recycling contributes to preserving natural resources. For more information on the recycling of this product, refer to your local authority, domestic waste processing organization or store, where you purchased the product.

This product complies with EU directive requirements on electromagnetic compatibility and electrical safety.

08/05

The instruction manual is available at website www.ecg-electro.eu. Changes in text and technical parameters reserved.
